SAM PATCH
SAM PATCH is a 1991 passenger vessel (inspected). The Coast Guard has recorded 22 inspections since 2016, most recently in May 2026, along with 40 deficiencies and 9 casualty investigations between 2007 and 2026.
Records from 2007 to 2026. Most recent: inspection, 30 May 2026.
- Built
- 1991
- Last inspected
- 30 May 2026
- Documentation
- Valid · documentation file of 10 August 2026
- Deficiencies
- 40 recorded · 0 without a recorded resolution
- Controls
- None recorded without a removal date
- Casualties
- 9 investigations · 2007–2026
Everything above is free. The detail below — the inspection history, the deficiency record, the casualty record and the documentation record — is Professional, $39 a month. Sign in.
Coast Guard record current through 23 August 2026, retrieved 5 September 2026 from PSIX. Every field on this page was recorded by the Coast Guard. Records for the Passenger Ship class in Maury's sources begin in 2016.
Inspection record
Last inspected
30 May 2026
…with no type recorded5
Deficiencies
40 recorded · 0
without a recorded resolution
Operational controls
None recorded without a removal date
Years with a record
11 calendar years (2016–2026)
Every line above is a count of records the US Coast Guard wrote, or a date it recorded.
A blank resolution means none was recorded in this data; it does not establish that a
deficiency is outstanding. Years with a record are calendar years in which a record
exists, not years in service. What Maury does
not do.
Identity
976232
WDE2888
363855
Flag
UNITED STATES
Maury page id
psix-363855
Documentation record
Registered dimensions (L × B × D)54.0 ft × 12.0 ft × 5.3 ft
Registered tonnagegross 23 / net 18
ITC dimensions (L × B × D)Not recorded
ITC tonnageNot recorded
BuilderMID-LAKES NAVIGATION CO · SKANEATELES, NY, UNITED STATES · built 1991
Hull materialSteel
PropulsionDiesel Reduction
Hull shapeShip
Hull configurationMonohull
Hailing portROCHESTER, NY
Trade endorsementsCoastwise, unrestricted, Registry
DocumentationValid · issued 12 June 2026 · expires 30 June 2027
Service, as the file records itPassenger (Inspected)
Hull formpowered (Maury's inference from propulsion, hull shape, material and length, rule hf-1; not a recorded fact)
Tonnage as PSIX records it23 - Simplified, Gross Ton
18 - Simplified, Net Ton
18 - Simplified, Net Ton
Every line above is a field of the National Vessel Documentation Center's file as served by NOAA Fisheries, dated 10 August 2026, matched to this hull on its Official Number. Registered and ITC measurements are two systems and are never combined. One snapshot is held so far; documentation history begins with the next.
Professional
Detail on this page
22 inspections, each with its date, unit and type; 40 deficiencies with the resolution recorded against each; 9 casualty investigations, with date and classification; the documentation record: dimensions, tonnage, builder, hailing port, endorsements, dates. The counts in the summary above are the same counts, and they are free.
$39 a month or $299 a year, every vessel page, cancel any time. Founding rate $19.99 a month for life, for the first 200 subscribers. Plans Sign in
Maury does not score, rate or grade vessels, at any price.
Vessel history report
Every record for this hull, in one document — $299
Every recorded inspection, 2016 to 2026 for this class, in one chronology · every deficiency, with system, dates and resolution · operational controls imposed and removed · every name this hull has been recorded under · the vessels it was inspected alongside, and when · how its record compares with hulls of similar age and size, as a fact about the population and never a judgement about this vessel.
Read one first, in full: a forty-year chronology · a hull that changed operators four times · the sparse case, shown as an example, not for sale.
This report is in development and is not for sale yet. There is no date, and nothing is charged. Leave an email and we will tell you when it exists, once.
Used only to tell you when the report exists. Not shared, not sold, and not added to a mailing list.
