WEEKS 544

Lifebuoys must have the following attachments and fittings: At least one-half the total number of lifebuoys on the vessel must each be fitted with a self-igniting light approved under approval series 161.010. The self-igniting light may not be attached to the lifebuoys required by this section to be fitted with lifelines. Vessel had 2 SM-3 float lights that were not fitted with lithium ion batteries. Replace currently installed batteries with batteries specified in 46 CFR 161.010. Vessel restricted to daylight operations only. 46 CFR 199.70(a)(3)(ii) 17 C

Each liferaft or group of liferafts must be arranged for float-free launching. The arrangement must ensure that the liferaft or liferafts, when released and inflated, are not dragged under by the sinking vessel. A hydrostatic release unit used in a float-free arrangement must be approved under approval series 160.162. Both of the vessel's two hydrostatic release units (HRU) are expired. Replace expired HRUs with new units. 46 CFR 199.130(c)7 16C

There must be a sufficient number of deck officers, able seamen, or certificated persons on board the vessel to operate the survival craft and launching arrangements required for abandonment by the total number of persons on board. Vessel failed to provide 2 lifeboatmen to satisfy requirements of this section. Provide credentialing for 2 lifeboatmen. 46 CFR 199.100(b) 50C

Electrical cable runs in main storage space on the 02 housing deck have sustained severe fire damage that deems it not serviceable. Must replace all damaged cable runs to the 120V distribution panel marked "Panel C" located on the main housing deck. All cable replacements must be in kind in accordance with the vessel electrical plan and 46 CFR 111.60 (Wiring Materials and Methods) to the satisfaction of the U.S. Coast Guard.

Must replace all damaged fire fighting appliances; e.g. fire extinguishers, caused by fire damage to the satisfaction of the U.S. Coast Guard.

Except as provided in paragraphs (b) through (g) of this section, each vessel must undergo drydock, internal structural, and cargo tank internal examinations as follows:(1) Except under paragraph (a)(2) of this section, vessels that operate in salt water must be examined in a must be examined in accordance with the intervals set forth in Table 91.40-3(a) of this section. Where Table 91.40-3(a) indicates a 2.5 year examination interval, it means a vessel must undergo two examinations within any five year period. No more than three years may elapse between any two examinations. Make the following spaces available for inspection, bow rake, port and starboard #3 voids, and center fuel tank. Spaces must be inspected by a USCG MI prior to the vessel receiving CG ISE credit. 46 CFR 91.40-3(a)(1)

In general, compliance with the standards established by the American Bureau of Shipping, see subpart 90.35 of this subchapter, will be considered as satisfactory evidence of the structural efficiency of the vessel. Corrosion was observed on the center stern rake’s forward bulkhead in the vicinity of the first and second bottom longitudinals adjacent to the space’s entrance ladder. Provide a 3 inch by 3 inch grid pattern gauging report of the forward bulkhead between the first and second bottom longitudinals from the bottom plate to 2 feet up the forward bulkhead. The gauging report shall be submitted and reviewed to the satisfaction of the attending USCG MI prior to the vessel receiving CG ISE credit. 46 CFR 92.01-10(a)

In general, compliance with the standards established by the American Bureau of Shipping, see subpart 90.35 of this subchapter, will be considered as satisfactory evidence of the structural efficiency of the vessel. Corrosion was observed on the center stern rake’s first and second bottom longitudinals from center in the space’s inner most bay. Provide a 3 inch by 3 inch grid pattern gauging report of the corroded bottom longitudinals or submit a repair proposal for the replacement of the longitudinals to the satisfaction of the attending USCG MI prior to the vessel receiving CG ISE credit. 46 CFR 92.01-10(a)

In general, compliance with the standards established by the American Bureau of Shipping, see subpart 90.35 of this subchapter, will be considered as satisfactory evidence of the structural efficiency of the vessel. An inset was observed in bottom plate at girthbelt 7.5 in the #2 starboard void. Make the inset available for USCG MI external inspection prior to receiving CG ISE credit. 46 CFR 92.01-10(a)

