FJORDLAND

A hatch exposed to the weather must be watertight. Port and stbd side exhaust space freeman hatches have a pin hole leak. Plug to prevent water ingress. 46 CFR 179.360(a)

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of its Certificate of Inspection. Welds at base of V strut on STBD side have porosity. Repair to satisfaction of USCG. 46 CFR 177.100

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of its Certificate of Inspection. Port side propeller blade tip has damage. Repair to satisfaction of USCG. 46 CFR 177.100

Each portable fire extinguisher on a vessel must be of an approved type. The minimum number of portable fire extinguishers required on a vessel must be acceptable to the cognizant Officer in Charge, Marine Inspection. STBD FWD fire extinguisher needs to be recharged. 46 CFR 181.500

A pre-engineered fixed gas fire extinguishing system must automatically shut down all power ventilation systems and all engines that draw intake air from within the protected space. STBD fire-boy system did not shut down main propulsion engine and powered ventilation. 46 CFR 181.420(a)(3)

At each initial and subsequent inspection for certification the owner shall be prepared to conduct test and have the vessel ready for inspection of its fire protection equipment, including the testing of ventilation shut downs. Port engine room ventilation closure obstructed by hose. 46 CFR 181.420

In systems where flixible hoses are permitted to be clamped, double hose clamping is required. Double hose clamp raw water hoses in Engine rooms. 46 CFR 181.410(d)(1)

A vessel must carry a first-aid kit approved under ISO 188113:2006 paragraph 4.12.

Where flexibility is necessary, a section of flexible metallic hose may be used. Nonmetallic hose may be used for wet exhaust systems provided it is especially adapted to resist the action of oil, acid, and heat, has a wall thickness sufficient to prevent collapsing or panting, and is double clamped where practicable. Stbd engine room flexible hose for wet exhaust water cooling system is missing double clamps on one end of the hose. 46CFR182.430(e)

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load under such requirements without exceeding its designed limitations. Raw water hose for stbd engine is damaged (torn) at hose clamp section, reducing effectiveness of double clamps.46CFR182.200(a)

A submersible electric bilge pump may be used as a power bilge pump required by Table 182.520(a) only on a vessel of not more than 19.8 meters (65 feet) in length carrying not more than 49 passengers, other than a ferry, provided that: The pump is listed by an independent laboratory as meeting the requirements in UL 1113 (incorporated by reference; see 46 CFR 175.600). Submersible bilge pumps in all compartments do not meet standard. Vessel maximum passenger capacity reduced to 12 passengers until owner/operator provides documentation attesting to submersible bilge pumps in port and stbd engine room being UL listed. All other submersible pumps on-board to meet standard within 30 days. 46CFR182.520(e)

Pre-employment testing requirements. (a) No marine employer shall engage or employ any individual to serve as a crewmember unless the individual passes a chemical test for dangerous drugs for that employer. Crew did not complete pre-employment testing. 46CFR16.210(a)

Except on a vessel limited to daytime operations, the compass must be illuminated. Compass is not illuminated. 46CFR184.402(c)

The servicing facility must issue a certificate to the life raft owner or owner's agent for each liferaft it services. Servicing facility did not issue a life raft servicing certificate. 46CFR160.151-57(p)

Individual power pumps used for separate spaces are to be controlled from a central control point and must have a light or other visual means at the control point to indicate operation. Starboard, forward bilge pump indicator light was inoperable when tested. Restore functionality.

Each ship transporting more than six passengers for hire equipped with a radiotelephone station IAW Part III of Title III of the Communications Act must carry a radio operator...Master (Ketch) did not have a marine radio operator permit or other appropriate license. Provide proof of license. 47 CFR 80.159(e)

Abandon ship, man overboard and fire drils and training shall be logged or otherwise documented for review by the Coast Guard upon request. The drill entry shall include: the date of the drill/training and a general description of the drill scenario and training topics. Vessel log did not include drill entries. Provide copy of May and June training and drill records.

Vessel's nav pubs were out of date. Provide current Coast Pilot [name withheld] and Current tables.

Provide means to prevent crew fro electrical shock in port engine room aft bulkhead on the positive terminal block.

Provide Fire servicing reports for both installed pre-engineered fire extinguishing systems.

Correctly install Float free link

Replace expired items in first aid kit.

Replace expired life ring buoy light battery

Provide a charged 2-A (formerly A-II) portable extinguisher to cover the passenger accommodation space. - 46 CFR 181.500 - 31 MAY 2018

Replace burn gel and eyewash in first aid kit. - 46 CFR 185.700 - 31 MAY 2018

Provide updated marine charts onboard the vessel. To the satisfaction of the attending Coast Guard Marine Inspector.

