BADGER

Cables located in dry locations shall be any cable constructed and classed as to type of insulation and mechanical covering in accordance with paragraph (b) (2) and(3) of this section. Provide proposal to MSU Sturgeon Bay for either full replacement of or an acceptable repair of the damaged single conductor cable from the #2 24VDC. Repairs must be made during the 2026/2027 dry-dock or winter lay-up. Cite: 46 CFR 111.60-1(d)(3) (old J)

Watertight integrity above the margin line in a vessel of 100 gross tons or more. Each opening in an exposed weather deck must— (1) Have a coaming that complies with the height requirements in table 171.124(d); and (2) Have a means for closing it weathertight. Provide a repair proposal for renewing the damaged sea gate to include the name of the vessel within 30 days.

It shall be the duty of the master or other person in charge of the vessel to see that all of the provisions of the certificate of inspection are strictly adhered to. Nothing in this subpart shall be construed as limiting the master or other person in charge of the vessel, at his own responsibility, from diverting from the route prescribed in the certificate of inspection or taking such other steps as he deems necessary and prudent to assist vessels in distress or for other similar emergencies. Due to the loss of the sea gate, vessel is to be operated in seas less than 8'.

Vessel must meet all applicable stability and subdivision requirements of sub chapter S and Classification Society Rules. Make permanent repairs to the area on the stern damaged by the marine Casualty that occurred on 17 SEP 2025.

On vehicular ferries, suitable chains, cables, or other barriers shall be installed at the ends of the vehicle runways. In addition, suitable gates, rails, or other devices shall be installed as a continuation of the regularly required rails. Install temporary rails while underway to prevent persons from falling overboard until the reinstallation of the sea gate.

During each inspection a demostration of the proper condition and operation of rescue boat shall be demostrated. Rescue boat did not function as intended repair rescue boat to the satisfaction of the marine inspector in a timely manner.

Fire doors 10 and 12 did not properly close.

Emergency lighting in engine boiler room is no longer designated with required markings.

Lifejacket stowage in engine boiler room were not marked with indicator or quantity.

Each launching appliance must be fitted with brakes that are capable of stopping the descent of the survival craft or rescue boat securely when loaded with its full complement. Starboard forward life boat davit winch slipped before coming to a stop when tested.

The installation of all systems of an electrical engineering or interior communications nature, together with the details of design, construction, and installation, shall be in accordance with the requirements of subchapter J (Electrical Engineering) of this chapter. Found an oil leak on the strbd side turbogenerator.

Position indicator at remote closure for WTD #4 is broken. Prove proper operation of indicator.

Escape ladder in upper boiler room has been cut 2 rungs short Fabricate and install a way to access the existing ladder without impeding the hinged grating for hoist access prior to 2023 COI inspection.

Lifeboat #3 is corroded and wasted through the bottom in way of aft stbd side outboard from drain plug. Vessel is restricted to carriage of not more than 540 passengers. Make permanent repairs as original to the satisfaction of the attending Marine Inspector.

Fire detection panel did not alarm properly for all zones. Prove proper operation of fire detection.

Upon USCG Sector Lake MI approval, repairs shall be made to all Cabin Deck plates corroded or wasted more than 25%. All repairs to be verified and to the satisfaction of the attending CG Marine Inspector. Repairs must be verified by an attending CG MI on or before May 15, 2022 and before carrying passengers for hire. As required by 46 CFR 71.55-5

Observed from upper vehicle deck, numinous existing cabin deck plates corroded or wasted more than 25% of original. In addition, noted numinous existing doublers previously installed. Company rep provided correspondence between Bay Engineering Inc., USCG MSC, MSD Sturgeon Bay, and MSO Milwaukee OCMI dated October 1996 thru October 1997, reflecting ¼ inch ABS grade A or ASTM A-36 plate, doubler plates were allowed to be installed per BEI SS BADGER Cabin Deck Corrosion-Patching Arrangement & Details drawing 110-01, Rev B. Drawing approved per USCG MSC Ltr H2-9702438, dated July 22, 1997. Considering documentation provided, company required to re-submit a revised drawing to USCG Sector Lake, MI., which identifies cabin deck plates wasted and required repairs.

