CAPITOL

For the purpose of this subpart, rooms containing “fire resistant furnishings” are considered to be those in which: Furniture such as chairs, sofas, and similar items are tested and meet the requirements in UL 1056 “Fire Test of Upholstered Furniture,” or meet the requirements in § 72.05-55 in subchapter H of this chapter. 46 CFR 116.115 states: when outfit items such as furnishings and mattresses are renewed, they must comply with the regulations in this part. 46 CFR 114.400 defines low risk service spaces as an accommodation space that contains only fire resistant furnishings and a fire load not greater than 3 pounds per square foot. New chairs were purchased for the dining spaces on board the vessel that are located in Category 5 (Low Risk Accommodation) spaces according to the space categorization plan. However these chairs do not meet the definition of "fire resistant furnishings" in subpart K or the guidance found in NVIC 9-97 (Ch. 1)page 37 which allows for the standard of CAL TB 133. The fire load calculations submitted to MSC account for the fire load of the chairs but do not address the approval of the chairs which is required to be submitted with the plan in accordance with PRG H2-14 page 2. 46 CFR 116.423(a)(1) 46 CFR 116.115(b) 46 CFR 114.400 46 CFR 116.427

At each initial and subsequent inspection for certification, the marine inspector may require that a fire drill, abandon ship drill, or man overboard drill be held under simulated emergency conditions to be specified by the inspector. The full drills for the vessel were not witnessed at time of inspection due to minimal crew on board for subsequent transiting to new OCMI zone where a new to zone inspection will be carried out. 46 CFR 115.808(g) 46 CFR 115.810(d)

A class bulkheads must be so insulated with approved structural insulation, bulkhead panels, or deck covering so that, if subjected to the standard fire test for the applicable time period listed. The structural fire protection insulation located in the overhead in the galley was replaced during this yard period, however the operator was unable to provide proof that the insulation meet A-15 standards. The only approval given was for 164.009 which is for noncombustible materials and not under 164.007 for structural insulation. 46 CFR 116.416(a)(2)(i)

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load under such requirements without exceeding its designed limitations. The vessel's propulsion is currently set up for 8 speeds forward and 4 speeds astern utilizing a diesel electric system. The owner requested to not run the vessel to the 8 forward setting during seal trials due to the vessel not being operated on a normal basis in that manner. Owner to submit a plan to ensure that vessel is not operated past 7 and also prove safety operations at lower design speed. 46 CFR 119.200(a)

Replace life ring float light with cracked housing located at stern of wheel house.

Replace retro-reflective tape on all life rings.

Tighten the loose stbd side rescue boat davit mounting bolt and install a backing plate to the support stanchion.

Replace the leaking stbd side, main deck firehouse. A temporary replacement hose (75 foot) is acceptable until a new 50’ hose is acquired.

Replace the expired alcohol test kit and Aspirin.

Ensure the Senior Deckhand Letter is updated and all SDH’s have proof of first aid and CPR training.

Replace the missing dryer electrical outlet cover

As per 46CFR121.115 AND 121.620(b) ensure the vessel has a reliable means for shutting down the propulsion engine, at the main pilothouse control station, which is independent of the engine speed's control.

Submit electrical calculations on the new washer and dryer installation.

Verify the 3 deck life ring is CG approved or replace it.

Update the vessel's first aid kit.

Replace damaged #5 fire station hose.

Lubricate the emergency fuel shutoff reach rod.

Replace engine room MARPOL Placard.

Move engine room electrical wire away from the discharge valve for the installed fire pump.

Ensure main deck P/A speaker volume is adequate for location.

Prove proper operation of the STBD navigational light.

Remove the extension cord and hard wire in additional outlets as needed in the gift shop.

Blank off dead end wires and properly wire the exhaust fan in the ice room.

Clean the galley exhaust fan.

Secure the overhead wire, stbd side, back void.

Properly adjust and chalk test the void WTD.

Properly wire the new refrigerator located in the port side, hold.

Ensure the items in the first id kit are not expired and meets 46CFR160.041.

Hydro or provide access to the air receiver in the engineroom.

Carry only 462 adult passengers until the PFD’s are replaced.

Repair the leaks on the #1 hydraulic hose.

Repair the leaking stbd steering ram seal and oblonged bushing mount.

Replace the missing glass light globes in the engineroom.

Provide a service report from an authorized CAT repair technician verifying the proper operation of the generator over speeds and engine safeties.

Prior to 25April08, ensure the sewage hold structural stiffening modifications are submitted to the USCG Marine Safety Center for approval.

