GRAND DUCHESS

All escape hatches and other emergency exits used as means of escape must be marked on both sides in clearly legible letters at least 2 inches high: EMERGENCY EXIT, KEEP CLEAR, Porperly label all emergency exits.

The station bill of a vessel of more than 65 feet in length, required to have more than four crew members, must set forth the special duties and duty station of each crew member for various emergencies. The station bill on board the vessel did not include or fully address for each crew member (list is from reg site): (1) The closing of (as applicable) hatches, airports, watertight doors, vents, scuppers, and valves for intake and discharge lines that penetrate the hull, the stopping of fans and ventilating systems, and the operating of all safety equipment; (2) The preparing and launching of survival craft and rescue boats (This content is NOT APPLICABLE, however, recommend content include duties for recovery of a person in water); (3) The extinguishing of fire; and (4) The mustering of passengers including the following: (i) Warning the passengers; (ii) Assembling the passengers and directing them to their appointed stations; and (iii) Keeping order in the passageways and stairways and generally controlling the movement of the passengers. Resolve by 05 July 2024.

IAW 46 CFR 116.115 vessel is authorized to meet regulations applicable to the vessel on March 10, 1996. On passenger decks of vessels engaged in an excursion type operation, rails shall be at least 42 inches high. The space below the rail shall be fitted with bulwarks, chain link fencing, wire mesh, or the equivalent. Space below rail was not fitted with an bulwarks, chain link fencing, wire mesh, or equivalent. Resolve by 05 July 2024.

Each vessel inspected and certificated under the provisions of this Subchapter (K) must, when any passengers are aboard during the tenure of the certificate, be in full compliance with the terms of the certificate. COI requires Senior Deckhand to be designated in writing by the vessel Master. Senior deckhands listed but not specifically designated by each credentialed officer employed as the vessel's master.

Spanner wrenches must be provided for each fire hydrant required by this regulation. A sufficient number of spanner wrenches (one per hydrant) were not provided.

Port and starboard RPM gauges are inoperable.

Port temperature gauge inoperable

10 adult and 16 children's lifejackets need new retroreflective tape

Bilge in E/R has excessive oil

Replace flexible fuel hoses; found cracked and weakened.

Put blanks where old switches have been removed in the electrical box in the engine room.

Make pressure vessel available for inspection.

Supports for cables/wires in the engine room must be metallic. Several zip ties were found throughout.

bilge alarm E/R inoperable

emergency lighting 1st deck inoperable

starboard generator engine oil and RPM gauge inoperable

Port generator RPM gauge inoperable

Life ring light inoperable. Battery expired March 2021

lifejacket stowage to be marked with number and type (adult, child)

Main deck bow hydrant valve leaks, and pipe to hose connection was missing.

port and starboard engine RPM gauges inoperable.

batteries were found connected with wing nuts.

bridge deck broken weld on bottom rail.

bridge deck bottom step starboard side found severely corroded.

Emergency light located on aft second deck was unable to be adequately tested. Make available for testing.

Portable lights must be located at the operating station and the access to propulsion machinery space.

2nd deck starboard aft outlet needs a cover

Forward compartment overhead outlet is charred and has a shorted outlet.

Placards containing instructions for the donning and use of lifejackets onboard the vessel must be posted in conspicuous places visible to the crew and passengers.

Cap or plug unused pipes penetrating bulkhead on 2nd deck starboard side aft and forward.

Replace lifeline on bridge deck lifebuoy. Found worn and frayed.

Replace retro tape on 13 child size lifejackets.

Label child and adult lifejacket stowage boxes with the correct number of jackets.

Electrical boxes in bow and engine room need latches.

Repair MDE RPM, starboard generator RPM and starboard generator water temp gauges.

01 fire hose located on first deck forward leaking excessively.

02 emergency lights on second deck are inoperable.

Make repairs, as original, to rescue platform. Multiple holes noted throughout.

Provide current Certificate of Documentation.

Provide on board current navigational charts for area of operation. Existing charts dated 1989.

Provide on board Inland Navigation rules.

Remove permanent extension cords from various locations. i.e. Speaker on second deck, panel on bridge and women’s restroom on main deck,

Remove wire nut connectors from refridgerator in forward space and electrical panel in pilothouse.

Make operational Port main engine RPM and oil pressure gauges.

Make operational Main Generator Oil pressure and water temp gauges.

Provide on board current FCC station License

Label secure areas as per security plan.

Replace broken window located on the 2nd Deck, aft

Fix light fixture in Galley starboard side.

Connect ground wire on electrical recepticale, 2nd deck fwd car (orange code)

Replace missing light fixture glass globe on 2nd deck in way of 3rd deck stairwell.

