HARBOR EMPEROR

They must be so constructed that, if subjected to the standard fire test, they are capable of preventing the passage of smoke and flame for 1 hour. In addition, they must be so insulated with approved structural insulation. MI identified absence of structural insulation above port side main engine. 46 CFR 116.415(a)(2)(i)

Electrical equipment exposed to the weather must be watertight. MI identified missing light bulb on floodlight aft of the pilot house. 46 CFR 120.210(b)

Electrical equipment on a vessel must be installed and maintained to: Protect passengers, crew, other persons, and the vessel from electrical hazards. MI identified dead end wires on port side above main engine. 46 CFR 120.200(b)

Each item of survival craft equipment must be of good quality, and efficient for the purpose it is intended to serve. MI observed buoyant apparatus with degradation intruding into the foam material. 46 CFR 117.175(a)

All piping, valves, and fittings shall be in accordance with good marine practice and suitable for the purpose intended. Fire main pipe corroded and leaking along span from starboard exhaust stack to top deck. Submit permanent repair proposal and affect approved repairs to satisfaction of MI. Old T 46CFR 181.15-5(c)

A vessel must be fitted with ground tackle and mooring lines necessary for the vessel to be safely anchored or moored. The ground tackle and mooring lines provided must be satisfactory for the size of the vessel, the waters on which the vessel operates, subject to the approval of the cognizant [name withheld] shows significant corrosion wastage in several areas.46 CFR 121.300

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspections. A wire from a lighting enclosure in the starboard fiddly is not secured against chafing. Old T 183.01-15

Each vessel must be provided with a visual and audible alarm at the operating station to indicate a high water level in each of the following normally unmanned spaces... A high bilge level visual indicator light at the operating station is labeled "All" yet only indicates for either of the forward two voids. Label indicator lights with associated voids to the satisfaction of MI. 46 CFR 119.530(a)

Unless other means are provided to ensure that a potential waste receptacle fire would be limited to the receptacle, waste receptacles must be constructed of noncombustible materials with no openings in the sides or bottom. Plastic waste receptacles were located on the main deck and in the wheelhouse. 46 CFR 116.405(i)

At each initial and subsequent inspection for certification of a vessel, the owner or managing operator shall be prepared to conduct tests and have the vessel ready for inspections of the hull structure and its appurtenances, including the following: Inspection of all accessible parts of the exterior and interior of the hull, the watertight bulkheads, and weather decks. Second deck bow found with areas beyond 25% wastage that require permanent repair by 31OCT2024. Temporary repairs authorized with no passengers allowed in this area, reduction in passengers by 50, for total persons allowed 456.

Vent pipes terminating on the hull exterior shall be so installed or equipped as to prevent the accidental contamination of the fuel by water under normal operating conditions. The fuel vent on the starboard side had a hole. Temporary repair authorized until next drydock examination. 46 CFR 182.15-35 "OLD T"

At each initial and subsequent inspection for certification, the marine inspector shall view the vessel afloat and shall conduct the following tests and inspections of the hull structure and its appurtenances: Examine all accessible parts of the exterior and interior of the hull, the watertight bulkheads, and weather deck. The bulkhead separating the CO2 void and laz has a 2" hole located 6" port of the centerline approximately 2" above the bottom plate. Temporary repair authorized until next drydock exam. 46 CFR 176.25-5 (1) "OLD T"

At each initial and subsequent inspection for certification, the marine inspector shall view the vessel afloat and shall conduct the following tests and inspections of the hull structure and its appurtenances: Examine all accessible parts of the exterior and interior of the hull, the watertight bulkheads, and weather deck. There was a hole found on the 2nd deck weather deck on the port side. Repair prior to credit drydock. 46 CFR 176.25-5 (1) "OLD T"

At each initial and subsequent inspection for certification, the marine inspector shall view the vessel afloat and shall conduct the following tests and inspections of the hull structure and its appurtenances: Examine all accessible parts of the exterior and interior of the hull, the watertight bulkheads, and weather deck. Observed questionable condition of the 2nd deck bow. Conduct UT shots to examine for wastage. 46 CFR 176.25-5 (1) "OLD T"

At each initial and subsequent inspection for certification, the marine inspector shall view the vessel afloat and shall conduct the following tests and inspections of the hull structure and its appurtenances: Examine all accessible parts of the exterior and interior of the hull, the watertight bulkheads, and weather deck. The bilge area along the keel of the CO2 void and beneath the shafts in the engine room require pumping and cleaning prior to next drydock inspection. 46 CFR 176.25-5 (1) "OLD T"

Except on a vessel limited to daytime operations, the compass must be illuminated. The compass onboard the vessel did not illuminate.

