MSC DIVINA

The width of corridors, doorways and stairways which form part of the evacuation paths shall be not less than 900 mm for passenger craft and 700 mm for cargo craft. This width maybe reduced to 600 mm for corridors, doorways and stairways serving spaces where persons are not normally employed. There shall be no protrusions in evacuation paths which could cause injury, ensnare clothing, damage lifejackets or restrict evacuation of disabled persons. Requirements of this paragraph do not apply to aisles (fore-aft passageways separating seating areas) or to spaces between adjacent rows of seats. However, the width of aisles and the seat pitch shall be such as to allow the craft to comply with the provisions of 4.8. Observed obstructed means of escape in MVZ4/Deck 4 Crew stairs, Perfum & Liquor Room, and Laundry Room. 74 SOLAS 2O X/3 HSC Code 4.7.13

The construction of doors and door frames in 'A" class divisions, with the means of securing them when closed, shall provide resistance to fire as well as to the passage of smoke and flame equivalent to that of the bulkheads in which the doors are situated. Fire Doors FD04211, FD044102, FD04203, FD05303, and FD06307 did not close completely. 74 SOLAS 20 II-2/9.4.1.1.2

The emergency source of electrical power may be either a generator or an accumulator battery, which shall comply with the following: started automatically upon failure of the electrical supply from the main source of electrical power... PSCOs received report the vessels transitional UPS system had malfunctioned, resulting in the emergency generator not being able to automatically start in case of an emergency. 74SOLAS Cons. 2020 II-1/42.3.1.2

Fire Doors in main vertical zone bulkheads, galley boundaries and stairway enclosures shall be self-closing and be capable of closing with an angle of inclination of up to 305 degrees opposing closure. PSCO observed 05 fire doors that failed to close and latch completely. The doors are, FD 16307, FD 13804, FD 05705, FD 05707, and FD 06402. 74 SOLAS 20 II-2/9.4.1.1.5.1

Control handles shall be provided at each side of the bulkhead at a minimum height of 1.6m above the floor and shall be so arranged as to enable persons passing through the doorway to hold both handles in the open position without being able to set the power closing mechanism in operation accidentally. The direction of movement of the handles in opening and closing the door shall be in the direction of door movement and shall be clearly indicated. PSCOs observed that after activating one of the handles for the watertight door 401 it failed to operated and close. 74 SOLAS 04 II-1/15.7.4

Every ship of 100 gross tonnage and above, and every ship which is certified to carry 15 or more persons, and fixed or floating platforms shall carry a garbage management plan which the crew shall follow. PSCO observed a garbage bin located in the theater changing area by door 05105 that was being used incorrectly by having food, plastic, metal, and paper waste products when is should only have had paper products. MARPOL 2017 Annex V/10.2

The following functional requirements shall be met escape routes shall be maintained in a safe condition, clear of obstacles. Within the medical center, PSCOs observed medical equipment incorrectly stored in the hallway leading to the exit. 74 SOLAS 20 II-2/13.1.2

Fire doors in main vertical zone bulkheads, galley boundaries and stairway enclosures, the approximate time of closure for hinged fire doors shall be no more than 40 s and no less than 10 s from the beginning of their movement. Crew stair 38 double leaf fire door 04403 closes both doors in 5 seconds from start of movement. 74 SOLAS 20 II-2/9.4.1.1.5.2

Any ship of 10,000 gross tonnage and above shall be fitted with oil filtering equipment complying with paragraph 7 of this regulation. Vessel does not have testing procedures for the oily water separator. MARPOL 2017 Annex I/14.2 MEPC.107(49) Annex 13.6.1

The main inlets and outlets of all ventilation systems shall be capable of being closed from outside the spaces being ventilated. The means of closing shall be easily accessible as well as prominently and permanently marked and shall indicate whether the shut-off is open or closed. Port bow thruster space ventilation fire damper does not remotely actuate. 74 SOLAS 20 II-2/5.2.1.1