#3 void/compartment (sewage tank) - remove old motor, pump valves and excess gear and reconnect galley floor /drain piping & pump out water.

Recharge fire extinguisher near galley door, main deck

Galley: Attach electrical J-box above stove top to bulkhead IAW 46 CFR 183.10-20

Remove and renew refeer units power recpt. and plug (overhead std side) IAW 46 CFR 183.10-20

Provide service report for all portable fire extinguishers IAW 46 CFR 181.30 (note they are due to be serviced by end of this month)

Remove rags in #3 Void IAW 46 CFR 176.25-50

Cement ballast note in #3 Void. Provide stability letter to OCMI, fixed ballast to be verify IAW per stability letter.

Clean STBD generator oily IAW 46 CFR 176.25-50

Secure STBD generator cover

Lag both ship service generator tubo chargers IAW 46 CFR 182.20-20 and 182.15-20

Make repairs to both generator amp meters and ground detection indicators on the main switchboard IAW 46 CFR183.10-5

Remove and properly stow gear on top of eng room switchboard and gear STBD side of engineroom. IAW 46 CFR 176.25-50

Make repairs to port main engine RPM meter in engine room and STBD generator IAW 46 CFR 182.15-5

Power to light above port generator not in junction box-correct. IAW 46 CFR 183.10-20

Remove portable cable runing thru out engine room (not temp lighting) IAW 46 CFR 183.10-20

Label Engine room emergency exit IAW 46 CFR 122.606

Label fire pump controller and disconnect switch STBD side in way of batteries IAW 46 CFR 183.0-10

Stap/Secure water heater aft engine room IAW 46 CFR 176.25-50

Properly secure battery box STBD side engine room iAW 46 CFR 183.05-20

Properly secure electrical junction box aft of STBD generator IAW 46 CFR 183.10-20

Properly secure all electrical cables in engineroom, and lift cables resting on engine exhaust pipes IAW 46 CFR 183.10-20

Replace cracked waterlight for ring buoy 46 CFR 180.30-1

Remove all dead end wires beneath bridge console 46 CFR 183.01

Replace cracked glass on 2nd deck in passenger accomodation space one window starboard bow corner, one window port stern both are to be replaced. 46 CFR 177.30

Provide 60 ft line for ring life buoy currend line is not 60 ft in length 46 CFR 180.30-10

Provide shackle on anchor line that will fit in anchor chain. 46 CFR 184.10-1

Paint navigation lights reflector black IAW 33 CFR 80

New emergency lighting installed was not functional during time of inspection

Several engine room light covers and globe light covers were missing and needed to be replaced.

Life ring buoy dry rotted, needs to be replaced.

Annual servicing on all portable fire extinguishers not complete at time of inspection

Missing Fire Control Plan

Cracked front window near ladderwell needs to be replaced.

Missing handle on aft laz hatch cover.

Provide First Aid Kit IAW 46CFR121.710 & 46CFR160.041

Provide Drud & Alcohol Program Test Records IAW 46CFR16.230 & 46CFR16.260.

Provide current training log book/bridge log. IAW 46CFR122.420

Provide proof of first aid & CPR training IAW NVIC 1-91

Provide documentation of proper passenger count.

Renew / Repair rudder bushings at next dockside availability, no later than September 2002

Install protective light covers in galley

PROVIDE AND INSTALL PROTECTIVE COVERING OVER LIGHT FIXTURES

REMOVE TEMPERARY STUNG LIGHTING FIXTURES IN ENGINE ROOM.

PROVIDE AND INSTALL FLAME IMPINGMENT BOWLS ON BOTTOM OF ALL FUEL SEPERATORS

PROVIDE AND INSTALL MISSING A-60 INSULATION ABOVE WATER HEATER IN E/R

PROVIDE AND INSTALL, PROPERLY, ELECTRICAL CONNECTIONS FOR ALL ELECTRICAL EQUIPMENT THAT WAS USING EXTENSION CORDS.

REMOVE ALL EXTENSION CORDS BEING USE IN A PERMENENT INSTALLATION.

PROVIDE AND INSTALL NEW SHUT-OFF VALVE FOR FIRE HOSE NEAR GALLEY DOOR PRIORTO CARRYING PASSENGERS.

PROVIDE AND INSTALL HIGH LEVEL BILGE ALARMS (VISUAL & AUDIBLE) NEAR THE PILOT STATION FOR THE ENGINE COMPARTMENT & RUDDER COMPARTMENT AS PER 46CFR119.530 PRIOR TO CARRYING PASSENGERS.

