JADE LADY III

The owner or managing operator shall make a vessel available for drydock examinations, internal structural examinations, and underwater surveys (UWILD) required by this section. The vessel's credit dry dock was due on April 30, 2025. The owner failed to make the vessel available for dry dock. 46 CFR 176.600

All vessels shall be provided with bilge pumps in accordance with Table 182.25-10(a). The portable hand pump was inoperable when tested by the crew. The rubber on the pump was found deteriorated and cracked preventing the pump from creating suction and pumping water from each space. 46 CFR 182.25-10

On a vessel of at least 7.9 meters (26 feet) in length, a visual and audible alarm must be provided at the operating station to indicate a high water level in each of the following normally unmanned spaces: A space with a through-hull fitting below the deepest load waterline, such as a lazarette; A machinery space bilge, bilge well, shaft alley bilge, or other spaces subject to flooding from sea water piping within the space; and A space with a non-watertight closure, such as a space with a non-watertight hatch on the main deck. Vessels constructed of wood must, in addition to paragraph (a), provide bilge level alarms in all watertight compartments except small buoyancy chambers. The bilge high level alarm panel was relocated from the operating station to inside of the cabin on the main deck. Provide a bilge high level alarm at the operating station for all watertight compartments using the MWTB frame numbers identified on the stability letter as spaces that would be considered watertight. 46 CFR 182.530

A vessel on which a pre-engineered fixed gas fire extinguishing system is installed must have the following equipment at the operating station: A light to indicate discharge. The starboard side pre-engineered FireBoy visual alarm was inoperable when tested by the crew. 46 CFR 181.420(b)

Except for engine exhausts, each inlet or discharge pipe that penetrates the hull below a line drawn parallel to and at least 150 millimeters (6 inches) above the deepest load waterline must have means to prevent water from entering the vessel if the pipe fractures or otherwise fails. A positive action valve or cock that is located as close as possible to the hull is an acceptable means for complying with paragraph (b) of this section. The shutoff valve for the starboard main engine sea strainer was found frozen open and will not prevent water from entering the vessel if the pipe fractures. 46 CFR 171.119(b)

Shutoff valves, installed so as to close against the fuel flow, shall be fitted in the fuel supply lines, one at the tank connection and one at the engine end of the fuel line to stop fuel flow when servicing accessories. The shutoff valve at the tank must be manually operable from outside the compartment in which the valve is located, preferably from an accessible position on the weather deck. The remote fuel shutoff valves located in the port and starboard fuel tank spaces were not operable when tested. The shut off valve at the engine end in the port engine room was not operable when tested by the crew. 46 CFR 182.20-40(b)(3)

All wiring and cables shall be suitable for marine service and for the particular installation used. All electrical installations shall be to the satisfaction of the OCMI. The operator installed a 6000W power inverter behind the operating console. The inverter's AC power conductors were found connected at stud on the bulkhead with no enclosure. The unprotected stud and AC conductor is live when energized and a bundle of other DC/AC conductors were found installed on top of the live stud connection creating enough heat/resistance to melt some of those conductor's thermoplastic. The AC connections shall be made in an enclosed UL listed junction box or UL listed distribution panel and is now considered a new electrical installation IAW 46 CFR 183.115(c). 46 CFR 183.01-15

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected and all required guards and protective devices must be in satisfactory condition. The marine inspector identified flammable paint and diesel portable fuel tanks stored in the port and starboard internal cabin over top of the fuel tanks. The electrical devices in these spaces are not suited for storage of flammable paint and the storage of each of these items presents a fire hazard onboard. 46 CFR 176.25-50

All wiring and cables shall be suitable for marine service and for the particular installation used. All electrical installations shall be to the satisfaction of the [name withheld] all dead end conductors found in the electrical cabinet behind the operating station. 46 CFR 183.01-15

All wiring and cables shall be suitable for marine service and for the particular installation used. All electrical installations shall be to the satisfaction of the [name withheld] found a 16 AWG conductor connected to a 225 Amp fuse. The 225 Amp fuse is too large to serve as the overcurrent protection for the 16 AWG conductor. Size the overcurrent protection IAW the current carrying capacity of the conductor. 46 CFR 183.01-15

All wiring and cables shall be suitable for marine service and for the particular installation used. All electrical installations shall be to the satisfaction of the OCMI. Identified welding cable installed in the DC circuit behind the operating station and in both engine compartments. All conductors must be in accordance with the approved conductors listed in 46 CFR 183. Welding cable is not permitted due to the thermoplastic minimal thickness which presents a fire hazard when installed in a branch circuit. 46 CFR 183.01-15

