USNS CATAWBA

Vessels must have sufficient starting air compressor capacity to ensure the main engines and emergency equipment can be started as required. The air starting system must be capable of at least 6 starts without recharging the air receivers. ABS Rules Part 4 9.5 ISM Code Part A Reg 10.1

Means must be provided to prevent over pressure in any part of the compressed air system. The number 1 air compressor was found in condition that it would not shut-off automatically and required constant manning to operate. ABS Rules Part 4 9.1.3 ISM Code Part A Reg 10.1

Ships are required to have at least two independent source of electrical power and an emergency source of power. Number 2 generator could not be started using ships air during inspection.

Each bus-tie between a main switchboard and an emergency switchboard must be arranged to prevent parallel operation of the emergency power source (Generator 1) with any other source of electric power, except for interlock systems for momentary transfer of loads.

Each rescue boat launching appliance shall be fitted with a powered winch motor capable of raising the rescue boat from the water with its full compliment of persons and equipment at a rate of not less than .3 m/s. Davit was only capable of lifting unloaded rescue boat intermittently, requiring long pauses before raising could be achieved again. SOLAS III LSA 6.1.1.9 ISM Code Part A Reg 10.

Every launching appliance shall be fitted with brakes capable of stopping the descent of the survival craft or rescue boat and holding it securely when loaded with its full complement of persons and equipment. Between intermittent raising of unloaded rescue boat, the brake was not holding securely and the boat would lower several feet.

The Administration, shall periodically verify the functioning of the ship’s safety management system. In accordance with vessel’s SMS casualty reporting; procedure 7.1-002-ALL, CASREPS shall be submitted not later than 24 hours after it is determined a casualty cannot be corrected within 48 hours. Vessel drafted CASREP, but due to 5th fleet requirements of editing CASREP before release, CASREP was not released within 24 hours. SOLAS IX, Reg 6.1 ISM Code Part A Reg 10.1

The Coast Guard issues the following endorsements for towing vessels: (1) Master of towing vessels. (2) Master of towing vessels, limited. (3) Mate (pilot) of towing vessels. (4) Apprentice mate (steersman). (5) Apprentice mate (steersman), limited Vessel master and only 1 mate are endorsed for towing. Vessel shall not perform towing evolutions unless properly manned. 46 CFR 11.463

The public address system must be reliable and capable of broadcasting emergency announcements throughout the ship from the bridge. System currently not functioning from the bridge. ABS Part 4 11.5.4

A powered watertight door must emit a visual and audible alarm when it begins closing. Watertight door in engine room had no visual alarm. SOLAS II-1, Reg 13

Remote fuel shutoff valves must be installed to stop the flow of fuel to equipment in event of a fire. The remote fuel shutoff valve for the #6 tank was found disconnected. SOLAS II-2, Reg 4

Electrical installations must be installed to prevent fire and electrical shock hazards. Electrical connection found on forward port side bulkhead in main engine space outside of an approved junction box. SOLAS II-1, Reg 45

SMS external audit required prior to departure from port. ISM Code Part A Reg 10.1

Vessel's no.3 fuel tank in engeineers workshop has pinhole leak at a rate of approximately 0.5gal/min.

A60 integrity of the bulkhead at the no. 3 fuel tank was compromised to locate source of fuel leak.

Smoke detectors located above the starboard main engine and between diesel pumps in the pump room were found covered in plastic. This will require an internal ISM audit.

(02) ABs do not meet STCW requirements for underway watch. The vessel is currently moored with no orders for getting underway, but will require sailing short notification if activated before requirements are met.

General condition of hospital space was not satisfactory.

Fuel piping flange was improperly installed, creating leak of approximately 0.5 gal/min into the engine room.

Protection Against Shock. General examination of safety precautions against shock, fire and other hazards of electrical origin. • Port side bulkhead forward of GMDSS, multiple electrical hazards: splices, missing covers, daisy chains power cord/power strips • Daisy chain power strips for coffee mess, and inboard bulkhead, to include dead-end wires for helo announcing system. • Daisy chain power strip in galley for food prep electrics. • Daisy chain power strips in stores office below galley. • Port side power strip of the non-marine type (orange) routed from port aft of bridge to outside deck. • Dead-end wire for GPS cable at chart table. • Extension cord through port side bridge vent. • Extension cord plugged into light in head (forward of galley), connected to another extension cord, through hole drilled in bulkhead into DC locker. • Exposed wiring on overhead just aft of house. • Light in galley never secured when power was secured for fire drill.• Two dead-end wires protruding from deck on inboard side of rescue boat. • Dead-end wire on port side light for rescue boat. Appears to not be connected to light fixture. • Portable extension cord from starboard side outlet on main permanently routed through overhead to starboard side tool shop, hooked up to a power strip. • Broken light fixture just aft of house. Light is hanging from wire. • Electrical wiring in DC closet overhead not properly secured. • Electrical wiring in overhead of Port workshop secured by plastic zip ties. • Multiple non-marine grade power strips identified on board (DC Locker). • Fans in engine room run with extension cords. • Light in EOS above engine control station hanging by rope • Electrical cable splice through deck outboard of gangway (stbd side) • Steering flat multiple cables with insulation failure • Steering flat junction boxes covers missing • Broken lens/diffusers for lights in steering gear • Grounding cable near port/stbd steering disconnected The SMS indicated that only one shipboard certified power strip was authorized per outlet. Cite: ABS Steel Vessels Under 90 Meters in Length (2001) Part 7-6-2/1.1.8(b)