Coast Guard Data Base MISLE Reflects annual user/inspection fee's for account 265156JUN21 have not been paid. Contact USCG CG FINCEN at Phone: [phone withheld], Toll Free: 1-[phone withheld] or Email: [email withheld] and make payment. Thereafter or if paid, provide documentation to attending CG Marine inspector reflecting payment was made IAW 46 CFR 2.10-101

General Alarm bells in various spaces were found not working or found with tone inadequate. Repair or adjust and prove proper operation.

Port bow anchor crown pin was found fractured during inspection. Make proper repairs to satisfaction of ABS/USCG

Sanitary conditions of crew accommodations were on poor condition. Showers throughout were rusty, missing paint or had not been cleaned. Rectify sanitary condition.

Floor tile and condition of flooring throughout many crew spaces were detached or raised from the deck. Company to survey and submit corrective action plan to Sector Lake Michigan to address.

Conduct a full load weight test on davits for lifeboats No. 1, No. 3 and No. 5 upon arrival in Manitowoc. Wi in the presence of a Coast Guard Marine Inspector.

Provide copy of the service reports for the fire extinguishers, Inflatable Buoyant Apparatus's (IBA's) and Great Lakes Radio agreement annual inspection.

Replace worn vent fan flexible boot on vent aft of pilothouse upper deck.

Provide onboard an approved vessel security plan (VSP)

Master was not aware of who the Company Security Officer (CSO) was as the vessel had gone through change of ownership. Update security plan to reflect new company CSO with name and contact number.

Fire screen door No. 8 does not fully close when magnetic release is activated. Prove proper operation.

4 foot applicators would not attach to the navy all purpose nozzles and chains where found detached on the nozzle cones. Survey all fire stations and ensure all chains are attached and prove applicators will attach to the nozzles.

Painters and weak links were not attached to IBA's.

Various lights were found removed and unwired throughout the passenger cabin. Reinstall and prove proper operation of lights and emergency lighting throughout ship.

Fire alarm ilumintation light was found inop. Repair and demonstrate proper operation.

Vessel had onboard new EPIRB. New EPIRB was missing registation decal although record of registration was provided. Upon reciept provide proof EPIRB registation decal is installed.

Aft port boiler after drum would not fully lift after multiple attempts within set range. Prior to placing boiler in service prove proper operation.

No. 3 feed pump is out of service due to a faulty impeller. prove proper operation and demonstrate operation of overspeed trip.

Due to change of ownership vessel security plan must be audited. Provide documentation of Audit, Drills and last exercise.

During attendance a small fire was discovered by Marine Inspectors consisting of oil soaked lagging on the starboard aft draft fan turbine. Clean Fan space and remove all oil soaked lagging on all turbines in the space and renew lagging.

Ship Service Air compressor was out of service. Prove proper operation.

Pitting and wastage noted in tanktop of #3 ballast in way of coal conveyor/crusher equipment. Crop and renew as per repair proposal dated Oct 19, 2020.

Wastage noted on bilge floor frame #79 and bracket port side coal conveyor space. Crop and renew to satisfaction of attending Marine Inspector.

Corrosion wastage noted on trip brackets of side frames to deck at vehicle deck stbd side #24 & #36. Crop and renew to satisfaction of attending Marine Inspector.

Observed low water level alarm on the forward stbd propulsion boiler did not reflect correctly on monitoring and control system history. Investigate and resolve issue on or before November 26, 2019.

Counterweight on brake lever for #1 lifeboat contacts the gearbox housing and does not properly engage when released by operator. Adjust counterweight to prevent contact with gearbox housing when released.

Observed gasket(s) missing for doors to sideport opening stbd side for emergency egress to IBA/rafts. Install proper gaskets/seals to maintain weather/watertight integrity of sideport.

Each self propelled vessel must have at least two electric generatoring sources i.a.w. 46 CFR 111.10-3 Vessel's Stbd SSTG was unable to maintain adequate electrical load due to failure of voltage regulator.

Vsl is broadcasting: Call Sign from expired FCC License, invalid IMO #, and NAME with Vsl type precursor (NAME must not include Vsl type precursors, e.g. F/V, M/V).