In general, compliance with the standards established by the American Bureau of Shipping, see subpart 90.35 of this subchapter, will be considered as satisfactory evidence of the structural efficiency of the vessel. Corrosion was observed on the upper most side longitudinal between frames 9 and 10 in the #2 port void. Provide a gauging report of the corroded side longitudinal or submit a repair proposal for the replacement of the longitudinal to the satisfaction of the attending USCG MI prior to the vessel receiving CG ISE credit. 46 CFR 92.01-10(a)

Each lifejacket must have a lifejacket light approved under approval series 161.112 securely attached to the front area of the lifejacket. 09 of the onboard lifejackets have lights that are expired. 46 CFR 199.70

All electrical engineering details and installations shall be designed and installed in accordance with sub chapter J (Electrical Engineering) of this chapter. Multiple dead end wires were found above upper generator and in the below deck storage compartment. Remove all dead end wiring. 46 CFR 90.25-1

When musters are held, details of abandon-ship drills, fire drills, drills of other lifesaving appliances, and onboard training must be recorded in the vessel's official logbook. Vessel has no record of fire or abandon ship drills. 46 CFR 199.180(h)

Pressure vessels that are required by 54.10-3 to be stamped must have the following information, manufacturer's name and serial number, maximum allowable working pressure, class, etc. The fwd and aft deck winch as well as the crane 2nd deck pressure vessels had data plates that were unreadable.

Each lifejacket must have a lifejacket light approved under approval series 161.112 securely attached to the front area of the lifejacket. 06 of the onboard lifejackets have lights that have expired.

All marine engineering details such as piping, ..., shall be designed, constructed, and installed in accordance with the provision of subchapter F (Marine Engineering) of this chapter. The generator exhaust piping in the overhead of the downstairs forward storage reached a temperature of 250 degrees F while inspector was onboard with possible ignition material (cardboard boxes, absorbent pads, etc.) within close proximity.

All marine engineering details such as piping, ..., shall be designed, constructed, and installed in accordance with the provision of subchapter F (Marine Engineering) of this chapter. In the downstairs starboard aft storage there were 2 heating elements installed in the overhead with possible ignition material (cardboard boxes, absorbent pads, etc.) within close proximity.

Each vessel must carry lifebuoys approved under approval series 160.150. The forward lifebuoy has a deteriorated plug and no longer meets the Q spec approval.

Suitable hand covers, guards, or rails shall be installed in way of all exposed and dangerous places such as gears, machinery, etc. The salt water pump does not have a guard in place.

The type of piping joint used shall be suitable for the design conditions and shall be selected with consideration of joint tightness, mechanical strength and the nature of the fluid handled. Discovered exhaust leak on the upstairs generator. Demonstrate proper operation of exhaust piping under normal working conditions. Do not operate engine until corrected.

The use of oil-level gauges with flat glasses and self-closing valves between the gauges and fuel tanks is acceptable. Plastic guage was found installed on lube oil tank and waste oil tank. Install glass or other type of guage glass that will not melt in the case of a fire.

Replace damaged electrical cable for lower machinery space generator.

Replace blade type fuse with proper UL listed cartridge type fuse.

Replace bare unprotected wire with proper electrical cable.

Ensure splices are made in a junction box and support cables with metallic clamps every 24".

Provide data sheets for new machinery installations. Provide information for hoses, valves, and piping. Machinery located on the crane machinery deck to include new generators.

Prove proper operation of relief valves for air receivers.

Provide valid Loadline Certificate that corresponds with the markings on the port and stbd side of the vessel.

Provide 08 lifejackets for use on approved route.

Provide new batteries and corrosion resistant clip for water light attached to ring buoy.

Service and demonstrate proper operation of fuel shutoff valve for fuel tank located centerline of the barge.

Replace wiring and connections in crane operator space. Electrical connections must comply with 46 CFR Subchapter J.

Repair crane winch engine exhaust leak. 1" hole found on muffler.

Re-install missing exhaust lagging on exhaust side of crane prime mover turbo charger

Provide an IBA to replace the life float.

Repair the wasted structure under the crane operating station.

Provide a dead front cover inway of the D/C distribution control panel.

Provide a junction box for the exciter motor.

Reinstall the lube oil line supports on the main crane engine in way of the lube oil by-pass.

As indicated on 7MAR16 worklist item 1.

As indicated on 7MAR16 worklist item 2.

