STAR BREEZE

07105 - Fire doors in main vertical zone bulkheads and stairway enclosures, other than power-operated watertight doors and those which are normally locked, shall be of the self-closing type. Fire door 3.3.620A did not latch in the closed position and fire door 6.2.354 only partially closed. 74 SOLAS 81 Amend II-2/30.4 (10c)

Indicators shall be fitted on the navigation bridge for...propeller speed and pitch position in the case of controllable pitch propellers. Vessel port-side CPP is displaying 40 degrees as maximum pitch on bridge indicator. Dive survey conducted on 14JUN2022 indicates that CPP is fully functional, however indicator is reporting incorrect pitch position to bridge display. SOLAS 2004 CONS. II-1/ 49.6.2

The company and the ship shall comply with the requirements of the International Safety Management Code. In meeting these requirements, the company should ensure that any non-conformity is reported, with its possible cause and appropriate action is taken. 8” wide temporary fiberglass patch found on 4” diameter auxiliary salt water cooling system outlet, supplying cooling water to critical main propulsion reduction gear, fuel coolers and reefers. Patch placed on cooling line in August 2021. No required reports made to company or class society. Parts received on board in December 2021. Crew has still not taken action to make permanent repairs for 4 months. Further, Main engine lube oil purifiers found out of service for 6 months. Main engine lube oil purifiers found on continuous survey machinery list which requires vessel to notify Class if an issue is found. Ship acknowledged no notification to Class – confirmed by Class (BV) representative onboard. Not making proper reports mitigates the purpose of the SMS which provides safe practices in ship operation and a safe working environment. NOTE: All deficiencies are of a technical and operational nature which collectively provide objective evidence of a serious failure, or lack of effectiveness in implementation of the ISM Code. Sector San Diego requires as ISM audit to be conducted within the scope of maintenance and reporting of non-conformities.

The company and the ship shall comply with the requirements of the International Safety Management Code. Company should establish procedures, plans and instructions for key shipboard operations concerning the safety of the personnel, ship and protection of the environment. Vessel conducted non-routine 14 day cruise operation whereby garbage was generated beyond ship’s capacity to properly store it – garbage management plan does not address such a situation. Garbage found in steering gear room (a category 10 space where storage of combustible is prohibited) and above sprinkler heads in garbage room and adjacent garbage holding room – filled completely to the ceiling.

The purpose of this regulation is to contain a fire in the space of origin. The fire integrity of the divisions shall be maintained at openings and penetrations. Observed the following fire doors not sealing correctly or missing gasket sealing materials: Door 291, 286 and A214. Door 594 (emergency escape trunk from machinery space) self-closing device is not operational and will not remain shut due to also having a broken latch. SOLAS 74am (04 Cons Ed) II-2/9.1.3

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons onboard. 1) Pinhole leak found on fire main topping up pump supply pipe. 2) 2” diameter circle bulkhead penetration in purifier room. 3) Two pinhole leaks found on steam condenser piping with jubilee patches. 4) Excessive water and hydraulic fluid found under port and starboard steering gear. 5) General alarm light on alarm column in purifier flat non-operational.

0999 - The speed of door closure shall, if necessary, be controlled so as to prevent undue danger to persons. Approximately 80% of the fire doors tested closed at a rate that could cause injury to a person in the way of the door (less than 2 seconds). 74 SOLAS (81) II-2/30.4

0710 - It shall be possible for each door to be opened and closed from each side of the bulkhead by one person only. All fire doors are only able to be closed on one side of the door. 74 SOLAS (81) II-2/30.3

0710 Fire doors in main vertical zone bulkheads and stairway enclosures...shall be of the self-closing type and capable of closing against an inclination of 3.5 degrees opposing closure. Fire door 340 (double leaf door in main passenger stairway) does not close automatically when the local door release is activated. 74 SOLAS (81), II-2/30.4.

1499 The angular position of the rudder shall: if the main steering gear is power-operated, be indicated on the navigation bridge... and be recognizable in the steering gear compartment. Angle indicators on bridge and steering gear room differ by more than 5 degrees.

The vessels maneuvering fact sheet was incomplete in that the time and distance to stop at half speed, and the speeds at which the bow thruster iseffective were missing.

REPAIR AND PROVE PROPER OPERATION OF LOSS OF POWER ALARMS ON BRIDGE CONSOLEPANEL FOR STEERING MOTORS 1,2,3, AND 4 AS PER SOLAS CHAPTER 2-1, REG. 29, PART 5.2.