Disassembly and inspection of forward horizontal falls sheave on Lifeboat Davit #4 indicated bearing failure. Renew/repair sheave, retest in presence of CG Inspector. Vessel passenger count reduced to 540 until resolved.

Lifejacket stowage in passenger staterooms must be stenciled where location is not readily visible i.a.w. 46 CFR 78.47-45

Exit lamps not illuminated in several locations i.a.w. 46 CFR 78.47-40

Lifeboat falls splices should be Wrapped (whipping) tight 46 CFR 199.190 / 199.153

General alarm bell not ringing centerline vehicle deck frame #14

Fire door from vehicle tween deck to fwd crew berth not closing/latching tight. 46 CFR 72.05-25

Deck covering in wheelhouse port side is lifting and creates tripping hazard. 46 CFR 72.20-05

Dead end wire located in centerline overhead of vehicle deck must be connected or removed or proven no longer in service and disconnected from power source.

Remote manual linkage not operating for Sliding watertight door #5 Bhd 191. Corrected prior to completion of inspect.

Stbd anchor was lost during manuvering at the dock in Ludington, MI. Vessel is required to have 2 anchors.

Bilge manifolds port and starboard manifolds in boiler room not properly labeled i.a.w. 46 CFR 78.47-38

Conduct hydro test of fwd port boiler to 750 psi in presence of CG Marine Inspector. Side wall tubes leaking during initial season light off of fwd port boiler. It was estimated that 03 tubes required renewal and subsequently 08 were renewed. Boiler was not returned into operation until a satisfactory hydro test conducted with ABS and CG present.

Prove proper operation of port fwd boiler and set safety valves. Boiler shall not be placed into operation until after a hydro test conducted with ABS and CG present. Side wall tubes leaking during initial season light off and operation of fwd port boiler. It was estimated that 03 tubes required renewal and subsequently 08 were renewed.

Prove escape scuttle hatch to #6 Hold space on car deck is watertight.

Conduct full weight test and light weight test of starboard lifeboats #1, #3, #5 in accordance with 46 CFR 199.45

Power supply for gyro compass and repeater must be independent of the EDG start battery or general alarm battery i.a.w. 46 CFR 113.25-7(b)

Connect escape piping to relief valve of dearating tank.

Prove proper operation of all General alarm bells. Bells in passenger accomodation passageways and various other vessel compartments not ringing loudly or did not operate at all. Corrected prior to completion of inspection.

Hydrostatic test of Aft Port Boiler identified leaking generating tube. Engineering crew to isolate and plug leaking tube and retest to the satisfaction of attending marine inspector.

Vent/grease extraction hood above stove in galley accumulated with dirt and grease.

Fire door #14 and #15 on the cabin deck are prevented from closing when passenger seat, closest to door, is reclined. Ensure fire doors are able to fully close.

Unlicensed crew assigned abandon ship duties are not completely familiar with the operation and deployment of IBAs. Implement additional training or other methods to improve knowledge of crew members assigned to emergency duties.

Re-install soft patch on coal day-bunker feeder system piping on the upper level in between boilers.

Install grab rail on front of galley stove for the safety of personnel.

Lifeboat #6 was holed in way of bottom drain. Submit repair proposal and make proper repairs in accordance with approved procedure. Vessel is restricted to carriage of 585 passengers until reapirs completed to the satisfaction of an attending Marine Inspector.

Conduct full load weight test of #6 lifeboat/rescue boat, davit and falls in accordance with 46 CFR 199.45(b).

Make proper repairs to fire main piping in way of frame #157 sbd side vehicle deck at staion #33 and conduct hydrostatic test of repairs to the satisfactio of an attending Marine Inspector.

Annual full load weight test of starboard lifeboat davits and falls unable to accomplish due to mooring arrangement to stbd side. Conduct full load weight test of #1, #3, & #5 davits and falls at earliest opportunity when vessel docks in Manitowoc.

Deck rails in vicinity of port and starboard raft (IBA) stowage and release racks were wasted and broken in several spots. Make suitable repairs to same.

Post emergency radio broadcast instructions in vicinity of VHF radios.

