USNS HENSON

The Company should establish procedures to ensure that the ship is maintained in conformity with the provisions of of the relevant rules and regulations. In meeting these requirements the company should ensure the inspections are held at appropriate intervals, any non-conformity is reported, with its possible cause, if known, appropriate corrective action is taken; and records of these activities are maintained. Vessel is enrolled in ABS Planned Maintenance Program (PMP). A review of randomly select items from the annual vibration and oil analysis reports, identified that several critical components required immediate attention (Bow Thruster Lube Oil Pump, Air Operated Oily Waste Transfer Pump, #1 Main Propulsion Generator). Review of the vessels SAMMS maintenance program revealed no corrective actions had been taken for these items. Conduct external audit on ABS planned maintenance program. 74 SOLAS (24)IX/3.1, ISM Reg. 10.1 and 10.2

Vessel reported a scheduled AFFF agent lab test cameback as unstable. Vessel used back-up agent to replace the primary that was unstable. Vessel is required to have backup AFFF agent in accordance with their approved fire plan. 46CFR193.05-10(b)

A sufficient number of lifejackets shall be carried for persons on watch. Lifejackets shall be so placed as to be readily accessible and their position shall be plainly indicated. Where, due to the particular arrangements of the ship, the lifejackets provided may become inaccessible and alternative provisions shall be made to the satisfaction of the Administration which may include an increase in the number of lifejackets to be carried. Engine Control Room does not have adequate number of life jackets and immersion suits for watch standers when personal survival appliances may be inaccessible. Fire control plan and SOLAS placards to be updated to include personal survival appliances to be stowed in the ECR for both watchstanders. 74 SOLAS (1997) III/7.1.1.2 and 74 SOLAS (1997) III/7.2.2

The port and stbd engine room supply dampeners and natural supply dampeners do not fully close when activated.

The port and stbd life boat's aft quarter is damaged by the davit's inboard aft resting blocks. Make repairs in accordance with manufacture's approved procedures and provide approval letter.

The port and starboard life boat's davit has excessive metal wastage on the davit's harbor locking pins receptacle padeyes and accepting flat bar, cable pulley mounts, & davit arm heads.

The port life boat embarkation station flood lamp mount has broken off.

Every ship shall be provided with a main and auxiliary steering system to the satisfaction of the administration. Vessel's thruster system is inoperable and satisfactory operation was unable to be witnessed. 74 SOLAS(14) II-1/29.1

The following fire protection systems shall be kept in good order so as to ensure their required performance if a fire occurs: structural fire protection, including fire resisting divisions, and protection of openings and penetrations in these divisions. Machinery space fire dampers failed to fully close upon activation of remote ventilation shutdown. 74 SOLAS(14) II-2/14.2.1.1.1

Where penetrations of watertight bulkheads and internal decks are necessary for access, piping, ventilation, electrical cables etc. arrangements are to be made to maintain watertight integrity. Power cable for STBD underwater hull shall be routed through the fore and aft watertight bulkheads of the space with type approved penetrations. 74 SOLAS(04) II-1/25-9.1

Electrical installations shall be such that: the safety of passengers, crew and ship from electrical hazards will be ensured. 480 volt junction shall be replaced with appropriate type/size and dead end cable shall be removed or properly terminated. 74 SOLAS(04) II-1/40.1.3

The condition of the ship and its equipment shall be maintained to ensure that the ship in all respects will remain fit to proceed to sea. The main deck port side vent at location 01-25-2 found wasted and non weathertight. 74 SOLAS(14) I/11

The following fire protection systems shall be kept in good order so as to ensure their required performance if a fire occurs: Structural fire protection, including fire resisting divisions, and protection of openings and penetrations in these divisions. Vent cover associated with generator room (01-7-1) on 01 starboard deck has 04 holes cut into the bottom which circumvent closure as well as a wasted portion on the bottom outboard and a separate hole around the exterior siding of the vent housing. 74 SOLAS(04) II-2/14.2.1.1.1