Fire doors in main vertical zone bulkheads, galley boundaries and stairway enclosures shall be self-closing and be capable of closing with an angle of inclination of up to 3.5 degrees opposing closure. Fire doors 02203, 05710, 05802, 06707, and 16209 did not fully close when opened fully and released. 74 SOLAS 20 II-2/9.4.1.1.5.1

Fire doors in main vertical zone bulkheads, galley boundaries and stairway enclosures, hold-back hooks not subject to central control station release are prohibited. Interior fire door 17302 to lift machine space in AC room 573 held open by chain and unattended. 74 SOLAS 20 II-2/9.4.1.1.5.4

In addition to complying with the specific provisions for fire integrity of bulkheads and decks shall be as prescribed in tables 9.1 and 9.2 AC room 452 has several cardboard boxes of new AC filters stowed within the space. 74 SOLAS 20 II-2/9.2.2.3.1

Each NOA must contain all of the information items specified in Tale 160.206 ... (6) Operational condition of equipment. Vessel's AIS does not receive signals from other vessels, transmits signals intermittenly, and also does not communicate with the VDR System. Vessel has a condition of Class, and this Condition of Class states that vessel shall notify all concerned parties. The vessel did not notify the United States by reporting it on their Notice of Arrival. 33 CGR 160.206(a)(6)

07105 - Fire Doors/Openings - The approximate uniform rate of closure for sliding doors shall be of no more than 0.2 m/s and no less than 0.1 m/s with the ship in upright position. Fire door 14315 did not close completely, stopping halfway after multiple tries. 74 SOLAS - 20 II-2/9.4.1.1.5.2 74 SOLAS 20 II-2/9.4.1.1.5.2

07105-Fire Safety- Fire doors in main vertical bulkheads, galley boundaries and stairway enclosures... shall be self-closing and capable of closing with an angle of inclination of up to 3.5 degrees opposing closure. PSCOs observed galley door 14613 unable to fully close. - 74 SOLAS 09 con. II-2/1.1.4.1

07199-Fire Safety- The purpose of this regulation is to prevent the ignition of combustible materials or flammable liquids. Means shall be provided to limit the accumulation of flammable vapours. PSCOs observed the accumulation of diesel fuel in the engine bilge compartments of lifeboats 5, 6, 8, and 12. - 74 SOLAS 09 con. II-2/4.1.2

Prior to ship leaving port and at all times during the voyage all lifesaving appliances shall be in working order and ready for immediate use. Tender #31 STBD engine will not set to neutral.

There shall not be any doors along any designated escape route which require keys to unlock them when moving in the direction of escape. Food store deck door to aft mooring station is locked and is the second means of escape. (Deck 4 frame 4 area)

Electrical installations shall be suchthat the safety of persons, crew, and ship from electrical hazards will be ensured. 04 ground wires found not connected to rudder angle indicatorsin steering rooms.

1499 - The condition of rhe ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fir to proceed to sea without danger to the ship or persons on board. Vessel's stern thruster #1 found to have a ground within its motor, stern thruster inoperable. 74SOLAS(2009) CH.I/Reg 11(a)

Passenger ships engaged on international voyages which are not short international voyages shall carry... lifeboats complying with the requirements of section 4.5 or 4.6 of the code on each side... lifeboat #13 is not operational due to starting motor failure. The ships maximum number of passengers has been reduced from 4345 to 4145 based on amended PSSC issued by B.V.

The construction of doors and door frames in "A" class divisions with the means of securing them when closed. Shall provide resistance to fire and smoke. FD's 13803, 13804, 12702, 1071, 05802 and FSD 14802 did not latch.

Furniture in stairway enclosures shall be limited to seating... A linen cart is geing stowed in the galley stair, Aft on Deck 6.

Flammable storage item found stored in port side theatre store room, carpenter shop, and upolstry shop. Flammable liquids shall be stored in category 14 spaces.

In addition to the emergency lighting required by regulations II-1-42 and III / 11.5, the means of escape, including stairways and exits, shall be marked by lighting.. The exit sign in the simulator room is not illuminating by electric power.