#1 lifeboat release hook was repaired and satisfactorily weight tested but requires non-destructive testing (dye penetrant) subsequent to full load weight test.

Launching appliance for number 1 lifeboat failed and aft davit would not release.

Gyro was hunting and not operationing properly.

Two required Class "A" fire doors would not properly close.

Sheave mounting bracket for #5 lifeboat davit falls is fractured. make proper repairs and conduct 110% load weight test. Vessel restricted to not more than 540 passengers.

Emergency lighting for STBD circuit not operating de-energized for repairs to adjacent piping in overhead Texas deck. Prove proper operation of all "E" lights.

Aft wheel house helm binds at points through wheel rotation. Make repairs and prove proper smooth and even operation of afte helm wheel.

Deck plates in machinery spaces not properly secured. Secure loose deck plates in machinery spaces.

Aft masthead/range light not operational, disconnected for maintenance. Prove proper operation of aft masthead/range light.

Coal ash retention system not operational/under repair. Prove proper operation of ash retention system.

Superheater casing cover for stbd fwd boiler is missing studs/nuts for cover mounting. Install/repair studs for casing cover mounting.

Steam stop valves at boiler room to engine room bulkhead are not insulated. Install suitable insulation where necessary to preclude injury to personnel i.a.w. 46 CFR 56.50-1(k).

Fire main piping leaking in way of overhead line crew's berthing passageway, Texas deck just forward of fire station #6. Make permanent repairs to satisfaction of an attending marine inspector.

Your request to employ a 1st AE Motor/2nd steam in lieu of 1st AE steam & promote 1A/E to C/E is approved in accordance with 46 CFR 15.825. You may temporarily adjust manning until end of the operating season in October 2014. You may be manned as follows: 01-C/E, 02-2nd (steam), 01 3rd.

Test releasing gear for the #2 Lifeboat at waters edge.

Repair #1 and #2 lifeboat aft sheave brackets that are warped and fractured. Reduce passenger capacity by 120 persons until repairs have been made to the lifeboats in the presence of an attending CG MI.

Repair #1 lifeboat brake system (note, written CG-835 had listed #2 lifeboat. Spoke to Master, [name withheld], on 20MAY14 regarding correction). See item #1 for passenger reduction.

Provide emergency lighting along all egress routes and survival craft embarkation locations, particularly on the cardeck, lifeboat, and liferaft locations. This was a "blanket" requirement for E-lts; most of the E-lts had been repaired or where being repaired at the end of the inspection and will need to be verified for completion.

Provide proper bracket and repair lifering bouy light located on car deck between stbd frames 116 and 118. Light lens was found fractured and the mounting bracket was too big and held the light loosely resulting in the light falling out onto deck.

Provide machinery covers or guards to rotating shafts (ventilation motors) in the aft "Fidley" fan house/machinery space.

Batteries for fire alsarm system have excessive corrosion on terminals and connections. Clean and prove good electrical contact.

Fire main above overhead ceiling tiles along port passageway on the "Texas" deck had leak along weld seam. Cropped and renewed satisfactorily during inspection.

Fwd sheve/block on #1 life boat installed at improper angle resulting in binding and improper operation. Master stated that sheve/block will be removed and installed correctly during winter lay up.Proper operation demonstrated on/before 31May2012.

Galley pantry E-light cover is loosely hanging

Install blank plug on side of galley pantry electrical breaker panel #T3

Adjust self closing door fwd of immersion suit stowage room port side, master requested repairs be made over the winter lay up. Extended date to on or before 31 May 2012

Make repairs and verify E-light in children's recreational room.

Make repairs to the #1 lifeboat releasing gear motor controller and fwd sheave. PAX and crew carriage lmited to 665 persons until repaired.

Install/add embarkation ladders for and at each lifeboat embarkation deck.

Complete waterside inspection of all four propulsion boilers to include mud drums iaw 46 CFR Table 61.05-10.

Provide 43 additional TPA's. Vessel is limited to carrying no more than 637 total persons until additional TPA's are onboard.

Conduct full load weight test for lifeboat #5 iaw 46 CFR 199.45(b)(1).

