HURON

port side engineroom vents are damaged & should be repaired or replaced; wastage sighted at both ladderwell windows; forward draft marks are not correct; vessel does not have loading marks, confirm whether required or not, properly apply if required.

Pilothouse MDE oil pressure gauge inoperative/erratic & unreliable, must be corrected Pilothouse MDE emergency stop inoperative, must be corrected Pilothouse MDE alarm panel inoperative, must be corrected

MDE emergency fuel shut-off mechanism needs to be adjusted or modified to ensure complete closure and reliability ** corrected but still needs additional routing to be considered permanently repaired.

Port side genset inoperative due to faulty starter. Company is awaiting replacement part. Complete repairs and demonstrate proper operation to attending CG Marine Inspector. Vessel must be provided with and maintain battery back-up power for vital systems until second genset is repaired & operational.

Crew is unable to provide accurate documentation/attestation to the amount of cargo/baggage that is carried. This is in direct contradiction to the vessels issued stability letter. The carriage of passengers and cargo/baggage combinations is not authorized until accurate weight calculations can be obtained for the vessels crew/shore-side facility personnel and presentable to the OCMI.

1 pilothouse window is cracked and must be replaced.

All dead-end wiring must be properly terminated &/or removed. Any new wiring installations must be properly approved prior to installation.

Vessels engine room has accumulation of oil on the machinery and oil/trash on deck plates and in the bilges, all must be properly cleaned.

Auxiliary heating boiler has been installed by reputable vendor with Marine Inspector oversight, however submitted installation plans & equipment list have yet to be approved by the MSC. Until approval is granted, installation confirmed to be in compliance with these approved plans (to include an emergency fuel shut-off valve), hydrostatic test & operational testing of all the installed safety devices are witnessed by CG MI, operating the boiler is prohibited.

Maindeck overhead sprinkler system diffuser heads must be standardized, both relating to type and position. Correct prior to "winter season" operations.

Pilothouse emergency comms battery requires proper cover.

Gensets do not have emergency fuel shut-offs. Install & demonstrate proper operation. Correct prior to "winter season" operations.

Cover missing from electrical J-box under stbd side of helm. Replace.

Several wasted areas sighted at maindeck forward area outboard by loading doors. Correct prior to "winter season" operations.

While underway carrying passengers en route to Mackinac Island, Captain reported feeling a resistance in the steering system. Upon investigation deckhands found the forward-most chain knuckle in the steering shaft to be cracked. This is the second time in three days the steering had bound up and caused this same knuckle to crack under heavy torsion. Upon inspection, MI found that the steering shaft had shifted approximately 1/4 to 3/8's of an inch at numerous spots along the joints and unions. As well as the key had rolled in the key-way at the section where the shaft reduces from 1 1/2 down to 1 inch. Submit repair proposal to this office for approval in correcting failures occurring in the steering system and, once approved, affect repairs to the satisfaction of the attending Coast Guard Marine Inspector.

Mechanics found flattened cam lobe on MDE. Effect repairs and confirm safe operation via underway trials with Coast Guard Marine Inspectors.

Locally fabricated steering gear pillow block/bearing must be replaced with a properly manufactured and system appropriate pillow block/bearing. Installation and operational testing must be witnessed by attending CG Marine Inspector.

Replace rejected (burst) maindeck fire hose.

Sighted many areas of concern relating to corrosion/wastage. Areas included: lazarrette, stairs to 2nd deck, port side mooring bits, holding tank compartment, accommodation space outer edges, pilothouse landing and deck, along with port qtr damage.

Engineroom – sighted MDE oil leak, MDE exhaust leak, throttle/transmission linkage needs to be professionally assembled with proper hardware. Oil leak on genset at dipstick requires repair/replacement. Transmission oil temp alarm constantly on in pilothouse, sensor/transducer on order.

Found 1-50 person IBA servicing expired April 2022.

Found all 4 IBAs painter lines not properly secured. Instructed crew how to properly install & regularly inspect.

Vessel experienced a loss of steering while transiting between Mackinac Island and St. Ignace, MI. The cause appears to be damage sustained to the rudder by ice. Assess damage, submit repair proposal to OCMI, repair IAW approved plan, demonstrate proper operation prior to carriage of passengers.

Vessels 4-50 person permanent IBAs servicing has expired; IBAs must be sent out for annual servicing. Vessel is not authorized carriage of passengers until IBAs are serviced or replaced & the OCMI is notified.

Make vessel available for underway operational testing, demonstrate emergency drills. All to be witnessed by CG Marine Inspectors.

Clean and descale port side sewage void and schedule CG Marine Inspector to attend and inspect.

Fire extinguisher bracket is loose on the deck in engine room. Secure fire extinguisher bracket.

Label GENSET with de-rating placard.

Remove extension cords from under the port bridge console, passenger cabin, and aft life jacket storage. They have been there for some time and are no longer temporary.

Flange on fire main pump is leaking. Effect repairs to make pump not leak into engine room.