Vessels operated solely within 20 nautical miles of land must be equipped with a VHF–DSC radiotelephone installation meeting the requirements of § 80.1101(c)(2). The vessel did not have its latitude and longitude coordinates programmed into the VHF-DSC radio.

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load under such requirements without exceeding its designed limitations. Vessels Port/Starboard shaft seal was dripping excessively. Vessel to tighten shaft seal packing glands to the satisfaction of the marine inspector. 46 CFR 182.05-1 "OLD T"

AIS Class A device. The following vessels must have on board a properly installed, operational Coast Guard type-approved AIS Class A device: (iii) A self-propelled vessel that is certificated to carry more than 150 passengers. Vessel was found with an AIS that is not transmitting their location. Repair AIS to the satisfaction of the Marine Inspector. 33CFR164.46(b)(1)(iii)

Whenever damage or deterioration to hull plating or structural members that may affect the seaworthiness of a vessel is discovered or suspected, the cognizant OCMI may conduct an internal structural examination in any affected space, including fuel tanks, and may require the vessel to be drydocked or taken out of service to assess the extent of the damage, and to effect permanent repairs. Operator reported wastage in the hull plating that is causing water intrusion into the lazarette. Identify extent of damage during drydock using NDT. Submit repair proposal for approval prior to starting work. Make permanent repairs to the satisfaction of the attending Marine Inspector prior to carriage of passengers.

Each entrance to a space storing carbon dioxide cylinders... must be conspicuously marked as follows: “CARBON DIOXIDE GAS CAN CAUSE INJURY OR DEATH. VENTILATE THE AREA BEFORE ENTERING. A HIGH CONCENTRATION CAN OCCUR IN THIS AREA AND CAN CAUSE SUFFOCATION.”. CO2 storage space does not have proper sign. Install sign to the satisfaction of the marine inspector. 46 CFR 122.612(i)(1)

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspection. Electrical junction box in steering space is not attached and hanging by the wires. Properly support box, to the satisfaction of the marine inspector. 46 CFR 183.01-15 "OLD T"

...Each vessel inspected and certificated under the provisions of this subchapter must, when any passengers are aboard during the tenure of the certificate, be in full compliance with the terms of the certificate. COI requires vessel to designate senior deckhands in writing, in accordance with NVIC 1-91. Vessel did not have a document clearly indicating Senior Deckhands. Create document stating Senior deckhands, to the satisfaction of the marine inspector. 46 CFR 115.100(b)

The cognizant OCMI may require that a vessel and its equipment undergo any additional test or inspection deemed reasonable and necessary to determine that the vessel and its equipment are suitable for the service in which they are to be employed. Hole found in deck from the main deck to the CO2 void, however, the location of the water intrusion to the main deck could not be determined. Determine location of water intrusion. Submit repair proposal for approval. After proposal is approved, make permanent repairs to the satisfaction of the marine inspector. Rectify prior to receiving credit drydock. 46 CFR 115.840

Examine all weathertight closures above weather deck and inspect the provisions for drainage of sea water from the exposed decks. Weather tight door on second deck does not close properly and has extensive internal damage. Repair to the satisfaction of the marine inspector prior to receiving credit drydock. 46 CFR 176.25-5(a)(5) "OLD T"

All enclosed spaces within the vessel shall be properly vented or ventilated. Where such openings would endanger the vessel under adverse weather conditions, means shall be provided to close them. Ventilation closure on starboard side, second deck, had corrosion. Repair to the satisfaction of the marine inspector prior to receiving credit drydock. 46 CFR 177.20-1(a)

At each inspection for certification and at every other vessel inspection the bilges and other spaces may be examined to see that there is no excessive accumulation of oil, trash, debris, or other matter that might create a fire hazard, clog bilge pumping systems, or block emergency escapes. Engine was leaking hot coolant. Engine was repaired and bilge cleaned to the satisfaction of the marine inspector. 46 CFR 115.830(b)

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load under such requirements without exceeding its designed limitations. Vessel reported loss of port propeller and tail shaft. 46 CFR 182.200(a)

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of of its Certificate of Inspection giving consideration to provisions for a seaworthy hull. Significant pitting in port fuel tank. New inserts by end of dry dock.