As indicated on 7MAR16 worklist item 3.

As indicated on 7MAR16 worklist item 4.

Provide additional bottom hull gauging as indicated by the attending CG Marine Inspector.

General - gauge the original longitudinal bottom stiffeners and replace as need to the satisfaction of a CG Marine Inspector.

Measure and repair insets located on the stern and forward logs of the vessel IAW NVIC 7-68.

Provide plans indicating or prove the priginal scantling of the vessel's bottom side shell and transvers/logitudinal bilkheands.

Gauge/replace all wasted vertical and jogitudinal frames/stiffeners located within the P/C/S forward rake.

As indicated on 10MAR16 worklist item 2.

No transfer procedures exist onboard

Test all five (5) presure safety relief valves.

Open bow and stern voids for inspections

One portable fire extinguishers just by office needs to be serviced.

Provide current transfer procedures iaw 33 CFR 155.720

Provide updated local contacts in SOPEP iawa 33 CFR 157.26

Company ballast plan conflicts with stability letter, personel fill all ballast tanks at same time, stability states to fill either centerline or p/s tanks, not all tanks. Gave company option to update company ballast plan to reflect stability letter or propose to MSC new stability measurements.

Some washed out welds in external bow rake, centerline. Approximately 20 linear feet.

Flammable lockers on back side of crane maindeck were not mounted.

The port #3 Ballast tank bottom longs were suspect due to heavy rust. It was discovered that the vessel ballasts in uncoated spaces with salt water so rust is highly prevelant.

Provide transfer procedures.

Provide floating waterlight.

Provide missing (2) paddles

Mark emergency scuttle located on main deck "emergency exit".

Properly mark L/L IAW load line certificate.

Provide valid radio station licence

Provide flame deflector bowls for all racor fuel filters.

Provide vessel response plan.

Provide SOPEP

Provide stability letter on board the vessel

update SOPEP to reflect required clean up equipment

install lights on lifejackets

install burn protection on the exhuast stack on the bow wench near operator's station.

provide covers on rotatiing pullies on the bow wench engine

install water float light to lifefloat

Make paint lockers self closing.

Conduct operational safety test of safety test on main engine prior to its operation

18in x 18 in inset on bottom plate between bottom longitudinal in the stbd #2 void.

All Hatch Gaskets wasted.

Repair wasted section of deck plating above #3SWT

Install guard on light fixture in crane house.

Replace all Air Recievers on open Deck. (wasted)

Replace two wasted paint lockers aft of deck house.

properly mount all portable fire extinguishers for easy access.

Replace wasted emergency tow cable

Provide complete gauging report of entire hull and deck plating. Next drydock.

Vessel must complete satisfactory ISE prior to operating beyond the Bounday Line IAW 46 CFR 91.40-3(a).

In crane operating station, provide UL approved electrical power strip.

Provide second means of escape from machinery space for crane.

Paint all fuel shut-off valves in contrasting color.

Properly mount and stencil all ring lifebouys and attached lights (inlcuding light brackets).

Replace containment plug for stbd fuel containment.

Replace retroreflective tape & painter for bouyant apparatus.

Ensure proper storage in 1) all flammable lockers & 2) oils in storage room (i.e. motor, hydraulic oil).

Remove or properly dead end all loose or dead ended electrical wiring. LEGACY COMPONENT DESC: Conductor

Provide covers or blanks for all open electrical panels and boxes including: 220V heater thermostat in aft shop, top/btm power feed breaker in lower generator rm. LEGACY COMPONENT DESC: Distribution Panel Bus

Properly lable all portable extinguisher stations throughout vessel; ensure all extinguishers are properly mounted, and remove excess portable extinguisher signage. LEGACY COMPONENT DESC: Marking

Replace plastic wire ties with metallic ties on wiring installations throughout vessel. LEGACY COMPONENT DESC: Conductor

Prove proper operation and adjustment of watertight door located below main deck. LEGACY COMPONENT DESC: Door

Provide cover on florescent light in port aft shop above outboard motor.

Properly mark loadline on both side of vessel in accordance with vessel's loadline certificate. LEGACY COMPONENT DESC: Load Line Mark

Ensure all batteries and battery boxes are properly maintained including: port battery on main deck single drum winch, and battery box located on the stbd 01 deck.

