RIVERBOAT LOUIS ARMSTRONG

46CFR § 199.45 Tests and inspections of lifesaving equipment and arrangements.(a) Initial inspection. The initial inspection of lifesaving appliances and arrangements for certification includes a demonstration of—(6) The proper condition and operation of embarkation appliances, including embarkation ladders and marine evacuation systems; Make proper repairs to the STBD side embarkation gate damaged by earlier event and make proper repairs to the PORT side embarkation gate which is frozen by rust. Both gates are for the rescue boats.

The vessel is not ready for a COI inspection, issues with Fire Doors, Deck coverings, water leaking in overheads and on electrical lighting, door closures broken, windows broken all the above items discussed with the crew and they were instructed to conduct a vessel survey and make the vessel ready for the Inspection. Call when the vessel is ready. To be completed within 30 days and prior to carrying passengers.

§ 199.45 Tests and inspections of lifesaving equipment and arrangements. (b) Reinspections. Tests and inspections of the lifesaving equipment shall be carried out during each inspection for renewal of certification and periodic inspection, and shall include, as applicable, a demonstration of— (4) The proper servicing of each inflatable liferaft and inflatable lifejacket has been serviced as required under this chapter; The life rafts on board the vessel are over due for servicing and will be required to be serviced prior the the vessel getting underway and prior to carrying any passengers on board even dockside. This must be completed within 30 days of this 835 issue date by 10Aug25.

§ 72.01-15 Structural standards.(a) In general, compliance with the standards established by the American Bureau of Shipping, see subpart 70.35 of this subchapter, will be considered satisfactory evidence of the structural efficiency of the vessel. However, in special cases, a detailed analysis of the entire structure or some integral part may be made by the Coast Guard to determine the structural requirements. Make the temp. repairs to the main deck BLKHDS Around Vessel IAW 17Nov25 repair proposal.

§ 113.25-9 Location of general emergency alarm signal. General emergency alarm signal must:(a) Be located in passenger and crew quarters areas where they can alert persons in spaces where those persons may be maintaining, repairing, or operating equipment, stowing or drawing stores or equipment, or transiting, such as public spaces, work spaces, machinery spaces, workshops, galleys, emergency firepump room, bow thruster rooms, storage areas for paint, rope, and other stores, underdeck passageways in cargo areas, steering gear rooms, windlass rooms, holds of roll-on/roll-off vessels, and, except those that are accessible only through bolted manhole covers, duct keels with valve operators; and (b) Be audible in the spaces identified in paragraph (a) of this section with all normally closed doors and accesses closed; and (c) Be installed in cabins without loudspeaker installation. Other audible devices, such as electronic alarm transducers, are permitted. Currently 15 alarm bells are not working or not working properly. Make repairs and re-schedule the quarterly inspection within 2 weeks.

§ 78.37-5 Actions required to be logged. The actions and observations noted in this section shall be entered in the official log book. This section contains no requirements which are not made in other portions of this subchapter, the items being merely grouped together for convenience. (a) Onboard training, musters, and drills: held in accordance with subchapter W (Lifesaving Appliances and Arrangements) of this chapter. VESSEL IS RESTRICTED IN OPERATIONS THAT REQUIRE THE VESSEL TO GET UNDERWAY UNTIL ALL REQUIRED FIRE/SAFETY/ABANDON SHIP/SECURITY DRILL HAVE BEEN WITNESSED BY THE USCG. CONTACT SECTOR NEW ORLEANS DISPATCHER OFFICE WHEN THE DEFICIENCY IS TO BE CLEARED.

46 CFR 111.10-3 Power Supply. In addition to the emergency power sources required under part 112 of this chapter, each self-propelled vessel and each mobile offshore drilling unit must have at least two electric generating sources. Currently the SSDG's on board are not operating properly and cannot be paralleled either automatically or manually. Make repairs to the operation of these three SSDG's so the parallel operation is working properly. Prior to the vessel getting underway with passengers.

46CFR 113.40-5 General requirements. The position of the rudder, if power-operated, must be shown at the principal steering station. If there is non-follow-up steering control at the alternative steering station, there must be a separate rudder angle indicator system for that station that is electrically independent from each other rudder angle indicator system. Currently the rudder angle indicators are not operating properly, make repairs to the indicators prior to getting the vessel underway with passengers.