Prior to 25March09, repair, replace or provide documentation from a Naval Architect which states the condition of the current foam filled rudders are adequate for service. If a different type of rudder is desired than is currently installed on the vessel, an approved plan must be submitted from a Naval Architect or reproduced from the original approved plans.

Prior to 15APRIL08, determine source of stray electrical current and properly repair to prevent further hull deterioration.

C/R base of the deteriorated, outboard, main deck rail stanchions.

Properly mount and prove operation of the forward, high level, bilge alarm and ensure the wires are properly hung with metal supports every 24 inches.

Properly hang overhead wires with metal supports every 24 inches, in the # 2 void.

Ensure Emergency Fuel Shut-off valve operates freely.

Ensure all bulkhead stuffing tubes are properly sized and properly seal the wire.

Properly adjust both below deck watertight doors.

Ensure both watertight doors have individual corresponding indicator lights on the bridge console.

Permanently wire stbd side freezer in the storage room.

Properly install the port fan motor capacitor box located in the electrical room.

Properly install the engineroom deck plates, stbd side, outboard of the MDE.

Clean and install a guard on the exhaust fan, stbd side, outboard of the MDE.

Properly hang, with metal supports every 24 inches, wires in the engineroom overhead, stbd side, outboard of the MDE.

Ensure Vessel Master's have a FCC restricted radio operator's permit.

Properly mount second deck, P/A speaker.

Properly clean and sanitize all bars, galley and food service areas.

First deck ring buoy line not braided properly to the ring buoy itself.

Ring buoys on 2nd and 3rd deck not Coast Guard approved.

Bridge deck life ring buoy had rotted life line.

Post instructions for the operation of the MSD. LEGACY COMPONENT DESC: Control of Discharge of Sewage

In the MSD compartment close opening in the distribution panel. LEGACY COMPONENT DESC: Panelboard

Remove dead end wiring under the 2nd deck bar. LEGACY COMPONENT DESC: Wiring

Post life jacket instructions at all life jacket lockers. LEGACY COMPONENT DESC: Condition

Stencil all ring buoys throughout vessel. LEGACY COMPONENT DESC: Markings (ship name/port)

Provide guard over exhaust fan on 2nd deck. LEGACY COMPONENT DESC: fan guard

Provide cover on distribution panel in MSD compartment.

Provide wire supports for electrical wire in cooler compartments.

Provide placard and operating instructions for vessel's MSD.

COMPLETE INSTALLATION OF BILGE ALARM SYSTEM AS REQUIRED BY 46 CFR 119.530.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

REPLACE POLYPROPYLENE GRAB LINES ON 3 LIFE RINGS.

REPLACE ROTTED WOODEN WICKETS ON TOPSIDE LIFE RAILS.

MULTIPLE DISCREPANCIES: LABEL EMERGENCY LIGHTING IN PASSENGER AREAS, REPLACE 2 MISSING LIGHT SWITCH COVERS, REPAIR 2 DAMAGED 110V OUTLET COVERS,REPLACE MISSING GUARD ON LIGHT, REPAIR DANGLING LIGHT FIXTURE IN 2ND DECK LADIES HEAD, BLANK OPEN CIRCUIT IN PANEL.

REPLACE FIREHOSE THAT BURST WHILE CONDUCTING HYDRO.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Properly repair diesel fuel leak on piping in void space adjacent to fuel tank.

Properly repair port rub rail to original.

Properly repair port outer ring on paddle wheel.

REPLACE MISSING FIRE AX, LOCATED AT AFT STATION

REPLACE MISSING LIGHT LIST ON BRIDGE.

REPAIR LEAKING PACKING ON VALVE STEM FOR THE EMERGENCY FUEL SHUTDOWN FOR THE GENERATORS.

REPLACE MISSING 110 VOLT OUTLET COVER, IN AFT LOUNGE.

REPLACE FIRE HOSE, THAT BURST WHILE CONDUCTING HYDRO.

REPLACE NON-SKID MATERIAL ON STAIRS LEADING TO ENGINERROM AND #5 COMPARTMENT.

PROVIDE PERMANENT WIRING FOR THE ICE MACHINE SUMP PUMP AND REMOVE EXTENSIONCORD.

PROPERLY SECURE ALL CO2 BOTTLES FOR BEVERAGE SYSTEM.

CLEAN PAINT FROM WTD KNIFE EDGES.

REPLACE PVC PIPING FOR ICE MACHINE SUMP PUMP DISCHARGE WITH METAL PIPING.

REMOVE WOOD BOX COVER FOR COMPRESSOR IN #4 COMPARTMENT.

REMOVE PLASTIC WIRE TIES AND PROPERLY SUPPORT/SECURE WIRES IN THE STORE ROOM, #4 & #6 COMPARTMENTS.

