SWEET LIBERTY

A visual indicator must be provided at the operating station to indicate when any automatic bilge pump is operating. Port and Starboard automatic bilge pump visual indicator at the operating station in non-operable. Make permanent repairs and prove proper operation to the attending CG Marine Inspector. 46CFR182.530(c)

The Preventative Maintenance Plan (PMP) should include an inventory of all rigging components, including the age of component, size, type of material, and a replacement schedule for all rig components based on inspection results, service history, and manufacturer or designer recommendations. 46CFR177.202

Sail rig aloft inspections are not completed as documented on the vessels Preventative Maintenance Plan PMP as follows: Close inspections aloft conducted by Captain or experienced Crew Member. Checking for missing cotter pins, parted strands on shrouds or stays, splits in swage tails and furling system and halyard attachments. Complete and document maintenance IAW PMP. 46CFR177.330

Except when in the judgment of the cognizant OCMI the operation of a vessel does not present one of the hazards listed, the emergency instruction placard should contain at least the applicable portions of the “Emergency Instructions” listed in § 185.512. The emergency instructions must be designed to address the particular equipment, arrangement, and operation of each individual vessel. The vessel's emergency instructions do not address sail rig equipment and steps that must be taken during an emergency and/or hazardous situation while conducting sailing operations. 46CFR185.510

An inspection for renewal of a Certificate of Inspection is conducted to determine if the vessel is in satisfactory condition, fit for the service intended, and complies with all applicable regulations. It normally includes inspection and testing of the structure, machinery, equipment, and on a sailing vessel, rigging and sails. The owner or operator must conduct all tests as required by the OCMI, and make the vessel available for all specific inspections and drills required by subpart H of this part. In addition, the OCMI may require the vessel to get underway. (b) You must submit your written application for renewal of a Certificate of Inspection to the OCMI at least 30 days prior to the expiration date of the Certificate of Inspection, as required in § 176.105 of this part. COI expired on 18OCT2022. Owner was instructed on 21OCT2022 to not carry passengers until a satisfactory inspection was completed. Owner has been operating with passengers as of this date. COI renewal inspection is now scheduled for 09NOV2022. 46 CFR 176.404

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI, except during an emergency. The owner or managing operator shall submit details of any proposed alterations to the cognizant [name withheld] are not required to be submitted for repairs or replacements in kind. The OCMI may require an inspection and testing whenever a repair or alteration is undertaken. The SWEET LIBERTY is outfitted with a three point rigging system. The shrouds are split with a rig tensioner to facilitate removing the flopping or slap in the leeward shroud when tacking. The marine inspector identified a stress point and tension on the port and starboard shroud clevis pins at the attachment to the chain plate. The owner removed the clevis pin for visual inspection and fractures were identified on the end of the clevis pin in the vicinity of the cotter pin attachment. Additional grooving and pitting was observed on the body of the clevis pin. Replace clevis pins and contact USCG for re-inspection once replaced. 46 CFR 176.700

In accordance with 46 CFR 185.602, the subject vessel is required to have draft marks or loading marks. This was indicated on the June 25, 2014 MSC revised stability letter H1-1402245. Per the approved stability letter: A minimum freeboard of at least 4 feet 2 inches to the main deck at amidships must be maintained. This corresponds to a maximum midship draft of 2 feet 3 inches, measured to the bottom of the keel, and 10 inches measured to the design waterline. Amidships is located 26 feet 6 inches aft of the bow. Provide loading marks in accordance with the dimensions listed on the stability letter. 46 CFR 185.602

The cognizant OCMI may require that a vessel and its equipment undergo any additional test or inspection deemed reasonable and necessary to determine that the vessel and its equipment are suitable for the service in which they are to be employed. Vessel does not have a Preventative Maintenance Plan (PMP)and could not provide documentation of a recent rigging inspection. No routine or prescriptive maintenance regarding sail rigging could be provided. Coast Guard inspectors have provided guidance and templates of PMPs to owner over the past year for implementation. Prior to carrying passengers, have a 3rd party rigging inspection to include aloft inspection and submit a draft PMP to Coast Guard DDO Fort Myers for review

Deck rails must be designed to withstand 200 pounds applied at any point. Port quarter hand rail is loose as evident by 02 missing deck bolts. Repair to satisfaction of a Marine Inspector.

A vessel must carry one floating waterlight, waterlight for ring life buoy is inoperable. Restricted to daylight operations only until rectified.

The marine employer must have a sufficient number of alcohol test devices. No alcohol testing kits are onboard.

All cable and wires must be installed with metal supports, spaced not more than 24 inches apart. Electrical wire for running light on starboard void is laying along bilge, properly secure.

A suitable metal marine type strainer, must be fitted in the fuel supply line. Fuel filter installed has plastic drip tray.

A vessel must carry adequate and up to date, Coast Pilot [name withheld] List and Tide Tables. Provide updated listed publications for navigation area.

Hydrostatic release unit for the EPIRB expired October 2020. Replace with new unit.