46 CFR111-30-25(e) (3) (f) For each shore power connection each switchboard must have: (1) A circuit breaker or fused switch; (2) A pilot light connected to the shore side of the circuit breaker or fused switch; and (3) One of the voltmeters under paragraph (b)(5) of this section connected to show the voltage of each phase of the shore power connection. Currently two of the shore tie breakers and connections are not working properly, make corrections/repairs within the next 30Days.

46CFR199.630(a) in addition to the alternatives for certain requirements in § 199.620, passenger vessels operating in oceans; coastwise; Great Lakes; lakes, bays, and sounds; and rivers service may comply with alternative requirements to subparts A through C of this part as described in this section for the services specified in table 199.630(a) of this section. Currently there are no liferafts on board the vessel. Prior to getting underway install the required life rafts.

46 CFR 72.05.50 Where automatic fire dampers are required, they shall be designed to operate at approximately 165 degrees F. for normal locations, and approximately 212 degrees F. for locations such as galleys. The dampers shall be so designed as to close against the anticipated draft in the duct. The damper shall be made accessible for periodic inspection by means of a hinged or bolted plate in the duct. The damper and the portion of duct containing the damper shall be constructed of at least 1/8 inch steel plate suitably stiffened. No insulation need be applied to the damper blade. Currently the damper on the 3rd deck is not operating properly and not allowing the complete zone to show Green on the control panel.

All lifesaving appliances and arrangements on passenger vessels must be in accordance with subchapter W (Lifesaving Appliances and Arrangements) of this chapter. Vessel did not have documentation that the weekly and monthly inspections required by 46 CFR 199.190(d) and (e) were completed. 46 CFR 70.28-1

Currently the side shell fire door midship on the 2nd deck PORT side has been damaged and is not able to be closed or operated properly. Prior to operating the vessel with passengers, make proper repairs to the damaged fire door so it is closed and maintains the fire boundary. Since this door is only used while moored at the Hilton Docking facility and not used under way as an egress route the door may be made tight in a non operational way until a new door can be installed. Contact Tom Alho at [phone withheld] for proposed correction to this problem and it must be corrected prior to the carriage of passengers.

Currently the STBD main engine thruster control transducer is bad and will not allow pilot house control for this engine. The current module is obsolete and will have to be manufactured or a modification to the system installed. To be determined by cost of each. Prior to getting the vessel underway.

. Currently the EDG switchboard breaker for the emergency fire pump trips immediately after the pump is energized when on the emergency source of power. Correct this issue and provide demonstration to the USCG. Prior to getting vessel underway.

Prove proper operation of General Alarm bells. Ensure two bells on 3rd level near stairwell are operating.

Prove proper operation of NR2 SSG after repairs affected to turbocharger.

Submit Notice of Intent for Vessel General Permit to EPA. Provide proof to USCG inspector.

Prove proper operation of refrigerant leak detector system and alarm.

Provide USCG inspector proof of proper dayshapes required are onboard.

Provide proof to USCG inspector that requirement is met for visual distress signals (flares). IAW 46CFR199.60(c) Each vessel must carry not less than 12 rocket parachute flares.

Replace INOP L/O pressure gauge on starboard MDE.

Repair/replace inoperable gauge in the strbd main diesel engine jacket water system.

Repair/replace inoperable hydraulic pressure gauge in bow thruster piping.

Repair/replace inoperable clutch pressure gauge on the port main diesel engine clutch.

Have liferafts serviced prior to expiration date.

Have portable fire extinguishers serviced by the end of July 2011.

Secure loose wires and remove water on deck in the bar area on third deck starboard forward.

Replace missing blank inside electrical panel 407 located on third deck port side, aft of cage.

Tighten fire safety door (FSD) magnets on FSD located on second deck port forward.

Place retro-reflective tape on back side of life ring located on third deck starboard forward.

Service general alarm bells on third deck port and starboard sides so they are audible.

Replace three defective 1.5 inch nozzles discovered during fire hose hydro test.

Prove proper operation of Starboard Bridge Wing auxiliary steering station. Parts on order.

Replace the section of fire hose that failed during pressure test.

Place General alarm placards in proper locations where visible.

Properly install wire thru deck penetration for Emergency Generator door alarm.

