MILLER GIRLS

"On a vessel of at least 26 feet in length, a visual and audible alarm must be provided at the operating station to indicate a high water level..." Vessel audible bilge alarm at operating station is inoperable, along with visual bilge alarm for parlor. Fix bilge alarms at the operating station.

"A vessel on an oceans, coastwise, limited coastwise, or Great Lakes route must carry: six hand red flare distress signals... and; six hand orange smoke distress signals..." Vessel's red flares are expired. Replace with the appropriate amount of flares.

"Except on a vessel limited to daytime operations, the compass must be illuminated." Vessel's compass is not illuminated. Provide illumination prior to operating at night.

46 CFR § 177.10-5 Fire protection: The general construction of the vessel shall be such as to minimize fire hazards insofar as reasonable and practicable. Marine inspectors found missing fireproof material in the forward engine room overhead. Submit repair plan for approval.

46 CFR § 183.350 Batteries - General: Each battery must be located as high above the bilge as practicable, secured to protect against shifting with the roll and pitch of the vessel, and free from exposure to water splash or spray. Marine inspectors found water in a battery casing on the starboard side of the engine room.

Small unfired pressure vessels which do not fully comply with the requirements of this subchapter may be accepted by the Commandant for installation on vessels subject to inspection by the U. S. Coast Guard, provided: 1. The failure of such unfired pressure vessels will not endanger the safety of the vessel. 2. The internal volume does not exceed 5 cubic feet. 3. The construction complies with the requirements of a recognized code, or tests as prescribed by the Commandant are carried out to prove that the design and fabrication are suitable for the intended application. 4. Such unfired pressure vessels shall otherwise comply with the requirements for plan approval and marking as specified in this subchapter. 2 gal air compressor used for horn on board does not have the ASME stamp and must be replaced within 14 days. 46 CFR 54.01-5(e)

Annual inspection. Your vessel must undergo an annual inspection within the 3 months before or after each anniversary date. This vessel's COI anniversary date is 09 JUN 2023. It lapsed is latest date to conduct a 1st annual inspection 09 SEP 2024. Schedule a COI renewal through [email withheld] to clear.

Each water light must be of an approved automatic electric type constructed in accordance with subpart 161.010 of this chapter. The light attached to the ring bouy on board was expired.

The master shall determine that the vessel complies with all applicable stability requirements in the vessel's stability letter... The vessel may not depart until it is in compliance with these requirements. Vessel was not found in compliance with conditions of their stability letter for deck cargo. Boom is stored too high off the weather deck.

All valves in the fuel lines shall be tested by operation locally and at remote operating positions. Fuel shutoff valves were found to be inoperable at the time of inspection.

The power fire pump shall be self priming and of such size as to discharge an effective stream form a hose connected to the highest outlet. Fire pump did not build up enough discharge pressure to be considered an effective stream and be utilized for its intended purpose.

The means provided for pumping bilges shall be tested by operation. Vessel's bilge system was inoperable at the time of inspection and inspectors were unable to witness the proper operation of the bilge pump

All vessels except non-self propelled vessels shall be provided with suitable steering apparatus. At the time of inspection, vessel's main steering ram was found actively leaking oil. Replace leaking steering ram.

The general construction of the vessel shall be such as to minimize fire hazards insofar as reasonable and practicable. Wire feed through aft engine room bulkhead on the starboard side require fire stop or a suitable alternative.

Auxiliary machinery shall be suitable in type and design for the purpose intended. Helm pump was found leaking hydraulic fluid at the time of inspection.

Rails or equivalent protection shall be installed near the periphery of all-weather decks accessible to passengers and crews. Multiple stanchions were missing, and rails were not tightened.

A hatch exposed to the weather must be watertight. Hatch to fore peak was not watertight.

A hatch exposed to the weather must be watertight. Replace deteriorated gasket on the hatch on top of the slop tank.

Your vessel must undergo an annual inspection within the 3 months before or after each anniversary date. Vessel missed its fourth annual inspection due 14Apr2023.