The following fire protection systems shall be kept in good order so as to ensure their required performance if a fire occurs: structural fire protection, including fire resistant divisions, and protection of openings and penetrations in these divisions. Vessel found with the following fire screen doors out of compliance: 1-5-4-3 (fan room inside conference room does not fully close), 1-112-0 (staging bay door main deck does not fully close). 1-87-2 & 01-66-1 (lower hose ports damaged), and the galley and compactor spaces have holdback hooks which prevent required self-closing. 74 SOLAS(04) II-2/14.2.1.1.1

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Forward and aft wire ropes on port lifeboat that attach to bow and stern horns have frayed and broken wires. 74 SOLAS(14) I/11

Electrical installations shall be such that the safety of passengers, crew and ship from electrical hazards will be ensured. Electrical box in overhead of chart room missing cover and wire wrapped in electrical tape. Exposed wire associated with wiper on port bridge wing. 74 SOLAS (04) II-1/40

Every person designated to take charge of medical care onboard vessels subject to the STCW Convention must hold an MMD or MMC endorsed as person in charge of medical care. Vessel has onboard ships 'Medic/Nurse' who does not currently hold endorsement for person in charge of medical care. 46CFR15.404(i).

The following fire protection systems shall be kept kept in good order so as to ensure their required performance if a fire occurs: structural fire protection, including fire resisting divisions, and protection of openings and penetrations in these divisions. The following multiple cable transits shall be installed IAW type approval: All transits from chart room to bridge; bridge console to belowdecks; main switchboard transits fore and aft; MCT # 76 & # 12 74 SOLAS(04) II-2/14.2.1.1.1

In addition to complying with the specific provisions for fire integrity of bulkheads and decks of cargo ships, the minimum fire integrity of bulkheads and decks shall be as prescribed in tables 9.5 and 9.6. Opening in two class A galley pass through bulkheads are protected with steel roller shutters and dedicated fusible links. Fubislbe links are concealed within metal overhead and shielding them from heat/proper operation. Install links so they are exposed to properly operate in the event of a fire. 74 SOLAS(14) II-2/9.2.3.3.1

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Upper boat deck near port bridge wing had wasted handle and piping on pneumatic line coming through house bulkhead. 74 SOLAS(14) I/11

The Administration shall satisfy itself that the general structural strength of the ship is adequate for the draught corresponding to the freeboard assigned. Noted holed bulkhead on port side main deck below vent 01-90-2. IICL 66, Reg 1

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Port side main deck ‘sea beam cable’ vent wasted and broken off where pipe penetrates main deck. Forward railing around port lilfeboat wasted and port and starboard stanchion eyes for securing railing on main deck are wasted in several locations. 74 SOLAS(14) I/11

All such openings in the bulwarks shall be protected by rails or bars spaced approximately 9 inches apart. Removable chains on starboard main deck exceeded 9 inches in two locations. Install proper rail heights on removable portions of starboard main deck rails. IICL 66, Reg 24

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Port side forward davit hook tied into gripe is showing signs of necking/wastage. Replace or repair hook. 74 SOLAS(14) I/11

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Several faded ring buoy placards throughout weather decks. Replace all faded ring buoy placards. 74 SOLAS (14) I/11

The following fire protection systems shall be kept in good order so as to ensure their required performance if a fire occurs: structural fire protection, including fire resisting divisions, and protection of openings and penetrations in these divisions. Noted lifting arrangement on galley deck that passes through hatch on several subsequent A boundary decks below for the purpose of moving ship’s stores were left open. Crew stated hatches were left open during working hours which would allow a fire to immediately propagate to multiple decks in the event of a fire. Directed crew to secure hatches immediately after each use. 74 SOLAS(14) II-2/14.2.1.1.1

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. The number one start air compressor's electric motor failed which rendered the number one start air compressor inoperable.