Properly install wires in surveillance UPS.

Properly dead end wires in shaft alley.

Repair/ replace leaking crossover pipe on # 2 sprinkler pressure vessel.

Prove proper operation of starboard bridge wing rudder angle indicator.

Remove scale in #4 ballast tank starboard side bilge knuckle at the forward bulkhead and treat

Remove scale from #5 ballast tank bottom plate and treat.

Place consortium Letter of Regulatory Compliance in DAPI binder.

Repair/ replace bottom pipe fitting on #2 sprinkler pressure vessel gage column.

Repair/ replace bottom pipe fitting on #1 sprinkler pressure vessel gage column.

Repair/ Replace and prove proper operation of general alarm bells five (5) on first deck, three (3) on second deck and four (4) on third deck.

Repair fuel oil leak on port main engine fuel pump.

Repair oil leak on number one generator governor.

Recharge and service Emergency Breathing Apparatus in ECC.

Recharge Emergency Breathing Apparatus in chiller room and replace breakaway glass.

Properly label all emergency signaling lights in all engineering spaces.

Plug knockout holes in number one generator 24 volt control box.

Prove proper operation of depth sounding device.

Prove proper operation of port bridge wing flanking rudder angle indicator.

Prove proper operation of stbd bridge wing stbd flanking rudder angle indicator.

Prove proper operation of stbd bridge wing main rudder angle indicator.

Replace retroreflective material on five (5) lifejackets in 3rd deck bow, one (1) in main deck bow, one (1) in stern deck life jacket lockers.

Properly mark starboard bow and main deck stern fire axes with vessel name.

Properly mark No. 5 extinguisher.

Properly mark No. 11 extingusher.

Install non-conducting deck covering behind emergency generator switchboard.

Repair fuel oil leak on emergency generator fuel oil filter.

Repair lube oil leak on emergency generator lube oil drainage piping.

Repair fuel oil leak on bow thruster engine.

Make proper cut-out for bow thruster battery cables to ensure cover fits properly.

Make permanent repair to radar monitor to work as designed.

Update fire control plan.

Port steering rudder winging erratically, not following rudder commands.

Identify and label all emergency lighting breakers and fixtures.

Provide a means to keep the CO2 room door closed and locked.

Submit corrected/updated Fire Control Plan to Marine Safety Center for review.

Extinguisher's pressure gage found below normal reading.

Floating water light found full of water.

General alarm bell on fouth deck stbd side aft inoperable.

Clean dampener blades for both engine room stack closures.

Clean dust from all sprinkler heads located in stair towers.

Adjust stair tower door 1st deck port side.

Adjust exterior door closures 3rd deck aft port side and 2nd deck aft port side.

Remove outdated supplies from ALL first aid boxes and eyewash stations and REPLACE with new supplies. LEGACY COMPONENT DESC: Medicine Chest

Switch flanking rudder controls & gauges to reflect true relationship when manning station in steering space. LEGACY COMPONENT DESC: Rudder Angle Indicator

Investigate and correct cause for amperage to ground indicated on gaming power distribution panel in engine room. LEGACY COMPONENT DESC: Ground Detection

Repair/replace P&S 4th deck ring buoy lights with approved buoy lights. LEGACY COMPONENT DESC: Self-igniting Lights

Identify and label throughout vessel fire extinguisher station numbers. LEGACY COMPONENT DESC: Number

Prove/provide evidence of fire chalk is Coast Guard approved.

Relocate slot machines located in egress route 2nd deck to ensure proper spacing between chairs. LEGACY COMPONENT DESC: Corridors

Inspect and repair all "A" & "B" class bulkhead penetrations and apply approved fire caulk as needed. LEGACY COMPONENT DESC: Wiring

Repair/renew/replace guards for fan motor/drive belts located in Texas Deck Stack area.

All decks, all levels monitor and adjust as appropriate PA Sound levels to ensure sound can be heard above background noise.

REPLACE INSTALLED SURGE SUPPRESSOR(S) WIRE PERMENANT HARDWIRING IAW IEEE ON ALL GAMING TABLES. LEGACY COMPONENT DESC: Wiring

REPAIR/REPLACE TWO FORWARD PORTSIDE FIRE DOOR FRAMES IAW 46 CFR 72.05, SFP REQUIREMENTS DUE TO HOLEING DUE TO RUST. LEGACY COMPONENT DESC: Openings - Fire Doors

LABEL WITH PLAQUE FIRE CONTROL PLANS STARBOARD SIDE.

