FREEDOM

The two required fixed power bilge pumps shall be self-priming and shall each be driven by different sources of power. Vessel has combined bilge/fire pump, cross connection for suction was not operation during the time of inspection. Repair or replace as necessary to the satisfaction of the attending marine inspector prior to carrying passengers. 46 CFR 182.25-10(c) (Old T)

The minimum capacity of the power fire pump shall be 50 gallons per minute at a pressure of not less than 60 pounds per square inch at the pump outlet. The pump outlet shall be fitted with a pressure gauge. Port side pump gauge not working during inspection. Repair/replace to the satisfaction of the attending marine inspector. 46 CFR 181.10-1(c) (Old T)

The individual bilge suction lines shall be led to a central control point or manifold. Each line shall be provided with a stop valve at the control point or manifold and in addition shall be provided with a check valve at some accessible point in the bilge line. Starboard engine room bilge suction line does not have a check valve installed to prevent back flooding. Install to the satisfaction of the attending marine inspector. 46 CFR 182.25-5(c) (Old T)

Fuel lines shall be accessible, protected from mechanical injury, and effectively secured against excessive movement and vibration by the use of soft non-ferrous metal straps with no sharp edges. Port fuel tank return line was leaking during inspection. Repair to the satisfaction of the attending marine inspector. 46 CFR 182.20-40(b)(2) (Old T)

Decks between various spaces must meet the requirements of Table 116.415(c). The deck separating the port side engine room and the main deck accommodation space is required to be an A-60 boundary. Insulation was not properly secured in the port side engine room on the left side of the overhead and along the left side bulkhead. Secure with the proper grating to ensure A-60 boundary is met as per manufacturers recommendations for fire rating insulation, to the satisfaction of the attending marine inspector.

Marine employers must establish programs for the chemical testing for dangerous drugs on a random basis of crewmembers on inspected vessels who: (1) Occupy a position, or perform the duties and functions of a position, required by the vessel's Certificate of Inspection; (2) Perform the duties and functions of patrolmen or watchmen required by this chapter; or, (3) Are specifically assigned the duties of warning, mustering, assembling, assisting, or controlling the movement of passengers during emergencies. Provide proof of company policy established for crewmembers that meet this requirement for chemical testing to the satisfaction of the attending marine inspector.

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspection. Port generator light was out on main generator panel during inspection. 46 CFR 183.01-15 (Old T)

Vessels whose routes are restricted to 20 miles from a harbor of safe refuge shall carry life floats or buoyant apparatus for not less than 50 percent of all persons on board. 01 life float needs to be serviced and repaired. When vessel is more than 01 mile from shore passenger count is reduced to 220.

At each subsequent inspection for certification, re-inspection, and at every other vessel inspection, the marine inspector shall require that all observed unsafe practices and hazardous conditions are corrected. Vessel’s port generator had excessive oil on the rear part of the engine in the vicinity of the turbocharger. O/O is to clean affected area and re-route crankcase breather to prevent future oil and fire hazards from occurring. 46CFR176.25-50 (Old T-L)

At each subsequent inspection for certification the marine inspector shall view the vessel afloat and conduct tests and inspections of the hull and its’ appurtenances. Upon visual examination of the hull and watertight envelope, damage was noted on the main deck port quarter of the vessel where the transom meets the side shell and deck. An approximate one-foot crack/tear was noted that penetrates the deck into the steering compartment. O/O is to submit a repair proposal documenting temporary and permanent repairs to the area for OCMI review. 46CFR176.25-5 (Old T-L)

Portable fire extinguishers shall be installed and located to the satisfaction of the [name withheld] extinguisher and mounting bracket in the vicinity of the bar area on the second deck was loose and never mounted to its’ designated location. O/O to mount extinguisher and its’ associated bracket in accordance with the vessel fire control plan. 46CFR181.30-10(b) (Old T-L)

Each ring life buoy must be marked with Type II retroreflective material approved in 46CFR164.018 in subchapter Q of this chapter or other standard specified by the Commandant. The arrangement of the retroreflective material applied after March 11, 1996, must be as specified by IMO Resolution A.658(16). Stern and Stbd 2nd deck lifering buoys missing pieces of correct retro-reflective tape.

Each floating waterlight must be attached to a lanyard with a corrosion-resistant clip. The clip must allow the waterlight to be quickly disconnected from the ring life buoy. Waterlight was found to be attached with a shackle.

A hatch exposed to the weather must be watertight. Port aft lazarette hatch was found with a 1 inch missing piece of gasket.

All wiring and cable shall be suitable for marine service and for particular installations used. In addition, flexible or portable cords such as SO, STO, and similar types cannot be used for permanently installed wiring. Pilot house has multiple navigation electronics plugged into surge protector portable cord. Remove surge protector and install a permanent power supply for vital navigation equipment. 46CFR183.10-20(a)(2)

Vessels must have navigation lights that are in compliance with the applicable sections of the International and Inland Navigation Rules, except that a vessel of more than 19.8 meters (65 feet) in length must also have navigation lights that meet UL 1104, “Marine Navigation Lights,” or other standard specified by the Commandant. Port and Stbd side lights do not meet this requirement.