Examine all accessible parts of the exterior and interior hull to assess the condition of the hull structure. There is a hole through the hull, starboard side, engine room. 46 CFR 176.25-5(a)(1)

Liquid level indicating gages shall be of heat resistant materials and adequately protected from mechanical damage. The liquid level gages in the engine room were constructed of plastic and not protected from damage. 46 CFR 180.20-25(a)(5)

Each opening port light must be constructed so that it can be secured watertight. The port-side port light in the engine room has a crack running through it. 46 CFR 171.116(f)(3)

A vessel of less than 20m must have a sound signal with a range of at least .5 nautical miles. The sound signal is not strong enough to be heard at .5 nautical miles. 33 CFR 83.33(a)

Batteries shall be effectively screened to minimize the risk of accidental sparks through dropping of metallic items on the connections. The battery forward of the generator has no cover. 46 CFR 183.05-20(a)

Wiring joints and splices shall be mechanically secure and made in junction boxes. Wires for the bilge pumps were spliced with electrical tape. 46 CFR 183.05-50(b)

An inspection of the bridge-to-bridge radio stations on board vessels subject to the Vessel Bridge-to-Bridge Radiotelephone Act must be conducted by an FCC-licensed technician. The Safety Radiotelephony certificate was expired. 47 CFR 80.59(a)(2)

Life ring buoys must be approved in accordance with 160.050. Both life ring buoys on the vessel had grab lines that were weathered to the point of breaking and fraying. 46 CFR 180.70(b)(1)

The fuel shutoff valve at the tank shall be operable from outside the compartment. The fuel shutoff reach rod was disconnected from the fuel line valve. 46 CFR 182.20-40(b)(3)

A vessel must carry adequate and up-to-date charts. The charts had not been updated with notices to mariners. 46 CFR 184.420(a)(1)

Provide ground detection.

There are several broken stanchions onboard, these need to be replaced to provide more stable railing. The cables used as courses on the deck rails are not properly spaced, re-run the cables to provide the required 12" spacing.

Provide proper weak link for life floats. Vessel limited to 100ft depth or less until weak link replaced.

Properly mark lifefloats

Repair replace #11 portside stantion from bow.

Provide proper operation of bilge drainage system.

Arrest leak in way of rear main oil seal for port side generator.

Vessel is fitted with two (02) buoyant apparatus 160.010/78/2. Vessel shall be fitted with lifefloats meeting lifesaving requirements to date. The vessel will have one year to provide lifefloats approved in 46 CFR 180.500(c) and in accordance with the COI.

Remove electrical submersible bilge pump currently not in service IWO void #1, aft centerline

Repair wasted section of strainer on bilge suction pipe located in the forepeak.

Make watertight door for entry into the house watertight. Replace worn and hard gasket and chalk test to the satisfaction of a Coast Guard Marine Inspector.

Crop and renew sections of the shelf that are wasted for the generator foundation mount as discussed with the vessel representative.

Arrest/repair exhaust leak in way of the starboard MDE.

Repair/re-install loose lagging in way of the exhaust on the generator.

Crop and renew sections of deck and bulkhead located on the portside, aft area in void #4 as discussed with the vessel representative.

Provide cotter pins or additional nuts for two (2) bolts servicing the steering ram linkage on both port and starboard side.

Make forward deck hatch watertight in accordance with 46 CFR 171.124 (Old T). Chalk test and hose test hatch to 30 PSI to ensure watertight to the satisfaction of a Coast Guard Marine Inspector.

Make pipe penetration located in the #4 void, aft bulkhead on the starboard side, watertight.

Replace fuel hose in way of ships service generator.

Replace missing lagging in way of starboard main diesel engine.

Replace bottom rail course in way of starboard deck rail.

Submit plans to the OCMI for review and approval of changes to 12 volt electrical system.

Lash paddles to lifefloats.

Determine source of hydraulic leak and make proper repairs to piping in engine room.

Double clamp flex hose on electric bilge pump in lazarette.

Double clamp flex hose on hatch drain in main hold.

Prove proper operation of power bilge pump.

Re-stencil floating waterlight and 04 paddles on lifefloat on roof.

Replace hydraulic line high pressure hose on steering pump.

Both 10 person life floats are damaged beyond repair. Replace both life floats. Vessel route is restricted to operate within 1 mile from shore until life floats are replaced and installation verified by USCG Marine Inspector.