In and from all …crew spaces and in spaces in which the crew is normally employed, other than machinery spaces, stairways and ladder shall be arranged to provide ready means of escape to the lifeboat and liferaft embarkations deck. Laundry room egress blocked by mop and gear. Rectified then blocked again. Cite: 74 SOLAS II-2/Reg 21(a)

Fire doors…in stairway enclosures…shall be of the self-closing type. The release mechanism functioned properly when operated, but the fire doors did not close properly. Cite: 74 SOLAS II-2/Reg 37(f)

The training manual…shall contain instructions and information, in easily understood terms illustrated wherever possible, on the life-saving appliances provided in the ship and on the best methods of survival. SOLAS training manual was missing lifejacket donning instructions for all types on board (3 types). Cite: SOLAS (2009) III/Reg 35.3

In all classes of watertight doors indicators shall be fitted which show, at all operations stations from which the doors are not visible, whether the doors are open or closed. The watertight door position indicator for the hand-operated location on the main deck is faded. Cite: 74 SOLAS II-1/Reg 13 (f)(5)

The company should establish procedures, plans and instructions, including checklists as appropriate, for key shipboard operations concerning the safety of the personnel, ship and protection of the environment. Danger tag on valve at stbd bunker station is not filled out and was not in Lockout Tagout (LOTO) logbook. Breaker CKT 6P-415 (forward of EOS), tagged out not in LOTO logbook. Danger tag 22-038 OWS (disconnected) not properly tagged (does not correspond with LOTO log). Cite: SOLAS (2020) IX / Reg 3, ISM Code Part A 7

Verification, as far as practicable, that the remote controls for stopping fans and machinery and shutting off fuel supplies in machinery spaces are in working order. Emergency fuel shut offs not marked, and key not identifiable. Fuel tank reach rods for #1 and #2 fuel tanks were disconnected. Cite: ABS Steel Vessels Under 90 Meters in Length (2005) 7-6-2/1.1.9(i) Remote Controls

Ships shall be fitted with two means of communicating orders from the bridge to the engineroom. The 1JV is not connected to control station, the wire is not permanently mounted, and the wire is separating from the gland. Cite: 74 SOLAS II-1/Reg 32

The AIS Pilot Plug on any vessel subject to pilotage by other than the vessel Master or crew must be readily available and easily accessible from the primary conning position of the vessel and permanently affixed (not an extension cord) and adjacent (within 3 feet) to a 120-volt 50/60 Hz AC power receptacle (NEMA 5-15). AIS pilot plug requires installation. 33 CFR 164.46 (g)

After any survey of the ship under Regulations 7, 8, 9 or 10 of this Chapter has been completed, no change shall be made in the structural arrangements, machinery, equipment, etc. covered by the survey, without the sanction of the Administration. • Leaking valve from CHT with effluent on deck. • Missing glass cover on port main “raw water” gauge. Stbd bunkering station missing gauge. • Exposed fan blade in port side main deck workshop. • Active leak from CHT valve with effluent on deck. • Missing position indicator for rudder angle indicator on stbd steering gear. • Compressed air line on main deck routed in overhead not properly secured. • General housekeeping in machinery spaces. Identified 2 5-gal buckets of grease and misc. wires in steering flat, garbage, bags etc in engineroom bilge. • Main engine RPM gauges differ from Engine Room. Noted stbd gauge was sticking on bridge. Noted several degree pitch discrepancy btwn bridge and EOS stations.

The means of control of any such fixed gas fire-extinguishing system shall be readily accessible and simple to operate… The operating instructions for the remote and local bow thruster CO2 system were not consistent. Cite: 74 SOLAS II-2/Reg 8(h)

Fire fighting systems and appliances shall be kept in good working order and readily available for immediate use. Fire station #12 missing spanner wrench. Fire station #12, hoses not attached for immediate use. SOLAS (2009) II-2/Reg 14.2.1.2

Every ship of 400 gross tonnage and above other than an oil tanker shall be provided with an Oil Record Book Part I (Machinery space operations). The Oil Record Book, whether as part of the ship’s official logbook or otherwise, shall be in the form specified in appendix III to this Annex. Missing the master’s signature, tank details in accordance with IOPP, and entry details. Cite: MARPOL Annex I/Reg 17.1

The master or person in charge of a ship to which this section applies shall ensure that the ship is not operated unless a garbage management plan meeting paragraph (b) of this section is on the ship and that each person handling garbage follows the plan. Garbage Management Plan/Record Book had 7 entries incorrectly documented. Cite: 33 CFR 151.57(a)

On all ships, within the machinery spaces, emergency escape breathing devices shall be situated ready for use at easy visible places. An EEBD was found expired in the port shaft tunnel. Cite: SOLAS (2009) II-2 / Reg 13.4.3.1

Where the emergency source of electrical power is a generator, it shall be, started automatically upon failure of the main source of electrical power supply. The emergency generator could not take electrical load automatically upon loss of power from SSDG.