All escape hatches and other emergency exits used as means of escape must be marked on both sides in clearly legible letters at least 50 millimeters (2 inches) high: “EMERGENCY EXIT, KEEP CLEAR”, unless such markings are deemed unnecessary by the cognizant [name withheld] all escape exits according to regulation.

A vessel of more than 19.8 meters (65 feet) in length must carry a minimum of three life buoys of not less than 610 millimeters (24 inches) in diameter and must be IAW 160.050 in subchapter Q. Port aft ring buoy on main deck found with a hole in it exposing internal material. Repair or replace life ring.

All vessels of 26 feet in length and over shall be provided with individual bilge lines and bilge suctions for each watertight compartment. The bilge suction in the portside water tank room (space #4) was not able to pump out water.

The bilge suction shall be fitted with suitable strainers having an open area not less than three times the area of the bilge pipe. No strainer was found on the bilge pipe in the portside forepeak space.

At each initial/subsequent inspections for certification of a vessel, inspection of all accessible parts of the exterior & interior of the hull. There is extensive pitting in the WTD bulkhead in the #1 starboard void on the aft bulkhead just inboard of the fresh water intake bulkhead fitting. Replace prior to hull exam credit.

At each initial/subsequent inspections for certification of a vessel, inspection of all accessible parts of the exterior & interior of the hull. The fresh water intake bulkhead penetration in aft starboard void #1 is severely corroded. Replace prior to hull exam credit.

Auxiliary machinery shall be suitable for the purpose intended and maintained in such a manner as to afford adequate protection again machinery failure and personnel injury. The port main engine in the starboard engine room exhaust discharge flexible pipe was missing a double clamp on the hull side.

Mechanically propelled "L" vessels shall comply with the provisions of Subchapter F of this chapter. Nonmetallic flexible hose may be may be used in vital fresh and salt water systems at a maximum service pressure of 150 psi. Nonmetallic flexible hose may be used in lengths not exceeding 30 inches where flexibility is required. 04 sections of straight bilge pipe have been replaced with nonmetallic flexible hose where flexibility is not required. Replace prior to hull exam credit.

One length of fire hose shall be provided for each hydrant. 03 hoses unserviceable. Required prior to carrying passengers. 46 CFR 181.15-10

Vsl is broadcasting invalid MMSI, Vsl is broadcasting NAME with Vsl type precursor (NAME must not include Vsl type precursors, e.g. F/V, M/V), Vsl is broadcasting no dimension information (AIS Antenna Position ABCD values equals 0) and Vsl is broadcasting no static draft information

Replace stuffing box flange on portside inboard shaft.

Repair crack in frame in void #3 & cracks on frames in void #2 as marked.

Repair leak in port side fuel tank to the satisfaction of the attending marine inspector.

Repair port side aft fire station fitting.

Provide structural fire protection in port side engine room in the two discussed location.

Repair or replace inboard portside flange on stuffing box.

Secure dead end wires in box.

Provide flashlight for each engine room.

Provide spanner wrench for fwd fire station.

Stencil life float paddles with vessel name.

STBD aft fire station leaking. Repair leaks.

Port fire main on main deck leaking. Repair leaks.

Port aft fire station leaking. Repair leaks.

Cover opening on PORT switchboard.

Label 04 emergency escape hatches- "Emergency Exit, Keep Clear".

Mount junction box in galley.

Repair deck drain pipe in PORT Lazarette.

Repair hydraulic leak forward of operating station.

Make 02 pilothouse doors weather tight. 46 CFR 116.1160

Port engine room bulkhead and overhead fire protection insulation were found to be damaged. Issued requirement to repair or replace insulation outboard and above the port reduction gear.

Replace gasket in void #2, STBD side.

Fill hole port side deck aft of 2nd frame above tunnel.

Replace wasted fuel return line in Port Machine Shop.

Repair leaking union on fire main above Z/C breaker in Port Machine Shop.

Provide corrosion resitant fire nozzle of suitable material.

Provide Senior deckhand designation letter.

Repair "A" class fire door on 2nd deck accomodation space.

Separate child and adult life jackets in fantail storage.

All of the vessel's buoyant apparatus are in unserviceable condition and have been removed for repair or replacement. Until they have been replaced on board, the vessel is limited to a Lakes, Bays and Sounds route inside a line drawn from Eastern Point, MA to the Graves then to Strawberry Point, MA and not more than one mile from shore under reasonable operating conditions.

Temperature gauge in pilot house inoperable for port outboard engine.

Repair inoperable magnetic compass light.

Waterlight full of water. Replace waterlight for life float secured in stbd side, bottom, inboard.

Properly support engine wiring in accordance with 46 CFR 111.60-17

Transformer protection for shore power must be in accordance with 46 CFR 111.20-1. Secure and label for pax safety.

