PINE ARROW

WHERE CABLES WHICH ARE INSTALLED IN HAZORDOUS AREAS INTRADUCE THE RISK OF FIRE OR EXPLOSTION IN THE EVENT OF AN ELECTRICAL FAULT. IN SUCH AREAS SPECIAL PRECAUTIONS AGAINST SUCH RISK SHALL BE TAKEN TO SATISFACTION OF THE ADMINISTRATION. PSCO OBSERVED FOUR 04 IEC 60529 IP 68 LIGHTS WITH MISSING GLANNS AND EXPOSED WIRING. REPLAIRS TO BE CARRIED OUT IN ACCORDANCE WITH MANUFACTURERES INSTRUCTIONS BY A QUALIFIED PERSONNEL. SOLAS CON 04 II-1 REG 45.5.4

DANGEROUS GOODS SHOULD BE ADEQUERLEY SEPERATED FROM IGNITION SOURCE. DUE TO DEFECTIVE ELECTERICAL EQUIPMENT LOCATED OUTSIDE CARGO HOLDS ON DECK AREA VESSEL IS NOT PERMITTED TO CARRY DANGEROUS GOODDS. SOLAS CON(04) II-2 REG 19.1.2

IN ADDITION TO ANY OTHER APPLICAABLE REQUIREMTNS OF THE PRESENT REQULATIONS A CARGO SHIP CARRING SHALL COMPLY WITH REQUIREMENTS OF THE INTERNATIONAL GRAIN CODE. DUE TO THE DEFECTIVE ELECTRICAL EQUPMENT AS PREVIOULY STATED VESSEL SHALL NOT CARRY GRAIN UNTIL ALL REPAIRS HAVE BEN MADE AND APPROVED. SOLAS CON (04) VI REG 9.1

EVERY CANDIDATE FOR CERTIFICATION SHALL BE REQUIRED TO PROVIDE REVIDENCE OF HAVING ACHIEVED THE REQUIRED STANDARD OF COMPETENCE TABULATED IN COLLUM 3 AND 4 OF TABLE A-III/6 ELECTRICAL EQUIPMENT (IEC 60529) IP 68 SHALL BE REPAIRED BY A TRAINED INDIVIDUAL IAW MANUFACTURERS INSTELATIONS AND STCW. STCW 17(CON) REG III 6.5

The condition of its ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons onboard. The pilot reported that while heading inbound Delaware Bay, DE, the vessel experienced a loss of propulsion after the ship's generator tripped off-line which caused the main engine to lose power completely. Prior to departure of the vessel, a causal analysis must be conducted and proper repairs completed, if needed. Coast Guard reequires a class report to verify that the deficiency is fully rectified and that vessel is safe to proceed.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction for the service for which they are intended.PSCO observed cooling water leaks on main engine cylinders #4 and #5.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction for the service for which they are intended.PSCO observed lube oil leak on aux engine #3 and cooling water leak on aux engine #2.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction for the service for which they are intended.PSCO observed active leaking of aft peak tank ballast line causing a large pool of water in void space.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction for the service for which they are intended. PSCO observed chain case lube oil leak causing pooling oil in engine room floor and bilge.

0715 The function of the detection system shall be periodically tested to the satisfaction of the Administration by means of equipment producing hot air at the appropriate temperature. PSCO observed heat producing equipment being used to test detectors with no temperature control and producing temperatures well in excess of the 50 degrees Centigrade recommended by manufacturer. 74SOLAS(97)II-2/13.1.13

1510-The navigational equipment and systems referred to in this regulation shall be so installed, tested and maintained as to minimize malfunction. PSCO noted 4 RPM indicators on the bridge INOP, 4 gyro repeaters INOP, Radars not receiving GPS/Gyro/AIS/ARPA signals, and the wind speed indicator INOP. 74SOLAS(14)V/19.4 17a,c

0615-The condition of ship equipment shall be maintained to proceed to sea. PSCO observed that the crew could not shift rescue boat outboard engine in reverse 74 SOLAS (14) I/11

0330- PSCO noted fuel lines on cylinders 1,2, and 6 may not be double jacketed. 74 SOLAS (14) I/11

0521-PSCO noted hole drilled into bulkhead in steering gear room to adjacent passageway for electrical wire pass through with no grommets or class report. 74 SOLAS (14) I/11

0830-PSCO noted a non mounted platform had been installed over slop tank piping and chafing into piping, near OWS discharge valve.74 SOLAS (14) I/11
