HAFNIA ANE

IN TANKERS, ELECTRICAL EQUIPMENT, CABLES, AND WIRING SHALL NOT BE INSTALLED IN HAZARDOUS LOCATIONS UNLESS IT CONFORMS WITH STANDARDS NOT INFERIOR TO THOSE ACCEPTABLE TO THE ORGANIZATION * (IEC 60092-502). PSCO OBSERVED MULTIPLE EXPLOSION PROOF / SAFE TYPE LIGHT FIXTURES IN THE HAZARDOUS ZONE OF THE FOREPEAK THAT HAD MODIFICATIONS OF ELECTRICAL TAPE TO CABLE GLAND AND BROKEN BONDING WIRE. 16ac 74 SOLAS (20) II-1/45.11

...THIS REGULATION IS TO CONTAIN A FIRE IN THE SPACE OF ORIGIN...THE FIRE INTEGRITY OF THE DIVISIONS SHALL BE MAINTAINED. PSCO OBSERVED DAMAGED INSULATION IN THE VALVE SOLENOID ROOM. 74 SOLAS (20) ii-2/9.1.3. 16ac

IN ADDITION TO THE REQUIREMENTS CONTAINED ELSEWHERE IN THE PRESENT REGULATIONS, SHIPS SHALL BE DESIGNED, CONSTRUCTED AND MAINTAINED IN COMPLIANCE WITH THE STRUCTURAL, MECHANICAL AND ELECTRICAL REQUIREMENTS OF A CLASSIFICATION SOCIETY WHICH IS RECOGNIZED BY THE ADMINISTRATION IN ACCORDANCE WITH THE PROVISIONS OF REGULATION XI-1/1, OR WITH APPLICABLE NATIONAL STANDARDS OF THE ADMINISTRATION WHICH PROVIDE AN EQUIVALENT LEVEL OF SAFETY. PSCOs OBSERVED UNKNOWN STRUCTURAL DAMAGE OF APPROXIMATELY 01 METER IN LENGTH ON THE STARBOARD QUARTER OF THE VESSEL. CITATION: 74SOLAS(20)II-1/3-1

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Vessel reported it had sustained an approximate 8cm crack in hull between frames 24 and 25 in the purifier room, resulting in ingress of approximately 3 cubic meters of water. PSCO attended and observed that a temporary repair has been made with Mulax plastic steel paste. The vessel is currently trimmed so that repaired area is approximately 13 inches above the waterline. 74SOLAS 14Cons I/11(a) 60 A/C

2050- At least two blowers shall be fitted and capable of delivering to the cargo tanks at least the volume of gas required by paragraphs 2.2.1.2 and 2.2.1.3. The secondary blower has been removed and the vessel does not have spare parts available. 74 SOLAS (14 CONS) Chapt. II-2 Reg 5.5.3.2; FSS Code 2.2.3.1:

0615- Before the ship leaves port and at all times during the voyage, all life saving appliances shall be in working order and ready for immediate use. The PSCO observed inoperable rescue boat shift lever on the center console. 74 SOLAS (14 CONS) Chap III Reg 20.2

1199- Following installation, the Master, Owner, Operator, Agent or Person in Charge of the vessel subject to this subpart must properly maintain the BMS in accordance with all manufacturers specifications. The vessel discharged untreated ballast water in Port Arthur, Texas on 16 JUL 2016 and 26 SEP 2016 33 CFR 151.2025(a)(1)

1220- The ring, lines and letters shall be painted in white or yellow on a dark ground or in black on a light ground. The vessel’s rings, lines and letters are not painted in contrasting colors ILLC Reg 8.

1899 - For tankers 20,000 deadweight tons and upwards, the protection of cargo must be achieved by a fixed inert gas system. IGG was shutting down when the burners were trying to ignite, making it inoperable.
