USNS LOYAL

All electrical apparatus shall be so constructed and so installed as not to cause injury when handled or touched in the normal manner. Vessel's switchboards in port and starboard pump rooms had (03) missing insulation caps for controller knife switches. Install protective measures to ensure no personnel risk remains.

Filling pipes may be led directly from the deck into the tanks or to a manifold in an accessible location permanently marked to indicate the tanks to which they are connected. A shutoff valve must be fitted at each filling end. Port side lube oil bunkering station on main deck had ball valve handle wasted. Install handle to port standard discharge connections.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended. Vessel's has 377 gauges with expired calibrations (6-Feb-2026).Vessel has 6 gauges 'rejected' or with 'no gauge'. Calibrate and/or install all identified gauges in accordance with DD/ROH scope of work and provide satisfactory evidence of calibration results to the attending MI.

When cylinders of Class 2 (compressed gas) materials being transported by vessel are stowed in a vertical position they must be stowed in a block and cribbed or boxed-in with suitable sound lumber and the box or crib dunnaged to provide clearance from a steel deck at least 10 cm (3.9 inches) off any metal deck. Pressure receptacles in the box or crib must be braced to prevent any shifting of the pressure receptacles. The box or crib (gas rack) must be securely chocked and lashed to prevent shifting in any direction. Vessel had 8 compressed gas R-134 refrigerant DOT cylinders stowed in the AMR space where 4 where outside of brackets and braced via a ratchet strap. Install gas rack to accommodate all 8 cylinders permanent stowage during next DD/ROH.

Before the ship leaves port and at all times during the voyage, all life-saving appliances shall be in working order and ready for immediate use. Master has reported that FRB a faulty house battery has rendered the FRB inoperable, that there is a corroded gear selector switch, and an inaccurate battery volt meter. Make repairs to satisfaction of ABS prior to departure. 74 SOLAS (20 Cons.) III/20.2

Persons designated by the owner of the vessel must conduct all tests and the Design Verification and Periodic Safety tests (PSTPs) must be witnessed by the Coast Guard. After approval by USCG (Marine Safety Center), demonstrate PSTPs for attending Marine Inspector. Due by 04JUN2025. 46 CFR 61.40-1(b)

Before the vessel leaves port and at all times during the voyage, each lifesaving appliance must in working order and ready for immediate use. The vessel reported a frayed wire rope on the port and starboard life raft davit launching arrangements. The deficiency is to be rectified before departure from the vessels next port. Provide evidence of proper op testing associated with the new wire rope and davit are to take place.

Vital systems are those systems that are vital t a vessels survivability and safety. For the purpose of this sub chapter the following are vital systems: (iv)bilge systems. Attending inspectors attempted to test the bilge suction from the starboard bow thruster void with the ships force, this test was unsuccessful. 46CFR46.07-5(f) and 46CFR56.50-50 Prior to underway operations proper bilge operation must be demonstrated in all 4 Machinery space bilges in both the port and starboard hulls (8 total) in the presence of a Coast Guard inspector or RO. THIS ITEM IS CLEARED, MISLE WILL NOT DISPLAY THE VIEW TO CLICK ON RESLOVED DATE BELOW.

Before the vessel leaves port and at all times during the voyage, each lifesaving appliance must in working order and ready for immediate use. The vessel reported a parted wire rope on the port side lifeboat davit. The deficiency is to be rectified before departure from Yokohama, JP. Provide evidence of proper op testing associated with the new wire rope and davit are to take place. 46 CFR 199.190(a)

All life-saving appliances shall be in working order and ready for immediate use. Ship reported that Fast Rescue Boat davit winch shaft seal has failed making davit inoperable. 74 SOLAS (1997) CH III Reg. 19.2

The alarm system shall be continuously powered... in case of loss of normal power supply. Ship reported failure of an internal cooling fan on the UPS supplying power to the main generator PCU and Bailey alarm system. 74 SOLAS (1997) CH III Reg. 31.3 Reg. 51.2.1

Remote control for the means of stopping fuel oil transfer pumps shall be tested at each regular inspection. MIs noted water ingress and corrosion within port and starboard side housing units for remote F/O transfer pump controls. Satisfactory maintenance to restore condition of controls and weather-tight enclosures. Cite - 46 CFR 61.20-3

Installed fire equipment and its installation shall meet the requirements of this part. Aux Machinery room A-60 fire door temporally repaired with Belzona. Belnoza does not meet fire rating for class A boundary and is not approved for permanent repair. 46CFR 95.01-5,

Where “A” class division are penetrated, such penetrations shall be tested in accordance with fire test procedures code. 02 MCTs in Aux Machinery room installed with mixed methods (rocks blocks & firestop) and not up to code. 74 SOLAS (2001) II-2 Reg 9.3.

Ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Oil leak IWO #4 SSDG turbo lubrication bearing drain line. 74 SOLAS(2020) I/II (a)

Ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. EDG exhaust leak IWO of pressure joint, leaking exhaust into the space. Foolow risk mitigation and repair to OEM. 74 SOLAS(2020) I/II (a)

The SMS should be effectively implemented and include specific measures aimed at promoting the reliability of equipment and systems. During in-service inspection, the following objective evidence indicates that the start air system may be improperly configured and/or not effectively maintained: - System operating at 195 psi rather than design pressure of 250 psi - 4000 hour overall overdue - Missing spare parts that were ordered in Oct2019 but not received - Five inhibited alarms You are directed to complete an internal SMS audit within the next 30 days to include a root cause analysis and implement corrective actions to prevent recurrence. The effectiveness of any corrective actions will be assessed at the next regulatory scheduled external audit.

Condition of the ship shall be maintained fit to proceed to sea without danger to the ship or persons on board. Vessel’s air compressors are 2 years overdue for maintenance overhaul. Parts ordered by vessel in October 2019, company never processed order. Vessel marked overhaul completed June 2020 in SAMMs system with note deferring until drydock. Per company procedure maintenance can only be deferred up to one year. Additionally, Hours meters were installed February 2020 not in accordance with OEM and non/standardized. Service/repair to OEM specification. SOLAS 74a (2020)I-11a 705ac (15SEP2021)

After any survey of the ship under regulations 7, 8, 9 or 10 has been completed, no change shall be made in the structural arrangements, machinery, equipment and other items covered by the survey, without the sanction of the Administration. Start air compressors and tanks are desi gned to operate at system MAWP 250 PSI. Provide system analysis of any limiting/safety factor for compressor set pressure of 200 PSI limiting total capacity of ship start/service air. SOLAS 74a (2020)I-11b 705ac (15SEP2021)

Vital systems that are automatically or remotely controlled must be provided with an alarm system if instrumentation is not continuously monitored or is inappropriate for detection of a failure or unsafe condition. 05 alarms are inhibited. Provide casual analysis and justification for continued operation with alarms inhibited. 46 CFR 62.2501 705ac

#3 SSDG High Jacket water temperature sensor failed during inspection. Conduct hourly engine room rounds when in use, repair/replace to OEM specifications. 46 CFR 58.01-5 ABS Rules 4-9-4 705a

The fire integrity of division bulkheads shall be maintained. A60 door 2-90-1 is holed and integrity compromised, repair/replace to OEM specifications. SOLAS 74 a (81) II-2/Reg. 9.1 705c

Electric equipment must be arrange as far as practicable, to prevent mechanical damage to the equipment from the accumulation of dust, oil vapors, steam, or dripping liquids. Condensate dripping excessively on AUX Machinery Room NO.3 450V EMCC, install drip shield. 46 CFR 111.01-3 705 c (15SEP2021)

All electrical equipment must be designed and installed to operate for the particular location and environment in which it is to be used, and operated under any combination of 15 degrees static list, 22.5 dynamic roll, and 7.5 degrees static trim. Properly block and brace EDG start batteries. 46 CFR 111.01-19 16 c

02 Cracks have been discovered IWO frame 90 pump room access trunk. Temporary repairs completed. Make permanent repairs IAW ABS steel repair procedures. **If cracks promulgate or additional cracks are discovered, notify our office ASAP. *** 46 CFR91.45-1, 50a

Ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Fuel leak IWO of EDG outboard fuel injectors weeping, presenting excessive fire risk. SOLAS 74a (2020) I/11

Maintenance, testing an inspections shall be carried out in a manner have due regard to ensuring reliability of fire-fighting appliances, Engine room Halon system has a kinked hose preventing proper operation and effectiveness of system. SOLAS 74a (2020) II-2/14.2.2.1