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended. Ballast/SW Cooling pipe located in overhead in aft pump room found with temporary repair (JB Weld/rubber patch/C-clamped) Make permanent repairs to the damaged section of piping as designed.

The main inlets and outlets of all ventilation systems shall be capable of being closed from outside the spaces being ventilated. Ventilation closure on port side 01 deck at FR76 found to be inoperable as handle moves but internal mechanics do not operate. Make permanent repairs as required.

ICLL 66 Reg. 1; 46 CFR 42.09-45(a): Crop out wasted edges on watertight ventilation enclosure on stbed main deck and repair to as original prior to departure to the satisfaction of attending Classification Society.

ICLL 66 Reg. 1; 46 CFR 42.09-45(a): Watertight door to ET shop on stbd side main deck with hole. Crop out to good metal and repair to as original prior to departure to the satisfaction of the attending Classification Society.

ICLL 66 Reg. 1; 46 CFR 42.09-45(a): Watertight door to lab on stbd side main deck with wastage. Crop out to good metal and repair to as original prior to departure to the satisfaction of attending Classification Society.

46CFR199.70(a)(3)/199.45(b)(3): Stbd ring buoy lanyard with dry rot. Replace with new to as original. Ring buoy, smoke float, and buoyant light must be properly installed in a quick release buoy bracket to allow all three to easily deploy.

46CFR199.70(b)(2)(i): USCG observed crewmember on bridge having difficulty removing PFDs that are jammed inside stowage box attached to bulkhead. Install larger stowage box for bridge watch stander PFDs or provide alternative location on bridge to stow PFDs to be readily available.

Oily Water Seperator is inoperable as designed. When operating underway vessel must retain waste oil/slops onboard. In-port vessel will discharge to approved shore side facility or another vessel until repairs are completed. Make permanent repairs IAW manufacturers specifications.

Approximately 20% of onboard life-jackets have holes/tearing and are past service life. Replace holed/deteriorating jackets. The remaining 80% are nearing service life expiration. Recommend implementing replacement plan over next few years to replace remaining deteriorating life-jackets.

Provide tech report from [name withheld] showing satisfactory repair of port lifeboat lube oil leak. Turbo charger seal allowed lube oil to leak through exhaust outlet.

PROVE PROPER OPERATION OF # 1 MOTOR PROPULSION UNIT.

PROVE PROPER OPERATION OF # 2 SSGD.

PROVE PROPER OPERATION OF THE OWS.

PROVE PROPER OPERATION OF THE # 3 SSDG.

Replace rubber guards on port lifeboat.

Provide letter as to shelf life of EEBD's.

F/O shut off valves not operating, prove proper operation.

Label emergency fire pump on diagram.

Repair emergency fire pump, to the satisfaction of the attending ABS surveyor.

Prove steering gear alarms as required by SOLAS.

Place on the SAMMS PMS the testing of fuel shutoff valves.

Adjust WTD in steering gear room.

Repair leaks in steering gear.

Repair supply/exhaust vents on deck for MDE.

Repair the starboard lifeboat steering system.

make permanant repairs to pneuemtaic fuel oil shut off vales in 1-12-2, 4-81-2 and 4-80-3.

port life boat engine produces an oil sheen when put in the water. Make necessary repairs and prove proper operations of port life boat.

Bushings failed on #2 lifeboat propulsion shaft. Vessel has conducted temp repairs and will complete permenant repairs prior to departure from next port call. LEGACY COMPONENT DESC: Propeller Shaft

Provide all SOVC statutory compliance documents per MSC message.

FIXED HIGH PRESSURE HALON CYLINDER USED AT PAINT LOCKER; RETEST, REFILL ANDRETURN TO SERVICE ACCORDING TO 49CFR173. INSTALLATION TO SATISFACTION OF ATTENDING MARINE INSPECTOR.