Repair/re-build inop starboard generator

Replace all cracked 32 volt batteries in pilot house console.

Place exposed wires under pilot house in proper junction box.

Replace out of date sigmnal flares.

Replace fuel hoses in port and starboard fuel filter system that do not have properly fitted connections.

Replace missing machinery guards for all MDE's

Provide fire service report.

Install all Bouyant apparatus properly prior to carrying passengers.

Replace f/o hose on stbd outboard MDE.

Make repairs to cracked vent line & replace rubber boot on port, outboard MDE

Replace rubber hose connection on discharge side of firepump w/ metallic piping.

Install lagging of exhaust pipe of starboard, inboard MDE

Provide six orange smoke distress signals.

Stencil the vessels name on the new life ring.

Repair all of the cracks as needed with an approved repair kit on all of the lifefloats.

Inspect the fixed CO2 fire extinguishing system for the engine room.

Provide and install retaining devices for the lazzarette hatches.

Due to piping and pump replacement system will need to be operationally tested prior to vessel operation

Repair fuel supply piping on Port outboard MDE. Pipe needs to be in bracket.

Repair all fire extinguisher brackets.

Renew hatch gaskets on port and starboard voids.

Repair hatch lanyards on stbd void.

Provide chaffing protection on transformer cable that runs under port generator.

Renew port forepeak valve.

Shelf connecting port and starboard hull voids is holding water and starting to rot the aluminum, properly repair or remove this water.

Renew lagging on all engine exhaust.

Renew oil crankcase breather hose on port outboard MDE.

Renew inboard bilge dewatering pipe running through port storeroom void. (pipe is wasted)

Remove water from #1 void in both hulls prior to carrying passengers.

Properly repair doubler plate on sewage tank bulkhead. (Void #2 Stbd tank)

Prior to carrying passengers Remove vessel from water and conduct further inspection on HUll.

Void #1 stbd hull properly repair through hull valve. (valve will not open or close)

Properly repair through hull valve in #2 void port side hull (valve will not open or close)

Properly repair through hull valve in #2void stbd hull (valve will not open or close)

Properly repair loose fuel piping (pipe is not properly secured)

Remove port side waste oil from fuel tank void. (waste oil was being stored in port side old fuel tank, supposed to be void) explained to owner that this cannot be used as waste oil storage.

Properly repair deck drain (currently piped to sewage system vice ovbd)

Properly secure battery boxes in port engine room.

Provide plug for old fuel piping currently used as void, if this void were to flood and old piping is not blanked off it could possibly flood engine room.

Properly run battery cables in stbd engine room.

Properly repair knife switch used as a disconnect for anchor windlass.

Properly repair all fire screen doors so that they self close and latch.

Provide servicing certificate for both CO2 fixed fire extinguishing systems.

Provide a fire hose listed by either Underwriters Laboratories (UL) of Factory Mutual (FM), and perform a satisfactory hydrostatic test of the hose in the presence of the attending marine inspector. LEGACY COMPONENT DESC: Condition

Provide a recently calculated magnetic compass deviation table. LEGACY COMPONENT DESC: Deviation Table/Graph

Prove proper operation of second Furuno VHF-FM radio. LEGACY COMPONENT DESC: VFH Radiotelephone

Block and brace generator batteries and bridge equipment batteries. LEGACY COMPONENT DESC: Battery Installation

Prior to carrying passengers, properly repair bilge high level system.

Prior to carrying passengers, properly service both Port and Stbd fixed firefighting systems.

Prior to carrying passengers prove proper operation of both fire pumps. Proper operation is 60psi at 50 gallons per minute.

Prior to carrying passengers, properly repair port hull outboard MDE-excessive oil leaking from filter housing.

Prior to carrying passengers, remove unathorized fuel level hose from port hull fuel tank. LEGACY COMPONENT DESC: Gauge

Prior to carrying passengers, prove proper Man overboard drill.

Prior to carrying passengers, properly repair fwd stbd hull bilge valve.

Properly repair remote shutdown switch prior on port outboard MDE.

Replace oil psi gauge line on port inboard MDE.

Replace port outboard MDE fuel line between valve and filter.

Properly wire bypassed A.C. knife switch.

Provide updated light list.

Mount Bell in accessible area.

Properly label red lights on console.

Prior to carrying passengers replace hydrostatic release on EPIRB.

Replace port bridge window.

Replace Stbd FWD lanyard on weatherdeck hatch.

Repair all doors so that they are self closing and self latching. LEGACY COMPONENT DESC: Weatherdeck doors

Properly wire lights in pumproom.

Properly mount hot water heater. LEGACY COMPONENT DESC: hot water heater

Properly secure Co2 cylinders in storeroom. LEGACY COMPONENT DESC: Pressurized CO2 cylinders for soda fountain

Prior to carrying passengers prove proper operation of Port Bilge system.