Each receptacle outlet must be compatible with the voltage and current of the circuit in which it is installed. Remove daisy chain power strip in ECR. 46 CFR 111.79-1©

The general construction of the vessel shall be such to minimize fire hazards. Are behind ECR switchboards are not clear and being used for storage. 46 CFR92.05-1

Marine shipboard cable must meet all the requirements for construction and ID of either IEEE 1580, UL1309, IEC 60092-553. Non marine grade power cable ran through fire boundary to EDG jacket water murphy switch. 46 CFR 111.60-1

Installed fire equipment and its installation shall meet the requirements of this par. Disconnected pilot valve IWO #3 SSDG HALON engine cutoff. 46 CFR 95.01-5

Installed fire equipment and its installation shall meet the requirements of this part. Motor gen & Aux machinery room fire doors are holed from previous hardware installations. 46 CFR 95.01-5

Periodic safety test procedure documents approved by the Coast Guard must be retained aboard the vessel. Submit PSTPs to MSC for final Coast Guard approval. 46 CFR 61.40

All electrical engineering installations shall be designed and installed in accordance with subchapter J of this chapter. Excessive use of extension cords and temporary modifications that are not satisfactory installation. Remove or make approved permanent installations. 46 CFR 90.25-1

Ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Oil leak IWO #3 SSDG turbo lubrication bearing, presenting excessive fire risk. SOLAS 74a (2020) I/11

Each class 1 door must have a quick action closing device operative from both sides of door. Pump room escape door is seized in the open position. 46 CFR 170.270(a)

13199-Non-metallic flexible hoses must be IAW SAE-J1942. ENG. MDG’s has section of unmarked flexible hose from filter to pump. Provide evidence hose meets standard or replace with SAE J1942 fuel line. 46 CFR 56.60-25 50 a

09108-Provide adequate overhead lighting in the galley, engine control room and the engineering deep spaces. SOLAS 74 a (2014) I/11 50a

14503-Provide a garbage management plan from company that is vessel specific to collecting, storing, and processing garbage. MARPOL V Reg. 9.2 50a

07115-Fire protection systems and firefighting systems and appliances shall be maintained ready for use. Engine room STBD exhaust ventilation damper is inoperable. SOLAS 74 a (1997)II-2/14 10c

07124-maintenance, testing and inspection shall be carried out based on the guidance developed by the organization and in a manner having due regard to ensuring the reliability of fire-fighting systems and appliances. Engine room Halon system has a crushed hose preventing proper operation and effectiveness of system. Replace hose. SOLAS 74 a (2014) II-2/14.2.2.1 10c

01315-incorrect code entries were used for bilge water discharge to reception facilities inside oil record book. MARPOL Annex I/17 10c

08101-Each general alarm signal must be capable of producing signal or tone distinct from another audible signal on the vessel. General alarm was INOP for the STBD canard space; public address was INOP in Steering gear rooms, propulsion motor rooms, pump rooms and canard rooms. 46 CFR 113.25-12 (a)(c) 10c

13199- Cables and wiring shall be supported in a manner as to avoid chafing or other damage. Emergency stop cable for NO. 2 MDG was found chafed. SOLAS 74 a (1997) II-I/45.5.5

13199- Metal support should be designed to support cables every 610 mm vertically. Missing metal supports for cables sagging and unsupported IWO engine room upper level. 46 CFR 111.01-1 (a)(3), IEEE 2002 reg 25.5 10c

07105- Fire resistance of doors shall be that of the division in which fitted. Interior galley self-closing A-60 door was not properly adjusted and did not secure upon activation. SOLAS 74 a (1997) II-2/30.2 10c

Make permanent repairs to #4 Main Engine cooling outlet piping.

Vessel will begin a 1,000 hour trial period for PUMS, to establish a history, where upon completion, will report back to the OCMI requirements to obtain PUMS full time on the COI.

Inadequate overhead lighting in both pump rooms.

Port oily water separator breaker is not attached to the panel board switch.

Ensure all penetrations and stuffing tubes are secure for all motor controllers, fire boundaries and watertight bulkheads.

Ensure fire damper in port engine room supply closes properly.

Conduct an operational test of the 15 ppm alarm for the port and stbd OWS.

Replace forward general alarm loudspeaker on weather deck.

Replace in kind the following vital system sea valves found to have failed during operational tests: two 8" cooling water valves, two 4" firemain suction valves, two 3.5" ballast/de-watering valves.