Secure/ remove exposed wiring in the forepeak overhead. 46 CFR 183.01-5

Vessels 4-50 person permanent IBAs have been sent out for annual servicing. Replacement IBAs total capacity is 160 persons (2-50 person & 2-30 person). Vessel is limited to 320 total persons allowed until permanent IBAs are re-installed.

A quarter sized crack is present on the stbd side, 6 inches from the keel, in the void aft of the forepeak. Submit repair proposal for approval and effect permanent repairs to hull plating to the satisfaction of the attending marine inspector prior to carrying passengers.

Bilge suction piping wasted, leak caused loss of suction, corrected during inspection.

The vessel is currently broadcasting (1) Improper MMSI Number, (2) Improper Call Sign, (3) Improper Ship Type. Ship Type should be a two digit number (60) Per the US Official Encoding guide.

Wastage identified in internal structural members. Areas identified to be cropped and renewed.

Hatch covers leak and need to be maintained or renewed.

Provide oil resistant insulation to prevent combustible materials from coming into contact with hot surfaces of engine exhausts for main engine and ship service generators.

Discharge end of fuel tank vent piping shall be fitted with a removable flame screen made of corrosion resistant wire in at least 30 X 30 mesh.

Demonstrate proper operation of engineroom access door; must be weathertight and securing devices must work properly as per 46 CFR 116.1160.

Determine extent of steel wastage in internal structures and hull plating in way of forepeak void and 1st void abaft the collision bulkhead, and complete permanent repairs to same, prior to operating in commercial service.

Complete appropriate hazardous material employee training prior to the carriage of hazardous materials.

Make permanent repairs to steering system and demonstrate proper operation of same to the satisfaction of the attending marine inspector.

Post EAP policy and hotline information wither oin vessel or at crew time-clocks.

Permanently repair broken non-return flap on freeing port in way of port bulwark next to engineroom access.

Reconfigure fuel supply piping to aft ship service generator to eliminate risk of damage.

Replace wasted bilge suction strainers as required throughout the vessel.

Cover exposed high temperature areas on main engine exhausts to prevent contact eith combustible materials.

Provide oil resistant insulation on exposed high temperature areas of main engine exhausts as to prevent contact with combustible materials.

Life floats with deteriorated lines must be replaced or repaired, before operating after 31MARCH2016.

Provide permanently installed electrical circuit for Modine heater in engineroom.

Provide fire hoses and nozzles that have fully compatible threads. Meanwhile leave hoses and nozzles connected at all times.

On the hot water heating boiler, relocate safety valve directly into boiler casing, and provide servicing report that documents testing and proper operation of all safefty devices and operating controls.

Main fuel oil tank top severely wasted and epoxy coatings have not been maintained. Tank top was cleaned and new epoxy was applied to maintain remaining integrity until permanent repairs can be completed, related to outstanding requirement #10 issued 10/23/13 per Activity 4748242.

Make permanent repairs/ weld 1" fracture in port quarter steering compartment just below rubrail.

Replace missing quadrant nut on bracket.

Several fractured welds in the steering compartment on the outboard port side upper area. Renew welds or replace metal.

Repair leaking pump seal on main fire pump.

Install a indicator light at the operating station showing whether the watertight door in the engineroom is open or closed.

Replace belt on engine driven fire pump.

Replace gasket on water tight door engine room.

Replace set screw on steering connection.

Repair two weld fractures port side fwd void.

Repair remote reach rod for forward bilge valve inside the forepeak prior to the compliance date.

Provide copies of the latest service report for the hot water heater and the current certificate of documentation sticker prior to the compliance date.

Repair the cracked fire main shut off valve prior to operations and prior to the compliance date.

Replace the damaged 1.5 inch fire hose prior to operations and prior to thecompliance date.

Replace the fuel oil return line (non-metalic flex-hose section) for the # 2 generator prior to the compliance date.

Label watertight door in engine room "Watertight door-keep closed" in 4 inch letters, and repair the gasket, prior to the compliance date.

Label engine room emergency escape hatch with "Emergency exit-keep clear" in 2 inch letters prior to the compliance date.

Tighten and double nut the rudder post packing flange bolts prior to the compliance date.

Install strainers in the bilge suction lines, both port and starboard sides, inside the fuel tank space prior to the compliance date.

PRIOR TO GETTING UNDERWAY REPAIR AND PROVE OPERATSION OF ENGINE-DRIVEN FIRE& BILGE PUMP, BEFORE THE COMPLIANCE DATE.

PRIOR TO CARRYING PASSENGERS, RENEW DEFECTIVE FIRE HOSE ON MAIN DECK FIRESTATION BEFORE THE COMPLIANCE DATE.

3 ADULT SIZE PFD'S REJECTED, DETERIORATED, RENEWED DURING INSPECTION.

FLOAT-LIGHT LANYARD TOO LONG ON RING-BUOY, CORRECTED DURING INSPECTION.

BROKEN GLOBE ON EMERGENCY LIGHT, 2ND DCK LANDING, PORTSIDE. CORRECTED DURING INSPECTION.