Conduct hydro test of all composite self contained breathing appratus air bottles._x001C_ _x001C_ _x001C_

PROPERLY REPAIR FIRE SCREEN DOOR 2-104-0._x001C_ _x001C_ _x001C_ _x001C_

Adjust auto closure to fire screen door 1-87-2.

Repair fire hose port to fire screen door 1-120-2.

PROVIDE FOAM ANALYSIS REPORT TO MSO SAN JUAN._x001C_ _x001C_ _x001C_ _x001C_

Remove dead-end wiring to port and starboard propulsion meter temperature guage.

CONDUCT FUNCTION TEST OF FUEL OIL EMERGENCY CONTROL VALVES LOCATED IN CONTROL_x001C_ ROOM.

PROPERLY LABEL ACTIVATION INSTRUCTIONS TO ESD SWITCHS TO MAIN PROPULSION SYSTEMS INDICATION DIRECTION OF ACTIVATION.

PROVIDE TRAINING MANUAL TO CREW AND OFFICERS MESS IN ACCORDANCE WITH 46 CFR199.180_x001C_

CONDUCT FUNCTION TEST OF FUEL OIL TRANSFER PUMP REMOTE SHUT DOWN._x001C_

INSTALL FLAME SCREENS TO VENTS: 4-10-0 & 4-35-1.

CONDUCT WEIGHT TEST OF PORT LIFEBOAT TO THE SATISFACTION OF CG MARINE INSPECTOR.

PROPERLY INSTALL LIFERAFTS INTO CRADELS PRIOR TO VESSEL DEPARTURE._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE SERVICING REPORTS FOR AL LIFERAFTS TO MSO SAN JUAN.

RENEW RETRO-REFLECTIVE TAPE ON TOP AND OUTBOARD SIDES OF BOTH THE PORT AND STARBOARD LIFEBOATS.

REPAIR THE PORT LIFEBOAT AFT WINDOW.

CONDUCT FUNCTION TEST OF PORT LIFEBOAT ENGINE PRIOR TO VESSEL DEPARTURE._x001C_ _x001C_ _x001C_ _x001C_

PROPERLY BLANK ELECTRICAL BOX OPENING ABOVE FSD 1-99-1. BULKHEAD IN THE DRY& BIOCHEM LAB.

STENCIL BOAT NUMBER AND NAME ON TOP OF BOTH LIFEBOATS.

Conduct hydro test of fuel oil bunker piping in accordance with 46 CFR 156.170(c)(4)._x001C_ _x001C_ _x001C_

Provide calibration gas for the breath testing device._x001C_ 46CFR16.240

Remove all foot and other door hold backs to firescreen doors in machinery spaces prior to departure._x001C_ _x001C_ _x001C_

Provide fire fighting report to MSO San Juan._x001C_ _x001C_ _x001C_ _x001C_

CHECK AND REPLACE AS NEEDED BATTLE LANTERN BATTERIES THROUGHOUT VESSEL AND IN PARTICULAR - BRIDGE BATTLE LANTERNS.

REPAIR OR REPLACE THE OXYGEN ANALYZER IN FORWARD REPAIR LOCKER.

REPLACE BATTERIES IN WATERLIGHTS WITH APPROVED TYPE.

PROVIDE EVIDENCE OF ANNUAL FIXED & PORTABLE FIRE EXTINGUISHING SYSTEMS FROMAN APPROVED SERVICING FACILITY.

REPAIR INOPERATIVE CLASS 3 DOOR INDICATING LIGHTS ON BRIDGE PANEL.

REMOVE UNAPPROVED CO2 SHUTDOWN SWITCH IN BOW THRUSTER ENCLOSURE OR SUBMIT TO G-MSC FOR APPROVAL.

FREE UP AND TEST ALL WEATHER DECK FIRE DAMPERS.

PROVIDE EVIDENCE OF ANNUAL LIFERAFT SERVICING FROM AN APPROVED SERVICING FACILITY.

Perform satisfactory abandon ship drill.

Perform satisfactory fire drill.
