09 - Working and Living Conditions › 092 - Working Conditions › Electrical
Issued 10 June 2020
Resolved
Where ends of stranded conductors are to be clamped under terminal screws, they shall be formed and soldered unless fitted with pressure terminal connectors listed by Underwriters' Laboratories, Inc. Terminal boards located behind console were fitted with non-authorized terminal connectors. Vsl currently has flat spade connectors, but is required to have flanged or ring terminal connectors due to vsl vibration.
46 CFR 183.05-50(b)(3)
60c
Action required: 60 - Rectify deficiencies prior to movement
Resolved 25 June 2020
Resolution: Vsl provided photo documentation of authorized ring terminal connectors.
09 - Working and Living Conditions › 092 - Working Conditions › Electrical
Issued 10 June 2020
Resolved
Wiring joints and splices shall be mechanically secure and made in junction boxes. Wiring on bilge pump sensor in steering space was found to have two splices not enclosed in a junction box. Exposed wiring located under Captain's chair in wheelhouse. Secure splices/dead end wiring in junction box or remove if unnecessary.
Action required: 60 - Rectify deficiencies prior to movement
Resolved 25 June 2020
Resolution: Vsl provided photo documentation of removed unauthorized wiring.
11 - Life Saving Appliances › N/A - No Subsystem › Lifebuoys incl. provision and disposition
Issued 10 June 2020
Resolved
Each ring life buoy must be marked with Type II retro- reflective material. Current reflective tape is deteriorated or portions torn off. Replace per regulations.
46 CFR 185.604(i)
60c
Action required: 60 - Rectify deficiencies prior to movement
Resolved 25 June 2020
Resolution: Vsl provided photo documentation of new ring buoy w/acceptable reflective material.
11 - Life Saving Appliances › N/A - No Subsystem › Lifebuoys incl. provision and disposition
Issued 10 June 2020
Resolved
Each ring life buoy with a floating waterlight must have a lanyard of at least 3ft in length but not more than 6ft securing the waterlight around the body of the ring life buoy. The lanyard attaching the waterlight to the ring life buoy is sundamaged and no longer pliable. Replace lanyard to satisfaction of CG.
46 CFR 180.70(d)(2)
60c
Action required: 60 - Rectify deficiencies prior to movement
Resolved 25 June 2020
Resolution: Vsl provided photo documentation of new ring buoy w/acceptable lanyard.
13 - Propulsion and Auxiliary Machinery › N/A - No Subsystem › Operation of machinery
Issued 10 June 2020
Resolved
Generators for use in machinery spaces shall generally be designed for an ambient temperature of 122 degrees Fahrenheit. Current generator is rated for 104 degrees Fahrenheit. Generator in engine space must be derated to 80 percent of full load rating by manufacturer or have manufacturer supply new data plate rating the generator for 122 Fahrenheit.
46 CFR 183.10-5(f)
60c
Action required: 16 - Rectify deficiencies w/in 14 days
Due 24 June 2020
Resolved 29 June 2020
Resolution: Vsl provided photo documentation of new generator data plate authorizing generator operation of 95% at 50C degrees.
10 - Safety of Navigation › N/A - No Subsystem › Lights, shapes, sound-signals
Issued 10 June 2020
Resolved
All vessels must have navigation lights that are in compliance with the applicable sections of the Inland Navigation Rules. Vsls stern light was inoperable. Correct to satisfaction of the CG and prior to nighttime operations.
Action required: 705 - Other - as specified
Resolved 25 June 2020
Resolution: Vsl provided photo documentation of operable navigation light.
01 - Certificates & Documentation › 011 - Ships Certificates › Other (certificates)
Issued 10 June 2020
Resolved
Every vessel must have a detailed inspection of the radio installation by an FCC-licensed technician once every five years. Vsl's FCC Radiotelephony Safety Certificate expired March 2020.
47 CFR §80.903
16c
Action required: 16 - Rectify deficiencies w/in 14 days
Due 24 June 2020
Resolved 15 June 2020
Resolution: Vsl provided photo documentation of current/issued Radiotelephony Certificate.
07 - Fire Safety › N/A - No Subsystem › Fire fighting equipment and appliances
Issued 28 March 2019
Resolved
Operating station fire extinguisher not inspected within past 12 months. Correct to satisfaction of attending Marine Inspector.
Action required: 10 - Deficiency Rectified
Resolved 28 March 2019
05 - Radio Communications › N/A - No Subsystem › Functional requirements
Issued 28 March 2019
Resolved
MMSI not programmed into VHF radio. Correct to satisfaction of attending Marine Inspector.
Action required: 16 - Rectify deficiencies w/in 14 days
Due 12 April 2019
Resolved 29 March 2019
Resolution: Received proof of MMSI being programmed into VHF/DSC. Cleared deficiency.
10 - Safety of Navigation › N/A - No Subsystem › Charts
Issued 28 March 2019
Resolved
Local charts not up to date. Correct to satisfaction of attending Marine Inspector.