Provide proof of obtaining Marine Operator [name withheld] for capatain's onboard and obtain new Safety Certificate from FCC

Provide Proof of vessel logs being recorded and maintained for drills and EPIRB.

Provide Coast Pilot and update charts

Provide posted Emergency Instructions for fire, rough weather and man overboard.

Hull impact to port catamaran from allision to dock corner.

A-frame is cracked and requires replacement.

Renew fiberglass on both hulls where reinforced for beaching (46CFR176.600)

Rewnew end cap for motor mount pin (46CFR176.600)

Replace two beams IWO bow area where netting is tied. (46CFR176.600)

Hydrostatic release is expired.

Start and maintain logs, lifesaving, EPIRB.

Provide current EAP and copy of MIS report.

Provide current tide tables.

Provide new first aid kit.

Place flares in proper, bright, watertight container.

Provide copy of latest rigging report, to include last mast unstepping.

Provide evidence of preventative maintenance plan to include, detailed description of the rig and associated gear; drawings/pictures of rig/key components; manufacturer, purchase and installation dates of all components; types of furlers/tensioning systems; description of sea trials.

Provide 50 additional asprin and ammonia inhalents for first aid kit. IAW 46 CFR 160.041

Provide current chart on board IAW 46 CFR 184.420.

Replace both port and stbd deck mounted rigging boards for lifting the dagger boards.

Make permanent repairs to spots identified on port hull.

Make repairs to exposed hull areas where rudder cross bar passes through. Prior to credit dry-dock

Service entire steering system. Most connection points are worn and loose, Prior to credit dry-dock.

Repair or replace top steering system cable pully bushing, Prior to credit dry-dock.

Replace stbd aft deck mounted rigging block, Prior to credit dry-dock.

Re-build back up bow areas used for beaching operations, IAW CID Note #04, Prior to credit dry-dock.

Tighten all entrance ladder attachment to hull screws, Prior to credit dry-dock.

Replace aft portlight, portside window seal and test for water-tightness, Prior to credit dry-dock.

Make repairs to mast identified during inspection, and provide rigging report to the CG, Prior to credit dry-dock.

Romove both dagger boards to make areas available for inspection, Prior to credit dry-dock.

Label escape hatches as required by 46 CFR 185.606.

Provide 01 type B-I portable fire extinguisher at the operating station, IAW 46 CFR 181.500.

Vessel was struck by lightning while u/w w/ passengers. Vessel's bonding system is not 100% intact. Vessel must haul out and conduct hull inspection including rigging inspection and report and unstep the mast for inspeciton. 46 CFR 176.610

Provide a copy of MIS report for drug testing IAW 46CFR16.

Provide means of alcohol testing after a serious marine incident IAW 46CFR16.

Install a 60 foot, bouyant, 5/16 diameter lifeline to ring buoy IAW 46CFR180.70(c).

Install retroflective tape on ring lifebouy IAW 46CFR185.604(i)

Provide an approved first aid kit IAW 46CFR184.710

Provide a means to dewater each watertight compartment IAW 46CFR182.25-5(a)

Repair bilge high alarm

Repair PA system

Replace items in first aid kit.

Install smoke detection system sensors

Re-install fuel shutoff valves.

Replace expired flares.

Provide drug testing documentation copy of latest MIS report .

Provide registration for EPIRA along with servicing report for hydro test .

Conduct underway emergency drill and test the vessel's propulsion and sails.

Replace expired items in first aid kit.

Service two fire extinguishers.

Mark high level bilge alarm indicator and breaker.

Replace portside fresh water fuel line.

Install missing light cover port side lower deck.

Replace damaged O ring forward starboard side lower deck.

Remove paint from the vessel.

Provide evidence of an Employee assistance program and the latest MIS report.

Refresh all expired items in the first aid kit.

PROVIDE A DETAILED REPAIR PROPOSAL PRIOR TO INSTALLING NEW WOOD AND FRP TO HULLS WHERE SEVERELY DAMAGED BY HURRICANE WILMA; INCLUDE BUILDER RECCOMENDATIONS, MATERIALS TO BE USED, FRP LAY-UP SCHEDULE ETC.

PROVIDE A STANDARD REPAIR PROCEDURE FOR THE MINOR HULL DAMAGE THAT DIDN'T PENETRATE THE WOOD BOTTOM.

Provide rigging report to MSD Fort Myers.

PROVIDE A COPY OF CURRENT DRUG TESTING CONSORTIUM CONTRACT.

PROVIDE AN ADDITIONAL 6 HAND HELD FLARES ONBOARD VESSEL.

APPLY RETRO TAPE TO RING BOUY.

RENEW EYEWASH AND AMMONIA INHALENTS IN FIRST AID KIT.

PROVIDE A FUEL TANK SHUT-OFF VALVE.

Properly repair small gouges in bottom gelcoat just forward of the centerboard in way of port and starboard hulls. LEGACY COMPONENT DESC: Keel

Provide copy of Drug and Alcohol testing program contract and MIS report. LEGACY COMPONENT DESC: MIS Submission

Provide a copy of the rigging inspection report.