Submit a repair plan, voyage plan and risk assessment to the satisfaction of OCMI prior to movement.

Submit a repair plan, voyage plan, and risk assessment to the satisfaction of the OCMI.

Cracks were discovered at the structural attachment for the starboard steering ram attachment point. Make permanent repairs IAW ABS Steel repair procedures to the satisfaction of the attending USCG Marine Inspector.

Provide service report of all main and emergency switchboard circuit breakers. Have a third party technician attest to proper operation of circuit breakers.

Repair or replace USP's in main control room and bridge that are in disrepair. Prove proper operation of UPS's once repaired.

Replace two large cable splices in overhead near FM 74 repairs.

Identify the source of fuel leaking into WBT 6-108-1 and make permanent repairs.

Properly repair 19" crack in the deck of the vessel's fast rescue boat. Repairs must be to the satisfaction of USCG and prior to departure.

Properly repair/replace damaged inflatable sponson for the fast rescue boat IAW the manufactures repair recommendations.

Repair emergency diesel generator contactor and demonstrate satisfactory operational test.

Inner seal on the port propulsion shaft leaking sxcessively. Identify cause and repair to the satisfaction of attending marine inspector.

Frame 74 has a 1" crack on the top deck. Make permanent repairs to the satisfaction of [name withheld] may attend to witness fit up and NDT on behalf of USCG.

Port Stack steel is wasted and holed on the inboard, aft corner. Make permanent repairs to the satisfaction of OCMI.

Make permanent repairs to MSD piping with 2 soft patches. Repairs and operational testing to be completed to the satisfaction of OCMI.

Make permanent repairs to Port SW bow thruster piping. Repairs and operational testing to be completed to the satisfaction of OCMI.

Fan for Gyro back up batteries is inoperable. Repair or replace fan.

Diazepam medication is expired since Feb 2017. Provide valid, non expired medication

Complete LSA mod towing test of port and stbd davit hooks. USCG or ABS must be in attendance.

Multiple leaks have been found in teh SW cooling line. Pressure test line and conduct 100% visual inspection to identify all leaks. Notify FEACT of results.

Make permanent repairs to all wasted piping identified in the SW cooling line pressure test. Repaqirs and testing to be completed to the satisfaction of OCMI.

Reevaluate existing structural mofications for Frame 74 and perform a structural stress analysis by a certified naval architect or structural engineer that identifies structural issues found. Correct to the satisfaction of OCMI.

The Fast Rescue Boat Davit remote control station was found inoperable. Make permanent repairs to the satisfaction of the attending USCG Marine Inspector.

Make permenant repairs to leak in starboard evaporator SW inlet. Repairs and operational testing to be completed to the satisfaction of OCMI.

Make permenant repairs to leak in stbd thruster cooling water line. Repairs and operational testing to be completed to the satisfaction of OCMI

Ensure satisfactorily testing of installation on rescue boat and life raft davit by OEM. OEM technician was unable to attend previously due to schedule conflict.

Cracks were discovered at the structural attachment for the uppermost port steering ram attachment point. Make permanent repairs IAW ABS steel repair procedures to the satisfaction of the attending USCG Marine Inspector.

Cracks were discovered at the structural attachment for the starboard steering ram attachment point. Make permanent repairs IAW ABS steel repair procedures to the satisfaction of the attending USCG Marine Inspector.

Following a report from the Master to USCG FEACT about inoperable Emergency Generator found during regular scheduled maintenance, verified the Emergency Generator does not start automatically and does not take electrical load in the event of an emergency. Vessel must have an emergency source of power with a capacity to supply all required loads.

Gyro-repeaters located in the port and starboard steering spaces are inoperative. Each vessel must have an illuminated repeater at the main steering stand.

Installed bilge-pumping arrangements in both port and starboard pump rooms are not approved or annotated on the vessel’s approved bilge piping diagram. Update and seek approval for the update that includes installed pump and hose arrangements currently in use.

Engineroom emergency fire dampers for stbd side exhaust fan failed to actuate. Means shall be provided to secure dampers in the event fixed firefighting systems are energized.

Following a scheduled USCG inspection & proper repair procedures, the crack identified at Frame 56 stbd side-shell in fuel tank 6-40-2 started leaking seawater. Most probable cause was the redistribution of stresses on bulkhead 40 & surrounding area after scheduled insert on bulkhead 56 was cut out & removed. Previous CG-835 issued on 13APR2017 allowing temporary repair to this area is vacated.