Each buoyant apparatus must be fitted with a light. Buoyant apparatus on starboard of pilothouse has inoperable light. 46 CFR 180.175

A vessel must carry one ring buoy with a floating light. Ring buoy outside pilothouse has inoperable light. 46 CFR 180.70

Repairs or alteration to the hull machinery, or equipment that affect the safety of the vessel must not be made without approval of the cognizant OCMI, except during an emergency. Vessel struck antoher vessel causing exterior and interior damage while getting underway from pier. Vessel is not permitted to movement prior to an MI conducting a damage assessment and internal structural exam to ensure that no damage occured from mishap.

ZERO DRAFT: no static draft information

Make permanent repairs to holes in deck IWO main deck bar currently repaired with a doubler in no more than 60 days.

Fixed CO2 systems on inspected vessels need to be type approved and installed in accordance with applicable regulations. Relocate the CO2 pressure switch outside of the protected space. Cite: 46CFR118.410(b)(1)(i), See MSIB 1512 for reference

Vessel had correct # of PFDs however ~30 were stowed in wrong lockers.

Missing cap on generator fuel strainers.

Submit repair proposal and affect repairs to integral fuel tank leak.

Place instructions with line diagramn of system at CO2 pull station, 46 CFR "Old T" 181.20-15.

Prove proper operation of AIS.

Provide technician's report and prove proper operation of port main engine to the satisfaction of the USCG Marine Inspector as per 46 CFR 176.840.

Provide proof safety relief valve of port-side pressure vessle has been tested and approved IAW manufacturer specifications.

Replace F/O service hose to STBD MDE.

Provide properly Supplied first-aid kit IAW 46CFR160.041(b)

Inspect and make proper repairs to identified "pinhole" leaks in MSD tank.

"Provide proof of proper operation of the port main engine (loss of propulsion). Prior to being returned to service, the vessel shall be attended by Coast Guard inspector to witness/validate repairs. Prior to the operation of the vessel with passengers." 46 CFR 121.620

Demonstrate proper operation of the STBD MDE and provide details on suspected cause of casualty and repairs made.

Provide repair proposal for impact damage to port side aft.

Complete repairs in accordance with approved repair proposal.

Provide UT readings and replace hull plate as required in sewage void. Prior to credit dry-dock.

Repair sewage overboard disch. line (STBD side by ladder). Prior to credit dry-dock.

Renew deck drains in engine room.

Renew pipe in overhead in water tank void, STBD side by check valve. Prior to credit dry-dock.

Provide UT readings in water tank void. Repair if needed. Prior to credit dry-dock.

Provide UT readings in lazarrate port side and repair as needed. Prior to credit dry-dock.

Renew bulkhead bottom between sewage void and water tank void. Prior to credit dry-dock.

Prove proper operation of portside air receiver relief valve.

Properly label bilge high level alarm indicator lights at the operating station.

Provide spacers in between Bouyant Appartus on the starboard side stack.

Make proper repairs to double doors on 2nd deck aft.

Provide proof of current senior deckhand letter in accordance with NVIC 1-91.

Seal wire penetration in the starboard aft corner of the bridge.

Install spacers to the starboard buoyant apparatus tier in accordance with 46CFR 117.137(f)

Remove the temporary starboard oil temperature gauge on the reduction gear.

Tighten the port stern tube packing gland.

Repair as new, inoperable floating waterlight.

