DOLPHIN RACER

Each item of lifesaving equipment determined by the marine inspector to not be in serviceable condition must be repaired or replaced. 10 life jackets were found with deteriorated floatation foam and were condemned. Replacement jackets bought, labeled, and stowed before the inspection was completed. 46 CFR 176.808

Thewater light, required for night time operation, shall be stowed and attached the the ring life buoy nearest the opeating station. The float light was not operating as it should. Repair or replace the float light. A new float light was onboard prior to the completion of the inspection. 46 CFR 180.30-10

An adult life jacket must be provided for each person carried on board a vessel 13 adult life jacket in non-serviceable condition. Max persons on board reduced to 118. 46 CFR 180.71(a)

A vessel on which a pre-engineered fixed gas fire extinguishing system is installed must have the a light to indicate discharge. Lights on pre-engineered fixed gas fire extinguishing system alarm display are inoperable. 46 CFR 181.420(b)(1)

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected and all required guards and protective devices must be in satisfactory condition. Cracks located on the starboard bow rail and loose mounting hardware located on multiple rail mounts. 46 CFR 176.830(a)

A vessel must comply with the applicable requirements for any radio...set forth in 47 CFR part 80. Each ship transporting more than six passengers for hire equipped with a radiotelephone station in accordance with Part III of Title III of the Communications Act must carry a radio operator who meets the following requirements: (1)Where the station power does not exceed 250 watts carrier power or 1500 watts peak envelope power, the radio operator must hold a marine radio operator permit or higher class license. 2) Where the station power exceeds 250 watts carrier power or 1500 watts peak envelope power, the radio operator must hold a general radiotelephone operator license or higher class license. Vessel representative did not radio operator permit present. 46 CFR 184.502 46 CFR 80.159(e)(1)(2)

An adult life jacket must be provided for each person carried on board a vessel. Vessel had 6 unserviceable life jackets. 46 CFR 180.71

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI. The port side bulkhead longitudinal stringer located in the engine room is cracked. Operator will make repairs like and in kind. 46 CFR 176.700

Overcurrent protection must be provided for each ungrounded conductor for the purpose of opening the electric circuit if the current reaches a value that causes an excessive or dangerous temperature in the conductor or conductor insulation. There is no overcurrent protection between the alternator and the distribution panel. 46 CFR 183.380(a)

Overcurrent protection must be provided for each ungrounded conductor for the purpose of opening the electric circuit if the current reaches a value that causes an excessive or dangerous temperature in the conductor or conductor insulation. There is no overcurrent protection between the battery and the distribution panel. 46 CFR 183.380(a)

Overcurrent protection must be provided for each ungrounded conductor for the purpose of opening the electric circuit if the current reaches a value that causes an excessive or dangerous temperature in the conductor or conductor insulation. There is no overcurrent protection between shore power and the battery chargers. AC conductors must be protected by a UL 489 circuit breaker. 46 CFR 183.380(a), 46 CFR 183.380(m)

New installations of electrical equipment and material, and the repair or replacement of wire and cable, on an existing vessel, which are completed to the satisfaction of the cognizant Officer in Charge, Marine Inspection (OCMI) on or after March 11, 1996, must comply with this part. A new battery charger and shore power connection conductors were installed on the vessel without submitting plans. Vessel must submit plans for approval to MSC. 46 CFR 183.115(c) 50C

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without approval of the OCMI. Identified fractured starboard rudder post mount base plate. The mount was found fractured entirely from fwd to stern and permitting water to enter the space when steering maneuvers were performed. Provide repair plan to OCMI and make satisfactory repairs. 46 CFR 176.700

Seating accommodations for passengers are required to be provided only when the max number of passengers permitted has been determined by using fixed seating criteria. Identified (18) passenger seats fractured and unusable. Passenger count reduced by (18). Renew seating as original or provide proposal for seating arrangement. 46 CFR 177.30-1

An adult life jacket must be provided for each person carried onboard the vessel. (01) adult life jacket was found in poor condition. Passenger count reduced by (01) adult. 46 CFR 180.71(a)

Rails or equivalent shall be installed near the periphery of all weather decks accessible to pax & crew. Stbd fwd railing found fractured. Renew as original. 46 CFR 177.35-1

On or before March 11, 1999, an existing vessel must comply with the bilge high level alarm requirements in 182.530. Vessels greater than 26 feet shall have a visual and audible alarm at the operating station to indicate high water levels in spaces identified in 182.530. 46 CFR 182.530

Provide operational test of the main propulsion system to the satisfaction of the marine inspector. 46CFR182.200

A vessel must be provided with a main steering gear that is: Of adequate strength and capable of steering the vessel at all service speeds. The vessel's steering gear was reported as inoperable. Repair to the satisfaction of the attending marine inspector.