Submit repair proposal to ABS and MSC for the permanent repair strategy for the cracked weld in fuel tank 6-40-2.

ABS and vessel crew discovered a cracked weld at Frame 56 port side-shell, which does not appear to penetrate thru the heart of the weld. Make temporary repairs to the satisfaction of [name withheld] may correct on behalf of the OCMI.

Vessel crew discovered the dual-seal on the stbd propulsion shaft had failed. Replace seal at next scheduled credit dry-dock. Notify Activities Far East, Japan of scheduled repair and request USCG attendance to witness repairs.

Vessel crew discovered the dual-seal on the stbd propulsion shaft had failed. Internal seal does not appear to be damaged. Provide engineering standing orders to be followed in the interim to Activities Far East, Japan. Notify Activities Far East, Japan with any changes to the status of the seal.

Temporary repairs at Frame 56 port side-shell and 166 port and stbd are required to be permanent. Make permanent repairs to the satisfaction of the cognizant [name withheld] all permanent repairs have approved repair proposals.

Multiple areas of fractures in way of fuel tanks, bulkheads and structural members have been identified on USNS LOYAL. The vessel is directed to complete permanent repairs to the satisfaction of the cognizant OCMI. Prior to departure from MRA period and not later than 21 March, 2017.

Provide permanent repair proposal to USCG Marine Safety Center (MSC) and Officer in Charge of Marine Inspections (OCMI) for FM 90 STBD where two inserts were welded together through the square MCT's creating several hard spots.

Provide permanent repair proposal to USCG Marine Safety Center (MSC) and Officer in Charge of Marine Inspections (OCMI) for FM 90 PORT where two inserts were welded together through the circular MCT's as a temporary repair.

Provide temporary repair proposal to Officer in Charge of Marine Inspections (OCMI) for FM 74 PORT where small crack appears on corner of oval MCT IWO small insert. NDT and drill stop prior to repairs.

Provide permanent repair proposal to USCG Marine Safety Center (MSC) and Officer in Charge of Marine Inspections (OCMI) for FM 74 PORT where small crack appears on corner of oval MCT IWO small insert.

Provide temporary repair proposal to Officer in Charge of Marine Inspections (OCMI) for FM 166 STBD where NDT showed a crack in the weld on the motor room side. Drill stop and gouge weld prior to repairs.

Provide permanent repair proposal to USCG Marine Safety Center (MSC) and Officer in Charge of Marine Inspections (OCMI) for FM 166 STBD where temporary repair is made near MCT.

Provide permanent repair proposal to USCG Marine Safety Center (MSC) and Officer in Charge of Marine Inspections (OCMI) for FM 166 PORT where temporary repair is made near MCT.

Replace frayed E-Shutdown cable for #4 MDG.

Crop and renew cracks located on top corners of door frame near sewage machinery room 4-96-2.

Until such a date that MSC issues final approval of PSTP document, PUMS is not authorized. A three watch system shall be implemented while the vessel is at sea and a generator watch shall be set in port if on generator.

Crop and renew machinery space deck IWO port evaporator.

Properly repair leaking pneumatic actuators for 2-166-1, 2-146-2, 2-90-3 (2).

Replace damaged fire station placard in port motor room.

Repair leaking butterfly valve for port fire pump located in port pump room.

Repair leaking wye-gate valve for fire station No. 4 located in port motor room.

Re-locate general alarm placard in port motor room.

Provide proper shutdown of vent damper located near 1-91-2, ladder well from A/C flat.

Provide 03 new spare batteries for portable VHF radios on the bridge.

Replace all damaged latches for fire stations throughtout weather deck area.

Class will amend IOPP SOVC after relocating 02 tanks from sludge retention to oily bilge retention section. Also, to issue a Form A and not a Form B.

Properly demonstrate all MDG shutdowns when activating Halon pressure switch.

Machinery space fire dampers do not close or operate properly. Demonstrate proper operation prior to departure.

1. P.A. system transmission is broken and intermittently inoperable. Repair P.A. system to full functionality to ensure shipboard announcements can be heard clearly throughout vessel.

Port and Stbd life-boat searchlights are inoperable. Stbd life-boat canopy light is inoperable. Repair/Replace searchlights and Stbd canopy light.

