SEA EXPLORER

The light must be a floating waterlight approved under approval series 161.010 or other standard specified by the Commandant. The floating waterlight must be attached around the body of the life float or buoyant apparatus by a 10 mm (3/8 inch) lanyard, resistant to deterioration from ultraviolet light, and at least 5.5 meters (18 feet) in length. Marine Inspector (MI) observed the waterlight on 3 life floats was attached with zip ties.

All cable and wire must be installed with metal supports spaced not more than 610 millimeters (24 inches) apart, and in such a manner as to avoid chafing and other damage. The use of plastic tie wraps must be limited to bundling or retention of multiple cable installations, and not used as a means of support. MI observed wires that were held up only by plastic ties.

Electrical equipment on a vessel must be installed and maintained to: Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. A light fixture in the fuel compartment had a faulty connection and the running cable was not marine grade approved.

Electrical equipment and installations must be suitable for the roll, pitch, and vibration of the vessel underway. The hertz meter in the engine room was not secured to the bulkhead.

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected. The hydraulic line in the engine room was not mounted to the ceiling creating an overhead hazard.

Vessels operated solely within 20 nautical miles of land must be equipped with a VHF-DSC radio installation. The installed VHF radio did not have GPS position input for full DSC capabilities.

Vessels required to have VHF radio equipment must undergo a detailed inspection of the radio installed by an FCC-licensed technician once every five years. If the ship passes the inspection, the technician will issue a Communication Act Safety Radiotelephony Certificate. Vessel did not have a valid FCC Radiotelephony Certificate onboard.

The portable hand bilge pump shall be provided with suitable hoses for pumping bilges on the suction and discharge ends. The length of the hose for the portable hand bilge pump did not reach overboard.

Rails shall consist of evenly spaced courses and the spacing between courses shall not be greater than 12 inches. The top deck aft rails did not have courses.

Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Prove dead end wiring in the "Main Void" is not a hazard.

The owner shall provide to the OCMI all data needed to reflect installation of new generator. This data must account for any weight changes to the vessel. Reduce passenger count by 01 passengers until plan review can be completed. Total persons allowed is now 82.

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant [name withheld] or alterations that affect the safety of the vessel include, but are not limited to: replacement of propulsion and power supply systems. The owner or managing operator shall submit drawings, sketches, or written specifications describing the details of any proposed alterations to the cognizant [name withheld] alterations must be approved by the OCMI before work is started. Provide for review and approval data and or drawings of the new generator with feeder cable size and over-current protection. The vessel may not get underway prior to the resolution of this deficiency.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Vessel had expired COD, provided proof of pending issuance, issued 835 requiring valid COD by 16Jul17

Discovered dead end wiring, vessel corrected on the spot.

Discovered one master wasn't listed on MIS report. Discovered he was removed due to an administrative mistake by consortium. Corrected on the spot.

Discovered tether for paddles was insufficient. Vessel corrected prior to departure of Marine Inspector.

Infant PFDs werent segregated from Adult PFD's. Corrected on the spot

Provide visual indicator at the operating station for each automatic bilge pump to indicate when pumps are in operation.

Prove proper operation of the port Main Propulsion Engine.

Crop and renew bilge piping with corrosion identified in the "void" compartment (second most forward space).

Replace, as new, sea painter on life floats IAW 46CFR180.175.

Label lifefloats IAW 46CFR180.175

Provide proper clip for starboard side life ring IAW 46CFR180.70

Provide proper o-ring for the light on the starboard side lifering IAW 46 CFR 180.70.

Replace with new lightswitch cover in engine room IAW 46 CFR 183.410

Provide proper nozzle for hose at fire station IAW 46 CFR 181.320.

Remove dead end wiring on vessel as indicated IAW 46 CFR 183.340

Install double hose clamps on flex hose IAW 46 CFR 182.720

Provide permanently affixed official number IAW 46 CFR 67.21

Repair pin hole leak on inspection cover plate for water tank in lazarette IAW 46 CFR 176.802

Repair deck on port side fantail IAW 46 CFR 176.802

Make permanent repairs to bottom bilge pipe in fuel tank compartment prior to carrying passengers for hire

Undergo a hull examination by a USCG Marine Inspector prior to carrying passengers for hire.

Replace J-Box cover for hydrualic pump motor in fuel tank compartments and secure wire nuts.

Provide a single line electrical diagram and generator specs for newly installed generator, Submit to USCG Sector LA-LB for approval.

Ensure all wire/cables in the engine room are properly supported with metal supports not more than 24 inches apart as required by 46 CFR 183.340.

Provide a sufficient number of alcohol testing devices on board the vessel to determine the presence of alcohol of each individual involved in a Marine Casualty as required by 46 CFR 4.06-15.

Machinery guard over the rotating belts on port engine, FWD was missing and needs to installed.

Main AC Distribution Panel missing drip shield. LEGACY COMPONENT DESC: Distribution Panel Bus

Stanction on starboard side between frames 6-7 fractures. G/W to original.

Seal penetrations in engine room and fuel tank compartments IAW 46 CFR 179.320(c)

Install metallic supports on wire runs in engine room and fuel tank campartment IAW 183.40(a)(4). LEGACY COMPONENT DESC: Wiring

Provide placard for maximum persons on the upper deck IAW 46 CFR 185.602(g)

Provide wire hangers in fwd compartment IAW 46 CFR 182.720(d).

Install new petro hose to cooling water pump on generator.

Plug stuffing tubes in water tight bulkheads IAW 182.720(d).

Install new retro-reflective tape on 6-child lifejackets.

Remove and replace broken starboard side bridge window as per 46 CFR 177.1010.

PROVIDE A VISUAL INDICATOR AT THE OPERATING STATION TO INDICATE AUTOMATIC BILGE PUMP OPERATION AS PER 46 CFR 182.530(C).

Make vessel available for a check ride.

Demonstrate satisfacory simplified stability test._x001C_ _x001C_ _x001C_ _x001C_

SUBMIT SINGLE LINE DRAWINGS FOR NEW INSTALLATION AND CABLE OF SHORETIE CONNECTION

PROVIDE PROPER NOZZLES FOR FIRE HOSES._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE PROPER ELECTRICAL CABLE SIZE AND TYPE FOR HYDRAULIC POWER SYSTEM.

PROVIDE DOUBLE NUTS FOR ALL STEERING LINKAGES.

PROVIDE PROPER E-FUEL SHUTOFF VALVES FOR FUEL TANK. VALVES MUST BE OPERATED FROM OUTSIDE THE SPACE.

PROVIDE WEAK LINK FOR LIFE FLOATS.

SUBMIT PLANS OF MATERIALS AND SCHEMATICS OF HYDRAULIC SAMPLING SYSTEM.

PROVIDE RESCUE LADDER/PLATFORM.

PROVIDE METALLIC NOZZLES FOR TWO FIRE HOSES ON MAIN DECK.

PROVIDE UPDATED/CORRECTED LIGHT LIST AND COAST PILOT OF LOCAL OPERATING AREA THROUGH LATEST LOCAL NOTICE TO MARINERS.

PROVIDE UPDATED/CORRECTED CHARTS OF LOCAL OPERATING AREA THROUGH LATEST LOCAL NOTICE TO MARINERS.

RESTENCIL NAME AND HAILING PORT ON STERN OF VESSEL.

PROPERLY INSTALL BULKHEAD STUFFING TUBES THROUGHOUT VESSEL.

MAKE MAIN DECK HATCH INTO ENGINE ROOM WATERTIGHT.