9 ADULT AND 1 CHILD PFD'S UNSAT, REPLACED DURING INSPECTION.

REPAIR, HYDROSTATICALLY TEST AND PROVE OPERATION OF HEATING BOILER BEFORE PLACING IT IN SERVICE AND BEFORE THE COMPLIANCE DATE.

PROVIDE CREW TRAINING AND CONDUCT DRILLS FOR MANOVERBOARD AND FIRE BEFORE THE COMPLIANCE DATE.

J-BAR DAVIT CONTROL LINES MISSING, CORRECTED DURING INSPECTION

MAN-OVERBOARD LADDER/RECOVERY UNWORKABLE, RE-VAMPED DURING INSPECTION, SEE MINS.

ELECTRICAL SHOCK HAZARDS IWO 220VAC MAIN POWER PANEL WHICH IS PRE-1958 AND EXEMPT FROM CURRENT SAFETY STANDARDS IN REGULATION. DANGER SIGN REQUIRED ASALTERNATIVE PRECAUTION. CORRECTED DURING INSPECTION.

REPAIR AND DEMONSTRATE PROPER OPERATION OF BOTH SHIP SERVICE ELECTRICAL GENERATORS BEFORE CARRYING PASSENGERS AND BEFORE THE COMPLIANCE DATE.

LABEL FUEL OIL SHUTOFF VALVE AS PER 46 CFR 185.608 BEFORE THE COMPLIANCE DATE.

BILGE PUMP FUNCTIONED BUT COULD NOT DRAW SUCTION FROM VARIOUS COMPARTMENTS,DUE TO AIR LEAKS IN SUCTION PIPING. CORRECTED DURING INSPECTION.

EMERGENCY LIGHTS IN WAY OF PASSENGER EGRESS ROUTES INOPERABLE, CORRECTED DURING INSPECTION.

VARIOUS LIGHTING FIXTURES, GLOBES AND GUARDS IN PASSENGER AND CREW AREAS BROKEN OR MISSING, BROKEN-EXPOSED LIGHT BULBS IN SEVERAL LOCATIONS, SHOCK HAZARDS, CORRECTED DURING INSPECTION.

ALL TOILETS SPACES EXCESSIVELY SOILED AND INOPERABLE, CORRECTED DURING INSPECTION.

LIFE PRESERVERS WERE STOWED IN EXTERIOR BOXES WHICH WERE DIFFICULT TO OPEN AND WERE MOT PROPERLY MARKED. CORRECTED DURING INSPECTION.

PRESSURE GAGE ON PORT AIR RECEIVER BROKEN, RENEWED DURING INSPECTION.

EXCESSIVE OIL LEAKS AT REDUCTION GEAR, CORRECTED DURING INSPECTION, REPLACED BAD O-RINGS.

HIGH PRESSURE HYDRAULIC OIL HOSES ON REDUCTION GEAR BADLY WORN AND WEAKENED, RENEWED DURING INSPECTION.

EMERGENCY POWER BATTERY CONNECTIONS CORRODED AND LOOSE, CORRECTED DURING INSPECTION.

RING-BUOY LIFELINE EXCESSIVELY WEATHERED, CORRECTED DURING INSPECTION

RADIO EMERGENCY BROADCAST INSTRUCTIONS NOT AVAILABLE, POSTED DURING INSPECTION.

REMOVE OILY WASTE AND DEBRIS FROM ENGINEROOM BILGE BEFORE THE COMPLIANCE DATE.

Carry no passengers prior to correcting discrepancies on attached worklist,no later than 29NOV97.

Install a pilot house propulsion engine shut down switch, in accordance with 46 CFR 184.620(b).

Carry no more than 337 persons until 17 additional adult PFD's are provided.

Install retro-reflective tape and stencil marked ring buoys, buoyant apparatus, and the rescue boat.

Replace portable nitrogen fire extinguisher on the bridge with an approved halon, CO2, or dry chemical extinguisher.

Replace portable fire/bilge pump.

Repair deteriorated engine exhaust stack.

Remove excess oil from engine room bilges._x001C_ _x001C_ _x001C_ _x001C_

Replace carbide type life float lights with approved electric lights._x001C_

Replace bow and stern lines on rescue boat.

Provide 19 additional adult PFD's.

Repair seats, second deck.

PRIOR TO CARRIAGE OF HAZARDOUS CARGO, DEMONSTRATE OPERATION OF MAIN DECK WATER SPRINKLER SYSTEM.

PROVIDE COVERS FOR BATTERY BOXES.

RENEW FUEL TANK VENT SCREENS.

REPLACE RELIEF VALVE ON PORT A/R.

PERMANENTLY CLOSE OPENING IN BLKHD BETWEEN NOS. 5&6 VOIDS AND PROVIDE ACCES THROUGH MAIN DECK TO NO.6 COMPARTMENT FITTED WITH SUITABLE HATCH COVER.

PROVIDE STRAINERS ON BILGE SUCTIONS IN FOREPEAK & NO. 6 VOID.

PROVIDE 30X30 MESH FLAME SCREEN ON FUEL OIL VENT.

PROVIDE WATER SERVICE TO SINKS IN HEADS