Prior to carrying passengers, repack 16 lifefloats to be able to float free. LEGACY COMPONENT DESC: Lifefloats

Properly repair oil pressure alarm system NLT 21JUN02. LEGACY COMPONENT DESC: Lube Oil Low Pressure Alarm

Properly repair fixed fire fighting extinguishing system to show that system is charged. LEGACY COMPONENT DESC: Quantity of CO2

Properly repair all rail courses prior to 05 JUN 02.

Properly repair cracked weld in forepeak stiffiner NLT 03APR02.

Properly repair Approx 2" hole in Men's head deck. LEGACY COMPONENT DESC: Deck Plating

Properly repair A. C. drain line hole in Port engine room bulkhead.

Remove or reattach corrugated sheet metal in way of port steering ram.

Make aft Integral fuel tanks available for inspection NLT05APRIL02.

Repair all rail courses prior to carrying passengers.

Remove sewage from port void and prove float works on hegh level alarm. LEGACY COMPONENT DESC: Bilge Alarm

Replace all captive chains on deck hatches that need them.

Remove and wipe out fuel in FWD engine room bilges prior to carrying passengers.

Properly repair Transformer on fantail prior to carrying passengers.

Prior to final approval for operation of the oil-fired furnace, complete 8 item worklist as indicated in MINS for this case.

PROVIDE GLOBES AND GUARDS FOR ENGINE ROOM LIGHTS.

REPAIR ALL FIRE DOOR LATCHES AND INSTALL MISSING FIRE DOORS.

PROVIDE PRESSURE GAUGES AND PROVE PROPER OPERATION TO BOTH FIRE PUMPS.

LABEL ENGINE ROOM EMERGENCY EXITS IN ENGINEROOM.

PROVIDE ROTATING MACHINERY GUARDS FOR BOTH GENERATORS.

PRIOR TO CARRYING PASSENGERS REPAIR LUBE OIL LEAK TO PORT ENGINE ROOM OUTBOARD MDE TURBOCHARGER.

PRIOR TO CARRYING PASSENGERS INSTALL EPIRB.

PROPERLY SECURE SEWAGE OVERBOARD VALVES.

PROVIDE FLYWHEEL GUARD ON OUTBOARD MDE IN STBD ENG RM.

Starboard engine room bilge suction soft patched. Make proper permanent repair to the bilge suction piping.

Side shell wasted and holed in board on the starboard hull inway of sewage tank. Empty tank gas free space crop to sound metal and make properly insert side shell.

Ballast tank fill line passing through the sewage holding tank wasted and holed. Crop and renew ballast fill line to restore as original._x001C_

Engine room bilge suction line located in the port machinery space os soft patched, wasted and holed. Make permanent repair to bilge line as original.

Diagonal support for the port rudder tube fractured. Make permanent repairto the port rudder tube diagonal support.

Electrical cables not properly supported improper plate penetration cable chaffing. Properly support electric cables located in the port #2 void.

Port rudder slamming against shaft tube. Shaft tube visibly gouged. Provide proper rudder stops for the port rudder.

RELABEL BILGE MANIFOLD.

RELABEL VALVES TO COINCIDE WITH POSTED INSTRUCTIONS FOR PROPER OPERATION OFBOTH PORT AND STARBOARD FIRE PUMPS.

MAKE VESSEL AVAILABLE WITH CREW TO CONDUCT SATISFACTORY UNDERWAY DRILLS TO THE SATISFACTION OF AN ATTENDING USCG MARINE INSPECTOR.

VESSEL IS NOT TO BE OPERATED WITH PASSENGERS UNTIL PROOF IS PROVIDED THAT THE PORT E/R FIXED EXTINGUISHING SYSTEM IS PROPERLY CHARGED AND TESTED.

PROVIDE THREE RING BUOYS.

PROVIDE ONE WATERLIGHT.

PROVIDE HANDLES FOR PORT AND STARBOARD EMERGENCY ESCAPE HATCHES IN PUMP ROOMS AND ENGINE ROOMS.

REMOVE DEAD ENDED WIRE IN PORT PUMP ROOM.

REPLACE MISSING GLOBES AND GUARDS ON LIGHT FIXTURES THROUGHOUT THE VESSEL.

REPLACE THREE MISSING EMERGENCY LIGHT BULBS.

MAKE PERMANENT REPAIR TO CRACKED RUDDER TUBE SUPPORT BRACING IN THE STARBOARD STEERING COMPARTMENT.

MAKE PERMANENT REPAIR TO THE HOLED MAIN DECK FIRE HYDRANT PORT SIDE FORWARD.

MODIFICATIONS OF PIPE PENETRATIONS THROUGH WATERTIGHT BULKHEADS INCLUDE IMPROPER PVC PIPE INSTALLATION. RESTORE PIPE PENETRATIONS AS ORIGINAL OR BRING INTO COMPLIANCE WITH 46CFR 119.720 AND 46CFR 56.50.

RUBBER HOSE IN USE IN THE BILGE SYSTEM. REMOVE ALL RUBBER HOSE AND REPLACEAS ORIGINAL IN ACCORDANCE WITH 46 CFR 119.510 AND 46 CFR 56.50-50.

