KNOX T

Each item of survival craft equipment must be of good quality, and efficient for the purpose it is intended to serve. MI observed the 22-person life float to be worn and damaged. Service life float to satisfaction of attending MI. Vessel is to have temporary or replacement life float on-board to meet required equipment listed on the COI.

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. PA system was not audible in galley area and salon. Make PA in compliance with regulations to the satisfaction of the attending Marine Inspector.

The master and crew of a vessel will be familiar with the content of and have mounted at the operating station, emergency instructions containing the actions to be taken in the event of fire, heavy weather, or man overboard conditions. Except when in the judgment of the cognizant OCMI the operation of a vessel does not present one of the hazards listed, the emergency instruction placard should contain at least the applicable portions of the “Emergency Instructions” listed in §185.512. The emergency instructions must be designed to address the particular equipment, arrangement, and operation of each individual vessel. Vessel utilizes Jason's Cradle. Incorporate Jason's Cradle into Emergency Instructions and station bill to the satisfaction of attending Marine Inspector.

A vessel that has a power driven fire pump, must have a sufficient number of fire hydrants to reach any part of the vessel using a single length fire hose. Portside fire main piping was found to be wasted, resulting in a hole that reduced the firefighting capability.

All cable and wire must be installed with metal supports spaced not more than 24 inches apart, in a manner to avoid chafing and damage. Portside overhead electrical wiring is attached with zip ties.

If the vessel carries more than one life float or buoyant apparatus in a group with each group secured by a painter. Each must be secured in a series or by a single painter. Top two lifefloats were attached in series but not to the bottom, in turn, not attached to the weak link.

An inspection for renewal of a Certificate of Inspection is conducted to determine if the vessel is in satisfactory condition, fit for the service intended, and complies with all applicable regulations. The vessel has not completed a satisfactory renewal inspection. Vessel cannot carry passengers or cargo until conducting a satisfactory renewal inspection.

02 paddles were missing and 02 were not servicable.

All three main engine cooling water flow sensors were disconnected.

The navigation light for the aft nav light was not the correct bulb as required by regulation.

Clad weld isolated pits as marked in aft lower salon void.

Wire wheel and clad weld isolated pits as marked stbd side between frames 5&6 in lower salon void.

Post certificate of inspection in vessel location to be seen by passengers.

Re-label fuel shut off valves.

Label engine room escape hatch, 2 inches, "emergency escape, keep clear."

Provide proof of cody sancchez crewmember is actively enrolled in drug testing program, not allowed to hold afety sensitive or C.O.I. duties until verified.

Update all charts in operating areas, charts not updated since 2013.

Label, inside and out, the lazarette hatch, "emergency exit, keep clear," as crew has access on a regular basis.

Two of four pressure vessel mounts are fractured, re-weld both to properly secure pressure vessel.

Ensure public address system is operable throughout vessel and below-deck spaces accessible to both crew and passengers.

Vessel had a loose connection on the port ssdg breaker which caused a loss of power and melting/failure of the circuit breaker.

Drug and alcohol history checks not being completed as required by 49 CFR 40.25.

Alcohol testing devices not onboard as required by 46 CFR 4. Devices located onboard were expired.

Kapok bladders failed on two L/Js.

Prior to conducting commercial operations and/or carrying passengers, vessel must complete satisfactory drydock inspection.

Prove proper operation of stbd wx deck fire main

Make deck hatch cover to E/R operational - hatch cover cannot be secured.

Prove proper operation of laz high-water alarm.

Replace stbd fire hose.

Replace port engine exhaust muffler.

Replace raw water exhaust (remove PVC).

Repair stbd engine exhaust bracket.

Clean fuel filters.

Label circuits in breaker box (Electrical panel #1 and #2) in lazarette.

Weld cracks in Port & Stbd generators exhaust pipes as the connect to the aft bulkhead (lazarette).

Repair holes in aft bulkhead E/R (portside outboard)

Repair ammeters for both generators.

Install speakers for PA systeme in passenger accommodation space below.

Prior to operating, replace lamp in anchor light.

Provide means to open scuttle from Laz/Gen space to main deck.

Clean expanded metal screen for blowers in E/R.

Prove proper operation of "Tachometer" for port engine.

Show proper operation for bilge suction in lower passenger compartment.

6 red hand held flares expired this month. Port Engineer purchased 6 new and placed on vessel.

Water light on stbd ring buoy was attached to buoy via an eye splice vs a removable clip. Issued rqmt to remove eye splice and attach water light to the buoy via a halyard clip vs eye splice.

Remove fuel oil from flame impingement bowls for center and port main diesel engines.

Repair water leakage on starboard rudder post.

Provide required items in 1st aid kit in accordance with 46CFR184.710.