Replace cracked window in pilot house. LEGACY COMPONENT DESC: Window

Replace cracked stbd port light in engine room. LEGACY COMPONENT DESC: Port light

Change fuel filter gasket on port diesel engine. LEGACY COMPONENT DESC: Fuel filter

Repair holed bulkhead IVO accomodation entrance. LEGACY COMPONENT DESC: Bulkhead

Replace flex hose for electric bilge pump in lazarette. LEGACY COMPONENT DESC: Flex Hose

Mark person capacity on all LF's. LEGACY COMPONENT DESC: Life Float

Replace gasket on #1 fwd void hatch. LEGACY COMPONENT DESC: Gasket

Replace gasket on lazarette hatch. LEGACY COMPONENT DESC: Gasket

Make rescue platform able to withstand effects of wave action. LEGACY COMPONENT DESC: Rescue Platform

Repair leaks to fire pump and fire hose valve. LEGACY COMPONENT DESC: Gland Sealing

Provide wire splint for 1st Aid Kit.

Renew retro-reflective tape on life floats. LEGACY COMPONENT DESC: Markings

Make cargo compartment hatch watertight and provide securing devices.

Prove proper operation of Rule bilge pump in lazaret. Properly attach float switch. LEGACY COMPONENT DESC: Pump

Provide a weather tight hatch for main deck hold forward.

Provide proper adjustment for steering system chain idler pulley in engine room.

C&R overhead in engine room in way of (IWO) hydraulic assist for steering and exhaust supports. Forward and aft 6" of frames and outboard to good metal.

Renew cooling system piping at strainer for port engine.

Renew primary bilge suction hose for engine room.

Renew strainer for bilge suction in engine room.

Renew transverse frames located in the engine room on port and stbd sides where marked.

C&R the #4 side shell vertical stiffener and associated hull plate on stbd side with a minimum insert of 18" x 18".

C&R side shell on port side forward in as marked in engine room.

Re-secure overhead wire in engine room over starboard engine.

C&R #2 frame on port side IWO hull plate as marked in galley.

C&R #5 vertical frame IWO side shell on port side in galley.

C&R 18" x 18" section of hull IWO #5 vertical frame in galley.

Renew bilge suction where blanked off into lazerette, renew as original.

C&R forward bulkhead of lazerette as marked and provide stiffeners on 24" centers.

C&R side shell on stbd side IWO turn, 4ft. aft of draft marks.

In fore peak; Crop and Renew (C&R) tripped frames/vertical stiffeners on port & stbd sides.

In forward hold; C&R #2, 3, & 4 side shell frames on port side as marked.

In forward hold; C&R flanges on centerline where marked.

In forward hold; C&R stbd side hull plate in lower bay where marked or audio gauge and prove less than 25% wastage.

Renew improper high level bilge alarm wiring with appropriate boat cable.

In forward hold; C&R 2" x 2" angle IWO #2 transverse stiffener where marked.

Provide Proper weak-link for both life floats on board. Weak links should be installed that are of appropriate size and breaking strength according to the size of the life float.

C/R wasted vents for slop tanks located aft of accom space

Provide proper flame screens for vent pipe IWO slop tank aft of accom space.

Properly affix lazerrette bilge pump switch to a stationary point.

Repair engine room bilge alarm to pilot house.

Provide proper flame screen for port side hydraulic tank vent line.

Make repairs in fwd cargo hold as follows: a. V/weld port side ovhd aft of transverse #7. b. Crop/renew ovhd port/fwd IWO #1 trans deck frame as marked. c. V/weld cracks IWO #3 & #6 port side bottom long.

Renew port aft cutlass bearing.

Make repairs in E/R as follows: a. Crop/renew #1 vert frame stbd as marked IWO trans bottom frame. b. Crop/renew #2 vert frame and trans deck frame stbd side.

Install junction box cover outbd stbd main engine.

Repair or renew stuffing tube for generator cable.

Install metal hangers for cables crossing over engine room overhead.

Repair, renew or remove as necessary, all light fixtures in engine room.

Provide cover for generator battery.

SECURE SNACK BAR EQUIPMENT TO SHELF OR REMOVE AS NECESSARY.

PROVIDE PLANS TO OCMI FOR APPROVAL OF INSTALLATION OF AUDIBLE/VISUAL BILGE ALARM SYSTEM AT OPERATING STATION.

Crop/renew #1/#3 stbd gunwale supports.

PROVE PROPER OPERATION OF PA SYSTEM.