REPLACE INSTALLED SURGE SUPPRESSOR(S), WIRE PERMNANT HARDWIRING IAW IEEE ON ALL GAMING TABLES. ITEM ERRONEOUSLY RESOLVED ON 07/09/2002 LEGACY COMPONENT DESC: Wiring

REPAIR/REPLACE TWO FOWARD PORTSIDE FIRE DOOR FRAMES IAW 46 CFR 72.05, SFP REQUIREMENTS DUE TO HOLEING DUE TO RUST. ITEM RESOLVED ERRONEOUSLY ON 07/09/2002 LEGACY COMPONENT DESC: Openings - Fire Doors

CONDUCT LOAD ANALYSIS VERIFICATION OF SURGE STRIPS BEING UTILIZED IN 3RD DECK REWARDS SECTION. SUBMIT PROPOSAL FOR INSTALLATION OF PERMAMENT RECEPTACLES AND CIRCUITS AS NECESSARY.

PROVIDE COPY OF PERIODIC SAFETY TEST PROCEDURES FOR ENGINE ROOM AUTOMATION.

DEMONSTRATE PROPER OPERATION OF REVERSE POWER RELAYS.

DEMONSTRATE PROPER OPERATION OF STEERING FROM ALL MODES AND LOCATIONS UPON COMPLETION OF REPAIRS TO SWITCHBOARD LOGIC CARD.

PROVIDE COPY OF PERIODIC SAFETY TEST PROCEDURES FOR ENGINE ROOM AUTOMATION. ITEM ERRONEOUSLY RESOLVED ON 07/09/2002

INSPECT AND REPLACE OR REPAIR ALL FIRE DOORS EXCEEDING PERIMETER GAP REQUIRMENTS PER 46 CFR 72.05-25(b).

MAKE PERMENANT REPAIRS TO ENGINE ROOM EXHAUST VENTILATION TO THE SATISFACTION OF THE ATTENDING MARINE INSPECTOR.

CLEAN DECK AND EFFECT SOLUTION TO LONG TERM HOUSEKEEPING PROBLEMS IN BAR/SERVICE AREAS.

BOLT THE SOUNDING TUBE TO ITS RESPECTIVE BRACKET IN THE #5 VOID.

INSTALL PACKING TO THE FORWARD PORT BILGE ALARM BULKHEAD FITTING IN THE #4 VOID AND REMOVE THE LOOSE BILGE ALARM WIRE BUNDLE IN THE #6 VOID.

PROVIDE BILGE SUCTION STRAINERS TO THE FOLLOWING TANKS: FOREPEAK, #5,6&7 VOIDS, AND #2&9 BALLAST TANKS.

PROVE THE PROPER OPERATION OF THE FOREPEAK BILGE SUCTION VALVE REACH ROD.

ADJUST THE PACKING GLANDS OF THE KEEL COOLER CUTOFF VALVES IN #4 VOID AS NEEDED TO STOP THEIR LEAKAGE.

DEMONSTRATE PROPER OPERATION OF BOW THRUSTER AND ASSOCIATED SAFETIES AFTER ENGINE BREAK IN PERIOD.

DEMONSTRATE PROPER OPERATION OF SSDG'S AND ASSOCIATED ALARMS/SHUTDOWNS AFTER ADEQUATE ENGINE BREAK-IN PERIOD.

DEMONSTRATE PROPER OPERATION OF MPDE ALARMS AND SHUTDOWNS.

VERIFY GAMING TABLE THROUGH DECK PENETRATIONS TO ENSURE MEET APPLICABLE FIRE AND WATER TIGHT REQUIREMENTS.

CONDUCT GENERAL HOUSE KEEPING REMOVING FIRE HAZARDS AND ENSURING ADEQUATE ELECTRICAL SERVICES.

DEMONSTRATE PROPER OPERATION OF UPS BATTERY BACK-UP FOR EOS, MACHINERY MONITORING AND ALARM SYSTEM.

DISCONTINUE OPERATION OF WINNER'S LOUNGE 3RD DECK FOOD SERVICE BAR UNTIL THE SANITARY CONDITION IS FOUND ACCEPTABLE TO THE VESSEL CAPTAIN.