Conduct boat drill for stbd lifeboats to include test of on-load release gear and exercise of fleming gear iaw 46 CFR 199.180(d)(4).

Provide procedure to be used to ensure compliance with 46 CFR 16.210 during winter layup period. If crewmembers do not meet exemption in 46 CFR 16.210(b)(2), they must pass a pre-employment drug screening.

Adjust #14 fire door so that it closes freely upon release from hold-back iaw 46 CFR 72.05-25(b)(9)(ii).

Connect fire hoses to hydrants iaw 46 CFR 76.10-10(h)

Repair rotten fleming gear support boards in #5 lifeboat iaw 46CFR 199.190(f)

Replace missing bulb in e-light at stbd liferaft station.

Install indicators at remote WTD operating stations to indicate open/closed.

Install e lighting in immersion suit locker area and prove proper operation.

At next Drydocking renew all Car Deck Hatches.

Prove proper operation of all Watertight hatches main deck and chauk test same.

Properly install all dogs on aft boiler access covers.

Effect repairs to the continous blowdown valve on the after port boiler valve to the satisfaction of the attending marine inspector.

Repair or replace diesel line cut-off valve in overhead for the emergency generator.

Replace all worn and painted retro-reflective material on the lifeboats.

Repair knife edges and gaskets in escape hatches for the machinery space on car deck and chalk test the same.

Make permanent repair to temp repair to piping on the stbd aft boat deck submit plans or approval prior to commencement.

Replace The cover for Fire Station #2.

Replace all wiring on outer deck lighting where the metallic sheathing to the wires is missing iaw 46 CFR 111.05-7.

Repair #1 lifeboat port handrail.

Replace stbd ladder ivo of lifeboat #5 platform.

Effect perminent repairs in way of the Starboard Boat deck Pipe Chase.

Relocate cleats on all IBA storage racks to prevent fouling of painters and weak links.

Provide and mount near all escape scuttles for all void spaces on the car deck spanner wrenches.

Remove all boxes from paint locker and provide lids for all open cans of paint.

Effect repairs to the fire main in way of Fire Station No. 13.

Provide ten 1 1/2 inch fire hoses.

Make repairs to deck plating in way of Boat Deck's stbd stair tower: wastage penetrated deck plating.

Provide 15 operable radios for crew to use during drills, routine patrols.

Provide locking devices for all panelboards accessible to passengers in accordance with 46 CFR 111.40-9.

Provide panel directories for all panels per 46 CFR 111.40-11.

Provide Deadlight cover for the portlight located on the portside car deck at frame 60 per 46 CFR 171.117.

Provide suitable size Immersion suit for crew per 46 CFR 199.70

Repair damaged and missing dogs, and demonstrate operation of the following hatchs on the car deck: Coal Bunker forward Hatch, Void No. 3, and Chain Locker.

Replace fractured sections of fire main pipe.

Replace plastic trash cans in galley with metal trashcans.

Repair General Alarm power system so that each bell rings throughout vessel.

Repair door latch. Door not able to close due to latch.

Gauge firemain and sprinkler system to determine extent of wastage paying particular attention to the undersides of the horizonal runs in the car deck area and submit findings to MSU Chicago.

Prove proper operation of the port forward boiler and attached hand lifting gear.

Prove proper operation of the standyby generator high jacket water alarm.

Properly support all wiring in the Bingo Locker with Metalic straps 24" on center.

Provide proof that coaxial cable meet 46 CFR 111.60-2, located in seagate winch room next to the aft steering station.

Provide non-conducting mat in way of the electrical panel in the winch room. LEGACY COMPONENT DESC: Metallic Enclosure/Frame

Remove all dead-end wires throughout vessel. LEGACY COMPONENT DESC: Wiring

Remove all plastic wire ties supporting wires throughout the vessel and replace with steel devices spaced at no more than a maximum of 24". LEGACY COMPONENT DESC: Wiring

Replace melted light cover located on the boat deck, port side. LEGACY COMPONENT DESC: Lighting Fixture

Prove rope lighting in boutique complies with 46 CFR subchapter J. LEGACY COMPONENT DESC: Lighting Fixture

Remove end seating in Rows 1 and 2 of museum space to improve flow of egress out of space. LEGACY COMPONENT DESC: Recreation Space

Repair egress handle inside deep freezer door.