Repair/reweld as nec. port side aft pilothouse hole in superstructure.

Install 30X30 mesh screening for fuel tank vent.

Repair steering chain to prevent rubbing along exhaust pipe.

Permanently mount air compressor.

Move multiple battery connections to a terminal block.

Crop/renew side shell plating as marked stbd side IWO #1/#2 vert frame (cracked) in lazarette.

Replace fuel shut-off valve labels.

V/weld port/stbd corner round plating IWO deck in lazarette as marked.

V/weld port aft transverse frame IWO port aft corner.

Replace missing ladder support nuts at access to Pilothouse roof.

Install cover for receptacle and remove dead-ended wire on aft engine room bulkhead.

Install valve handle for generator fuel supply.

Replace starboard shaft packing prior to floating vessel.

Remove unused exposed wiring on potable water pump.

Provide proof of servicing for one B-I fire extinguisher at operating station.

Replace one paddle for lifefloat and connect lifefloat to painter.

Provide 47CFR part 80.

Provide proof of garbage removal records.

Post Emergency Instruction Plan in conspicuous place for passengers.

Repair lower rub rail holding brackets as necessary.

Repair heater cover in accom space.

RE-STENCIL PORT EMERGENCY FUEL CUTOFF VALVE.

CORRECT FUEL LEAK ON PORT MDE.

CORRECT WIRING HARNESS IN ENGINEROOM.

CLEAN BATTERY TERMINALS IN ENGINEROOM.

CLEAN GASKETS AND KNIFE EDGES ON BOTH WATERTIGHT DOORS.

DOUBLE CLAMP VARIOUS HOSES ON MDE'S AND GEN SET.

POST 1-800# FOR EMPLOYEE ASSISTANCE IAW DAPI PROGRAM.

REMOVE DEAD WIRING AND SECURE GROUND WIRE IN ENGINEROOM.

POST STABILITY LETTER ON BRIDGE._x001C_ _x001C_ _x001C_

PROVIDE DETACHABLE CLIP FOR LIFE RING BOUY.

MISSING GUARD FOR STBD MDE ALTERNATOR.

MISSING FLASHLIGHT FOR BRIDGE EMERGENCY LIGHTING.

REPAIR OR REPLACE BRACKET FOR PORTABLE FIRE EXTINGUISHER LOCATED ON AFT BULKHEAD IN ENGINE ROOM.

Unknown Component - Unknown Cause/Condition

PROVIDE RETRO-REFELECTIVE TAPE FOR LIFERING.

REPAIR OR REPLACE BRACKET FOR PORTABLE FIRE EXTINGUISHER LOCATED ON BRIDGE.

BETTER SECURE GEAR BOX FOR STEERING GEAR.

Unknown Component - Unknown Cause/Condition

INSTALL PROTECTIVE GUARD ON HYDRAULIC PUMP AND BELT, STARBOARD ENGINE

REPLACE BROKEN OUTLET, PORT SIDE, PARLOR ROOM.

REPLACE PORTHOLE GASKET, FORWARD PORTHOLE, STARBOARD SIDE IN PARLOR ROOM.

FIX PUNCTURES ON LIFE RINGS

INSTALL RETROREFLECTIVE TAPE ON 11 MN BUOYANT APPARATUS

RENEW LIFELINE STANCHION, PORT SIDE, AFT, AT STERN ENTRANCE

PROPERLY WIRE FUEL OIL TRANSFER PUMP.

PROVIDE 6 MN BUOYANT APPARATUS.

CROP AND RENEW LIP UNDER VOID COVER ON STACK AFT OF HOUSE.

DOUBLE NUT ALL BOLTS ON STEERING APPARATUS

REPLACE OUTDATED CHARTS 12343 AND 12332.

CARGO HOLD #1: CROP AND REVIEW STBD SIDE SHELL VERTICAL FRAME #6, 7, AND 8.

PARLOR COMPARTMENT: CROP AND RENEW BOTTOM HORIZONTAL STIFFENERS #3 STBD, AND #4 & 5 PORT.

CARGO HOLD #1: CROP AND RENEW #1 CENTER HORIZONTAL STIFFENER.

VESSEL IS NOT TO OPERATE WITH PASSENGERS ONBOARD UNTIL THE ABOVE REPAIRS ARE MADE TO THE SATISFACTION OF ATTENDING MARINE INSPECTOR NLT 12 JULY 1993.