Remove water from fuel oil containment located at front of deckhouse. LEGACY COMPONENT DESC: Fixed Containment

Replace or repair pressure gauge on generator driven air compressor.

Prove operation of main crane PTO engine (398) trips and alarms.

Install retroreflective tape on all ring life buoys. LEGACY COMPONENT DESC: Markings (ship name/port)

Provide valid Certificate of Documentation. LEGACY COMPONENT DESC: Certificate of Documentation (CG-1270)

Provide valid SOPEP letter. LEGACY COMPONENT DESC: SOPEP

Paint all hull markings in contrasting colors. LEGACY COMPONENT DESC: Hull

Make all air receiver pressure relief valves available for testing. LEGACY COMPONENT DESC: Valve

Remove all flammable containers from below deck storage compartment. LEGACY COMPONENT DESC: Flammables

Properly adjust storage space watertight door. LEGACY COMPONENT DESC: Watertight Door

Replace expired chemical lights on all life jackets. LEGACY COMPONENT DESC: Lights

Prove proper operation of Crane Swinger Generator overspeed. LEGACY COMPONENT DESC: Overspeed Device

Repair flourescent light fixture located in lower storage hold (fwd/port). LEGACY COMPONENT DESC: Lighting Fixture

Repair temperature sensor connection to crane diesel engine. LEGACY COMPONENT DESC: Temperature sensor

Repair dead end electrical wire (s) on air compressor (engine space). LEGACY COMPONENT DESC: Cable

Clean inside of machinery space distribution panel (trash/dangling wires). Repair dead end electrical wire.

Replace missing cover-plate (2) on junction boxes on forward bulkhead of crane space engine room. LEGACY COMPONENT DESC: Junction boxes (COVER)

Make permanent repairs to leaking heat exchanger (crane diesel engine). LEGACY COMPONENT DESC: Heat Exchanger

Repair fractured mounting bracket to cooling line support (engine space fwd). LEGACY COMPONENT DESC: Mounting Bracket

Repaired dryed/wasted hose (or cap off) to "un-used" water retarder (system). LEGACY COMPONENT DESC: Water Retarder

Prior to barge operations, affect permanent repairs to damaged main-deck inset(s). Location: Storage hold overhead/port-side, and fuel tank overhead (center).

Prior to barge operations, affect permanent repairs to crane and its appliances.

Repair to orginal condition: PORT Stern Rake; Cracked weld on #1 (upper)_x001C_ main vertical frame (outboard) in way of #1 main transverse from (upper- overhead)._x001C_

Repair to original condition: #3 STBD Void; Renew wasted/cut out 1/4 frame inboard behind #2 main transverse frame.

Repair to original condition: #3 STBD Void; Cracked weld on #3 main transverse frame (outboard/inboard) in way of #3 main vertical frame.

Repair to original condition: #2 STBD Void; Cracked weld on #1 main transverse outboard frame (lower) in way of #1 main vertical frame.

Repair to original condition: #1 PORT Void; Bent/cracked bottom main transverse frames #1, 2 and 3 (outboard) intersecting #1, 2 and 3 vertical frames.

Repair to original condition: #1 PORT Void; Bent/cracked bottom main transverse frames #1, 2 and 3 (inboard) intersecting #1, 2 and 3 vertical frames.

Repair to original condition: #1 PORT Void; #2 overhead long (8in from #1 upper transverse frame) *fill in "half circle cut-out".

Repair to original condition: #1 PORT Void; Tripped weld at #4 side long (outboard) in way of #4 BHD.

Repair to original condition: #2 PORT Void; Cracked welds on #1 and 2 vertical frames in way of #2 and 3 side longs (outboard).

Repair to original condition: #2 PORT Void; Dent/inset on #1 vertical frame(outboard) in way of #1 overhead transverse frame.

Repair to original condition: PORT Stern Rake; Dent/inset on (inboard) centerline BHD in way of AFT BHD, * 4ft from deck to overhead.

Repair to original condition: PORT Stern Rake; 2 tripped welds,_x001C_ approximately 4 ft up on #3 vertical long in way of AFT BHD (inboard)._x001C_

Repair to original condition: #2 STBD Void; Crop and renew entire #4 (top) side long from FWD bulkhead to AFT bulkhead.