Inspection history · 22
30 May 2026
Type not recorded
No type recorded · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 8387207
19 November 2025
Drydock Exam · Internal Structural Exam
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 8271525
5 August 2025
Damage Survey
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 8243485
4 August 2025
Type not recorded
No type recorded · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 8208413
11 April 2025
Annual Inspection · In-Service Inspection · Plan Review "T" Boat
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 8131921
28 August 2024
In-Service Inspection · Deficiency Check
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7991810
28 August 2024
Type not recorded
No type recorded · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7996009
20 June 2024
Deficiency Check
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7938805
22 May 2024
COI Inspection
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7915514
4 September 2023
Annual Inspection · Deficiency Check
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7791494
4 August 2023
Type not recorded
No type recorded · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7762413
20 June 2022
Administrative Inspection · Annual Inspection
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7483051
24 February 2022
Administrative Inspection · Plan Review "T" Boat
Administrative · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7401574
8 September 2021
Administrative Inspection · Annual Inspection · Deficiency Check
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7307115
11 June 2021
Damage Survey
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7224722
11 June 2021
Type not recorded
No type recorded · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7247009
25 March 2021
Internal Structural Exam · Drydock Exam
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7158983
29 September 2020
Administrative Inspection · Annual Inspection
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 7051989
30 May 2019
Deficiency Check · DAPI Audit · Administrative Inspection · COI Inspection
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 6698739
26 June 2018
Deficiency Check · Annual Inspection · Administrative Inspection · DAPI Audit
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 6392365
13 June 2017
Administrative Inspection · DAPI Audit · Annual Inspection
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 6174265
2 May 2016
Deficiency Check · Annual Inspection · Administrative Inspection · DAPI Audit
Physical examination · Sector Eastern Great Lakes · USCG Great Lakes District (CGD-GL) · Activity 5867627
Deficiency record · 40
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Operation of machinery
Issued 5 August 2025
Resolved
Vessel is experiencing vibration issues due to damaging the prop during a recent grounding. Vessel owner/operator shall repair or replace the propeller to ensure safe and proper operation of the vessel.
08 - Alarms › N/A - No Subsystem › Other (alarms)
Issued 11 April 2025
Resolved
A visual and audible alarm must be provided at the operating station to indicate a high water level. Vessels high water indicating alarm float swith was removed during engine replacement and not re-installed. Make frequent rounds of engine space to ensure no flooding. Repair high water alarm to the satisfaction of attending CG Marine Inspector.
46 CFR 182.530
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Operation of machinery
Issued 28 August 2024
Resolved
Operator notified OCMI after the vessel experienced a loss of propulsion. Vessel reported that the control cable for the reduction gear failed, resulting in the gear being stuck in reverse. Repair to the satisfaction of attending Coast Guard Marine Inspector prior to carrying passengers.
46CFR185.202
99 - Other › N/A - No Subsystem › Other (Safety in general)
Issued 22 May 2024
Resolved
Conduct and log man overboard, fire, and abandon ship drills with newly reported crewmembers and every 3 months. Provide Coast Guard Marine Inspector objective evidence (log book) of drills conducted.
46 CFR 185.420&
46 CFR 185.520&
46 CFR 185.524
11 - Life Saving Appliances › N/A - No Subsystem › Operational readiness of lifesaving appliances
Issued 22 May 2024
Resolved
Label life jacket stowage under embarkation ladder on starboard side to the satisfaction of attending Coast Guard Marine Inspector.
46 CFR 185.604(f)
99 - Other › N/A - No Subsystem › Other (Safety in general)
Issued 22 May 2024
Resolved
Outfit first aid kit with the contents of 46 CFR 199.175(b)(10).
46 CFR 184.710
01 - Certificates & Documentation › 011 - Ships Certificates › USCG Certificate of Documentation (COD)
Issued 22 May 2024
Resolved
Certificate of Documentation is expired. Objective evidence of renewal application submission was provided to marine inspector. Provide a copy of the COD to attending CG Marine Inspector upon receipt.
46 CFR 67
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Propulsion main engine
Issued 4 September 2023
Resolved
Vessels Shaft slid from the engine coupling and therefore damaged the shaft. Vessel Owner/Operator shall repair or replace the shaft to esnure proper operation.
11 - Life Saving Appliances › N/A - No Subsystem › Lifebuoys incl. provision and disposition
Issued 8 September 2021
Resolved
The vessels float light battery was noticed to be expired. The vessel owner/operator shall replace the battery with a new battery of the approved type.
11 - Life Saving Appliances › N/A - No Subsystem › Lifebuoys incl. provision and disposition
Issued 8 September 2021
Resolved
The forward lifering labeling and refelective tape were found deteriorated. The vessel owner/operator shall replace with Solas type reflective tape and replace the lettering to ensure the vessels name is legible.
11 - Life Saving Appliances › N/A - No Subsystem › Lifebuoys incl. provision and disposition
Issued 8 September 2021
Resolved
The forward lifering was not supplied with a bracket. The vessel owner/operator should develop a system to hang the lifering to ensure the lifering is always stored in the same location.