Provide 2017 tides and currents onboard the vessel. To the satisfaction of the attending Coast Guard Marine Inspector.

Post identification and operating instructions for both the port and stbd fixed fire systems manual release pull handles.

Renew vsl's life ring buoy due to wasted grab line.

Discovered minor stress cracks in the gel coating aprox 3', 3" wide section where the hulls meet the mid body and minor pitting in the gel coat on the port & stbd aft hulls where they meet the midbody. Submit repair proposal to the OCMI for pre-approval to make permanent repairs these areas of the hull on or before the vessels next hull exam. By specified date: 04/30/2018.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Renew vessel' certificate of documentation at NDC.

Loose junction box for STBD engine room fire suppression system must be secured to bulkhead.

Ensure up-to-date copy of Coast Guard Light List is available on vessel.

Ensure up-to-date copy of Tide/Tidal Current Tables is available on vessel.

Ensure up-to-date copy of local US Coast Pilot is available on vessel.

Ensure up-to-date copy of 'Rules of the Road' is available on vessel.

Ensure portable bilge pump is available on vessel.

Ensure proof of enrollment in drug testing program is available on vessel.

Ensure current FCC Safety Radio Certificate is available on vessel.

Renew watertight seal for stuffing tubes in aft bulkhead of voids in wire penetration stuffing tubes.

Repair minor delamination in shelf that supports rudder arms in both port and stbd hulls.

Provide a CG approved first aid kit as per 46 CFR 184.710. Existing kit onboard found all items expired.

Provide replacement for expired (3) distress signals and (3) smoke signals as per 46 CFR 180.68.

Renew EPIRB automatic float free device, Hammer Hydrostatic release, expired June 2005 as per 46 CFR 180.64.

Provide the original Certificat of Documentation onboard the vessel.

Repair and demonstrate operation of the starboard main engine automatic shutdown and override circuit (part of the fixed firefighting system).

Repair the broken actuation pull cable for the starboard main engineroom fixed firefighting system.

Correct the leakage problem in the discharge line of the starboard lazarette bilge pump.

Provide an insulating cover for exposed terminals of the DC Positive Bus Bar in the port engineroom.

Provide guards for port and starboard main propulsion shafts and couplings per 46 CFR 177.960; No personnel are allowed to enter the engine compartments while shafts are engaged until this is corrected.

Troubleshoot and prove operation of automatic engine shutdowns for fixed firefighting systems. LEGACY COMPONENT DESC: Operating Controls

Register the EPIRB and replace the expired hydrostatic release; also log monthly tests. LEGACY COMPONENT DESC: EPIRB

Repair broken retention arm on overhead escape hatch.

Securely attach plastic mesh on aft rails to allow openings no greater than 4" per 46 CFR 177.900(g). LEGACY COMPONENT DESC: Deck Rail

Fully implement an employee assistance program per 46 CFR 16.401. LEGACY COMPONENT DESC: EAP Training Requirements

Provide drip proof cover for outlet in Port Engine Room. LEGACY COMPONENT DESC: Outlet Box

Remove improper wiring - an extension cord that is permanently installed running from the stbd engine room through a transverse watertight bulkhead forward to a void space. LEGACY COMPONENT DESC: Wiring

The vessel shall not carry passengers beyond 25 March, 2003 until such time as the vessel completes a credit drydock examination to the satisfaction of the attending marine inspector.

Repair/replace stbd rudder, prop, tailshaft, bearings, strut, and reduction gear assembly as original where necessary due to allision with submerged rock. LEGACY COMPONENT DESC: Gear, Timing

Repair bottom hull FRP fracture in way of stbd engine room and lazarette where damaged by allision with submerged rock. Submit for approval repair proposal to include area to be repaired, joint preparation and layup schedule. LEGACY COMPONENT DESC: Bottom Plating

Provide proof of current servicing for all portable fire extinguishers. LEGACY COMPONENT DESC: Service

Provide proof of servicing for fixed fire extinguishing systerms. Servicing must include testing of alarms and automatic shut downs.

Provide grounding wire to run length of fuel tank fill hose. LEGACY COMPONENT DESC: Hose

Provide current FCC Marine Radio Operator's Permit for Glen Jacobsen.

PROVIDE 3 FIRE BUCKETS PER 46 CFR 181.610.

Properly fix all labels on Emergency Exits, Fuel Shutoff Valves, LifejacketBins.

Properly attach painter and light to life ring.

Provide vessel for USCG "Welcome to the Zone" inspection.

Provide stability letter to USCG.

Properly secure/lock sewage overboard shutoff valve.