Repair to original condition: #2 STBD Void; Crop and renew entire #3 (from top) side shell long from frame #1 and 2.

Repair to original condition: #2 STBD Void; Cracked weld on #2 main transverse outboard frame (lower) in way of #2 main vertical frame.

Repair to original condition: Centerline AFT Rake; Cracked weld on center line bottom long at vertical frame on FWD Bulkhead.

Repair to original condition: #3 STBD Void; Crop and renew entire #4 (top) side long from FWD bulkhead to #2 frame main transverse.

Repair to original condition: #3 STBD Void; Cracked weld on #1 main_x001C_ transverse frame (outboard/inboard) in way of #1 main vertical frame._x001C_

Repair to original condition: #3 STBD Void; Cracked weld on #2 main transverse frame (outboard/inboard) in way of #2 main vertical frame.

Install missing screen/guard to #1 exhaust fan (lower level), IAW: 46 CFR 58.01-20.

Install missing guard/cover to light fixture (base of ladder, lower level) IAW: 46 CFR 111.75-20 (3) (b).

Install newly tested relief valves on air receivers. (46 CFR 54.15-10)

Post Oil Pollution placards. (33 CFR 155.450)

Test main generator overspeed and low lube oil trips in the presence of a USCG Marine Inspector. (46 CFR 111.12)

Repair or replace the lower right dog device on the port watertight door and the upper left dog device on the starboard watertight door._x001C_ _x001C_ _x001C_

Drain fluid out of downstairs battery boxes._x001C_ _x001C_ _x001C_ _x001C_

Replace upstairs grinder shields._x001C_ _x001C_ _x001C_ _x001C_

Replace Type I PFD waterlights._x001C_ _x001C_ _x001C_ _x001C_

Demonstrate overspeed trip on the generator motor._x001C_ _x001C_ _x001C_ _x001C_

Hydrostatically test all bunker and fuel transfer piping and hoses in accordance with 33 CFR 156.170._x001C_ _x001C_ _x001C_

Renew all relief valves on all inspected air receivers._x001C_ _x001C_ _x001C_ _x001C_

Install a door latch on the ship service generator space door.

Properly secure boom lights electrical wire splices in a junction box with pressure connectors, located in forward end of crane house.

Install the proper size and type relief valve on the forward deck winch airreceiver.

Install remote fuel shutoff valves for the crane engine and crane generator. The valves shall be operable from outside of the machinery space in which the engines are located.

Properly connect the buoyant apparatus weak link and sea painter to the vessel.

Properly label the buoyant apparatus with the capacity and vessel's name.

Provide a Coast Guard approved waterlight with an 18 foot lanyard for the buoyant apparatus.

Dewater; gas free certified safe for entry by a marine chemist; make the following voids available for Coast Guard internal exam: forward port rake,forward center rake, forward stbd rake, #4 port, #4 stbd and aft stbd rake.

Paint vessel name on port and stbd sides of bow, stern and on lifesaving equipment. Paint hailing port on stern.

Properly label all circuit breakers in all distribution panels.

Provide oil transfer procedures and person-in-charge (PIC) IAW 33CFR155.720and 33CFR155.710.

Hydrostatically test all bunker and fuel transfer piping and hoses IAW 33CFR156.170. Provide proper documentation of test results.

Renew worn bushings and properly adjust port and stbd watertight doors.

Properly insulate exhaust piping on the ship service generator, crane engine and crane generator.

Pop test all air receiver relief valves (5 each) in the presence of a CoastGuard marine inspector or provide documentation of the test.

Demonstrate operation of all safety devices (overspeed trip, low lube oil pressure and H. W. temperature) in the presence of a Coast Guard marine inspector or provide documentation of the test; crane engine and crane generator.

Provide specifications on newly installed air receiver (crane sub-base) indicating ASME Code approval, MAWP and manufacturer name plate data.

Provide a valid loadline certificate. Vessel is not permitted to operate beyond the boundary line until this item is satisfied.

Double hose clamp salt water hoses on the ship service generator.

Remove all wires/cables with solid conductors used throughout the vessel.

Install required ground detection system for the electrical plant.