Action required: 16 - Rectify deficiencies w/in 14 days
Due 12 April 2019
Resolved 3 April 2019
Resolution: Received proof of satisfactory charts onboard vessel. Cleared def.
Engineering › Bilge Water Management System › Piping
Issued 22 March 2018
Resolved
Provide proper metallic fitting on bulkhead between steering and engine compartment for bilge suction piping and secure all piping in engine compartment bilge. Conduct repair to bilge piping system.
Action required: 17 - Rectify deficiencies prior to departure
Resolved 27 March 2018
Resolution: Installed metallic fitting on bulkhead and installed brackets to keep piping in place in engine compartment bilge.
Engineering › Lubricating Oil Service System › Filter
Issued 22 March 2018
Resolved
Port and Stbd main diesel engines have major lube oil leaks on the l filter housing inlet/discharge flanges. Conduct repairs to both engines.
Action required: 17 - Rectify deficiencies prior to departure
Resolved 27 March 2018
Resolution: Replaced faulty seals on the oil filter housing on both main diesel engines.
Engineering › Reduction Gearing/Clutches › Clutch Plate
Issued 22 March 2018
Resolved
Port engine does not clutch ahead/astern. Conduct repairs.
Action required: 17 - Rectify deficiencies prior to departure
Resolved 22 March 2018
Resolution: Added Lubricating oil to reduction gear. Tested clutcing in forward and astern with satisfactory results.
Engineering › Bilge Water Management System › Piping
Issued 22 March 2018
Resolved
Bilge system deck connection piping inside engine space has a hole. Renew damaged section of pipe to satisfaction of marine inspector.
Action required: 17 - Rectify deficiencies prior to departure
Resolved 27 March 2018
Resolution: Cropped and renewed affected piping with new pipe.
Construction/Loadline › Hull › Weld
Issued 22 March 2018
Resolved
Conduct repair of cracks on Steering compartment hatch frame and outboard side of port engine near aft engine mount.
Action required: 705 - Other - as specified
Due 6 April 2018
Resolved 27 March 2018
Resolution: Cropped and renewed steering compartment hatch frame and repaired weld by aft engine mount by port engine.
Electrical › Lighting (service) › Conductor
Issued 22 March 2018
Resolved
Aft flood light wired incorrectly. Remove light or make a permanently wire the light to satisfaction of marine inspector.
Action required: 705 - Other - as specified
Due 6 April 2018
Resolved 27 March 2018
Resolution: Removed lamp and associated wiring for the same.
Engineering › Fuel Oil Service System › Vent Pipe
Issued 15 March 2018
Resolved
Flame screen on fuel tank vent is painted over. Renew vent screen with new material.
Action required: 705 - Other - as specified
Due 6 April 2018
Resolved 27 March 2018
Resolution: Installed new flame screen on fuel tank vent.
Construction/Loadline › Hull › Longitudinal Frame
Issued 15 March 2018
Resolved
Port engine, outboard side aft engine mount. While conducting repairs to crack by engine mount further cracking was developed. Existing crack- conduct proper procedures and weld crack. 3"X18"X3/8" doubler is authorized to strengthen engine mount/bed. Any further cracking will need to be inspected by CG Marine Inspector and final repairs will need to be inspected by Marine Inspector.
Action required: 17 - Rectify deficiencies prior to departure
Resolved 3 April 2018
Resolution: Witnessed satisfactory repair of port engine bed.
Engineering › Generator (propulsion/auxiliary-electric) › Winding
Issued 14 March 2017
Resolved
Clean generator of accumulated oil.
Condition: Improper/Lack of Maintenance
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified generator was cleaned of accumulated oil.
Construction/Loadline › Structures › Manhole
Issued 14 March 2017
Resolved
Provide repair proposal for cracked hatch and cracked weld on vertical frame of forward bulkhead in lazarette.
Condition: Improper/Lack of Maintenance
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified replacement of hatch cover, repair of crack in the hatch opening, and conducted satisfactory test of hatch's water tight integrity.
Electrical › Electrical Distribution System (service) › Wiring
Issued 14 March 2017
Resolved
Replace terminals for port engine flow sensor with appropriate type.
Condition: Improper Installation
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified replacement of terminals with ring type connections.
Engineering › Diesel Engine (propulsion-direct drive) › Charge Air Cooling
Issued 14 March 2017
Resolved
Clean air intakes on port and Starboard engine of accumulated oil.
Condition: Improper/Lack of Maintenance
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified cleanliness of both engine air intakes.
Engineering › Fuel Oil Storage/Transfer System › Ventilation
Issued 14 March 2017
Resolved
Replace flame screen on fuel vent with 30X30 screen.
Condition: Improper Installation
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified fuel vent had an appropriate flame screen.
Electrical › Electrical Distribution System (service) › Wiring
Issued 14 March 2017
Resolved
Repair loose wire on top of distribution panel and outlet box on side.
Condition: Improper/Lack of Maintenance
Action required: 705 - Other - as specified
Due 28 March 2017
Resolved 28 March 2017
Resolution: Attended vessel and verified replacement of the loose wires on top of the distribution panel and the side of the outlet box.