PLUG HOLES IN SIDE OF HOUSE/ENGINE ROOM AND REPLACE GLASS IN CRACKED PORTHOLE IN ACCOMODATION SPACE. TO BE COMPLETED TO THE SATISFACTION OF THEATTENDING CG MARINE INSPECTOR NOT LATER THAN 24AUG92.

REPLACE EXISTING FLOAT FREE/WEAK LINK WITH APPROVED TYPE LINK THAT HAS PROPER LABELING ATTACHED TO LINK. CORRECTION REQ'D BY 1900 11AUG92 TO THE SATISFACTION OF THE ATTENDING MARINE INSPECTOR.

RECONFIGURE LIFELINES TO COMPLY WITH 46 CFR 177.35-1(B) AND (G). COURSES SHALL HAVE NO MORE THAN 12" BETWEEN THEM. TO BE COMPLETED TO THE SATISFACTION OF THE ATTENDING CG MARINE INSPECTOR NO LATER THAN 17AUG92.

SCHEDULE A STABILITY TEST TO PROVE VSL'S ABILITY TO CARRY MORE THAN 11 PASSENGERS. VSL IS RESTRICTED TO CARRY 11 PASSENGERS, 12 TOTAL PERSONS UNTIL NEW STABILITY DATA IS DETERMINED.

REPLACE CRACKED WINDOWS IN PILOTHOUSE.

PROPERLY MOUNT COMPASS IN PILOTHOUSE AND PROVE OPERATION OF LIGHT.

PROVIDE PROPER FCC OPERATING PERMIT. TO BE COMPLETED TO THE SATISFACTION OF THE ATTENDING USCG INSPECTOR.

PROVE THAT STANCHIONS AND LIFELINES ARE SATISFACTORILY IN PLACE.

VESSEL IS RESTRICTED PIERSIDE PENDING REPLACEMENT OF STEERING GEARBOX U-JOINT AND PROPER OPERATION TESTED.

CROP AND RENEW TO GOOD METAL THE CHANNELS AND TRIANGULAR SUPPORTS FOR RUDDER TUBES IN AFTER COMPARTMENT.

RENEW THE RING LIFE BUOY WATERLIGHT ON THE PORT SIDE AFT.

PROPERLY SPLICE WIRE TO THE AUTOMATIC BILGE PUMP IN THE ENGINE ROOM, FORWARD.

OBTAIN FCC RADIO TELEPHONY CERTIFICATE. VESSEL RESTRICTED TO 1000 FEET FROMSHORE WHEN CARRYING PASSENGERS UNTIL FCC CERTIFICATE IS OBTAINED.

OBTAIN HAND PORTABLE FIRE/BILGE PUMP AND HOSE OF ADEQUATE LENGTH TO REACH ALL INTERIOR SPACES.

INSTALL BILGE PIPING AND STRAINER IN LAZARETTE PERMANENTLY PLUG LIMBER HOLELEADER FROM LAZARETTE TO VOID UNDER PASSENGER AREA.

RE-GLASS BASE OF PORT SIDE BATTERY BOX IN ENGINE ROOM.

PROVE THAT ALL ACCESSORIES SUCH AS SWITCHES, FUSES AND SOCKETS ARE OF THE TYPE LISTED BY UNDERWRITERS LABORATORIES OR OTHER RECOGNIZED TESTING LABORATORY.

PROVE THAT FLEXIBLE FUEL HOSE ON BOTH MAIN ENGINES IS OF AN APPROVED TYPE.

CONDUCT HYDROSTATIC TEST OF 5 PSI ON INTEGRAL FUEL TANK IN PRESENCE OF USCG MARINE INSPECTOR.

PROVE THAT THE OVER CURRENT PROTECTION FOR THE DECK AND CABIN LIGHT CIRCUITIS RATED AT 15 AMPS.

INSTALL IMPERVIOUS SHEATHED WIRING TO FOLLOWING EXTERIOR LOCATIONS: HORN, STERN LIGHT AND TOWING LIGHTS.

REPLACE FLEXIBLE HOSE CONNECTION MID-WAY BETWEEN FUEL PIPE TERMINATIONS WITH METALLIC UNION.