3. Installed Jotron EPIRB Hydrostatic release is not marked with Coast Guard or SOLAS approvals. Replace hydrostatic release with approved Hammar H2OE hydrostatic release or an approved equivalent that is both CG and SOLAS approved.

Main Port/Stbd Rudder angle indicators and bridge wing repeaters are off by 5-6 degrees. Repair rudder angle indicators to reflect correct rudder angle.

5. Port Side Aft life-boat embarkation light is inoperable. Repair/replace Port Side Aft life-boat embarkation light to ensure proper operation.

6. Stbd Side Aft Work/L.B. Embarkation light is inoperable. Repair/replace Stbd Side Aft Work/LB embarkation light to ensure proper operation.

7. Galley Range Guard Fixed Fire extinguishing system appears to be leaking and gauge is indicating it needs to be re-charged. Have servicing technician inspect and recharge fire extinguishing agent bottle.

8. Fire Hose Station Enclosure latches for stations #24 and #30 are broken and Enclosures are secured with line. Repair/replace enclosure latches so that enclosures can be secured as designed

9. 19 Life-jackets were found deteriorated and holed to the point that they are no longer serviceable. Ensure adequate serviceable life-jackets are available for all persons onboard in accordance with your Certificate of Inspection.

Several inspection and multiple engineering analyses have identified high stress areas susceptible to structural failure throughout the T-AGOS Class. Crowley and Military Sealift Command shall consolidate engineering studies and develop systematic approach to permanently repair areas of structural concern. All repair plans shall be submitted for approval to the satisfaction of the OCMI.

2. Develop a structural monitoring plan for all identified areas of high stress/concern. All high stress areas shall be made available for inspection at each CG annual and Class Survey.

3. Temporary repairs shall be made to the satisfaction of ABS and [name withheld] analysis and permanent repairs shall be completed by the next for-credit dry.

PSTP's was conducted on the new generator control upgrade system. Found multiple area within the prodecure that requires modification. PSTP's are required to be resubmitted to MSC for approval. Until such date that MSC issues final approval and the OCMI witnesses proper operation of the PSTP's PUMS is not authorized. A three watch system shall be implemented.

Crop and renew wasted plate on the lube oil tank to the satisfaction of the OCMI.If the OCMI is unable to attend the callout, ABS may witness on our behalf with prior notification. Surveyor must provide class report of repair.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Loss of power to emergency switchboard will not automatically start e-gen and bring online.

Vessel cannot demonstrate compliance to USCG requirements to operate a Periodically Unattended Machinery Space including failure to produce checkoff list to indicate suitability for commencement of unattended operation & failure to demonstrate tests to ensure continuity of electrical power provisions. Vessel to stand minimally attended.

Remove all holdbacks from machinery space doors. Noted all doors fitted with kick style door stops.

Install ladder rungs in way of escape hatch in space 2-56-5.

Vessel shall make permanent repairs to the port steering gear.

Install approved hydraulic hose fittings on stbd steering gear.

Have fixed CO2 actuator bottles replaces or hydrostatically tested IAW NFPA 12.

Have port and stbd steering gear hydraulic systems serviced to prevent excessive leaking.

Make proper repairs to STBD main motor aft journal bearing.

Emergency Diesel Generator switchboard circuit breaker failure.

company allowed COI and ISSC to expire. Company to submit NCR to addresse certificate renewal process.

Operate starboard lifeboat.

Complete all required class surveys and provide documentation to OCMI.

Some electrical penetrations missing stuffing. Vessel to survey all penetrations and identify those in structural fire protection boundries as identified on Fire plan. Repair as original those requiring stuffing.

Complete servicing of fixed and portable fire protection equipment.

Complete servicing of fixed fire detection system.

Correct persisitant fault for pump room #2 sensor.

Hydrosaticly test fire hoses.

Complete automation tests for #2 and #4 MDEG's

Complete sutomation tests for control transfer and EOT

Demonstrate proper operation of emergency stops for stbd FO transfer pump and port oily waste pump

Port ventilation evergency does not work. Demonstrate proper operation to attending Marine Inspector.

Hydrostatic releases expired.

Provide list of all EEBD expiry dates ot OCMI

Make permanent alterations as provided in Document titled "Ventilation Duct Modify & Electrical Fixture Renew In Paint Locker". Item No. 672.2. to the satisfaction of the attending marine inspector.