Provide a non-alkaline battery w/screw top post terminals for ring bouy light. LEGACY COMPONENT DESC: Self-igniting Lights

Repair stbd bilge alarm. LEGACY COMPONENT DESC: Bilge Alarm

Conduct underway man overboard and fire drills with a Coast Guard Marine Inspector. LEGACY COMPONENT DESC: Fire

REPAIR FRACTURED LONGITUDINAL DECK STRINGER FORWARD OF CABIN AT PORT HATCH FRAME.

PROPERLY SPLICE WIRING IN PORT HULL USING BUTT TYPE CONNECTORS. LEGACY COMPONENT DESC: Wiring

SECURE PORT TILLER CONNECTION WITH COTTER PIN, LOCKNUT, OR DOUBLE NUT. LEGACY COMPONENT DESC: Pin

PROVIDE 15 ADDITIONAL ADULT TYPE I PFD'S. VESSEL IS RESTRICTED TO CARRYING 37 TOTAL PERSONS UNTIL CORRECTED. LEGACY COMPONENT DESC: Quantity

RE-ATTACH FAN TO FORWARD PORT BERTH OR REMOVE FAN AND ALL ASSOCIATED WIRING.

PROVIDE A FUEL TANK SHUT-OFF VALVE IAW 46CFR182.455 LEGACY COMPONENT DESC: Valve

PROVIDE TWO TYPE I ADULT PFD'S. VESSEL IS RESTRICTED TO CARRYING 50 ADULTS UNTIL THIS REQUIREMENT IS MET.

PROVIDE VISUAL INDICATION AT OPERATING STATION OF BILGE PUMP OPERATION IN BOTH HULLS.

LABEL INSIDE OF EMERGENCY ESCAPE HATCH IAW 46 CFR 185.606

PROVIDE SIX TYPE I CHILD PFD'S. VESSEL RESTRICTED TO CARRYING ONLY ADULTS UNTIL THIS REQUIREMENT IS MET.

PROVIDE CREW TRAINING AND LOG.

REPAIR LIFEFLOATS AT SERVICE FACILITY OR REPLACE. _x001C_

PROVIDE PROOF OF EAP AND TRAINING IN DRUG TESTING PROGRAM.

RESTOW RING BUOY TO ALLOW FLOAT FREE AND MARK NAME ON BOTH SIDES.

PROVIDE AN APPROVED FIRST AID KIT IN ACCORDANCE WITH 46CFR160.041-4.

PROVIDE COPY OF NAVIGATION RULES OF THE ROAD.

REPLACE HYDRO RELEASE ON EPIRB.

INSTALL DETACHABLE CLIP ON RING BUOY LIGHT.

PROVIDE AND POST COPY OF STABILITY LETTER AND SAIL ARRANGEMENT.

PROVIDE WRITTEN PROCEDURE FOR MOB RESCUE, UTILIZE HANDHELD RADIOS TO MAINTAIN CONTACT WITH DECKHAND.

RENEW RETRO TAPE ON NUMEROUS ADULT AND CHILD PFD'S. _x001C_ _x001C_ _x001C_ _x001C_

INSTALL 3-6' OF LINE ON RING BUOY WATERLIGHT W/HALYARD CLIP ON END OF LINE THAT ATTACHES TO RING BUOY._x001C_ _x001C_ _x001C_

SERVICE ALL FIRE EXTINGUISHERS._x001C_ _x001C_ _x001C_ _x001C_

INSTALL MEANS OF CORDONING OFF AREA FORWARD OF THE DECK HOUSE WITH ROPE, CHAIN OR RAILING ARRANGEMENT THAT CAN BE REMOVED TO ALLOW A DECKHAND TO GO FORWARD WHEN NECESSARY.

Lable 2 aft hatches "Emergency Escape - Keep Clear".

Provide proof of drug testing - consortive membership.

Provide 3 additional red flares.

Renew ring buoy or repair beckett line.

PROVIDE FCC CERT. VESSEL LIMITED TO NOT MORE THAN 1000 FT FROM SHORE UNTIL COMPLETED.

PROVIDE WATERTIGHT CONTAINER FOR SIGNALLING DEVICES.

CONDUCT DYE TEST OF FWD STAY SUPPORT IN PRESENCE OF A USCG INSPECTOR

PROVIDE EMERGENCY CHECK-OFF LIST.

PROVIDE ONE ADDITIONAL CHILD PFD. NO MORE THAN 5 CHILD PASSENGERS ALLOWED UNTIL COMPLETED.

PROVIDE A MEANS TO PUMP SEWAGE TANKS ASHORE TO A RECEPTION FACILITY.

PROVIDE A MEANS TO SECURE SEWAGE OVERBOARD VALVES IN THE CLOSED POSITION AND POST SIGNS STATING VALVES MUST REMAIN IN THE CLOSED POSITION WHILE OPERATING WITHIN TERRITORIAL WATERS.

CLOSE IN SPACE BETWEEN RAILING COURSES WITH CHAIN LINK FENCING. WIRE MESH OR THE EQUIVALENT.

PROVIDE FCC CERTIFICATE.