Install missing electrical gauges/meters for the ship service generator.

Provide the cognizant OCMI with approved as-built electrical one line diagram of the electrical system on board.

Reinstall all the electric cables in the forward center and stbd rakes in conduits for protection from ballast water.

Remove all unapproved wire nuts used in electrical splices/connections throughout the vessel._x001C_ _x001C_ _x001C_

Provide emergency escape ladder below the 27" emergency escape hatch outboard to port of ladder leading to the engine room below deck._x001C_ _x001C_ _x001C_

Remove wasted pipe penetrating the long bulkhead between center forward rake and stbd forward rake and make bulkhead watertight._x001C_

Remove all type SOJ (portable) cables permanently installed inside the crane generator panel.

Install drip shield above the battery charger forward of the crane generator panel.

Properly install connection box covers above the crane generator.

Properly install covers for the crane lighting ballast in the crane machinery deck.

Renew all manhole covers to all the voids._x001C_ _x001C_ _x001C_ _x001C_

crop and renew wrinkled/buckled deck main deck edges on #3 stbd void (2 places)._x001C_ _x001C_ _x001C_

Properly weld the 4"x8" plug in the aft bulkhead of the port fwd rake approximately 2' below #3 underdeck long where a 2.5" pipe used to penetrate the bulkhead.

Repair fractured weld in the top sidelong in #3 port void, #1 bay._x001C_ _x001C_ _x001C_ _x001C_

Crop and renew 2'x2' damaged deck 3' inboard of #2 port void manhole.

Make deck hatch (emergency escape) overhead of the storeroom operable from the storeroom side for proper emergency escape._x001C_ _x001C_ _x001C_

Crop and renew buckled sidelong (top) in #1 port void, #4 bay._x001C_ _x001C_ _x001C_ _x001C_

PRIOR TO OPERATING VESSEL IN COASTWISE TRADE PROVIDE A COPY OF VESSEL'S SOPEP CG APPROVAL LETTER.

PROVE PROPER OPERATION OF REMOTE FUEL SHUT OFF VALVE.

CLEAN OR REPLACE AFT RING BUOY(COATED IN BLACK OIL) AND MAKE READILY ACCESSIBLE(STOWED BEHIND CABLE AND HOSE).

VESSEL MAY NOT OPERATE IN COASTWISE TRADE UNTIL CG D14 GRANTS APPROVAL FOR DRYDOCK EXTENSION.

PROVE PROPER OEPRATION OF THE CRANE GENERATOR, ASSOCIATED LUBE OIL ALARMS AND SHUTDOWN DEVICES.

PROVIDE A COPY OF THE VESSEL'S ABS CLASS DOCUMENT.

Stair room - remove or properly terminate dead end wires._x001C_ _x001C_ _x001C_ _x001C_

CRANE GENERATOR ROOM - REMOVE ALL DEAD END WIRING

CRANE GENERATOR ROOM - PROPERLY LABEL BREAKERS IN ELECTRICAL DISTRIBUTION PANEL.

CRANE GENERATOR ROOM - PROVE PROPER OPERATION OF GENERATOR OVERSPEED.

Prove proper operation of navigation lights. Vessel is restricted to daylight operations until requirement is corrected.

Renew weak link for Buoyant Apparatus.

Hydrostatically test air receivers IAW 46 CFR 61.10-5(d).

Prove proper operation of volt and ammeter for lower machinery space generator.

Prove proper operation of MSD. When manned, vessel is restricted to voyages of 30 minutes until requirement is cleared.

Provide window for winch operator house.

Provide metal shelves in place of wood shelves in the paint locker IAW 46 CFR 92.05-10 (a).

Remove fuel oil from containment under crane turret.

PROVE PROPER OPERATION OF THE ELECTRICAL LIGHTING SYSTEM IN THE SPACE CONTAINING THE ELECTRICAL GENERATOR FOR DECK POWER.

PROVE PROPER OPERATION OF THE DECK LIGHTS.

IN #1S, CROP AND RENEW WHERE BUCKLED, THE 3RD VERTICAL SIDE SHELL STIFFENERFROM THE FWD BULKHEAD WHERE THE 2ND SIDE LONGITUDINAL FROM THE OVHD PASSES THROUGH.