Provide corrected fire control plan with proper IMO/ASTM symbols. LEGACY COMPONENT DESC: Fire Control Plans

Complete Port and Starboard evacuation stairwells in accordance with approved plans. LEGACY COMPONENT DESC: Boarding Ramp/Ladder

Prove proper operation of W.T.D. No. 1. Door must close completely. LEGACY COMPONENT DESC: Doors

Repair of renew leaking hydraulic pump for W.T.D. No. 2 located in the boiler room, and prove proper operation of door. LEGACY COMPONENT DESC: Doors

Prove proper operation of all escape hatches and renew all gaskets.

Conduct static weight test, and prove proper means of launching No. 5 lifeboat. LEGACY COMPONENT DESC: Davit

Prove proper operation of the Port Forward Boiler hand lifting gear for all 3 Safety's.

Vsl required to install port and stbd stairwell evacuation station to meet 46 CFR 199.630(d)(1). LEGACY COMPONENT DESC: Designated Location

DEVELOP PROGRAM TO TEST AND INSPECT STATEROOM SMOKE DETECTORS LEGACY COMPONENT DESC: Smoke Detectors

PROVIDE [name withheld] WHICH FUNTIONS FROM BRIDGE TO ALL AREAS OF SHIP. LEGACY COMPONENT DESC: VHF Radiotelephone

REMOVE PIZZA OVEN FROM VESSEL AS REQUIRED BY MSC LETTER SERIAL # H2-0306306 PARA #2 LEGACY COMPONENT DESC: ELECTRICAL

PROVIDE SECURITY TRAINING TO VESSEL CRUISE DIRECTOR

POST LIFE JACKET DONNING INSTRUCTIONS

REMOVE ALL STORED MATERIAL IN STATEROOM #24

REPLACE PORT AND STARBOARD NON-METALIC EXPANSION JOINTS ON SUCTION SIDE OF CONDENSATE PUMPS. LEGACY COMPONENT DESC: Piping

PROVE PROPER OPERATION OF LOW LUBE OIL AND HIGH WATER TEMP SHUTDOWN ON AUX GEN SET ON CAR DECK. Granted extension to 1 May to allow work to be completed during spring quarterly. [name withheld] DESC: Indicator Circuitry

PROVIDE PROPER PROFESSIONAL ENGINEER ANALYSIS OF THE STRUCTURAL IMPACT CREATED WHEN THE BULKHEAD SEPERATING IN STATEROOMS #45 AND #48 WAS REMOVED. LEGACY COMPONENT DESC: Longitudinal Bulkhead

PROVIDE PROPER P.E. FIRELOAD ANALYSIS OF THE WHOLE LOWER PASSENGER CAFE' DECK AREA, TO INCLUDE NEW SEATING, COIN MACHINE, D.J. EQUIPEMENT, TABLE, CHAIR, LOWER PASSENGER GALLEY, TV'S, BAR, CRUISE DIRECTOR OFFICE SPACE. LEGACY COMPONENT DESC: Accommodation Space Protection

PROVIDE PROPER SEATING ARRANGMENT PLANS FOR NEW AIRPLANE STYLE SEATING AREAS PORT AND STBD AFT LOWER PASSENGER CAFE DECK.

PROVIDE PROPER SEATING ARRANGEMENT PLANS FOR THE NEW FAST FOOD MODULAR TYPE TABLES W/ CHAIRS ON THE NEW PASSENGER SPACE ON THE AFT LOWER PASSENGER CAFE' DECK.

PROVIDE ANALYSIS OF THE PASSENGER EMERGENCY ESCAPE ROUTE DUE TO POTENTIAL IMPACT CREATED BY THE NEW FAST FOOD MODULE SEATING AND NEW BULKHEAD CREATING THAT SPACE.

PROVIDE PLANS FOR THE NEW BULKHEADS, DOORS AND WINDOWS IN WAY OF THE AFT STEERING STATION, LOWER PASSENGER DECK.

PROVIDE FIRE LOAD ANALYSIS OF THE KIDDY ROOM AND ITS CONTENTS.