In the case of loss of the generator in operation, adequate provision shall be made for automatic starting and connecting to the main switchboard of a stand-by generator of sufficient capacity to permit propulsion and steering and to ensure the safety of the ship with automatic restarting of the essential auxiliaries including, where necessary, sequential operations. The automation function in all the breakers on the main switchboard are inoperable, reducing the automation capabilities of the ship's power system.

Oil filtering equipment referred to in paragraph 1 of this regulation shall be of a design approved by the Administration and shall be such as will ensure that any oily mixture discharged into the sea after passing through the system has an oil content not exceeding 15 ppm. The Oily Water Separator on board is inoperable.

Oil fuel pipes, which, if damaged, would allow oil to escape from a storage, settling or daily service tank having a capacity of 500l and above situated above the double bottom, shall be fitted with a cock or valve directly on the tank capable of being closed from a safe position outside the space concerned in the event of a fire occurring in the space in which such tanks are situated. The quick closing valve for the entire fuel supply was found to be inoperable.

Every ship of 100 gross tonnage and above, and every ship which is certified to carry 15 of more persons, and fixed or floating platforms shall carry a garbage management plan which the crew shall follow. A plastic garbage can is being used to collect and store garbage.

Doors provided to ensure the watertight integrity of internal openings which are used while at sea are to be sliding watertight doors capable of being remotely closed from the bridge and are also to be operable locally from each side of the bulkhead. The position indicator for the watertight door was not working.

The design, materials, and constuction of all watertight doors shall be to the satisfaction of the Administration. The Type III watertight door had a temporary modification so that it would indicate colsure on the bridge. Provide permanent repairs to the satisfaction of the Recognized Organization.

Fire-fighter's outfits shall comply with the Fire Safety Systems Code. Personel equipment shall consist of an axe with a handle provided with high-voltage insulation. The fire-fighter's outfits did not have axes.

Each panelboard must meet section 17.1 of IEEE 45-2002. Blank off exposed section of the fire alarm panelboard on the bridge.

The foundation for the gyro repeater on the starboard bridge wing is badly deteriorated and needs to be cropped out and the foundation renewed. Provide gauging report within 30 days to the satisfaction of the RO.

The port side steel of the tow booth is wasted. Gauge thickness of steel around the tow booth and provide gauging report within 30 days to the satisfaction of the RO.

Posters and signs shall be provided on or in the vicinity of the survival craft and their launching controls and shall give relevant instructions. BF Goodrich launching instructions were posted when the vessel used Elliot liferafts. Provide corresponding instructions.

The checks and tests of the steering gear shall include the operation of the means of communication between the navigation bridge and steering gear compartment. During test of the emergency steering gear, it was discovered that the means of communication was inoperable.

A power-driven vessel underway shall exhibit a masthead light forward. Forward masthead navigation light installed on rescue boat is currently inoperable. Repair or replace light and demonstrate proper operation.

Each item of lifesaving equipment required to be carried onboard must be approved. Lifebuoys installed for quick release from navigation bridge do not bear USCG approval. Demonstrate flag state apporval or replace with approved buoys.

Liferafts shall be readily available in case of emergency. Hydrostatic release for starboard aft inflatable liferaft found to be installed incoreectly and not ready for automatic release. Demonstrate proper installation of automatic release mechanism.

Machinery driving forced-draft fans, FO transfer pumps, and similar FO pumps must be fitted with remote controls from an accessible position outside the space so the fans/ pumps may be stopped in case of fire. The Diesl Oil transfer pump, LO transfer pump, Dirty Oil pump, and P/S MDE Turbo Ventilation Circuit Breakers do not have an under-voltage trip device. Maintain circuit breakers in LOTO status when not in use. When in use, the ER must be manned IAW amended transfer procedures.ABS Finding Number: DU3556506-I OSR 987. Please see Documents for Class Report. Class issued short term SLE certificate until circuit breakers can be replaced.

Replace worn fuel oil and lube lines on all generators with hoses complying with SAE J-1942

Repair fuel oil leak at #1 SSDG Racor outlet line check valve.

Ensure valves are labeled on bow thruster CO2 local release station as per discharge instructions.

Provide receipt of ABS endorsement on all international certificates

Upon operational testing of Vessel's semergency source of power, numerous lights were found to be inoperative & unable to adequately illuminate the muster stations, launching stations, & stowage positions of survival craft, automatically upon loss of ship's service power, 74SOLAS(Un-Amended) II-1/26(b). Proper operation of e-lightls to be demonstrated to the sat. of the ACS prior to departure.