REPAIR OR REPLACE THE MAGNETIC HOLD BACK FOR THE FIRE DOOR FROM THE MAIN DECK LEADING TO THE SECOND DECK ON THE PORT SIDE FORWARD PRIOR TO CARRYING PASSENGERS.

REPAIR OUTLETS NEAR HEATED FOOD HOLDING CABINETS.

PROVIDE AND INSTALL COVERS FOR ALL LIGHTS IN THE GALLEY.

PROVIDE AND INSTALL THE CORRECT MARKINGS FOR THE CHILD'S PFD STOWAGE LOCKERPRIOR TO CARRYING PASSENGERS.

PROVIDE AND INSTALL APPROVED DECK COVERINGS ON DOOR SILL AT BOTH FIRE DOORSLEADING TO THE SECOND DECK, AS PER 46CFR72.05-25(b)(6).

FILL IN OPEN HOLES IN GALLEY AND ENGINE ROOM CIRCUIT BREAKER PANELS, AND UPDATE DIRECTORY LISTS ON CIRCUIT BREAKER PANEL DOORS.

PROVE PROPER OPERATION OF RELIEF VALVE ON AIR TANK IN ENGINE ROOM.

MAKE PERMANENT REPAIRS TO WATERTIGHT BULKHEAD UNDERNEATH GALLEY, IN WAY OF PVC PIPE GRAY WATER LINE. REPAIRS MUST BE COMPLETED PRIOR TO SAILING.

REMOVE THE TWO FOGGER TYPE FIRE NOZZLES AND REPLACE WITH NOZZLES OF AN ACCEPTABLE TYPE .

DEMONSTRATE OPERATION OF PORT GENERATOR.

MAKE PERMANENT REPAIRS TO PILOTHOUSE TACHOMETER FOR PORT ENGINE.

MAKE PERMANENT REPAIRS TO STERNLIGHT. REPAIRS MUST BE COMPLETED PRIOR TO SAILING.

PROVE PROPER OPERATION OF LAZARETTE LIGHTS.

REMOVE DEAD ENDED WIRES FROM UNDERNEATH PILOTHOUSE CONSOLE.

PROVIDE A THIRD LIFERING. MUST BE COMPLETED PRIOR TO SAILING.

PROVIDE TWO MORE BLACK BALL DAYSHAPES.

PROVIDE NAVIGATION RULES, COAST PILOT AND LIGHT LIST (CURRENT COPIES).

PROVIDE PROPER DOORKNOB FOR FIRE DOOR BETWEEN MAIN DECK DINING ROOM AND STAIRWAY TO SECOND DECK. MUST BE COMPLETED PRIOR TO SAILING.

PROVIDE A HAND HELD FIRE AND BILGE PUMP. MUST BE COMPLETED PRIOR TO SAILING.

MODIFY FIRE HOSE RACK AT NUMBER 2 FIRE STATION TO ELIMINATE KINKING OF FIREHOSE WHEN IT IS CHARGED.

INSTALL VALVE ON BILGE SUCTION LINE FOR FOREPEAK.

MAKE PERMANENT REPAIRS TO VESSEL'S EMERGENCY LIGHTING NOT LATER THAN COMPLIANCE DATE. INSTALL AND MAINTAIN TEMPERATURE EMERGENCY LIGHTING IN STAIRWELLS AND AT PASSENGER LOADING DOORS ON MAIN DECK (PORT AND STARBOARD)BEFORE CARRYING PASSENGERS.

PRIOR TO LOADING PASSENGERS PROVIDE A FLAME SCREEN FOR FUEL OIL TANK VENT ON 2ND DECK NO LATER THAN COMPLIANCE DATE.

PRIOR TO LOADING PASSENGERS FOR A DINNER/LUNCH CRUISE CLEAN THE GALLEY RANGE VENT SYSTEM OF GREASE AND DIRT, THEN INSTALL GREASE TRAP/FILTERS FOR VENT OPENINGS NO LATER THAN COMPLIANCE DATE.

PROVIDE A GOOSENECK WITH PERMANENT FLAME SCREEN ATTACHED FOR THE FUEL OIL TANK VENT ON 2ND DECK NO LATER THAN COMPLIANCE DATE.

PROVIDE A PROPER BATTERY BOX FOR THE RADAR POWER BATTERY (ENGINEROOM PORT SIDE AFT)NO LATER THAN COMPLIANCE DATE.

PROVIDE AND ADEQUATE PORTABLE FIRE/BILGE PUMP WITH HOSES. THIS IS TO BE COMPLETED PRIOR TO OPERTION IN CANADA OR NO LATER THAN 15JUN87.
