If, during an internal structural exam (ISE), damage or deterioration to the hull plating, structural members, or cargo tanks is discovered, the Officer in Charge, Marine Inspection may require the vessel to be dry docked or otherwise taken out of service to further assess the extent of the damage and to effect permanent repairs. During the ISE, multiple areas of damage were discovered, including damaged structural supports and a leaking weld on the #2 cargo tank, port side in the #3 void. Barge shall discharge all cargo at the John W. Stone facility Intracoastal City, LA and proceed to the FMT shipyard in Harvey, LA, in accordance with the approved transit plan, to effect permanent repairs prior to carrying cargo. Vessel rep shall contact local OCMI upon arrival and prior to commencing repairs. 46CFR31.10-21(c)

Transfer hose, coming off loading arm, has kinks and needs to be replaced. Replace to the satisfaction of the attending USCG Marine Inspector prior to loading cargo.

Upper radiator hose on prime mover has a kink and needs to be replaced.

Replace fuel hose on port side due to outer layer wasted.

Several brackets throughout the barge need to be reattached. (Fuel line, fuel oil, hydraulic oil on loading arm) to the satisfaction of the attending USCG Marine Inspector.

Personnel engine platform is wasted and needs to be replaced or removed. STBD side.

Gauge on main cargo header needs to be replaced.

Replace hoses on fuel tank and port prime mover with new SAE J1942 hoses.

All three PV Valves inadequately labeled. Each valve shall be legibly marked with the style or other designation of the manufacturer, the size, pressure and vacuum settings.

Non Intrinsically safe batteries / electrical equipment located within 10 feet of discharge manifold/valve.

Observed multiple insets to the side shell plate in way of starboard #3 wing void. Insets appeared to have caused damage to internal frames: (side longs, diagonal stanchions, side transverse truss & intermediate floor frames). Internal framing was repaired during ISE. Side shell and intermediate floor frames to be cropped out and renewed during next dry dock in 2017.

Remove cargo hose obstructing the operation of OPA 90 rising stick gauge at the #2 cargo tank and ensure proper operation of that rising stick gauge.

INSTALL OVERFILL DEVICES IAW 33 CFR 155.480. VESSEL IS TO CARRY NO OIL AS DEFINED IN 33 CFR 151.05 UNTIL PROPER INSTALLATION OF OVERFILL DEVICES IS COMPLETE.

severe pitting on tank tops and exposed tank sides of all tanks - required to submit plan for guaging at next drydock

#4 & #5 starboard wing tanks standpipes repaired using red hand - required to submit plan for repair at next drydock

fractured weld on the external vertical tank frame on the tank side just forward of the #3 port wing void access - required to submit plan for repair at next drydock

PROVIDE CG APPROVED VESSEL RESPONSE PLAN OR CG LETTER THAT PLAN IS UNDER REVIEW.

VESSEL RESTRICTED FROM MOVEMENT OR CARGO OPERATIONS UNTIL CURRENT CERTIFICATE OF FINANCIAL RESPONSIBILITY PROVIDED.

STERN VOID, #5 VERTICAL LONG VEE AND REWELD (2) FRACTURE WELDS PORT_x001C_ SIDE.

#3PORT VOID, COUNTING FWD. TO AFT. IN #8 BAY COUNTING FROM BOTTOM TO TOP BETWEEN #3 &4 HORIZONTAL SIDE SHELL LONG MAKE REPAIRS AND REWELD FRACTURE WELDS.

#4 PORT VOID, COUNTING FWD TO AFT IN #1 BAY AND #5 BAY COUNTING FROM BOTTOMTO TOP, MAKE REPAIRS AND REWELD FRACTURE WELDS AT #5 HORIZONTAL SIDE SHELL LONG.

#2 PORT VOID, COUNTING FWD. TO AFT IN #3 BAY, COUNTING FROM BOTTOM TO TOP, MAKE REPAIRS AND REWELD FRACTURE WELDS AT #5 HORIZONTAL SIDE SHELL LONG.

STERN VOID, #4 VERTICAL LONG VEE AND REWELD (3) FRACTURE WELDS STBD SIDE AND (1) FRACTURE WELD PORT SIDE.

STERN VOID, #3 VERTICAL LONG VEE AND REWELD (1) FRACTURE WELD STBD SIDE.

STERN VOID, #1 VERTICAL LONG VEE AND REWELD (3) FRACTURED WELDS PORT SIDE.

STERN VOID, PORT SIDE REWELD FRACTURE WELD IN WAY OF #4 GUSSET.

PORT SIDE AFT MAKE REPAIRS TO QUICK DISCONNECT AIR STAND PIPE FOR DOUBLE BOTTOM.

D1-REPAIR/REPLACE EXHAUST MANIFOLD ON CARGO PUMP DIESEL ENGINE.

STERN VOID, #11 VERTICAL LONG VEE AND REWELD (1) FRACTURE WELD STBD SIDE AND (3) FRACTURE PORT SIDE.

STERN VOID, #14 VERTICAL LONG VEE AND REWELD (4) FRACTURE WELDS STBD SIDE.

STERN VOID, #12 VERTICAL LONG VEE AND REWELD (3) FRACTURE WELDS STBD_x001C_ SIDE

#2 STBD VOID, COUNTING FWD TO AFT. IN #4 BAY, COUNTING FROM BOTTOM TO TOP MAKE REPAIRS AND REWELD FRACTURE WELDS AT #5 HORIZONTAL SIDE SHELL LONG.

STERN VOID, #15 VERTICAL LONG VEE AND REWELD (2) FRACTURE WELDS PORT SIDE AND (5) FRACTURE WELDS STBD SIDE.

STERN VOID, #9 VERTICAL LONG VEE AND REWELD (2) FRACTURE WELDS STBD SIDE.

STERN VOID, #8 VERTICAL LONG VEE AND REWELD (3) FRACTURE WELDS PORT_x001C_ SIDE.

STERN VOID, #6 VERTICAL LONG VEE AND REWELD (1) FRACTURE WELD PORT SIDE.

D3-REPAIR RED NAVIGATION LIGHT.

D2-REPAIR/REPLACE OIL PRESSURE GAUGE AND TEMPERATURE GAUGE ON THE CARGO PUMP DIESEL ENGINE.

Permanently mark vessel name on stern. The complete name was not marked. Several areas were rubbed off.

Replace muffler on diesel driven cargo transfer pump.

Replace void hatch cover dogs on main deck as required where dogs are broken or missing.

REPAIR OR RENEW THE ACCESS HATCH TO THE FORWARD RAKE.

REPAIR WHERE CRACKED THE CENTERLINE BOTTOM SHELL PLATE ANGLE SHAPED FRAMINGMEMBER LOCATED IN THE SECOND BAY AFT OF THE FOREPEAK HEAD LOG, AT THE VESSELS NEXT DRYDOCKING.