ADJUST/RENEW DOOR HARDWARE TO THE EMERGENCY EXIT DOORS LOCATED MIDSHIP ON THE PORT SIDE OF THE MAIN DECK, BOILER DECK AND HURRICANE DECK.

CONDUCT DYE-PENETRANT TESTS VICINITY OF THE DECK PADS TO DECK WELDS OF THE STANDING RIGGING OF THE PORT AND STARBOARD STACKS OF THE TOP DECK.

MAKE REPAIRS TO THE EXPOSED WIRING AT THE SEARCHLIGHT IN THE VICINITY OF THE PORT AFT RESCUE BOAT.

REMOVE EXCESS WATER ON DECK OF ICE MACHINE SPACE AND MAINTAIN DECK IN A DRYCONDITION._x001C_

ADJUST PACKINGS TO PORT/STBD PROPULSION SHAFTS.

ADJUST LATCHING MECHANISM TO THE 4TH DECK PORT SIDE FORWARDMOST FIRE DOOR.

REMOVE CARDBOARD BOXES FROM DECK IN LIQUOR LOCKER AND PROPERLY STOW LIQUOR ON RACKS PROVIDED IN LOCKER.

PROVIDE A LABEL IDENTIFYING THE COMPARTMENT SERVED BY THE VENT PIPE ADJACENT TO THE ENGINEROOM MAIN DECK OUTSIDE DOOR STBD SIDE.

FABRICATE A GUARD TO PROTECT WIRES AT DECK LEVEL IN THE FIRST AID COMPARTMENT.

MAKE REPAIRS AS NEEDED TO THE BOW THRUSTER OVERBOARD DISCHARGE PIPING IN LIEU OF THE SOFT PATCH AS PRESENTLY INSTALLED.

REPLACE THE SCREEN TO THE INTAKE VENT LOCATED MIDSHIP AT THE STBD MAIN DECKLEVEL.

MAKE REPAIRS TO THE HEAD AND FOOT KEEPERS TO THE SERVICE RAMP DOORS AT THE PORT MAIN DECK.

PROVIDE STRESS RELIEF (WIRE BRAID) TO THE MAIN DECK STBD BOW FLOODLIGHT.

REPLACE AND PROVIDE PROOF OF TESTING OF THE #1 GENERATOR JACKET WATER HIGH TEMP ALRM/SENDING UNIT.

REVIEW ALL PANEL CIRCUIT BREAKER LABELS FOR AGREEANCE WITH BREAKER PANEL IDENTIFICATION CARDS.

REPLACE THE RETRO-REFLECTIVE TAPE ON THE LIFEJACKETS AS NEEDED.

RECAULK ELECTRICAL STUFFING TUBES AS NEEDED ON PILOTHOUSE ROOF.

ADJUST THE DECIBEL LEVEL OF THE AEVADS MESSAGING SYSTEM TO PROVIDE A DISCERNABLE LEVEL ABOVE CROWD NOISE. PROVIDE NEW MESSAGING SYSTEM READINGS TO USCG MARINE SAFETY OFFICE LOUISVILLE.

REVISE FLAME SCREENS OF THE OILY WATER TANK VENT AND THE BOW THRUSTER FUEL OIL TANK VENT TO PROVIDE A SEAL TO MATING SURFACE OF THE SCREEN BORDER.

PROVIDE DECIBEL READINGS OF AEVADS MESSAGING SYSTEM AND DECIBEL READINGS OFCROWD NOISE FOR COMPARISON.

REPAIR OR REPLACE THE STBD RADAR UNIT.

FABRICATE A GUARD FOR THE SPRINKLER HEAD IN THE HARD COUNT SPACE THAT WILL PROTECT IT FROM DAMAGE DURING BASKET HANDLING AND WILL NOT IMPEDE WATER FLOW/PATTERN.

PROVIDE SNAP HOOKS ON LANYARDS FOR ATTACHMENT OF WATERLIGHTS ON RING BUOYS.

REMOVE PLASTIC TRASH CANS THROUGHOUT VESSEL AND REPLACE AS NEEDED WITH METAL TRASH CANS.