PROVIDE A DETAILED REPORT OF THE SERVICING OF THE FIXED CO2 SYSTEMS SPECIFICALLY INDENTIFYING THE TESTS CONDUCTED AND ITEMS EXAMINED.

PROVIDE COMPLETE BUT SIMPLE INSTRUCTIONS FOR THE OPERATION OF THE FIXED GASFIRE EXTINGUISHING SYSTEMS. THE INSTRUCTIONS MUST BE LOCATED IN A CONSPICUOUS PLACE WHERE THE CYLINDERS ARE STORED.

INSTALL SECURING DEVICE FOR UPRIGHT CO2 TANKS USED FOR BAR.

DEVELOP AND POST EMERGENCY CHECK OFF LIST.

INSTALL SECURING DEVICE FOR SECURITY GATES THAT LOCK IN THE OPEN POSITION WHILE PASSSENGERS ARE ONBOARD

OPERATOR TO PROVIDE VALID FCC OPERATOR PERMIT.

REMOVE APPROXIMATELY 325 DEFECTIVE LIFEJACKETS WITH THE FOLLOWING DATA:_x001C_ GENTEX, GENTEX CORPORATION, CARBONDALE, PA. TYPE 1, MODEL #501U22_x001C_ AND REPLACE WITH COAST GUARD APPROVED DEVICES.

INSTALL HIGH WATER LEVEL ALARMS IN COMPARTMENTS WITH NEWLY INTALLED THRU- HULL FITTINGS FOR MSD RAW WATER INTAKE.

while conducting inspection for Credit Drydock Extension, noted numerous portable, fluid filled, electric heaters throughout the vessel. Issued CG-835 to remove or properly install heaters prior to carrying passengers for hire.

On March 27, 1998, completed inspection allowing Credit Drydock extension. Issued CG-835 requiring the vessel be made available for Credit Drydock examination prior to April 30, 1998.

AT THE NEXT REGULARLY SCHEDULED DRYDOCK BUT NOT LATER THAN 31MAR98, GRIND OUT AND REWELD THE TWO FRACTURES IN THE MAIN DECK SAFETY RAILING, PORT AND STARBOARD QUARTERS, WHERE MARKED.

PRIOR TO NEXT HULL EXAM BUT NOT LATER THAN 31MAR98, GRIND OUT AND WELD THE TWO FRACTURES IN THE MAIN DECK HAND RAIL, STARBOARD QUARTER AND PORT QUARTER WHERE MARKED.

REFASTEN THE OVERHEAD VENT IN THE MENS HEAD, MAIN DECK.

PROPERLY STENCIL THE UPPER DECK LIFEJACKET STORAGE LOCKERS WITH THE NUMBER OF JACKETS CONTAINED IN EACH.

PROPERLY DEAD END (CRIMP) THE LOOSE WIRES IN THE WHEEL HOUSE UNDER THE CONSOLE.

SUBMIT WRITTEN PROPOSAL FOR THE INSTALLATION OF NEW DECK DOORS ON THE #2 DECK.

PLACE MARPOL ANNEX V PLACARDS ON THE VESSEL AS DISCUSSED.

PRIOR TO CARRYING PASSENGERS, REMOVE THE WELDING MACHINE FROM THE STERN OF THE VESSEL.

SHOW PROPER STOWAGE OF ALL LIFE FLOATS, WATERLIGHTS AND PADDLES.

MAKE THE SHORETIE ELECTRICAL TRANSFORMER BOX ON THE STERN WATERTIGHT.

MAKE THE ELECTRICAL JUNCTION BOX, STARBOARD QUARTER NEAR LADDER, WATERTIGHT.

PROVIDE APPROPRIATE LATCHING DEVICES FOR THE PORT AND STARBOARD STORAGE LOCKERS ON THE STERN.

REMOVE ALL SHARP AND JAGGED EDGES FROM THE METAL LATTICE WORK NEAR THE STARBOARD QUARTER LADDER LEADING TO THE SECOND DECK.

GRIND OUT AND REWELD THE FRACTURED WELDS ON THE STARBOARD QUARTER RAIL STANCHION AND PORT QUARTER RAIL WHERE MARKED.

LABEL STERN PAINT LOCKER AND STENCIL AS "NO SMOKING AREA".

PRIOR TO CARRYING PASSENGERS, PERMANENTLY SECURE THE LARGE CONVECTION OVEN SITTING ON THE COUNTER IN THE GALLEY.

REHANG THE LOUVERED HEATER VENTS, MAIN DECK, PORT AND STRABOARD SIDE, WHERELOOSE.

PRIOR TO CARRYING PASSENGERS, REMOVE THE WELDING MACHINE OFF THE STERN OF THE VESSEL.

SUBMIT PLANS SHOWING THE ADDITION OF LIFE FLOAT STORAGE AREA.