Renew vessel name stencil on all Life Ring Buoys (as needed). LEGACY COMPONENT DESC: Markings (ship name/port)

Remove unprotected center light fixture in the windlass room. LEGACY COMPONENT DESC: Lighting Fixture

Move car fire fighting gear on upper car deck to a more accessible location, when vehicle are loaded the gear box is in-accessible.

Properly label mid-deck level ventilation hatches w/ "Close in case of Fire". LEGACY COMPONENT DESC: labelling

Provide proper protective guards around the starboard and port sea gate sheaves near the aft steering station.

Provide a functional portable communications system (Radios) for navigation crew and customer care crew. LEGACY COMPONENT DESC: Portable Radios

Make mounts for all four foster wheeler boilers available for inspection prior to 01May2003 LEGACY COMPONENT DESC: Mount

Repair and prove proper operation of all main boiler feed pumps.

Repair and prove proper operation of Emergency generator.

MAKE PROPER REPAIRS TO THE AFT FLICKER EMERGENCY ESCAPE HATCH TO THE SATISFACTION OF THE ATTENDING U.S. COAST GUARD MARINE INSPECTOR.

REMOVE IMPROPERLY INSTALLED ELECTRICAL WIRES WHICH PASS THROUGH THE EMERGENCY GENERATOR ROOM'S AFT PORTLIGHT.

PROPERLY PLACARD PORT AND STARBOARD CABIN DECK LIFESAVING GEAR STOWAGE LOCKER TO SEPERATELY INDICATE THE NUMBER OF STOWED PFDS AND THERMAL PROTECTIVE AIDS.

FOLLOWING EACH COAL TRANSFER, CLEAN SEATING SURFACES OF THE #3 WATERTIGHT DOOR. MAKE PERMANANT ARRANGEMENTS TO KEEP SURFACE CLEAN AND ENSURE PROPER SEATING OF DOOR.

DO NOT OPERATE THE NEW AIR CONDITIONING SYSTEM UNTIL SYSTEM PLANS AND INSTALLATION HAVE BEEN APPROVED BY THE USCG.

IAW MSO CHICAGO I&I POLICY #4-99, SUBMITT AN IBA CREWMEMBER TRAINING PROCEDURE FOR REVIEW BY MSD GRAND HAVEN.

FOLLOWING EACH COAL TRANSFER, CLEAN SEATING SURFACES OF THE #3 WTD. MAKE PERMANANT ARRANGEMENTS TO KEEP SURFACE CLEAN.

DO NOT OPERATE, FOR PROPULSION OR POWER, THE STBD AFT BOILER UNTIL SAFETY VALVES ARE SET BY THE USCG MARINE INSPECTOR. AS AN OPERATING CONDITION, VESSEL MAY OPERATE NORMALLY (IE. DEPART LUDINGTON) W/ AT LEAST 3 BOILERS INOPERATION, & MAY RETURN TO LUDINGTON W/ 2 BOILERS.

Center arm on the carriage assembly of the gyro not seated properly.

MAKE THE FWD-STBD BOILER AVAILABLE TO THE USCG MARINE INSPECTOR TO SET AND SEAL THE SAFETY VALVES PRIOR TO SAILING ON 15MAY99.

PROVE PROPER OPERATION OF THE FWD-STBD BOILER PRIOR TO SAILING ON 15MAY99.

WEITH TEST AND PROVE PROPER OPERATION OF ALL STARBOARD SIDE LIFEBOATS UPON FIRST PORT CALL IN MANITOWOC, WI, IN THE PRESENCE OF THE USCG.

Weight test the numbers 1, 3 and 5 lifeboats in the presence of USCG marineinspector.

Provide original plating thickness to compare to gaugings taken by Bay Shipbuilding representatives where they are absent to enable a marine inspector to make a determination whether plating is within allowable tolerances.

Nonmetallic expansion joints for main circ system due for renewal in accordance with 46 CFR 61.15-12(b). Renew all nonmetallic expansion joints located in a system which penetrates the hull in which both the penetration and the expansion joint are below the deepest load waterline.