A suitable hull strainer shall be installed in the circulating water intake line for the main engine. The starboard main engine strainer was found with heavy corrosion around the strainer lid. Clean the area for MI to inspect for serviceability. 46 CFR 182.20-10(b)(3)

All wiring shall be run as high as practicable above the bilges. The starboard main engine starting battery negative conductor was found installed without support from the starting battery under the main engine and directly in the bilge. 46 CFR 183.05-50

Batteries shall be secured against shifting of the boat. The batteries found in the port and starboard engine compartments were found unsecured for movement in any direction. 46 CFR 183.05-20(b)

On wooden vessels the enclosures and frames of electrical equipment must be bonded together to a common ground by a normally non-current carrying conductor. Metallic cases of instruments and secondary windings of instrument transformers must be grounded. The AC/DC inverter is not connected to the common ground. All metalic enclosures for any electrical equipment onboard shall be connected to the common ground. 46 CFR 183.05-50(d)(2)

Receptacle outlets and attachment plugs for portable lamps, tools, and similar apparatus operating at 100 volts or more, must have a grounding pole and a grounding conductor in the portable cord. The outlets attached to the new electrical installation, a 6000W AC/DC inverter, must have a grounding conductor attached to the common ground. 46 CFR 183.370(b)

Provision must be made for closing all supply duct cowls or scoops and exhaust duct discharge openings for a space protected by a fixed gas extinguishing system. All closure devices must be readily available and mounted in the vicinity of the vent. The port and starboard engine rooms have a window that can be opened which faces the main deck passenger space of the vessel. There is no means to effectively close or seal the window in the event the FireBoy pre-engineered system is discharged. 46 CFR 182.465(h)

Mechanically propelled "S" vessels which are ferry vessels or which carry more than 49 passengers shall comply with Subchapter F. The piping for the sea water cooling on the port main engine was found with non-metallic piping which is not permitted. 46 CFR 182.40-5

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected and all required guards and protective devices must be in satisfactory condition. Identified a soft spot in the deck directly above the port water tank located amidships. Remove the deck for further inspection. 46 CFR 176.25-50

Bilge high level alarms are not operational.

Repair damaged frame for aft overhead canopy.

Repair high temperature alarms for STBD propulsion engine cooling water.

Found expired medication in first-aid kit.

Found expired annual service tag on (06) portable CO2 fire extinguishers.

Found two waste receptacles not made of non-combustible materials.

Found two inoperable portable emergency lights.

Fire hose must be fitted with nozzle made of good grade bronze or equivalent material. Missing nozzle on port fire hose.

Remove all dead end wires under control console.

Repair inoperable navigation lights.

Escape hatches shall be marked " Emergency Exit, Keep Clear"

Third party survey on rigging is not complete due to COVID 19 travel restrictions. VSL shall not operate under auxiliary sail until a satisfactory unstepping of the mast and rigging tuning are conducted.

MSD Saipan approved the company's extension request for vessel's dry dock exam and unstepping the rig. Vessel will NOT carry passenger until satisfactory dry dock exam, unstepping the rig, sea trails under sail and rig tunning are completed.

Remove dead end wires in port engine room forward bulkhead.

Repair salt water leak on three way valve forward of port propulsion engine.

Repair non operational port fire pump.

Reinstall loose cover for port engine room fixture light.

Replace damaged starboard port holes.

Replace worn reflector tapes on AFT life buoy.

Reinstall captive chain to forward starboard watertight hatch.

Provide proof of annual service conducted on all portable fire fighting extinguishers and pre-engineering system.

Owners must provide satisfactory proof of the rquired service as required by 46 CFR 176.810.

Provide company drug & alcohol policy signed by employee as required by 46 CFR 16.

Found aft life ring buoy with deteriorated inner material. Life ring buoy must be in satisfactory condition as required by 46 CFR 180.70. Replace damaged life ring.

Found inoperable water light on forward life ring buoy. water light on life ring buoy must be in satisfactory condition as required by 46 CFR 180.70. Replace inoperable water light.

Passenger and crew must be protected from electrical shock as required by 46 CFR 183.200. Found overhead light fixtures in crew areas missing protective covers. Install light protective covers.

Electrical light fixtures must be installed and maintained as required by 46 CFR 183.200. Found inoperable light fixture in STBD engine room. Repair light fixture.

Vessel must maintain the steering system as required by 46 CFR 182.530. Found small hydraulic fluid leak at the base fo steering wheel. Repair hydraulic fluid leak at the steering hub.