PROPERLY TERMINATE LIGHTING WIRES FOR OUTSIDE LIGHT LOCATED FORWARD ON 3RD DECK.

CLEAN ALL BILGE SUCTION SCREENS.

REMOVE LIQUOR STORAGE LOCKER OR PROVIDE FIXED CO2 SYSTEM FOR LOCKER.

SERVICE PORTABLE FIRE EXTINGUISHER IN ENGINEROOM.

REPLACE FLAME SCREEN FOR FUEL TANK VENT WITH SCREEN OF SUITABLE MATERIAL.

FREE UP BILGE VALVE FOR FOREPEAK AND PROVIDE ASSIST HANDLE FOR VALVE.

INSTALL PERMANENT ELECTRICAL OUTLETS FOR MAIN DECK BAR AREA AND REMOVE MULTI-OUTLET EXTENSION CORD.

OBTAIN CURRENT RIVER CHART FOR AREA OF OPERATION.

OBTAIN AND MAINTAIN IN PILOTHOUSE A COPY OF THE INLAND NAVIGATION RULES.

REPAIR STRAP ON PILOTHOUSE RING BUOY AND REPLACE LINE.

REPAIR ALL TEARS IN COVER FABRIC OF RING BUOYS.

ADAPT RESCUE BOAT DAVIT TO ALLOW FOR BOAT TO BE SECURED AT THE RAIL WHILE PASSENGERS ARE ON BOARD THE VESSEL.

PROVIDE PORTABLE RADIOS FOR USE BY CREW DURING EMERGENCY OPERATIONS AND SEADETAIL.

PROVIDE SUITABLE BOARDING LADDER FOR RESCUE BOAT PERSONNEL.

SECURE ALL CO2 BOTTLES FOR BEVERAGE DISPENSERS.

REPLACE BROKEN CAP ON MICRO-FOR CHLORINE DISPENSER.

REPLACE ALL BROKEN/FRACTURED THRUST BOARDS ON THE PADDLEWHEEL.

CONDUCT SATISFACTORY FIRE DRILL.

PROVIDE SUITABLE RESCUE BOAT.

PROPERLY MARK FIRE STATIONS, CHILD PFD STORAGE AND FUEL SHUTOFF VALVE.

REPLACE MISSING COVER TO ELECTRICAL JUNCTION BOX IN MSD COMPARTMENT.

REPLACE BULBS/GLOBES/GUARDS FOR EMERGENCY LIGHTING IN ENGINEROOM.

REPLACE BULBS/GLOBES/GUARDS ON LIGHT FIXTURES AS NEEDED THROUGHOUT VESSEL.

SATISFACTORILY TEST VESSEL'S WHISTLE.

CONDUCT SATISFACTORY DRILLS FOR FIRE, ABANDON SHIP AND MAN OVERBOARD.

REPLACE/REPAIR MASTHEAD LIGHT.

TEST MAIN PROPULSION UNDERWAY (SEA TRIALS) PRIOR TO THE CARRIAGE OF PASSENGERS DURING UNDERWAY OPERATION.

REPLACE/REPAIR ALL DOOR LATCHES TO ENSURE PROPER WATERTIGHT/WEATHERTIGHT OPERATION.

REPLACE ROTTED/BROKEN WOOD RAILING SECTIONS. (TOTAL REQUIRING REPLACEMENT UNKNOWN. ALL RAILS TO BE INSPECTED/REPLACED BY OPERATOR).

TEST STEERING UNDERWAY (SEA TRIALS) PRIOR TO THE CARRIAGE OF PASSENGERS UNDERWAY.

REPLACE 53 ADULT PFDs WHICH WERE DEFECTIVE/MISSING.

REPAIR LIGHTING FIXTURE MAIN DECK STARBOARD SIDE AFT. _x001C_ CLEARED 13MAY1992.

PROVIDE REEFER FAN COVER (GALLEY STOWAGE AREA BELOW MAIN DECK).

PROVIDE SUITABLE STOWAGE FOR CO2 BOTTLES (VOID BELOW MAIN DECK - GALLEY STOWAGE AREA.

PERMANENTLY WIRE JACKPOT CAFE SIGN (REQUIRED REMOVAL OF EXTENSION CORD WIRING).

PROVIDE PROPER BULB TO NAVIGATION LIGHTS (HOUSEHOLD FIXTURES/BULBS TO BE REMOVED). _x001C_ _x001C_ CLEARED 13 MAY 1992

PROVIDE MAT FORWARD OF SWITCHBOARD. _x001C_ CLEARED 13MAY1992