In no. 2 S, arc out andreweld the fractured weld seam located between the 3rd vertical side stiffener and the aft bulkhead where the side shell ties to the main deck.

REPLACE THE CONTROL CIRCUITRY ELECTRICAL BOXES ON THE GENERATOR IN THE ELECTRICAL GENERATOR COMPARTMENT.

PROPERLY SECURE ELECTRICAL CABLES LOCATED IN THE CENTER BOW RAKE COMPARTMENT.

REMOVE OR PROPERLY BLANK UNUSED SECTION OF 1/4" PIPE LINES BROKEN OR WASTEDIN #2P, AND #3P VOIDS.

REPLACE CABLE CLAMP/TERMINAL LUG FOR THE BATTERY CABLE TO THE FWD NAVIGATION LIGHTS.

FAIR IN AND PARTIALLY CROP AND RENEW WHERE TWISTED, THE 1ST BOTTOM LONGITUDINAL FROM THE SIDE SHELL, AND THE ASSOCIATED GUSSET THAT TIES IT TOTHE STERN FRAME IN THE AFT RAKE STBD COMPARTMENT.

REPLACE THE TRIPPED BRACKET THAT TIES THE 1ST SIDE LONGITUDINAL FROM THE OVERHEAD TO THE BULKHEAD IN THE #3S VOID.

CROP AND RENEW WHERE BUCKLED, THE 1ST VERTICAL SIDE STIFFENER FM THE FWD BULKHEAD BETWEEN THE OVERHEAD AND THE 1ST SIDE LONGITUDINAL FROM_x001C_ THE OVERHEAD IN # 3S VOID.

In # 2 S, crop and renew where buckled, the 1st vertical side stiffener from the forward bulkhead between side longitudinals # 1 & # 2 from the overhead.

In No. 2 S, arc out and reweld the fracture weld located where the 2nd sidelongitudinal from the overhead passes through the 2nd vertical side stiffener from the forward bulkhead.

IN THE AFT RAKE STBD COMPARTMENT NEAR THE FWD BULKHEAD, ARC OUT AND REWELD THE FRACTURED WELD THAT TIES A 2' PIECE OF ANGLE IRON TO THE 1ST UNDER DECKLONGITUDINAL FROM THE SIDE SHELL. WELDMENT IS FRACTURED WHERE ANGLE TIES TOSIDE SHELL._x001C_

FABRICATE AND INSTALL A METAL COVER FOR THE DECK WINCH ENGINE LOCATED ON THE MAIN DECK PORT SIDE FWD.

REMOVE FUEL OIL IN CONTAINMENT AREA LOCATED ON FWD END OF CRANE ROUND HOUSE.

REPAIR LEAKS IN ROOF OVER CRANE GENERATOR SPACE.

REPLACE THE CONTROL CIRCUITRY ELECTRICAL BOXES ON THE ELECTRIC GENERATOR INTHE CRANE GENERATOR SPACE.

ARC OUT AND REWELD THE FRACTURED WELD LOCATED BETWEEN THE 1ST AND 2ND VERTICAL SIDE STIFFENERS FM THE FWD BULKHEAD WHERE THE SIDE SHELL TIES TO THE MAIN DECK IN # 3 P VOID.

BUILD UP THE INSIDE COAMINGS ON THE ACCESS HOLES FOR #1C, #2P, #3P, AND THEAFT RAKE STBD COMPARTMENT. BUILD UP WITH WELD METAL, GRIND SMOOTH, AND RETHREAD BOLT HOLES AS NEEDED.

RENEW THE TOP LADDER RUNG ON THE LADDER LEADING DOWN TO #1C.

PROVIDE ACCESS TO THE LOWER FRAMES IN THE LOCKER ROOM, TO ALLOW FOR COAST GUARD INSPECTION.

RENEW THE TOP 2 LADDER RUNGS ON THE LADDER LEADING DOWN INTO #3S.

CROP AND RENEW THE CONTAINMENT AREA AROUND THE STBD FUEL FILL AND VENT VALVE. EFFECT TEMPORARY REPAIRS UNTIL PERMANENT REPAIRS ARE MADE._x001C_ _x001C_ _x001C_

REMOVE PART OF THE WOOD FLOORING THAT COVERS THE FRAMES IN THE MACHINERY SPACES TO ALLOW FOR THE INSPECTION OF THE LOWER FRAMES.