REPLACE RELIEF VALVE ON NO.1 STBD AFT AIR RECEIVER IN ENGINE ROOM.

STENCIL VESSEL NAME ON OARS OF RESCUE BOAT.

REPLACE FADED PLACARDS ON VESSEL EXTERIOR AS NEEDED.

POST A "DANGER HIGH VOLTAGE" PLACARD ON EMERGENCY GENERATOR SWITCHBOARD.

PAINT A YELLOW RADIUS ON DECK AT STERN STOWAGE VICINITY OF OXY ACETYLENE BOTTLES AND DESIGNATE AS "NO SMOKING" AREA.

REPLACE 8 WATER-LOGGED PFD'S; TOTAL PERSONS ALLOWED REDUCED TO 2,992 PENDING REPLACEMENT.

PROVIDE TEST REPORT PRINT-OUT FOR ALL FIRE, HEAT AND SMOKE ALARMS/DETECTORS.

PROVIDE COVER PLATE FOR DETROIT PRESSURE SWITCH ON EMERGENCY DIESEL.

PERMANENTLY MOUNT CLIMATE CONTROL SENSOR HEAD ADJACENT TO ELECTRICAL PANEL IN THE ELEVATOR EQUIPMENT ROOM.

DO NOT OPERATE ENGINE ROOM SUPPLY FAN UNTIL PROPERLY WIRED TO SECURE UPON ACTIVATION OF THE FIXED CO2 SYSTEM.

LABLE DISTRIBUTION PANEL IN ELEVATOR EQUIPMENT ROOM.

Determine cause of bow-thruster failure; effect permanent repairs and proveproper operation to the satisfaction of an attending marine inspector.

PROPERLY ROUTE WIRING THROUGH PENETRATIONS (ONE WIRE PER PENETRATION) ON THE FORWARD BULKHEAD OF STARBOARD AUX MACHINERY SPACE.

PROPERLY INSTALL AND SECURE/BAND ALL WIRING/CABLES IN WAY OF HURRICANE DECKMODIFICATIONS; TERMINATE ALL SPLICES IN JUNCTION BOXES & MINIMIZE THE USE OF PLASTIC CABLE TIES IN ACCORDANCE WITH IEEE 45.

FIRE CAULK VARIOUS SURVEILANCE WIRE STUFFING TUBES IN THE PORT ELECTRICAL PANEL ROOMS ON THE 2ND AND 3RD DECKS.

REMOVE COMBUSTIBLE INSULATION SURROUNDING THE ENGINE ROOM CONTROL SPACE.

LABEL REMOTE EMERGENCY SHUTDOWN FOR FUEL OIL TRANSFER PUMP ON PORT SIDE MAIN DECK PER 46 CFR 111.103-9(b).

EFFECT PERMANENT REPAIRS TO THE PORT MAIN ENGINE FUEL OIL PUMP.

PROVIDE AN EMERGENCY POWER SOURCE TO THE REPEATER FOR THE CREW PORTABLE RADIO NETWORK PER 46 CFR 112.15-5(a).

EFFECT REPAIRS TO THE ENGINE ROOM CONSOLE AUDIBLE ALARM FOR THE PORT FLANKING RUDDER LOW HYDRAULIC OIL ALARM.

INSTALL SHAFT SPEED AND DIRECTION INDICATORS AT THE ENGINE ROOM CONTROL CONSOLE PER 46 CFR 113.37-5.

PROVIDE RELIEF VALVE FOR THE NO. 1 AIR RECEIVER WHICH WILL RELIEVE AT A PRESSURE NOT EXCEEDING THE MAWP OF THE TANK.

MAKE THE HVAC DRAIN PENETRATION IN THE PORT AFT ENGINE ROOM BULKHEAD WATERTIGHT (COMPLETE CONTINUOUS WELD ON BOTH SIDES).

REMOVE ALL STORED COMBUSTIBLES (PAINTS, OILS, PENETRANTS, ETC.) FROM THE VESSEL.

REMOVE THE COMBUSTIBLE RUBBER STEP GUARDS FROM THE STARBOARD AFT STAIR WELL.

INSTALL ACCEPTABLE WIRE SPLICES PER 46CFR111.60-19 INSIDE THE FIRE DETECTION/ALARM SYSTEM PANEL.