Records pertaining to, as well as evidence of, correcting the Vessel's onboard navigational publications up to the most recent Notice to Mariners not found readily available on board. Publs to be updated as required by the Vessel's SMS Procedures Manual 7.2.004 section 3.1 & by 33 CFR 164.33, for the intended voyage, to the satisfaction of the ACS (ABS) prior to departure from port.

The containments for the Stbd. side bunker station (iwo frame 60) and F.O. vent (Stbd. side aft, iwo frame 90) were found to be holed and wasted. Temporary repairs to be immediately affected. Proper permanent repairs to be affected to restore integrity of containment, to the satisfaction of the ACS (ABS), within 30 days. 23 October 2010.

The markings relating to the incremental position of the rudder angle to Stbd., Stbd. rudder stock, are illegible and no longer visible. Markings are to be made clear and visible from the emergency steering position, to the satisfaction of the ACS (ABS), within 30 days. 23 October 2010.

Provide on board a USCG approved first aid kit (under approval series 160.041) for the rescue boat as required by 46CFR199.175(b)(10) within 30 days. 23 October 2010.

The Vessel's SMS is to be upgraded to include provisions for recording corrections to electronic nautical publications and charts to the satisfaction of the ACS (ABS), within 90 days. 22 December 2010.

The Vessel's records pertaining to the on-board maint & testing of the e-lighting system inadequately reflecst the materiel condition of the system as found on board. Records pertaining to these required tasks to be reviewed for completeness & the Vessel's SMS upgraded to incorporate the proper procedure for testing & servicing of the e-lighting arrangement.

Vessel's on-board SMS fails to address & identify the periodic servicing of the launching appliance for the rescue boat. Vessel's SMS to be upgraded to incorporate the requirements of 74SOLAS2009 Cons. (All Ships) III/20.11.1 & Regulation 36 pertaining to the instructions for on-board maintenance to the satisfaction of the ACS (ABS), within 90 days. 22 December 2010.

The provision for the periodic testing (via test buttons/switches) of the equipment powered by the complete emergency installation unable to be properly demonstrated as required by 74SOLAS(Un-Amended) II-1/26(b)(iii) and 26(a)(v). Proper operation to be demonstrated to the satisfaction of the ACS (ABS) within 30 days. 23 October 2010.

The vessel had a large amount of older 2.5 hoses onboard. The Chief Mate was unsure of their use. Advised him to find out if there is a use or remove from over pack safety gear locker.

The rescue boat cable had been replaced and no weight test had been conducted. Received email from Master 9-18-08 advising test conducted as per NVIC 04-07, confirm at next attendance.

Prove proper operation of the Port and Starboard engine room remote bilge pump valves.

Prove proper operation of #1, #2, and #3 ship service diesel generator mechanical overspeed trips.

Air receiver relief valves 1, 2 7 4 do not lift properly. Service valves and recalibrate lifting pressure.

Rescue boat could not be run at full speed. Provide proof of full throttle rescue boat operation.

Vessel could not provide proof of fall renewal for rescue boat davit. Provide record of renewal or replace. If new fall is installed, insure testing is completed as required by SOLAS LSA code.

No annual 125% hydrostatic test for fuel transfer hoses. Complete pressure test to verify integrity of the hoses iaw 33 CFR requirement.

Galley serving windows self closing mechanism did not function properly. Window would not shut completely when fusible link activated. Service galley serving windows and prove proper operation.

Provide copy of final report for tailshafts wear down readings.

Provide copy of anchor gauging report. Received copy of the report prior to completion of the inspection.

Non-destructively test the tailshaft flange, including the fillet and coupling bolts and provide copy of the report.

Provide copy of the final report for all sea valves and engine room emergency bilge suction valve.

Replace expired medicines in hospital space no later than 15OCT04. 12OCT04 - Rcvd status from the master and extend due date to 15NOV04.

Replace missing metal flame guard cover on all MDE fuel filter no later than 15OCT04.

Replace missing light cover in port side lower pump room no later than 15OCT04. Rcvd e-mail from the master on the status on 12OCT04, extend due date to 15NOV04.

Provide USCG approved plans for modification to rescue boat davit, this requirement is re-issued from last exam. Rcvd e-mail from the master on the status on 09NOV04 extend due date to 15DEC04.

Update National Contact appendix to USCG approved SOPEP manual. LEGACY COMPONENT DESC: Removal Methods/Procedures

Provide and post vessel's Maneuvering Characteristics fact sheet on the bridge. LEGACY COMPONENT DESC: Maneuvering Information Fact Sheet

Install B-class fire screen door in the laundry room in accordance with the as built/approved plans.

Calibrate Alco Sensor IV testing equipment and provide calibration gas. Conduct and log required monthly calibration tests. LEGACY COMPONENT DESC: Testing, Equipment

Install all liferafts in a float-free arrangement prior to departure from port.

Provide USCG approved plans for modification to rescue boat davit arm and conduct weight test in presence of the USCG marine inspector or ABS surveyor.

Update SOLAS Training manaul to include donning procedures for on board emergency escape breathing devices and instructions for use of portable extinguishers. LEGACY COMPONENT DESC: Training Manual (lifesaving)

Conduct 100% weight test of the rescue boats rate load.