PRIOR TO CARRYING PASSENGERS, PERMANENTLY SECURE THE CURRENTLY UNUSED CONVECTION OVEN LOCATED IN THE GALLEY.

REPLACE MISSING BOLTS ON PORT QUARTER FUEL HATCH.

PROVIDE A BRIGHTLY COLORED WATERTIGHT DISTRESS SIGNAL CONTAINER STENCILED WITH "DISTRESS SIGNALS" IN 1/2" LETTERS.

MAKE BOTH ELECTRICAL JUNCTION BOXES ON TOP OF THE WHEEL HOUSE NEAR THE MASTWATERTIGHT.

MAKE THE VERTICAL CABLE RUNS ON TOP OF THE WHEEL HOUSE WATERTIGHT.

PROPERLY CRIMP THE ELECTRICAL SPLICE TO THE SPOTLIGHT.

PROVE PROPER OPERATION OF ALL EMERGENCY LIGHTING.

REMOVE OR MAKE OPERATIONAL THE CONVECTION OVEN BEING STORED IN THE GALLEY.

PROVIDE WRITTEN MAN OVERBOARD RECOVERY PROCEDURES.

REMOVE THE WELDING MACHINE FROM THE STERN OF THE VESSEL.

PROVE PROPER OPERATION OF ALL HEADS, WASH BASINS AND ASSOCIATED PIPING.

DOUBLE CLAMP ALL OVERBOARD DISCHARGE FITTINGS IN BOTH ENGINE ROOMS.

PROVIDE COMPLETE DRUG TESTING PAPERWORK AS DISCUSSED.

PROPERLY CRIMP CONNECT THE SPLICE AND PROVIDE CHAFFING RELIEF FOR THE STARBOARD ENGINE ROOM BATTERY LEADS.

PROPERLY CRIMP CONNECT ALL ELECTRICAL CONNECTIONS TO THE STARBOARD CONSTAVOLT.

PROPERLY DEAD END (CRIMP) THE CABLE HANGING FROM THE HEATING UNIT LOCATED INSIDE THE STARBOARD ENGINE ROOM DOOR.

PROPERLY LABEL THE PORT ENGINE ROOM ELECTRICAL PANEL LOCATED FORWARD OF THEWATERTIGHT DOOR.

Mark each ring buoy with type II retro-reflective tape approved_x001C_ in accordance with 46 CFR 164.018. Arrangement of the material must be as specified by IMO Resolution A658(16). _x001C_

PRIOR TO THE CARRIAGE OF PASSENGERS, PROVE PROPER OPERATION OF ALL HEAD FACILITIES, INCLUDING ALL ASSOCIATED PIPING, TO THE SATISFACTION OF AN ATTENDING COAST GUARD MARINE INSPECTOR.

PRIOR TO PLACING VESSEL IN SERVICE OR THE CARRIAGE OF PASSENGERS, REPLACE THE THRU HULL FITTING, PORT PONTOON INBOARD, SERVING THE HEAD DECK DRAIN WHERE CURRENTLY PLUGGED WITH A WOOD CONICAL PLUG.

MAKE PERMANENT REPAIRS TO THE MSD DRAIN LINE WHERE HOLED, PORT SIDE, WHERE PASSING THROUGH THE #1 VOID AFT BULKHEAD.

INSTALL GASKETS AND SECURING BOLTS ON BOTH PORT AND STARBOARD AFT FUEL TANKACCESS HATCHES.

RENEW BROKEN BILGE SUCTION LINE, PORT SIDE MIDDLE LINE, IN THE STORAGE SPACE.

REHANG AC/HEAT LOUVERED VENTS, MAIN DECK PORT AND STARBOARD SIDE.

REWIRE AND REPOSITION POWER SUPPLY CABLE TO STARBOARD PONTOON HIGH WATER ALARM.

RENEW/INSTALL AIR INTAKE SCREENS ON ALL FOUR MDE'S.

INSTALL LAGGING ON THE STARBOARD INBOARD MDE WHERE MISSING.

CAP BOTH PORT AND STARBOARD LUBE OIL TANK DRAIN LINES.

THE FIXED CO2 EXTINGUISHING SYSTEM IS TO BE PROFESSIONALLY SERVICED IN THE PRESENCE OF AN ATTENDING COAST GUARD MARINE INSPECTOR NO LATER THAN 30APR96.

PRIOR TO THE CARRIAGE OF PASSENGERS, PROVE PROPER OPERATION OF ALL HEAD FACILITIES, INCLUDING ALL ASSOCIATED PIPING, TO THE SATISFACTION OF AN ATTENDING COAST GUARD MARINE INSPECTOR.

LABEL ALL MAIN DISTRIBUTION PANEL ELECTRICAL BREAKERS.

DOUBLE CLAMP ALL MDE COOLING WATER SUCTION LINES.

PLACE A SPANNER WRNECH AT THE PORT SIDE AFT MAIN DECK FIRE STATION.

INSTALL 30X30 WIRE MESH FLAME SCREENS OVER BOTHE FUEL TANK VENTS.