Machinery and equipments must be installed and maintained in such a manner as to afford adequate protection from failure as required by 46 CFR 182.100. Found port reduction gear heat exchanger(H/E) with rusted & leaking hose fitting. Replace wasted hose fitting and properly secure the H/E to the support bracket.

Found several location below water line in both hulls previously repaired with Bondo. Remove Bondo from all indicated areas and repair to original.

Found two port propeller blades bend at the trailing edge of the blade. Replace port propeller.

Found rot wood beneath starboard rubber rail. Remove rubber rail and replace rot wood same as original.

Found FRP crack starboard forward space below hand rail stanchion. Repair damaged FRP.

Unable to inspect port & starboard strut welds due to resin and paint. Remove resin and paint on the strut welds.

Make all through hull valves and fittings avialable for inspection.

Found total (13) wasted fasteners on port and starboard chain plates. Renew all chain plates nuts and bolts as original

Found rot deck wood forward of the main cabin. Replace all indicated rot deck wood with marine grade material.

Found death end wires forward port work shop. Remove death end wires.

Found disconneted light fixture with death end wires in starboard work shop. Remove or repair light fixture.

Found deck rail stanchion missing fasteners forward main cabin port side. Install all missing screws.

Found weld cracks on deck rail stanchion starboard. Repair all indicated weld cracks.

Found damage FRP in starboard Keel. Repair indicated damaged FRP same as original.

Prove proper operation of stbd engine bilge pump.

Renew wet exhaust hose for both engines.

Renew stbd and port fuel vent hose and install 30x30 mesh flame screen.

Prove proper operation of stbd alarm light for fixed fire extinguishing system.

Provide one additional red hand flare.

Provide donning placard for 2nd type of life jacket.

Prove proper operation of high level bilge alarm in stbd midship compartment.

Provide inventory list to include age and recommend life span for all components, mast, and wire rigging IAW Hono CID note #13 dated 16Oct08.

Crop out de-laminated fiberglass to good glass and make permanent repairs to starboard hull outborad side mid ship near skeg.

Crop out de-laminated fiberglass starboard hull inboard side mid-ship near skeg, approximate 4' x 2' and make permanent repairs.

Crop out de-laminated fiberglass starborad hull inboard side 10 feet aft of mid-ship approximate 1' x 1' and make permanent repairs.

Crop out de-laminated fiberglass starboard hull inboard side 20 feet aft of mid-ship near skeg approximate 2' x 2' and make permanenet repairs.

Crop out de-laminating fiberglass port hull outboard side 15 feet from bow near bottom to mid-ship and make permanent repairs.

Crop out de-laminating fiberglass port hull keel near midship and make permanent repairs.

Remove damaged adult lifejackets.

Repair or replace both lifebuoys.

Remove metal clip from starboard lifebuoy.

Replace all expired items in first aid kit.

Found vessel missing Tidal Current Table. Prove Tidal Current Table or calculation method is on board the vessel.

Found magnetic compass not illuminated. Prove proper operation of compass light. Temporary lighting authorized until due date.

Found starboard engine room bilge audible alarm not properly operating. Repair or replace alarm.

Found crew unable to properly recover an unconscious victim. Provide a harness or means of recovering an unconscious victim.

Found vessels Certificate of Inspection not posted. Post COI with all pages visible.

Found vessels Stability letter not posted. Post stability letter in visible location.

Found vessels marine Charts not current with corrections. Prove charts are current with corrections.

Found Navigation publications not up to date. Prove all publications are current.

Found deck rail stanchions damaged. Make permanent repairs to deck rails.

Found life buoy retro-reflective tape worn. Repair or replace retro-reflective on life buoys.

Found fuel oil system without emergency shutoff valves on main engines. Prove main engines have emergency fuel oil shut downs.

Found fuel oil tanks shutoff valves not operable. Demonstrate proper operation of shutoff valves.

Found no closure devices for natural ventilation duct for engine room ducting. Demonstrate proper closure of ventilation ducts.

Found dead end wires in the main electrical panel. Repair or remove dead end wires.

Found non-approved electrical wiring throughout the vessel. Replace wiring with CG approved marine grade wiring.

Found vessel missing valid FCC Radio Safety Certificate. Prove vessel has valid FCC Radio Safety Certificate.

Found the vessel's Certificate of Inspection expired on 15Mar06.

Fixed extinguishing system(s) not annually serviced. Proper servicing shall be conducted not later than 10 Jun 2002. LEGACY COMPONENT DESC: Servicing

Provide a compass with light for the vessel. The vessel is restricted to operations within Tanapag Harbor only until completion.

Conduct emergency crew drills with sails set in the presence of the attending USCG marine inspector.