Remove or properly hydro-test portable oxygen bottle in hospital.

Make permanent repairs to all ventilation outlets in engine room where screens are damaged.

Make permanent repairs to fire detection sensors showing trouble lights on main detector panel. Until this item is clear, watch standers must make visual inspections of the effect spaces at 30 minute intervals and log rounds.

Provide permanently positioned means to remove pins from piracy lock bars. In emergency, pins are difficult to remove for opening scuttles.

9. Provide proposal for alterations to paint locker as follows: a. Prove explosive proof condition of fixed fire detector. b. Prove operability of fire dampers automatic closure. c. Prove exhaust ventilation does not pass non-explosion proof motors installed in the accommodations space air-conditioning system. d. Provide armored cable where non-armored cable is presently installed.

Restore loadline railing where missing on Stbd side aft.

Provide evidence that plywood installed in lifeboats is approved by the manufacture.

Connect all fire hoses to the hydrants.

Prove proper operation of the # 4 MDE lube oil pressure (low) alarm on the automation system in the presence of USCG inspector.

Prove proper operation of the time delay for the fixed fire fighting system in the main motor and generator room prior to conducting commercial operations.

Provide satisfactory servicing report from the fire servicing company for all fixed systems and extinguishers prior to conducting commercial operations.

Prove proper operation of the following general alarm bells: 1-5-1, 1-96-6, 1-140-1, array workshop, winch house, Fr 124 stbd, SOC and 2-0-2 Engr Strm. This item is to be completed to the satisfaction of the attending marine inspector prior to getting underway.

Proper calibrate all critical gauges used to monintor machinery & system conditions (pressure, temperature, RPM's, etc.) LEGACY COMPONENT DESC: Measuring Devices

Make proper, USCG approved repairs to structural fire protection in the Main Control Center (one cable way behind ES-400 switchboard) and four cable ways in the Emergency Diesel Generator space. LEGACY COMPONENT DESC: Fire Stop

Make proper, USCG approved repairs (back to original design) to cable ways disturbed by the installation of magnetic hold backs to fire doors. LEGACY COMPONENT DESC: Fire Stops

Conduct hydrostatic test to MAWP and test temperature/pressure relief valve on both electric H/W heaters. LEGACY COMPONENT DESC: Hot Water Heater Hydrostatic Test

Prove proper operation of both anchors.

Conducted hydrostatic test on replacment 2 1/2" and 1 1/2" fire hoses. LEGACY COMPONENT DESC: Hydrostatic Test

Provide (5) missing portable fire extinguishers.

Prove operation of the designated rescue boat in the presence of the USCG inspector. LEGACY COMPONENT DESC: Operation

Prove proper operation of magnetic holds on fire doors. LEGACY COMPONENT DESC: Magnetic Holds on Fire Doors

Provide/install watertight box utilized for GMDSS batteries on upper bridge deck.

Make watertight, all stuffing tube/kick pipes on upper bridge deck.

Repair deck rail below crane to original condition.

Repair of remove P/A systems phones on main deck.

Repair/replace stop valves to prevent leakage in fire stations 21,28,29,30,31.

Repair fracture in starboard life boat/rescue boat in aft guard/step.

Provide Fire Control Plans with IMO symbology in accordance with SOLAS 74/78 II-2, Reg 20 LEGACY COMPONENT DESC: Fire Control Plans

HYDRO THE 50 LB OXYGEN CYLINDER LOCATED IN HOSPITAL SPACE

PROVIDE PROPER BATTERY BOX IN EMERGENCY GENERATOR ROOM FOR SWITCHBOARD 24VDC POWER SUPPLY NO.2

RENEW QUICK RELEASE RINGS WITH PROPERLY WEIGHTED (4 KG OR GREATER) AND PROPER LENGHT OF LINE (MANUFACTURE INSTRUCTIONS)

MAKE FREEZER/CHILL BOX READY FOR INSPECTION

REMOVE STUD (TRIPPING HAZARD) ON DECK, LOCATED AFT OF PORT LIFERAFT

FREE UP STBD AFT EMBARKATION LIGHT TO ALLOW FOR DIRECTIONAL ADJUSTMENTS.

CALIBRATE MAGNETIC COMPASSES FOR BOTH LIFEBOATS.