PLUG HOLES IN THE ELECTRICAL JUNCTION BOX, PORT SIDE MAIN DECK ON THE RIGHTOF THE GALLEY WINDOW.

STENCIL BOTH ENGINE ROOM EMERGENCY ESCAPE HATCHES ON THE MAIN DECK SIDE OF THE HATCH TO PREVENT STORAGE OF GEAR OVER THE HATCH.

MARK THE HAILING PORT ON THE STERN OF THE VESSEL IN ACCORDANCE WITH 46CFR SUBCHAPTER G.

PRIOR TO OPERATING, REMOUNT THE MASTHEAD LIGHT IN ACCORDANCE WITH THE NAVIGATIONAL RULES OF THE ROAD, ANNEX I, PARAGRAPHS 1 AND 2.

RESTENCIL THE UPPER DECK LIFEJACKET STORAGE BINS AND LABEL THE MAIN DECK LIFEJACKETS STORAGE AREA FOR PASSENGER VIEWING.

RECONNECT THE PORT A/C LOOSE WIRE NEAR THE CONTROL BOX UNDER THE PILOT HOUSE.

REMOUNT THE UPPER DECK PORT SIDE ELECTRICAL OUTLET IN THE BAR.

MAKE PORT AND STBD ENGINE ROOM WEATHER DECK DOORS WEATHERTIGHT.

PROVE PROPER OPERATION OF ENGINE ROOM AND GALLEY EMERGENCY LIGHTING.

RE-STENCIL PORT ENGINE ROOM EMERGENCY ESCAPE.

INSTALL VALVE HANDLE ON PORT GENERATOR COOLING WATER OVERBOARD.

RENEW DECK DRAIN OVERBOARD HOSE IN PORT LAZARETTE.

REPLACE CRACKED WINDOW IN PILOT HOUSE.

REPLACE COOLING WATER HOSE ON PORT INBOARD ENGINE.

REWELD SHELL CONNECTION FOR STBD OUTBOARD MAIN ENGINE EXHAUST IN AREA OF POROSITY LEAK.

MAKE STBD ENGINE ROOM HATCH WATERTIGHT.

RENEW PORT OUTBOARD ENGINE COOLING WATER HOSE.

UPPER DECK AFT DECK LIGHT, SECURE WIRING IN WEATHERTIGHT JUNCTION BOX.

PROVIDE SERVICE REPORT FOR FIXED FIRE EXTINGUISHING SYSTEM.

REPAIR OR REPLACE AFT STBD MAIN DECK DOOR TO WEATHER DECK.

REMOVE BURNT WIRE BEHIND SCULLERY TABLE.

MAKE PORT HOLD SPACE WATERTIGHT DECK SCUTTLE WATERTIGHT.

REPAIR LEAKING UPPER DECK WINDOW ON PORT SIDE NEAR STAIRCASE.

RENEW HOSE ON #2 VOID (PORT) INBOARD OVERBOARD.

REPAIR WASTED WELD IN WAY OF PORT INBOARD SHAFT TUBE TO THE SATISFACTION OFAN ATTENDING COAST GUARD MARINE INSPECTOR PRIOR TO CARRYING PASSENGERS.

GRIND OUT AND REWELD FRACTURED WELDS AT JUNCTION OF FLOOR FRAMES AND SIDE SHELL FRAMES STARBOARD HULL IN SERVICE SPARE VOID (4 IN ALL).

ADJUST RUDDER STOPS TO PREVENT RUDDER BLADES FROM COMING IN CONTACT WITH HULLS.

REPAIR/REWELD FRACTURED RUDDER SUPPORT STANCHION (STARBOARD HULL).

REPLACE RUBBER HOSE AND VALVE IN FIRE AND BILGE SUCTION LINE (STARBOARD HULL).

REPLACE BOTH BILGE PUMPS.

INSTALL MISSING CONSTAVOLT BATTERY CHARGER OR REMOVE WIRING FOR SAME (STARBOARD HULL).

REPAIR ALL BATTERY KNIFE SWITCHES (SIX TOTAL).

DRILL STOP, GRIND DOWN AND REWELD FRACTURE IN STARBOARD ENGINEROOM FORWARD BULKHEAD.

RECONNECT OR REMOVE BATTERIES FROM BOTH SHIPS SERVICE GENERATOR BATTERY BOXES.

PRIOR TO PLACING VESSEL IN SERVICE AND PRIOR TO CARRYING PASSENGERS, MAKE VESSEL AVAILABLE FOR INSPECTION FOR CERTIFICATION.

AFFIX DRAFT MARKS IN CONTRASTING COLORS.

CROP TO GOOD ALUMINUM AREA IN WAY OF MIDBODY HULL PLATE BENEATH GALLEY AREAWHERE PATCHED AND HOLED FROM BLASTING.

MAKE ALL WEATHERDECK HATCHES WATERTIGHT.