Renew or replace fore peak bilge suction valve. LEGACY COMPONENT DESC: Valve

Renew bilge suction piping forward of the collision bulkhead. LEGACY COMPONENT DESC: Piping

Renew retroreflective material as needed on lifejackets.

Replace light fixture lens at the base of ladder in way of lower lounge.

The throttle linkage mounting screws on all three engines were loose.

The lifefloat sea painters were tied up with wire ties.

Renew F/O lines on both generators using approved hose per SAE J9142.

Renew waterlight on starboard side lifering buoy.

Provide copy of proof test on ships crane.

Repair as new depth finder.

RENEW CUTLASS BEARING FOR STARBOARD PROPULSION SHAFT STRUT.

INSTALL VALVE AND PROPER SIGHT GLASS FOR LUBE OIL STORAGE TANK IN LAZARETTE.

Prove proper operation of both water tight doors in engine room.

Provide 30X30 or 2 20X20 flame screens for P+S fuel vents.

CONDUCT U/W EMERGENCY DRILLS WITH CG MARINE INSPECTOR IN ATTENDANCE NLT 15 APR 94.

REPAIR ANCHOR LIGHT.

PROVIDE COMPASS DEVIATION CARD.

LABEL SAFE WORKING LOAD ON DECK CRANE.

REPAIR LEAKY HYDRAULIC CONNECTION TO RESERVOIR FOR STEERING GEAR.

PROVIDE TWO ADDITIONAL ADULT LIFE JACKETS PRIOR TO CARRIAGE OR OVER 50 PEOPLE.

PLUG TWO EMPTY CABLE PENETRATIONS (2) IN #2 TRANSVERSE BULKHEAD.

PLUG SCREW HOLES IN PORT SIDE OF FORWARD GENERATOR BULKHEAD.

REPAIR LEAKS TO WATER INJECTION OF FOUR INTERCOOLERS.

REPLACE BROKEN MOUNTING BOLT FOR PORT MAIN ENGINE.

PROVIDE HAND BILGE PUMP.

REPAIR OR REPLACE 15 MAN LIFE FLOAT PRIOR TO OPERATING VESSEL.

REPAIR AND PROVE PORT GENERATOR OVERSPEED SHUT DOWN.

REPLACE LOOSE GENERATOR MOTOR CONTROLLER RESET BUTTONS.

PROVIDE LABELS AT VALVE HANDLES FOR BILGE MANIFOLD.

REPLACE OR REPAIR WASTED B-V SEMI-PORTABLE FIRE EXTINGUISHER PRIOR TO CARRIAGE OF HAZARDOUS MATERIAL OR FLAMMABLE/COMBUSTIBLE LIQUID IN BULK.

PROVIDE TWO FUEL FILTER FLAME BOWLS FOR PORT AND STBD GENERATOR.

PROVIDE LOCK NUT OR EQUIVALENT ON STBD STEERING RAM CONNECTING BOLT.

PROVIDE COMPASS LIGHT FOR MAGNETIC COMPASS.

PROPERLY LOCATE PORT RUNNING LIGHT BULB IN CENTER OF FRESNEL LENS.

REPAIR LEAK IN FLEXIBLE CONNECTION FOR HEAD DISCHARGE LINE ON STBD SIDE OF BELOW DECK PASSENGER SEATING.

REPAIR HYDRAULIC LEAK IN PORT STEERING RAM CYLINDER.

REPLACE MISSING SWITCH BOX DOOR ABOVE STBD GENERATOR.

PROVIDE MEANS OF CLOSURE FOR STBD AFT FUEL VENT.

WEIGHT TEST DECK CRANE (TO 1 1/4 X SWL) PRIOR TO USE IN SERVICE.

MARK HOMEPORT ON STERN.

REMOVE APPROXIMATELY 3-4 INCHES OF OIL FROM LAZARETTE BILGES.

REPAIR FUEL LEAK AT FILTER GAGE FOR STBD GENERATOR.

REPAIR RUDDER ANGLE INDICATOR NIPPLE TO ROD

PROVIDE BELT GUARD FOR STBD MAIN ENGINE FIRE PUMP

COMPLETE INSIDE WELD ON INSERT IN STBD CORNER OF STERN

PLACE 31 SQ. INCHIS OF REFLECTIVE TAPE ON ALL 52 LIFE PRESERVERS.

POST ORIGINAL STABILTY LETTER.

PROVIDE ON BOARD VESSEL DOCUMENT.

ADJUST AFT STATION STBD ENGINE CONTROL.

PROVIDE 100' OF LINE FOR 15 MAN LIFEFLOATS

SECURE DECKPLATE AFT FWD ENGINE ROOM DOOR.

PROVIDE ENGINE ROOM AND GENERATOR ROOM LIGHT COVERS.

REPAIR PORT RUDDER STOP.

PROVIDE 30 PFD LIGHTS.