E1. Provide hand easing device for air receiver in the machine shop main deck port side in accordance with 46CFR54.15-10(c). LEGACY COMPONENT DESC: Relief Valve

E2. Remove excess lengths of non-metallic hose in use on the ships service generator. IAW 46CFR56.60-25(c)(4)

E3. Designate clear areas on the main deck for the remote fuel shut downs; to ensure area is clear at all times and the reach rods are accessible.

E4. Repair latch for bow thruster time delay access door and label door CO2 controls inaccordance with 46CFR97.37.13 LEGACY COMPONENT DESC: Operating Controls

E5. Provide operating instructions for the paint locker fixed CO2 system that are legible and at a reasonable height. LEGACY COMPONENT DESC: Fire

E6. Trouble shoot, repair and prove proper operation of the sound powered phone ringers for the 1JV and 2JV located in after steering compartment. LEGACY COMPONENT DESC: Sound-powered Telephone

E7. Repair the test switch for emergency light #21 engine room. Clean battery terminals for the emergency light port side shaft alley. LEGACY COMPONENT DESC: Lighting Fixture

E8. Prove proper operation of the audible alarm for the bridge fire alarm panel. LEGACY COMPONENT DESC: Fire Alarm

E9. Trouble shoot, repair and prove proper operation of the automation control panel in the engineer's stateroom.

1. Trouble shoot repair and prove proper operation of transient berthing sound powered phone bell and provide directory. LEGACY COMPONENT DESC: Sound-powered Telephone

2. Provide visual indicator for machinery space fire alarm. LEGACY COMPONENT DESC: Fire Alarm

3. Properly secure manhole covers on ventilation ducting penetrating machinery space watertight bulkhead port side refer flat and machine shop, and starboard side engine room next to console. LEGACY COMPONENT DESC: manhole cover

4. Properly secure tubing runs - starboard side console (ECR) LEGACY COMPONENT DESC: Piping

5. Verify all through hull deck and bulk head cable penetrations fire stops properly poured and complete. LEGACY COMPONENT DESC: Structural Bulkhead Construction

6. Provide hold back devices, as required, for the newly installed engine room control console doors. LEGACY COMPONENT DESC: Panelboard

7. Provide copy of report of repairs completed to the #6 fuel tank swash bulkheads.

Make permanent repair to the two bent swash bulkheads in #6 fuel oil tank in way of frames 79 and 81. LEGACY COMPONENT DESC: Transverse Bulkhead

Renew wasted pipe clamps in the number 3 and 8 sea water ballast tanks.

Crop to sound steel and renew wasted and holed drain lines in the number 4 sea water ballast tank.

(5) Label all remote fuel shut off valves as to their service IAW 46CFR 56.50-1(2)i.

(6) Conduct sufficient training for launching rescue boat to improve crew proficiency to reduce launch time. LEGACY COMPONENT DESC: Man Overboard Recovery

(7) #3 S/S generator inop. Make permanent repair and prove proper operation of #3 S/S generator.

(9) Excessive lengths (>30inches) of non metallic hose in use on #2 S/S generator . Bring all lube oil, fuel oil and fluid power systems into compliance with 46CFR 56.60-25(c)(4). LEGACY COMPONENT DESC: Hose

(10) Prove proper operation of non-operational emergency, "E" light at the engineroom console. LEGACY COMPONENT DESC: Lighting Fixture

(14) Remove/properly stow miscellaneous stores and clutter stashed in the bow thruster space. LEGACY COMPONENT DESC: Maintenance of Ship/Equipment

(17) Clean or renew all general alarm bell identification signs to make them legible in accordance with 46CFR 97.37-7

(18) Prove proper operation of the bilge alarms in transient berthing staterooms and machinery space. Alarms are not operational. LEGACY COMPONENT DESC: Bilge Alarm

(19) Label time delay bypass valve and update instructions as necessary for CO2 system serving the bow thruster space. Instructions to be complete and simple in accordance with 46CFR 95.15-10(h). LEGACY COMPONENT DESC: Operating Controls

(20) Conspicuously identify the aft CO2 discharge alarm in the engineroom in accordance with 46CFR 97.37-9, " WHEN ALARM SOUNDS - VACATE SPACE AT ONCE. CARBON DIOXIDE BEING RELEASED" LEGACY COMPONENT DESC: General Alarm

(21) Prove proper operation and permanently mount smoke detector in aft steering or remove alarm per 46CFR 95.05-1. LEGACY COMPONENT DESC: Fire Alarm

(22) Prove proper operation of 2nd element on lower forward mast head light. LEGACY COMPONENT DESC: Navigation Underway, General

(24) Prove proper operation of local manual water tight door controls for machinery space sliding watertight door.

(25) Prove proper operation of oily water separator and bilge monitor. LEGACY COMPONENT DESC: Oily Water Separator (15 ppm)

(2) Fire control plan required by 46 CFR 91.55-5d reflecting existing condition of the ship not posted. Post accurate approved fire control plan.

