GUADALUPE

09206-Satisfactory means for safe passage required by regulation 25-1 shall be provided for the protection of the crew in getting to and from any other spaces used in essential operation of the ship. PSCO observed no satisfactory protection for crew from falling into cargo hold nr.1. ICLL 1966 25.4, Annex I/16AC

13199-The machinery and fitting shall be of a design and construction adequate for the service for which they are intended. PSCO observed a temporary zip tie repair on Nr.3 fuel oil purifier water cooling line. 74SOLAS(97) II-1/26.1/16AC

07199-Cylinders must always be secured and be stowed,and in rack in an upright position,with the valve protection cap in place. PSCO observed that the required valve protection cap was missing on 01 cylinders. 46CFR147.60(b) /16AC

07106 - The function of the detection system shall be by means of equipment producing the phenomena associated with incipient fires to which the detector is designed to respond. PSCO observed inappropiate means of testing of flame detectors. 74SOLAS(97) II-2/13.1.13/50AC

Two sets of steel ladders as widely seperated as possible leading to doors in the upper part of the space similarly seperated and from which access is provided to the open deck in general, one of these ladders shall provide continuous fire shelter from the lower part of the space. PSCO observed an opening cut in the bulkhead of the emergency escape trunk leading from the main engineering space, allowing free movment of both smoke and flame. 74 SOLAS(97) II-2/45.3.1 17AC

Hydraulic power-operated steering gear shall be provided with the following: A fixed storage tank having sufficient capicity to recharge at least one power actuating system including the reservouir. PSCO observed empty hydraulic oil reservoir. 74SOLAS(97)II-2/29.12.3 17AC

All waste receptacles shall be constructed of non-combustable materials with no openings in the sides or bottom. PSCO observed combustable waste recepticales throughout the ship. 74SOLAS(97)II-2/18.5 40AC

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. PSCO observed fuel shut off valve failing to close when initially activated for the emergency generator. 74SOLAS(20)I/11 10C

Fire protection systems and firefighting systems and appliances shall be maintained and ready for use. PSCO observed 04 manually operated call points covered with clear tape. 74 SOLAS (97 CONS) Ch. II-2 Reg 2.2.7

THE OIL RECORD BOOK PART I SHALL BE COMPLETED ON EACH OCCASION, ON A TANK-TO-TANK BASIS IF APPROPRIATE WHENEVER ANY OF THE FOLLOWING MACHINERY SPACE OPERATIONS TAKES PLACE IN THE SHIP: COLLECTION AND DISPOSAL OF OIL RESIDUES (SLUDGE). DISCHARGE OF OILY WATER ON 21MAY24 WAS NOT LOGGED IN THE OIL RECORD BOOK. MARPOL I/REG.17.2.3 Code: 10c

Fire extinguishing appliances shall be kept in good order and be available for immediate use at all times. PSCO's observed 43 out of 54 total CO2 cylinders with cotter pins installed at the top-valve location on the cylinder head. Per the manufacturer's instructions, the presence of the cotter pins renders the cylinders inoperable. the cotter pins were installed into the top-valves on 22MAY2024 as a safety precaution while conducting cleaning, and the pins were inadvertently not removed, rendering the system not ready for immediate use for a total of 22 days. 74 SOLAS (97) Ch II-2/21

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Where the emergency source of electrical powe is a generator, it shall be started automatically upon failure of the main source. PSCO observed fuel cut off valve engaged when inspecting emergency generator. Crew reset valve on the spot, emergency generator able to start afterwards. 74 SOLAS (04) II-1/43.3.1 10c

07111 - A firearms outfit shall consist of items listed under II-2/17.1.1. PSCO observed firefighter outfit on bridge to be missing: gloves, torch, lifeline, and hatchet. The missing items were in a separate box labeled “training” not in accordance with Fire Control Plan. Crew moved equipment to correct location before PSCO left vessel. 74SOLAS(97)II-2/17.1 10c.