Sideshell frames and longitudinals are wasted in way of the stbd side outboard of the water softeners and on the lower level below them. _x001C_ Crop and renew to good metal wasted areas of framing, decking and associated internal members.

Replace in kind and prove proper operation of the admission valve for the #3 cylinder on the starboard main engine.

Prove proper operation of the port generator governor control valve.

Hydro port forward boiler, and set and seal safety valves prior to operating boiler with passengers onboard.

Place type II retroreflective material on all lifeboats to meet the requirements in IMO resolution A.658(16).

Conduct weight test of all 3 starboard lifeboats.

Properly install acceptable flex fuel hose on emergency generator to replace worn supply and return hose.

Prove proper installation of 2 FI feed tubes from mud drum to fire wall header on port forward boiler.

Vessel may operate with 3 boilers under the following conditions: tow vessels must be reasonably available and shall be used prior to entering a harbor if the vessel loses one of its 3 operational boilers prior to the port forward boiler being placed back in service.

PROVE SATISFACTORY WATERTIGHT INTEGRITY OF ALL WATERTIGHT DOORS ON VESSEL.

CROP AND INSERT AS ORIGINAL DEEP WEB FRAMES #88 AND #94 PORT AND STARBOARD FROM WEB TO WEB AND FROM TANK TOP UP TO GOOD METAL.

Prove proper installation and satisfactory operation of car deck exhaust fans and provide approved plans.

Complete temporary repairs to overhead in car deck per plan proposal in BayEngineering letter dated 29APR96.

Make addition to sprinkle zone 9 to provide adequate coverage under ramps including approved plans.

Repair and make all watertight doors watertight.

Prove proper installation and operation of mid car deck ramps.

Crop and renew back to good metal all wasted overhead areas located above car deck.

PROVIDE CURRENT COMPASS DEVIATION CARD.

REPLACE RETROREFLECTIVE TAPE ON PILOTHOUSE EXPOSURE SUIT.

PROVIDE ACID RESISTANT LINING IN GENERAL ALARM BATTERY BOX. ALSO, REMOVE OLD BATTERIES AND WIRING.

CONDUCT WEIGHT TESTS ON LIFEBOATS #1, #3, AND #5; AND EXERCISE THE RELEASING GEAR ON THE SAME BOATS.

ADJUST CLOSING DEVICES AND/OR DOORS TO PROVIDE FULL CLOSURE INCLUDING LATCHING AUTOMATICALLY ON FIRE SAFETY DOORS #7 AND #8.

PROVIDE RING TERMINAL ON WIRE CONNECTED TO THE POSITIVE TERMINAL OF THE FIRE ALARM BATTERY.

REPAIR OR RENEW ON/OFF SWITCH FOR VENT FAN ON STARBOARD SIDE OF GALLEY.

RENEW DECK PLATING STARBOARD SIDE IWO PASSENGER WALKWAY MAIN CAR DECK BETWEEN FRAMES 142 AND 150. THIS REPAIR TO BE COMPLETED PRIOR TO PLACING VESSEL INTO SERVICE SPRING 93, AND NO LATER THAN COMPLIANCE DATE.

OPEN BOILER MOUNTINGS FOR INSPECTION BY A USCG MARINE INSPECTOR NOT LATER THAN 30 NOVEMBER 1992. IF THE PROPULSION PLANT IS OUT OF SERVICE, THIS REQUIREMENT MAY REMAIN OUTSTANDING UNTIL 30 APRIL 1993.

MAKE LIFEBOAT #5 AND ITS EQUIPMENT AVAILABLE FOR INSPECTION, AND CONDUCT A WEIGHT TEST AS SOON AS THE LIFEBOAT IS PLACED BACK ABOARD BUT IN NO CASE LATER THAN JULY 1, 1990.

REPAIR BOW ANCHOR WINDLASS AND PROVE SATISFACTORY OPERATION.

PLACE #5 LIFEBOAT BACK ON BOARD THE BADGER COMPLETE WITH ALL EQUIPMENT NOT LATER THAN 15 JULY 1989. UNTIL THIS REQUIREMENT IS COMPLETED, THE VESSEL IS LIMITED TO A MAXIMUM OF 560 PERSONS (TOTAL OF PASSENGERS AND CREW).