07 - Fire Safety › N/A - No Subsystem › Fire fighting equipment and appliances
Issued 8 September 2021
Resolved
A vessel not required to have a power driven fire pump must have at least three 2 1/2 gallon buckets. Vessel was only supplied with 2 buckets, vessel owner/operator shall supply the vessel and crew with a 3rd fire bucke
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Operation of machinery
Issued 11 June 2021
Resolved
Loss of propulsion control due to a failure of throttle mechanism.
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Other (machinery)
Issued 25 March 2021
Resolved
Machinery and equipment installed on each vessel must be
suitable for the vessel and its operation and for the
purpose intended. All machinery and equipment must be
installed and maintained in such a manner as to afford
adequate protection from machinery failure. While
conducting an inspection of the vessel’s shaft bearing,
it was noted that the bearing was cracked and showing
signs of delamination from the metal housing. Any
cracking and/or delamination found on the rubber part of
the bearing must be replaced prior to the vessel
returning to service. Replace unsatisfactory bearing to
satisfaction of attending Marine Inspector.
02 - Structural Conditions › N/A - No Subsystem › Steering gear
Issued 30 May 2019
Resolved
A vessel must be provided with an auxiliary means of
steering. Vessel's auxiliary means of steering is their
bow thruster which is operating intermittently.
Auxiliary means of steering must be repaired to the
satisfaction of attending Marine Inspector and
operationally tested while underway. Rectify prior to
the carriage of passengers.
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Bilge pumping arrangements
Issued 30 May 2019
Resolved
A submersible electric bilge pump may be used as a power
bilge pump provided that the pump is listed by an
independent laboratory as meeting the requirements in UL
1113. Submersible electric bilge pump located in void
under galley did not indicate it was UL 1113 listed.
Provide proof of proper UL listing or replace with
satisfactory bilge pump to the satisfaction of attending
Marine Inspector.
11 - Life Saving Appliances › N/A - No Subsystem › Lifejackets incl. provision and disposition
Issued 30 May 2019
Resolved
Each child size life jacket must be stowed in a location
that is appropriately marked and separated from adult
life jackets so the child size life jackets are not
mistaken for adult life jackets. Life jacket box in bow
is not marked. Satisfactorily mark location of life
jackets in forward stowage box to the satisfaction of
the attending Marine Inspector.
07 - Fire Safety › N/A - No Subsystem › Other (fire safety)
Issued 30 May 2019
Resolved
A vessel not required to have a power driven fire pump must have at least three 2.5 gallon buckets, with
an attached lanyard satisfactory to the cognizant OCMI,
placed so as to be easily available during an emergency.
The words “FIRE BUCKET” must be stenciled in a
contrasting color on each bucket. The words “FIRE
BUCKET” were not visible on one bucket. Re-stencil "FIRE
BUCKET" on deficient bucket to satisfaction of Marine
Inspector.
07 - Fire Safety › N/A - No Subsystem › Fire fighting equipment and appliances
Issued 30 May 2019
Resolved
Portable and semi-portable extinguishers must be
inspected and maintained in accordance with NFPA 10.
Debris was found in nozzle to 01 fire extinguisher. Have
extinguisher nozzle maintained as per NFPA 10 and to the
satisfaction of an attending Marine Inspector. Until
serviced and deficiency cleared, have appropriate sized
standby extinguisher on board vessel.
11 - Life Saving Appliances › N/A - No Subsystem › Distress flares
Issued 30 May 2019
Resolved
A vessel on a rivers route must carry:three hand red
flare distress signals and three hand orange smoke
distress signals approved in accordance with §160.037 in
subchapter Q of 46 CFR. Hand red flare distress signal
may be substituted for any hand orange smoke distress
signals. Vessel only had 04 hand red flare distress
signals on board. Have satisfactory amount/type of
distress signals on board.
04 - Emergency Systems › N/A - No Subsystem › Damage control plan
Issued 30 May 2019
Resolved
The owner, charterer, master or managing operator shall
instruct each crew member, upon first being employed and
prior to getting underway for the first time on a particular vessel and at least once every three months,
as to the duties that the crew member is expected to
perform in an emergency. Crew was unaware of location of
port to collision bulkhead for dewatering. Moving
forward drill with all crew on proper dewatering of
collision bulkhead and maintain access so as to not
seize.
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Bilge pumping arrangements
Issued 26 June 2018
Resolved
A vessel must be provided with bilge pump where the pump
is listed by an independent laboratory as meeting the
requirements in UL 1113. Bilge pump was found to not
meet UL 1113. Please replace with appropriate pump.