99101 - A Ship, except a ship of less than 26 feet in length, must have a placard of at least 5 by 8 inches, made of durable material fixed in a conspicuous place in each machinery space, or at the bilge and ballast pump control station, stating the following: “Discharge of Oil Prohibited…” PSCO observed no placarding required by 33CFR155.450(a) in engine room. 33CFR155.450(a) 40ac

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

02-2035- IN ALL SHIPS GENERAL ARRANGEMENT PLANS SHALL BE PERMANENTLY EXHIBITED FOR THE GUIDANCE OF THE SHIP'S OFFICERS SHOWING CLEARLY FOR EACH DECK THE CONTROL STATIONS, THE VARIOUS FIRE SECTIONS ENCLOSED BY "A" CLASS DIVISIONS, THE SECTIONS ENCLOSED BY "B" CLASS DIVISIONS TOGETHER WITH PARTICULARS OF THE FIRE DETECTION AND FIRE ALARM SYSTEMS, THE SPRINKLER INSTALLATION, THE FIRE EXTINGUISHING APPLIANCES, MEANS OF ACCESS TO DIFFERENT COMPARTMENTS, DECKS, ETC. PSCO OBSERVED CLASS "A" FIRE DOORS LOCATED IN THE FORECASTLE, STEERING GEAR ROOM AND GALLEY, INDICATED AS SELF CLOSING ON THE FIRE CONTROL PLAN, SECURED OPEN USING HOLD BACKS AND WOODEN WEDGES. ADDITIONALLY, THE CLASS "A"FIRE DOOR LOCATED IN THE FORECASTLE WAS MISSING THE COMPLETE DOOR HANDLE ASSEMBLY. 74SOLAS (97CONS) CH II-2 / REG 20.1 30ABC

05-0720- FIRE EXTINGUISHERS SHALL BE PERIODICALLY EXAMINED AND SUBJECTED TO SUCH TESTS AS THE ADMINISTRATION MAY REQUIRE. PSCO OBSERVED 20 FIRE EXTINGUISHERS NOT SERVICED IN ACCORDANCE WITH ONBOARD PROCEDURES. PSCO OBSERVED 20 TOTAL SPARE FIRE EXTINGUISHERS LOCATED IN THE AFT STORAGE COMPARTMENT, 19 HAD NOT BEEN INSPECTED SINCE FEBRUARY 2018. FIRE EXTINGUISHERS LOCATED IN THE EMERGENCY GENERATOR COMPARTMENT, ENGINE ROOM LOWER LEVEL ON THE STARBOARD SIDE, AND ENGINEN ROOM NEAR THE FUEL OIL AND LUBE OIL PURIFIERS HAD NOT BEEN INSPECTED IN THE MONTH OF APRIL. ADDITIONALLY, THE EXTINGUISHER LOCATED IN THE RESCUE BOAT HAD NOT BEEN INSPECTED SINCE DECEMBER 2017. EVERY OTHER FIRE EXTINGUISHER CHECKED BY PSCOS HAD TAGS INDICATING A MONTHLY INSPECTION HAD BEEN CONDUCTED. 74SOLAS(97 CONS) CH II-2/REG 6.5 17AC

06-0720- FIRE HOSES SHALL BE KEPT READY FOR USE IN CONSPICUOUS POSITIONS NEAR THE WATER SERVICE HYDRANTS AND CONNECTIONS. PSCO OBSERVED 02 FIRE HOSE BOXES ON THE PORT SIDE TIED SHUT WITH NYLON LINE THAT TOOK APPROXIMATELY 03 MINUTES TO UNTIE, WHICH GAINS ACCESS TO THE FIRE HOSE, FIRE HOSE NOZZLE, AND SPANNER WRENCH. THIS WAS DUE TO THE LATCHES BEING BROKEN ON THE FIRE BOXES. 74SOLAS(97 CONS) CH II-2/REG 20.2 17AC