(4) Mark liferaft embarkation area IAW 46CFR 97.37.40/46CFR199.178 "INFLATABLE LIFERAFT NO ___ ___ PERSON CAPACITY".

Provide a SOLAS Training manual in all crew and officer lounges.

Provide a minimum 4kg starboard bridge ring buoy.

Provide the 8 missing lifejacket lights.

Prove proper operation of the daylight signaling lamp.

Update Sopep contact numbers.

Provide a station bill with a dedicated GMDSS operator.

Provide a metal mechanical fitting for the lube oil containment.

PROVIDE EXEMPTION FOR INTERNATIONAL DOCUMENTS OR PROVIDE INTERNATIONAL DOCUMENTS PER MSC VOLUNTARY COMPLIANCE POLICY.

PROVIDE EMBARKATION LADDERS FOR UNDER LIFERAFTS.

Insert a 4" ballast line located port side aft #3 ballast tank

Provide certs for material used to replace B-15 bulkheads in transient quarters, 3rd Mates rm & Eng Utility rm.

Repair transient quarter deck (pin holes in approximately 5 areas) to the satisfaction of the attending ABS Surveyor.

Replace strike plate for sounding tube to #7 diesel oil tank and #5 diesel oil tank.

Clean & gauge area 2' on either side of centerline in oily bilge collectiontank. Provide results of gauging compared to original scantling. Complete repair to the satisfaction of the ABS surveyor.

Mechanically scale & gauge all ballast and fuel tank vents, as indicated during exam. Provide report of findings and repair as needed.

Repair and prove the proper operation of the following watertight door/hatch indicators: Main Deck Passage Door, Transient Workers Access Door, Engine Room Escape Hatch, Starboard Steering Gear Room Escape Hatch.

Provide a new First Aid Kit for the vessel's Rescue Boat.

Repair and prove the proper operation of the General Alarm Bells located inthe Bowthruster Space, Lower Pump Room (#12), and forward Engine Room (#11)._x001C_ Item to be completed prior to operation of vessel to satisfaction of ABS.

Prove the proper operation of all Forward Masthead Lights, the Aft Tow Light, and the Aft Stern Light._x001C_ _x001C_ Item to be completed prior to operation to the satisfaction of ABS.

Provide a Sea Anchor for the vessel's Rescue Boat.

Renew/Repair the searchlight for the vessel's Rescue Boat.

Repair and prove the proper operation of the vessel's Oily Water Separator.

Install a closure device on the electrical junction box located in the lower pump room, starboard side.

Prove proper operations of S/S generator

Install and prove proper operation of STBD Anchor windlass.

Install illumination for RAI and Coms staion in steering flats.

OPERATE THE EVAPORATORS AND TEST ASSOCIATED ALARMS.

HOSE TEST ALL MAIN DECK WATER TIGHT DOORS, HATCHES AND SCUTTLES AND ENGINE ROOM SOFT PATCH. MINIMUM WATER PRESSURE IS 30PSI.

REPAIR THE START AIR RELIEF VALVE IN WAY OF THE #1 AIR TANK.

REPAIR THE #1 STEERING MOTOR FLOAT SWITCH. IF THIS PUMP IS OPERATED UNDERWAY, THE LEVEL MUST BE VISUALLY CHECKED BY ENGINE ROOM PERSONNEL EVERYTWO (2) HOURS.

PRIOR TO GETTING UNDERWAY, PROVE PROPER OPERATION OF THE SHIP'S SEWAGE SYSTEM.

PRIOR TO GETTING UNDERWAY, PROVE PROPER OPERATION OF THE SHIP'S A/C SYSTEM.

INSTALL A MACHINERY GUARD ON THE FUEL OIL TRANSFER PUMP.

LABLE THE AFTER STEERING 1JV AND 2JV SPP DIRECTORY.

PRIOR TO GETTING UNDERWAY, PROVE PROPER OPERATION OF THE MAIN FIRE PUMP.

REPAIR THE HOSPITAL HOT WATER HEATER RELIEF VALVE.

INSTALL SUCTION GAUGES WHERE REMOVED IN THE ENGINE ROOM.

PROVE PROPER OPERATION OF THE OILY WATER SEPARATOR. UNTIL SATISFACTORY TEST, THE VESSEL'S UNDERWAY DURATION IS LIMITED TO THE CAPACITY OF THE OILYWASTE RETENTION TANK.

PRIOR TO GETTING UNDERWAY, REPAIR THE REMOTE SHUTOFF TO THE DAY TANK FUEL OIL VALVE.

Install two engineroom CO2 bottles that wer removed for hydro.

Make repairs to #3 ship service generator remote stop assembly. Do not operate generator until proper operation has been proven.

Provide copy of fire extinguisher servicing report for portables and fixed systems.

Prove proper operation of emergency ventilation trip for pumproom exhaust fan (Port).

As per MSC-1 letter Ser H1-9601239 dated 25 April 1996 provide an approved stability letter.

PROVIDE CG APPROVED FIRE PLAN AS PER 46CFR 110.25 TO COGNIZANT USCG MARINE SAFETY OFFICE.