PROVE CURRENT HYDRO TEST AND INSTALL SATISFACTORY HARNESSES ON THE ACETYLENE AND OXYGEN BOTTLES AT THE TOP OF THE ENGINE ROOM STAIRWAY.

CORRECT CLEARANCES BETWEEN DOUBLE FIRE SCREEN DOORS NOT TO EXCEED 1/8 INCH.

INITIATE PERIODIC TESTS OF THE AEVADS SYSTEM AND MAINTAIN A LOG IN ACCORDANCE WITH NFPA 72, CHAPTER 10-2.4, AND ENCLOSURE (2) TO NVIC 8-93 PARAGRAPH 22(F).

COMPLETE WIRING INSTALLATION/RETENTION IN THE OVERHEAD OF THE FOLLOWING SPACES: COMPUTER ROOM, CCTV ROOM, SOFT COUNT ROOM, MAIN BANK ROOM, AND HURRICANE DECK IN WAY OF THE PORT SIDE/FORWARD STAIR TOWER DOORS.

PERMANENTLY MOUNT CABINETS IN THE HARD AND SOFT COUNT ROOMS.

INITIATE PERIODIC TESTS ON THE SPRINKLER SYSTEM AND MAINTAIN A LOG IAW NFPA 25 AND ENCLOSURE (1) TO NVIC 10-93, CHAPTER 9.

PERMANENTLY MOUNT WHITE SPEAKER BOXES IN THE OVERHEAD OF THE HOLD PASSAGE WAYS.

REMOVE, OR INCAPSULATE WITH APPROVED METAL SHEATHED INSULATION, ARMORFLEX ON THE BEVERAGE DESPINSING LINES IN THE SODA ROOM.

REPLACE THE SODA ROOM PRESSURE VESSEL WITH ONE PER 46CFR54.10(5)(C). LESS THAN 5 CUBIC FT. PROVIDE ACCEPTABLE RELIEF VALVE FOR SAME.

INSTALL INCANDESCENT LIGHTS OR OTHER ACCEPTABLE ALTERNATIVE TO INCREASE LIGHTING IN THE STEERING GEAR ROOM, EMERGENCY GENERATOR ROOM, AND CO2 ROOM UNTIL ACCEPTABLE HEATING EQUIPMENT IS INSTALLED.

INSULATE POTABLE WATER PIPING IN THE HOLD SPACES TO PREVENT CONDENSATION. THE INSULATION MUST BE APPROVED NONCOMBUSTIBLE.

EFFECT REPAIRS AND PROVE CORRECT OPERATION OF THE MAGNETIC LOCK ON THE DOORADJACENT TO THE SECURITY ROOM.

INSTALL A METAL GUARD ON THE COOLER ROOM INCANDESCENT LIGHT FIXTURE.

MAKE SERVICE ELEVATOR ENCLOSURE MEET "A" CLASS STANDARDS IN THE HOLD SPACE.

PROVE PROPER OPERATION OF THE MODIFIED STEERING SYSTEM PRIOR TO UNDERWAY OPERATIONS.

PROVIDE APPROVED PLANS FOR THE STEERING CONTROLS MODIFICATIONS.

MAKE CORRECTIONS TO INTERFERENCES WITH THE COOKSON SHUTTERS. THE SHUTTERS SHALL BE OPERATED IN THE FAIL SAFE MODE (SECURE POWER) BEFORE CORRECTIONS HAVE BEEN AND PROVEN TO THE SATISFACTION OF THE OCMI.

RESUBMIT A REVISED A/C LOAD ANALYSIS WITH THE GENERATOR CAPACITY PROPOSAL.

MAKE PERMANENT REPAIRS TO THE BOW THRUSTER PRIOR TO UNDERWAY OPERATIONS.

INSTALL TWO PFD STOWAGE BOXES AND STOW PFD'S ON THE TEXAS DECK IAW THE APPROVED FIRE CONTROL PLAN PRIOR TO UNDERWAY OPERATIONS.

PROVIDE THE OCMI A WRITTEN STATEMENT ADDRESSING WHAT ACTIONS ARE BEING TAKEN TO PREVENT LOSS OF POWER BEFORE THE SHIP'S SERVICE GENERATOR POWER REQUIREMENTS ARE SATISFIED.