07-2035- IN ALL SHIPS A DUPLICATE SET OF FIRE CONTROL PLANS OR A BOOKLET CONTAINING SUCH PLANS SHALL BE PERMANENTLY STORED IN A PROMINENTLY MARKED WEATHER TIGHT ENCLOSURE OUTSIDE THE DECK HOUSE FOR THE ASSISTANCE OF SHORE SIDE FIRE FIGHTING PERSONNEL. PSCO OBSERVED DUPLICATE SET OF FIRE CONTROL PLAN SEIZED SHUT IN WEATHER TIGHT CONTAINER, UNACCESSABLE TO PERSONNEL. 74SOLAS(97 CONS) CH II-2/REG 20.2 17AC

03-0925- CREW MEMBERS WITH ENCLOSED SPACE ENTRY OR RESCUE RESPONSIBILITIES SHALL PARTICIPATE IN AN ENCLOSED SPACE ENTRY AND RESCUE DRILL TO BE HELD ONBOARD THE SHIP AT LEAST ONCE EVERY TWO MONTHS. THE VESSEL WAS NOT CONDUCTING ENCLOSED SPACE ENTRY AND RESCUE DRILLS AS REQUIRED. 74SOLAS(14 CONS) CH III/REG 19.3.3 30 ABC

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

08-0616- THE NORMAL EQUIPMENT OF EVERY RESCUE BOAT SHALL CONSIST OF A SEARCHLIGHT. [name withheld] WHO IS IN CHARGE OF THE RESCUE BOAT DURING MAN OVERBOARD EVOLUTIONS. NEITHER THE [name withheld] COULD DEMONSTRATE PROPER OPERATION OF THE REQUIRED SEARCH LIGHT. 74SOLAS(97 CONS) CH III/REG 47.2.2.11 17AC

09-2540- THE LEVEL OF KNOWLEDGE OF THE SUBJECTS LISTED IN COLUMN 2 OF TABLE A-VI/2-1 SHALL BE SUFFICIENT TO ENABLE THE CANDIDATE TO LAUNCH AND TAKE CHARGE OF A SURVIVAL CRAFT OR RESCUE BOAT IN EMERGENCY SITUATIONS. THE CREW WAS NOT ABLE TO PRACTICALLY DEMONSTRATE THE ABILITY TO USE SEARCHLIGHT. STCW A-VI/2 17AC

10-0899- THE CONDITION OF THE SHIP AND ITS EQUIPMENT SHALL BE MAINTAINED TO CONFORM WITH THE PROVISIONS OF THE PRESENT REGULATIONS TO ENSURE THAT THE SHIP IN ALL RESPECTS WILL REMAIN FIT TO PROCEED TO SEA WITHOUT DANGER TO THE SHIP OR PERSONS ON BOARD. PSCO OBSERVED VESSEL BUNKER TRANSFER ELECTRICAL CONTROL PANEL ALARMS LOCATION ON AFT MAIN DECK SUBJECT TO ALL WEATHER CONDITIONS IDENTIFIED BOTH PORT AND STARBOARD ALARM PANELS WITH DAMAGED OR MISSING LEVEL INDICATOR LIGHTS. 74SOLAS(14CONS) CH 1 / REG 11(a) 17AC

11-0899- THE TRANSFER PROCEDURES REQUIRED BY 33CFR155.720 MUST BE PERMANENTLY POSTED OR AVAILABLE AT A PLACE WHERE THE PROCEDURES CAN BE EASILY SEEN AND USED BY MEMBERS OF THE CREW WHEN ENGAGED IN TRANSFER OPERATIONS. PSCO OBSERVED DURING BUNKER OPERATIONS, THERE WERE NO TRANSFER PROCEDURES ON BOARD. 33CFR155.740(c) 17C

12-0899- NO PERSON SHALL CONDUCT AN OIL OR HAZARDOUS MATERIAL TRANSFER OPERATION UNLESS EACH DRAIN AND SCUPPER IS CLOSED BY THE MECHANICAL MEANS REQUIRED BY 33 CFR155.310. PSCO OBSERVED DURING OPERATIONS THAT SCUPPERS WERE CLOSED BYA A WOODEN WEDGE. 33CFR156.120(O) 17C