04 - Emergency Systems › N/A - No Subsystem › Means of communication between safety centre and other control stations
Issued 26 June 2018
Resolved
The emergency instructions must be designed to address
the particular equipment, arrangement, and operation of
each individual vessel. Emergency instructions posted
did not follow the actual actions of the ship's crew in
case of a Man Overboard (MOB). Make posted emergency
instructions as to the actual emergency practices of the
vessel and drill procedures of the crew. Make any
changes necessary to express changes in procedure
(tethering/life jacket on Master/not using passengers)
11 - Life Saving Appliances › N/A - No Subsystem › Lifejackets incl. provision and disposition
Issued 26 June 2018
Resolved
Lifejackets must be properly stowed. Two lifejackets (as
required by the vessel's COI) were not properly stowed.
Provide proper stowage of lifejackets.
Operations/Management › Drug and Alcohol Testing › Proof of Enrollment
Issued 3 May 2016
Resolved
Provide Consortium contract for 2016 with listing of covered employees.
Operations/Management › Drug and Alcohol Testing › MIS Submission
Issued 3 May 2016
Resolved
Provide proof of MIS submission for 2015.
Operations/Management › Drug and Alcohol Testing › EAP Training Requirements
Issued 3 May 2016
Resolved
Provide proof of supervisors / masters completed 1 hr EAP training.
Operations/Management › Drug and Alcohol Testing › EAP Display Requirements
Issued 3 May 2016
Resolved
Identify Substance Abuse Professional (SAP)with contact information.(49CFR40.289)
Lifesaving › Lifebuoys › Approval
Issued 3 May 2016
Resolved
Waterlight w/ CRES clip attached around the body of the ring with lanyard 3-6'.
Engineering › Fuel Oil Storage/Transfer System › Valve
Issued 3 May 2016
Resolved
Mark direction of operation for fuel shut off valves; exercise valves.
Documentation › Markings/Placards › Warning Signs
Issued 3 May 2016
Resolved
Post emergency broadcast placard (corrected on spot).
Electrical › Lighting (emergency) › Battery Operated Lantern
Issued 3 May 2016
Resolved
Provide operable portable lights (corrected on spot).
Electrical › Electrical Distribution System (service) › Wiring
Issued 3 May 2016
Resolved
Provide chaffing gear for wiring on engine room forward bulkhead.
Documentation › Manuals/Policy Documentation › Bridge Resource Management Policy/Procedures
Issued 3 May 2016
Resolved
Provide up-to-date Rules of the Road onboard. (emailed)
Accommodation/Occupational Safety › Medical/First Aid › Medicine Chest
Issued 3 May 2016
Resolved
Provide missing/expired items for first aid kit. (List provided).
Lifesaving › Lifejacket/PFD (Type I) › Condition
Issued 3 May 2016
Resolved
Replace 1 adult lifejacket. (corrected on spot)
Lifesaving › Lifejacket/PFD (Type I) › Marking
Issued 3 May 2016
Resolved
Stencil vessel name on life jackets as required.
Engineering › Bilge Water Management System › Pump
Issued 3 May 2016
Resolved
Provide bilge pump meeting UL 1113 approval.
Fire Fighting › Portable CO2 Fire Extinguisher › Mounting Bracket
Issued 3 May 2016
Resolved
Provide rubber matting under fire extinguishers.
Operations/Management › Drug and Alcohol Testing › Testing, Equipment
Issued 3 May 2016
Resolved
Alcohol testing swabs expired, if carried must be current. (removed from vessel)
Casualty record · 9
6 June 2007Routine · role: Involved in a Marine Casualty · activity 2954180
2 September 2015Routine · role: Involved in a Marine Casualty · activity 5233396
19 September 2015Routine · role: Involved in a Marine Casualty · activity 5728873
20 September 2015Routine · role: Involved in a Marine Casualty · activity 5724356
11 June 2021Routine · role: Involved in a Marine Casualty · activity 7247009
4 August 2023Routine · role: Involved in a Marine Casualty · activity 7762413
28 August 2024Routine · role: Involved in a Marine Casualty · activity 7996009
4 August 2025Routine · role: Involved in a Marine Casualty · activity 8208413
30 May 2026Routine · role: Involved in a Marine Casualty · activity 8387207
Each line is an incident investigation the Coast Guard recorded with this hull among the vessels involved, with the date and the classification the Coast Guard gave it. Involvement is not fault. The investigation narrative is not published. Source: IIR, through 2026.
Ownership record
The Coast Guard's documentation record for this hull -- the Abstract of Title,
with its owners and liens as filed -- is not in PSIX. Ask, and Maury buys it from the National
Vessel Documentation Center, files it here with its date, and every reader of this page gets it.