PROVIDE PROPOSAL TO INCREASE THE GENERATOR CAPACITY TO COMPLY WITH 46 CFR 111.10-4: WITH ANY SHIP'S GEN SET STOPPED, THE REMAINING SETS MUST CARRY THE SHIP'S SERVICE LOAD. OR OTHER ACCEPTABLE MEANS SUCH AS LOAD SHEDDING TOPREVENT OVERLOAD IF ONE GENERATOR FAILS.

INSTALL A LATCH ON THE PANEL BOX IN THE CO2 ROOM.

MOUNT THE UPS REGULATOR IN THE CO2 ROOM.

PROVE PROPER OPERATION OF THE ENGINE MONITORING SYSTEM.

INSTALL 2 GENERAL ALARM BELLS ON THE TEXAS DECK IN THE AREA OF THE AFT STACKS AND 2 BELLS MIDSHIP ON THE MAIN DECK EXTERIOR WALK WAYS.

LABEL ALL ELECTRICAL CONTROL BOXES FOR THE VENT SYSTEM.

FIRE CAULK AND INSULATE THE STUFFING TUBES AT THE BULKHEAD OVER THE PORT FORWARD STAIRWAY ON THE HURRICANE DECK.

SATISFACTORILY TEST THE COOKSON SHUTTER SYSTEM.

MOUNT PANEL COVERS ON THE POWER PANELS INSIDE THE CCTV ROOM.

PLACE BREAKER PLUGS IN THE POWER PANELS LOCATED IN THE TELEPHONE ROOM AFT OF THE PILOT HOUSE.

SATISFY COMMENT 2 OF THE MARINE SAFETY CENTER LETTER SERIAL # E2-9503937 DATED OCTOBER 31, 1995 CONCERNING THE FIRE DETECTION SYSTEM.

CONDUCT SATISFACTORY DRILLS WITH THE CREW BEFORE OPERATING IN EVANSVILLE. 46 CFR 78.17-50

LABEL ALL ELECTRICAL BREAKERS, SWITCHES, AND PANELS.

LABEL THE FIRE DETECTION SYSTEM, SPRINKLER SYSTEM, SMOKE DETECTION SYSTEM, AND GENERAL ALARM PANEL CIRCUIT DESIGNATION.

INSTALL A COVER PLATE ON THE PORT MAIN DECK FIRE SCREEN DOOR MAGNET.

INSTALL AND TEST THE AEVADS SYSTEM IAW APPROVED PLANS.

THE REHEATER SYSTEM SHALL BE TAGGED OUT AND NOT USED UNTIL THE SYSTEM CAN BE OPERATED WITHOUT LOAD FLUCTUATIONS INHIBITING THE PROPER OPERATION OF THE S/S GENERATING SYSTEM.

REPLACE OR CALIBRATE THE #2 S/S GENERATOR KW METER.

MOUNT THE TELEPHONE EQUIPMENT IN THE SPACE AFT OF THE BRIDGE.

INSTALL A LATCH ON THE PANEL IN THE STARBOARD HURRICANE DECK PANEL ROOM.

INSTALL PERMANENT WIRING TO THE RAMP WENCHES ON THE BOILER DECK.

PLACE DIELECTRIC MATTING IN FRONT OF THE S/S AND EMERGENCY GENERATOR SWITCHBOARDS.

MOUNT THE PANEL COVER ON THE POWER PANEL IN THE PORT MAIN DECK ELEVATOR ROOM.

INSTALL APPROVED FIRE STOP SYSTEMS (ROX BOX) BY THE PORT ELEVATOR PANEL ROOMS, 3RD DECK, 2ND DECK, AND PILOT HOUSE.

SATISFY COMMENTS CONCERNING THE QUALITATIVE FAILURE ANALYSIS IN THE MARINE SAFETY CENTER LETTER, SERIAL # E2-9503957 DATED OCTOBER 31, 1995.

EXCERCISE VESSEL CONTENGENCY PLAN TO THE SATISFACTION OF THE CAPTAIN OF THEPORT LOUISVILLE, KY.

PROVIDE PERMANENT STABILITY LETTER BEFORE CARRIAGE OF PERSONS IN EXCESS OF TEMPORARY STABILITY LETTER (500) PERSONS.

PROVIDE DRUG TEST RESULTS FOR THE REMAINDER OF THE CREW.