Provide 6 hand held orange smoke distress signals.

Service the 2 portable fire extinguishers in the port and stbd engine rooms.

Renew the main sheet traveler line.

Prove the operation of the audible high level bilge alarms for the port andstbd engine rooms.

Provide a total of 6 red distress flares for the vessel.

Provide an 8 inch navigation bell with mounting bracket for the vessel.

Prove the operation of the safeties and alarms for the pre-engineered fire fighting system in the stbd engine room.

Label all high level bilge alarms and pre-engineered fire fighting alarms at the operating station.

Prove the operation of the port fire/bilge pump.

Prove the operation of the high level bilge alarms in the port engine room and port aft compartment.

Provide sufficient length of hose for the portable bilge pump. The bilge pump shall be capable of dewatering any compartment directly overboard.

Install watertight bulkheads required in the vessel's stability letter dated September 13, 1994 at frames 12 and 28 in each hull. Failure to comply with this requirement will result in reduction of passenger count tonot more than 49 passengers.

Stencil vessel name and place retro-reflective tape on the vessel's ring buoys.

Replace missing handles for hatch covers.

Currednt life ring buoys installed on board are not of an approved type. Replace in accordance with 160.050.

Up-date first aid kit contents.

Secure port sea strainer and associated piping.

Remove dead ended wiring from follwing areas: Port E/R (electric bilge pump), inboard wiring STBD E/R. Remove wire nuts from STBD M/E room and switchboard.

Install fixed gas fire ext system as per 46 CFR 181.410/420, 185.612.

Replace fuel line in port M/E room.

Install bilge high level alarms as per 46 CFR 182.530.

Each floating waterlight must be attached to the lanyard with a corrosion resistant clip as per 46 CFR 180.70.

Obtain portable watertight containers for distress flares and smoke signalsof a bright color. Containers shall be clearly marked in .5 inch letters "DISTRESS SIGNALS."_x001C_ _x001C_

Amend current emergency instructions to include flooding as per 46 CFR 185.512._x001C_ _x001C_ _x001C_

Elect bond fill piping to tank as per 46 CFR 182.445_x001C_ _x001C_ _x001C_ _x001C_

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Each operator of vsl must obtain FCC Operators Permit as per 47 CFR 80._x001C_ _x001C_ _x001C_ _x001C_

Placards containing instructions for the donning and use of life jackets aboard the vessel must be posted in conspicuous places that are regularly accessible and visible to the crew and passengers, as per 46 CFR 185.516

Obtain fire hose nozzle as per 46 CFR 181.320(d).

Install pressure guage at pump outlet, demonstrate 25gpm at 60psi as per 46CFR 181.300(b).

Provide/install firefighting hose as per 46 CFR 181.320(b)(1)._x001C_ _x001C_ _x001C_ _x001C_

INSTALL HAND RAILS AND EMERGENCY EXIT SIGNS FOR EMERGENCY ESCAPE LADDER.

INSTALL MEANS TO ACCESS AREA FORWARD OF THE COLLISION BULKHEAD FOR INSPECTION AND PUMPING BILGES WITH HAND BILGE PUMP._x001C_

CROSS SECTION MODULUS ON FORWARD DECK PLANKING AREA IS 25% UNDER SCANTILINGWITH 18" FRAME SPACING FOR UNDER DECK FRAMING. EITHER REDUCE THE FRAME SPACING OR INCREASE THE DECK PLANKING TO 1".

Properly mount and service portable fire extinguishers prior to carrying passengers for hire.

Provide currently corrected charts of operating area prior to carrying passengers for hire.

Properly post vessel stability letter.

Obtain and properly post required FCC certificates and licenses prior to carrying passengers for hire.

Properly post emergency check-off list prior to carrying passengers for hire.

Provide Coast Guard light list, Coast Pilot, tide and current table prior to carrying passengers for hire.

Provide proper portable/hand fire pump prior to carrying passengers for hire.

Properly mount EPIRB prior to carrying passengers for hire.

Install watertight bulkhead at frame 28 in accordance with Coast Guard approved plans.

Install all fixed seating and measure deck space in the presence of a CoastGuard inspector to determine passenger capacity prior to carrying passengers for hire.

Install proper watertight penetrations at frame 48 prior to carrying passengers for hire.

Install bolts for railing stanchions that fully penetrate nuts prior to carrying passengers for hire.

Properly mount all required placards prior to carrying passengers for hire.

Properly mark bilge manifolds prior to carrying passengers for hire.

Provide proof of enrollment in random drug testing program prior to carrying passengers for hire.