PROVE PROPER OPERATION OF THE OVERSPEED TRIPS FOR VESSEL'S ELECTRICAL GENERATORS (3) AS PER ABS 35.21.2 FOR DIESEL VESSEL CONSTRUCTED BEFORE 31MAY82._x001C_ _x001C_

Number 1 Ship's service generator smoked and then failed. Some internal wires were found melted. Contamination suspected.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

PRIOR TO SAILING, RENEW THE LEAKING COOLING WATER SUCTION FLEXIBLE HOSE FORTHE #3 SHIP'S SERVICE DIESEL GENERATOR.

MAKE REPAIRS TO LEAKING BILGE OVERBOARD VALVE. VALVE TO REMAIN BLANKED-OFFUNTIL SATISFACTORY REPAIRS ARE MADE

PRIOR TO SAILING, CONDUCT AN OPERATIONAL TEST OF THE STEERING SYSTEM (INCLUDING OPERATION OF BOTTH STEERING PUMPS) IN THE PRESENCE OF A USCG MARINE INSPECTOR.

RENEW LEAKING PORT SIDE OFFSHORE FIREMAIN MANIFOLD. PORT SIDE FIREMAIN MANIFOLD TO REMAIN ISOLATED UNTIL COMPLETION OF REPAIRS.

REPAIR LEAKING VALVES ON STARBOARD SIDE OFFSHORE FIREMAIN MANIFOLD.

RENEW STARBOARD HANDRAIL ON LADDER LEADING FROM QUARTERDECK TO MAIN DECK INWAY OF AFT TOW WINCH MOTOR.

REPAIR OR RENEW CABLE SUPPORTS FOR WIRING RUNS IN WAY OF STARBOARD FUELING STATION, FORWARD TOW WINCH MOTOR, AND QUARTERDECK

thoughly clean bilbes, tanktops, deck and ladder treads in engineroom, pumproom, and shaft alleys.

Replace or renew dirty oil tank vent flame screen.

PROVIDE ON BOARD VESSEL THE PROPER CALIBRATION GAS KIT FOR VESSEL'S TWO EXPLOSION GAS TEST METERS.

PROVE PROPER OPERATION OF THE MIO SHIP TOW LIGHT, ITS ALARM AND THE AFT ANCHOR LIGHT.

SUBMIT SERVICING REPORT OF VESSEL'S FIXED FIRE FIGHTING/EXTINGUISHING SYSTEMS. ITEMS TO BE TESTED SHALL BE ALARMS, PRESSURE SWITCHES AND TIME DELAYS.

HYDROSTATICLY TEST ALL FIXED CO2 BOTTLES THAT HAVE NOT BEEN HYDRO TESTED WITHIN THE LAST TWELVE YEARS, ALL PORTABLE AND SEMI-PORTABLE CO2 BOTTLES THAT HAVE NOT BEEN HYDROED WITHIN THE LAST FIVE YEARS. UPON COMPLETION SUBMIT SERVICING REPORT.

PROVE PROPER OPERATION OF FIRE/SMOKE DETECTION SYSTEM THROUGHOUT VESSEL.

PROVE PROPER OPERATION OF THE FOLLOWING BILGE HIGH LEVEL ALARMS; ENGINE ROOM STBD, PUMP ROOM STBD SIDE AND TRANSIENT BERTHING AREA.

PROVE PROPER OPERATION OF ALL REMOTE OPERATED VALVES THROUGHOUT VESSEL. ALSO LABEL LOCATION OF SAME AT EACH STATION.

PROVE PROPER OPERATION OF MACHINERY EMERGENCY SHUT DOWNS LOCATED AT THE CONTROL STATION.

PROVE PROPER OPERATION OF THE BOW LOOKOUT SOUND POWERED PHONE SYSTEM.

PROVE PROPER OPERATION OF THE WATER TIGHT DOOR INDICATOR LOCATED ON THE MAIN DECK STBD SIDE STATION.

PROVE PROPER OPERATION OF THEMACHINERY SPACE SUPPLY FAN VENT CLOSURE LOCATED PORT SIDE 03 DECK LEVEL.

TEST OR REPLACE THE RELIEF VALVES ON BOTH CLUTCH CYLINDERS.

REPLACE PRESSURE RELIEF VALVES ON PRESSURE VESSELS 1,4 AND THE CONTROL AIR CYLINDER.

RELOCATE FIREMANS OUTFITS TO LOCATIONS WHICH ARE WIDELY SEPARATE.

PROVIDE BOOTS AND A FLASHLIGHT FOR THE MAIN DECK AMIDSHIPS PASSAGEWAY FIREMANS OUTFIT; AND BOOTS, A FLASHLIGHT, AND A LINE FOR THE MAIN DECK STARBOARD FIREMANS OUTFIT.

MAKE PERMANENT REPAIRS TO THE BRIDGE PUBLIC ADDRESS SYSTEM.

MAKE PERMANENT REPAIRS TO THE 01 DECK PORT SIDE WTD WHICH IS JAMMED, AND FREE-UP AND REPLACE THE GASKET ON THE STARBOARD SIDE DOOR ON THE SAME DECK.