MAKE PERMANENT REPAIR TO TRIPPED FRAME IN WAY OF PORT HULL FUEL TANK FORWARD BULKHEAD, 100% WELD INSIDE AND OUT OF TANK. THEN SUBMIT FUEL TANK TO A 5 P.S.I. PRESSURE TEST.

REMOVE/ISOLATE MISCELLANEOUS HOSE FITTINGS ON FUEL TRANSFER SYSTEM.

MAKE PERMANENT REPAIRS TO ALL 4 MAIN ENGINE EXHAUST SYSTEMS.

CLEAN ANY AND ALL OIL FROM BILGES OF BOTH HULLS.

MAKE PERMANENT REPAIR TO DAMAGE ON BOTH PORT AND STARBOARD QUARTERS (RUBRAIL).

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

INSTALL ELECTRICAL MATTING IN FRONT OF BOTH MAIN ELECTRICAL DISTRIBUTION PANELS.

REPAIR EMERGENCY LIGHT IN FEMALE HEAD.

PROVIDE AND REPLACE ALL 3 RING BUOYS.

PROVIDE 10 ADULT AND 7 CHILD TYPE 1 PFD'S.

REPLACE ALL HAND HELD VISUAL DISTRESS SIGNALS (FLARES).

PROVE PROPER OPERATION OF BOTH EMERGENCY FUEL SHUTOFF VALVES.

PROVIDE AND POST WASTE MANAGEMENT PLAN.

INSTALL EXHAUST LAGGING ON ALL FOUR MAIN DIESEL ENGINE PIPING._x001C_ _x001C_ _x001C_

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

PROVE PROPER OPERATION OF PORT OUTBOARD MAIN DIESEL ENGINE.

REPLACE BROKEN/CRACKED WINDOW ON 2ND DECK AFTER DOOR.

REMOVE OR PROPERLY MOUNT 220 VOLT ELECTRICAL OUTLET IN GALLEY.

Replace cord to food warmer in galley.

Repair light at top of port dry stores compartment.

Provide one additional orange smoke flare.

Perform annual servicing of fire extinguishing systems.

Repair emergency light in starboard dry stores compartment and install globes on all lights in compartment.

Repair broken conduit fitting on main disconnect for galley stove.

Provide one additional fire hose.

Install globes and guards on outside deck lights as needed.

Dead end cable or install junction box for wiring to previously used galleystove.

Provide 22 additional child pfd's limited to not more than 180 total persons until completed.

Pressure test new fire hose using starboard fire pump once repairs are completed.

Demonstrate operation of starboard (inboard) engine from wheelhouse.

Repair starboard fire pump.

REPAIR PORT OUTBOARD MAIN ENGINE EXHAUST LEAK AND REPLACE MISSING LAGGING. (REMOVE SOFT PATCH)

RENEW WASTED 4" BHD PIPE PENTRATION (DRAINAGE) BETWEEN STBD VOIDS #1 & #2.

REPAIR LEAK TO 1 1/4" PVC PIPE ELBOW (DRAINAGE) IN PORT VOID #2.

REWELD FRACTURED INBOARD DIAGONAL STEERING STRUT BRACKET STBD HULL.

RENEW FLEX HOSE ON PORT GENERATOR EXHAUST PIPING TRANSITION TO THE HULL.

RENEW FLEX HOSE TO PORT INBOARD MAIN ENGINE EXHAUST PIPING TRANSITION TO HULL.

RENEW FLAME SCREEN ON PORT FUEL TANK VENT.

COMPLETE ANNUAL SERVICING OF FIXED CO2 SYSTEMS PRIOR TO CARRYING PASSENGERSAND NO LATER THAN 14MAY91.

REPLACE HOLED PIPE NIPPLE ON PORT FIRE MAIN PRIOR TO CARRYING PASSENGERS AND NO LATER THAN 14MAY91.

STENCIL EMERGENCY FUEL SHUTOFFS PRIOR TO CARRYING PASSENGERS AND NO LATER THAN 14MAY91.

REPAIR LEAKING RAW WATER PUMP ON PORT OUTBOARD PROPULSION ENGINE. TO BE COMPLETED NO LATER THAN 21MAY91.

RENEW BATTERY IN RING BUOY LIGHT NO LATER THAN 21MAY91.

PROVIDE (06) METAL FIRE HOSE NOZZEL,S.

PROVIDE (01) ONE RING BOUY.

REMARK LIFE PRESERVE BOXES ON THE 03 DECK FORWARD.

DECK HATCH COVERS ARE MISSING SECURING LINES.

FUEL FILTER PAN REQUIRED FOR RACPR FUEL FILTERS IS MISSING.

REPLACE PORT/STBD ENGINEROOM WEATHERDECK DOORS.

REPLACE HOLED FLEXIBLE HOSE ON GRAY WATER LINE IN #2 PORT VOID.

RENEW FUEL TANK FLAMESCREENS FOR PORT FORWARD AND STARBOARD AFT FUEL TANKS.

PROVIDE ONE HAND PORTABLE FIRE PUMP.