RENEW ALL LIFEBOAT PROVISIONS THAT HAVE LOST VACUUM SEAL

CONDUCT FIRE DRILL USING THE REQUIRED CREW AS STATED ON THE COI TO THE SATISFACTION OF THE ATTENDING CG INSPECTOR PRIOR TO GETTING UNDERWAY.

PROVIDE WRITTEN PROPOSAL FOR TESTING OR REMOVAL OF HALON OPERATED TIMER FOR SMALL PAINT LOCKER.

CONDUCT ABANDON SHIP DRILL USING THE REQUIRED CREW STATED ON COI,TO THE SATISFACTON OF THE ATTENDING CG INSPECTOR, PRIOR TO GETTING UNDERWAY.

PROVIDE ORIGINAL STCW FOR BOSN PRIOR TO MISSION DEPLOYMENT

REPAIR FWD PORT EMBARKATION LIGHT.

PROPERLY MOUNT LIGHT FIXTURE IN STARBOARD MOTOR ROOM

POST PERMANENT INSTRUCTIONS FOR LAUNCHING THE PORT LIFEBOAT NEAR PORT DAVIT

Replace non UL approved fire extinguishers with UL marine type fire extinguishers.

Remove davit launched life raft launching instructions and replace them with float free launching instructions.

PROVE SATISFACTORY LOWERING AND RELEASE OF STBD LIFEBOAT.

REPAIR HIGH JACKET WATER TEMP ALARM ON EMERGENCY GENERATOR ALARM PANEL.

PROVE PROPER SHUTDOWN AND RECIRC MODE OF OWS BY ELIMINATING THE "ALARM ONLY" FUNCTION OF THE MONITOR ON BOTH PORT AND STBD OILY WATER SEPERATORS.

INSTALL PORT AND STBD EMBARKATION LADDERS OF PROPER LENGHT.

PROVIDE APPROVED DRAWINGS FOR MODIFICATION OF OUTRIGGING IAW NVIC 10-82 OR OBTAIN COAST GUARD APPROVAL.

PROVIDE APPROVED DRAWINGS FOR MODIFICATION TO DECK HOUSE CORNER IAW NVIC 10-82 OR OBTAIN COAST GUARD APPROVAL.

REPAIR OR RENEW BROKEN SAFETY RAILS ON STBD LIFEBOAT.

COMPLETE STARBOARD LIFEBOAT DAVIT WEIGHT TEST NLT 31JUL97.

Vessel to provide certificates of inspection for portable fire extinguishers.

PLACE PROPER HOSES ON THE THREE NEW FIRE STATIONS.

UPDATE AND SUBMIT FIRE CONTROL PLAN SHOWING NEW FIRE STATIONS.

HAVE ALL (6) SCBA CYLINDERS PROPERLY HYDROSTATIC TESTED. PROVIDE NEW YORK [name withheld] TESTS.

MAKE PROPER REPAIRS TO BOTH SHIP'S ANCHOR WINDLASS'. CONDUCT TEST OF THE ANCHOR BRAKE AND WINDLASS AFTER REPAIRS HAVE BEEN MADE. LOG THE RESULTS INTHE DECK LOG AND PROVIDE NY OCMI A STATEMENT FROM THE MASTER/[name withheld] TO THE REPAIRS, AND A COPY OF THE LOG SHOWING THE TEST.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

INSTALL STBD LIFERAFT ON BOARD VESSEL AFTER IT HAS PASSED USCG INSPECTION. PROVIDE A STATEMENT FROM THE MASTER/CHIEF MATE THE NEW YORK [name withheld] INSTALLATION.

OBTAIN APPROVED PLANS FROM MARINE SAFETY CENTER SHOWING MODIFICATIONS TO UNINTERRUPTIBLE POWER SUPPLY SYSTEM FOR THE BAILEY CONTROLS. THIS ITEM TO BE COMPLETED NOT LATER THAN 30MAR95

PRIOR TO SAILING, CONDUCT A SATISFACTORY FIRE AND BOAT DRILL WITH SHIP'S CREW, AND IN NO CASE LATER THAN 20NOV94.

PROVIDE MARINE SAFETY CENTER EVALUATION OF EFFECT OF LIFEBOAT MODIFICATIONSON VESSELS STABILITY OR CONDUCT A STABILITY TEST.