Provide PFD instruction placards for third deck. LEGACY COMPONENT DESC: Placard

Renew retro-reflective tape for 2 child PFDs and 1 adult PFD on third deck. LEGACY COMPONENT DESC: Retroreflective Material

Provide name of vessel on 1 adult PFD on third deck. LEGACY COMPONENT DESC: Marking

Repair hole in deck aft centerline near stairs on second deck. LEGACY COMPONENT DESC: Deck Plating

ProvidePFD storage placard for port main deck bench seat. LEGACY COMPONENT DESC: Storage

Repair leaking fuel oil transfer hose leading to fuel tank from fuel transfer pump in engine space. LEGACY COMPONENT DESC: Hose

Repair cracked starboard aft quarter exterior of main deck of superstructure and associated hand rails when vessel goes into the yard. LEGACY COMPONENT DESC: Superstructure

Repair hole located on forward bulwark below access cover for air vent and bow statue on second deck. LEGACY COMPONENT DESC: Access cover

Prove fire pump operation at 60 PSI per 46 CFR 181.10. LEGACY COMPONENT DESC: Pressure

Remove fuel oil soaked absorbent pads in trash can and drip tray located under fuel oil transfer pump and hose. LEGACY COMPONENT DESC: Fuel oil

Repair & prove proper operation of bilge high level alarms in #2 & #3 voids. LEGACY COMPONENT DESC: Interface Detector

Relocate outlet box and alarm on tonnage opening near galley space.

REBUILD METAL RING AROUND FOREPEAK HATCH

INSTALL SECURING DEVICE ON FOREPEAK HATCH

REMOVE DEAD-END CABLE IN VOID #5 LEGACY COMPONENT DESC: CABLE

REPAIR WELDS TO THROUGH DECK FITTING, PORT QUARTER, VOID #5 LEGACY COMPONENT DESC: Weld

REPAIR EXCESSIVE LOCALIZED PITTING ON STARBOARD BOW IWO ZINC. LEGACY COMPONENT DESC: Hull Plating

Repair holes in deck in galley space, according to agreed upon plans. LEGACY COMPONENT DESC: Deck Plating

INSTALL METALIC PIPING IAW 46 CFR56.60 AND 46 CFR 119.710 IN STERN TUBE FLUSHING SYSTEM.

RENEW WASTED TRANSVERSE STIFFENERS BELOW PORT AND STBD SHAFT LOGS IN ENGINEROOM.

RENEW LOWER PORTION OF TRANSVERSE FLOOR FRAMES FORWARD OF SHAFT LOGS FOR PORT AND STBD SHAFTS.

PROVE OPERATION OF AUXILIARY RADAR.

PROVE THAT FIRE PUMP PERFORMS PROPERLY IN ACCORDANCE WITH 46 CFR 181.10- 1(c).

SUBMIT PLANS FOR APPROVAL OF EXISTING BILGE, FIRE, AND SANITARY PUMP SYSTEM.

REPLACE RELIEF VALVE TO STARBOARD SIDE PRESSURE VESSEL AND REDUCE RELIEF VALVE SETTING TO PRESSURE VESSEL ON PORT SIDE.

MAKE ALL PFD'S STOWED ON UPPER DECK AVAILABLE FOR STAMPING BY USCG.

HYDROSTATICALLY TEST BOTH PRESSURE VESSELS IN THE PRESENCE OF A MARINE INSPECTOR AS PRESCRIBED IN 46 CFR 176.25-30(4).

PROVIDE PLACARD / DESCRIPTION OF OPERATION OF FIXED CO2 SYSTEM, IN CONSPICUOUS LOCATION SO PULL HANDLE IS EASILY LOCATED.

PROPERLY REPAIR TRIPPED FRAME #6 IN WAY OF RUB RAIL ON PORT SIDE OF VOID #3DURING NEXT DRYDOCK.

REPAINT EMERGENCY FUELSHUT OFF ACCESS RED.

PROVIDE ON HAND FIR PUMP. (WITH SUFFICINT HOSE)

PROVIDE ON ORANGE SMOKE FOR A TOTAL OF SIX.

PROVIDE ONE MARPOL PLACARD.

REPAIR RUDDER POST WEB SUPPORTS ON PORT AND STBD RUDDER USING GOOD MARINE PRACTICE.

SUBMIT PROPOSAL TO KEEP WEB FROM FLEXING AND CRACKING AGAIN.

REPAIR AND PROVE OPERATION OF ANCHOR LIGHT.