Delamination in way of stern. 46CFR176.20-1

On wooden vessels, bonding together of the enclosures and frames of major electrical equipment to a common ground shall be effected. Inspector found bonding wires disconnected. Connect all bonding wires as required by cited regulation. 46 CFR 183.05-50(d)(2)

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspection. Inspector found lighting fixture in engine room without protective cover. Provide protective cover for fixture. 46 CFR 183.01-15(a)

Unless a splice is made by an insulated pressure wire connector listed by Underwriters' Laboratories, Inc., it shall be thoroughly soldered, taped first with rubber and then with friction tape, or the soldered joint shall be otherwise protected as to provide an insulation the same as that of the conductors joined. Inspector found dead ended wires in aft steering and tank compartments. Remove wires or properly secure as per cited regulation. 46 CFR 183.05-50(b)(2)

Vsl is broadcasting: Invalid MSI, no static draft information, and incomplete dimension information (AIS Antenna Position “X” equals 0).

Place name of vessel and hailing port on stern.

Prove proper operation of mast head light.

On lifebouy found buoyant lifeline way to long. Make buoyant lifeline 60 feet as required.

Found line for self-igniting light way too long. Make line 3-6 feet as required.

Fixed bilge water management system manifold in engine room was not labled. Lable all valves to location on vessel.

Replace aft stbd cutlass bearing.

Repair delamination and if greater than superficial Marine Inspector to re-exam.

Remove bad plywood (with angle hair) around upper vent over port and stbd engines to good plywood and seal engrains.

Remove bad plywood forward of stbd engine access cover to good plywood and insert a new piece, as original, and seal to include engrains.

Complete credited hull inspection and power trials for engines being overhauled.

Replace oil cool lines for reduction gear.

Replace 03 PFDs, reduced passenger count to 127.

Affix grounding straps to motor mount brackets.

Provide 13 lifevests. Vessel limited to carrying 118 total persons, 115 passengers. 46 CFR 180.71

Provide a workable portable hand bilge pump. They have placed a 8 foot pick-up tube to the hand pump instead of putting it at the discharge end of the hand pump. Pump does not take suction unless you prime pump first.

Provide a copy of [name withheld] Marine Operating Permit. [name withheld] states his card is at home.

Provide a safety guard for STBD engine PTO, as discussed. No guard around pulley next to switch to energize the bilge pump.

Remove all wire nuts on bilge pump wires and other misc. wiring through out the vessel.

Prove trim tab wires meet 46CFR183.340. They had new trim tabs installed and ran wire that has a label of (353.98 INSUL-8 CORP).

Label amount and size of life jacket storage under seats. They placed jackets under seats, but have not labeled size or amount.

Prior to the carriage of passengers, repair oil leak(s) on PORT MDE and prove repairs to attending USCG Marine Inspector. See narrative for details.

Prior to the carriage of passengers, clean oil from PORT engine room BLKHD, PORT MDE block, and under PORT MDE bilge. See narrative for details.

REPAIR COMPASS LIGHT PRIOR TO OPERATION AT NIGHT.

PROVIDE MANUFACTURER SPECIFICATIONS OF NORMAL OPERATING TEMPERATURE OF TURBOCHARGERS.

REPAIR STERN AND MASTHEAD LIGHTS PRIOR TO CARRIAGE OF PASSENGERS AT NIGHT.

WIRE BLOWERS IN ENGINE ROOM INTEGRAL WITH FIXED FIREFIGHTING SHUTDOWN. BLOWERS MUST REMAIN SECURED UNTIL COMPLETED.

Provide 6 daytime smoke signals prior to carrying passengers for hire. LEGACY COMPONENT DESC: Quantity

Renew retrotape on 15 child lifejackets as identified. LEGACY COMPONENT DESC: Retroreflective Material

Repair anchor light prior to night operations. LEGACY COMPONENT DESC: Navigation Lights

Replace 2 tabs for under deck transverse, 2nd compartment fwd of aft steering. LEGACY COMPONENT DESC: Transverse Frame

Replace 2 tabs in fuel tank space port. LEGACY COMPONENT DESC: Transverse Frame

Replace 2 tabs in fuel tank space stbd. LEGACY COMPONENT DESC: Transverse Frame

Renew port sea valve. LEGACY COMPONENT DESC: Valve Flange

TERMINATE OR REMOVE DEADEND CABLES IN PORT STORAGE LOCKER IAW 46 CFR 183.340

PROVIDE EPIRB REGISTRATION PRIOR TO CARRYING PASSENGERS FOR HIRE.

PROVIDE NAVIGATION PUBLICATIONS, CG LIGHT LIST, COAST PILOT, TIDE TABLES, IAW 46 CFR 184.420

RENEW RETRO REFLECTIVE TAPE ON IDENTIFIED LIFEJACKETS PRIOR TO CARRYING PASSENGERS.

RE-FIBERGLASS THE ENDS (TABS) OF THE UNDERDECK STRUCTURAL SUPPORTS TO THE HULL FOR BOTH THE LONGITUDINAL AND TRANSVERSE FRAMES TO SUPPORT THE BOX CAPTO HULL ATTACHMENT JOINT.

46 CFR 15 - ENROLL ALL CREW MEMBERS IN A DOT APPROVED DRUG CONSORTIUM.