MAKE PERMANENT REPAIRS TO THE AUTOMATION BILGE CIRCUIT FOR THE NUMBER 2 BILGE PUMP.

MAKE PERMANENT REPAIRS TO THE MANUAL STACK DAMPERS ON THE BRIDGE DECK.

REPAIR OR REPLACE THE ENGINEER ASSIST ALARM IN THE OFFICERS MESSROOM.

MAKE PERMANENT REPAIRS TO THE BOW THRUSTER TO ENSURE THAT IT DOES NOT STICK, I.E., REMAIN FULL ON WHEN GIVEN PARTIAL THROTTLE.

RENEW ILLEGIBLE GANGWAY FIRE CONTROL PLANS.

REPAIR OR REPLACE SMOKE DETECTOR IN AFTER STEERING.

REPAIR OR REPLACE LEAKING VALVES AT FIRE STATIONS 1,9,13, AND IN AFTER STEERING.

REPAIR OR REPLACE INOPERATIVE GENERAL ALARM NUMBERS 1-42-2, 1-56-1, AND THE ALARM IN THE FORWARD LINE LOCKER.

PROVIDE A LINE-THROWING APPLIANCE AND EQUIPMENT AS SPECIFIED BY 46 CFR 94.45-5(A) AND 46 CFR 94.45-15(A).

RENEW THE DETERIORATED RAIN OR WATERTIGHT ELECTRICAL JUNCTION BOXES, GROMMETS, PLUGS AND RECEPTICLES ON THE AFTER MAIN DECK AND IN WAY OF THE TOWING WINCH.

PROVIDE THE TEST RESULTS FOR THE HYDROSTATIC RELEASE FITTED ON THE INFLATABLE LIFE RAFT. THE TEST REPORT IS TO BE MAILED TO THE [name withheld], HAWAII.

PROVIDE ONE (1) BOUYANT ROCKET FOR THE KILGORE LINE THROWING APPLICANCE.

INSPECT AND TEST ALL PORTABLE FIRE EXTINGUISHERS. RE-SERVICE THE PORTABLE FIRE EXTINGUISHERS IN ACCORDANCE WITH THE REQUIREMENTS OF 46 CFR 91.25-20. THE CURRENT SERVICING BY THE SHIPS PERSONNEL WAS UNSATISFACTORY.

PROVIDE TEST RESULTS OF THE FIRE FIGHTING FOAM ANALYSIS TO THE [name withheld], HAWAII.

RENEW THE GENERAL ALARM BELLS WITH A USCG APPROVED TYPE THAT IS NOT AFFECTED BY CHANGES IN AMBIENT TEMPERATURE.

PROVIDE GUARDS FOR THE LIGHT FIXURES IN THE STORAGE ROOM, PORTSIDE, MAIN DECK AND THE DECK LIGHTING FIXTURE ADJACENT TO THE TOWING WINCH.

REPAIR THE ENGINE ROOM VENTILATION SUPPLY SHUT DOWN DEVICES. THE DEVICES ARE LOCATED IN THE STACK. [D11]

REPLACE THE DEFECTIVE TEMPERATURE GAUGE ON THE NUMBER 2 GENERATOR STATIONARY WINDING. [E2]

REPLACE 3 GOOSENECK VENT COVERS ON THE PORT SIDE, AFT WEATHER DECK. [D1]

DEMONSTRATE THE PROPER OPERATION OF THE FIRE & SMOKE DETECTORS LOCATED IN THE LOWER PUMP ROOM AND AFTER STEERING COMPARTMENT. [D2]

REPAIR THE FOLLOWING INOPERATIVE EMERGENCY LIGHTS: ENGINE ROOM FORWARD STBD CORNER; ENGINE ROOM AFT, CENTER BULKHEAD; PORT SHAFT ALLEY; 0-1 LEVEL FR60; 0-1 LEVEL FR61 STBD. [E8]

DEMONSTRATE THE PROPER OPERATION OF NUMBER 1 DIESEL GENERATOR OVERSPEED SOLENOID TRIP. [E1]

REPAIR AND DEMONSTRATE THE AFTER STEERING COMPARTMENT, COMMUNICATIONS SYSTEM BELL. [D12]

REPAIR GENERAL ALARMS NO. 2-75 (ENGINEROOM) AND NO. 1-18 (BOW AREA).

REPAIR PORT AND STBD MAIN ENGINE EMERGENCY REMOTE SHUTDOWNS ON BRIDGE CONSOLE.

PROVIDE ACCESSIBLE STOWAGE FOR PFDS IN TRANSIENT QUARTERS.

REPAIR AND CALIBRATE PORT AND STBD SHAFT TACHOMETERS ON BRIDGE CONTROL CONSOLE.

RE-INSTALL FIRE DETECTION SMOKE SENSOR IN MACHINERY PUMP SPACE.

REPAIR PORT AND STBD AFT STEERING W/T DECK HATCH "OPEN-CLOSED" INDICATORS ON BRIDGE.