REPAIR THE MSD AND THE TOILET AND PROVE OPERATIONAL.

PREPARE FOR CLOSER EXAMINATION, THE RAISED AREA ON THE DECK JUST AFT OF THE3RD VERTICAL SIDE STIFFENER FROM THE FWD BULKHEAD IN THE #1S VOID.

PLACE CURRENT LOADLINE CERTIFICATE ON BOARD VESSEL.

PROVE PROPER OPERATION OF GENERATOR PRIME MOVER TRIPS, ON BOTH GENERATOR SETS.

PROVE PROPER OPERATION OF THE SHIPS SERVICE GENERATOR SAFETY TRIPS.

PROPERLY MARK CRANE WITH THE SAFE WORKING LOAD IN ACCORDANCE WITH 46 CFR 91.37-45.

REPAIR(WELD) THE FRACTURED VERTICAL STIFFNER(#4 FROM STARBOARD) IN THE AFTER CENTER RAKE AT FRAME 15.

CROP AND RENEW A 20"X60" BUCKLED SECTION OF TRANSVERSE DEEP WEB FRAME #15, OUTBOARD STARBOARD RAKE._x001C_

PROVIDE PROOF TESTING FOR CRANE.

LABEL THE PFD STOWAGE LOCKER.

RENEW THE BROKEN WATER LIGHT AND INSTALL 100 FT. PAINTER ON THE BUOYANT APPARATUS.

SUBMIT STABILITY CALCULATIONS IN ACCORDANCE WITH 46 CFR 173 SUBPART B, FOR REVIEW AND APPROVAL.

INSTALL REACH ROD ON THE FUEL TANK DISCHARGE VALVE TO ENABLE SECURING THE VALVE FROM OUTSIDE THE SPACE.

LABEL THE WATER TIGHT DOOR IN THE 2ND TRANSVERSE BULKHEAD FROM THE STERN LEADING TO THE GENERATOR AND OIL STORAGE TANK TO READ, " TO BE CLOSED AND DOGGED WHEN VESSEL IS UNDERWAY."

INSTALL 30X30 MESH FLAME SCREENS ON THE TWO CRANE DAY TANKS, AND THE MAIN FUEL TANK VENT AND 20X20 MESH ON THE MSD TANK VENT.

REMOVE THE SHORE TIE CONNECTION FROM THE DISTRIBUTION PANEL OR PROVIDE A MEANS/SAFETY INTERLOCK TO PREVENT SHORE TIE FROM BEING PLACED ON THE SYSTEMWHEN THE GENERATOR IS ON THE LINE.

INSTALL BLANK ON THE 1/2 INCH SEA VALVE WHICH IS NO LONGER IN USE ON THE STBD SIDE SEA CHEST.

PROVIDE A PROTECTIVE COVER OVER THE BATTERY TERMINALS.

PROPERLY INSTALL GENERATOR METERS TO PREVENT ELECTRICAL SHOCK.

OBTAIN VALID LOADLINE CERTIFICATE.

INSTALL GUARD AT PUMP MOTOR COUPLING LDFT SIDE ON CRANE PRIME MOVER.

PROVIDE LIGHTS AND WHISTLES FOR LIFEJACKETS.

INSTALL GLASS GLOBES ON ALL INCANDESCENT LIGHT FIXTURES.

MAKE PRESSURE VESSELS AVAILABLE FOR INTERNAL INSPECTION OR HYDROSTATIC TEST.

ALL PORTABLE FIRE EXTINGUISHERS ON BOARD NEED ANNUAL SERVICING.

PERMANENTLY INSTALL BUOYANT APPARATUS ON WEATHER DECK AND PROPERLY AFFIX SEA PAINTER AND FLOAT FREE WEAK LINK.

BUOYANT APPARATUS SHALL HAVE VESSEL'S NAME STENCILED ON IT.

STENCIL LIFE RINGS WITH VESSEL'S NAME.

PERMANENTLY INSTALL LIFE RINGS (2) ON WEATHER DECK. AFFIX LINE AND FLOAT LIGHT TO BOTH OF THESE RINGS.
