CONDOR

A vessel must comply with the structural design requirements of one of the standards listed below for the hull material of the vessel. Steel hull vessels:(1) Lloyd's Yachts and Small Craft; or(2) ABS Steel Vessel Rules (<61 Meters)(incorporated by reference, see 46 CFR 175.600). Numerous pitts located on hull and welds below the waterline. Remove paint to make all pits ready for inspection. Provide 3rd party gauging of pitts and nominal plate thickness in pitt area. Survey showed severe corrosion throughout hull plating. Almost all steel hull will need to be replaced. See documents in activity for proposed crop and renew. Complete crop and renew prior to operations. 46 CFR 177.300

All machinery and equipment must be installed and maintained in such a manner as to afford adequate protection from causing fire, explosion, machinery failure, and personnel injury. Vessels starboard steering ram had a minor hydraulic leak during operation.

Vessels must have a roving watch alarm for all spaced that crew or passengers routinly have access to. Roving watch was inoperable at the time of the inspection and appeared to not have been in use for awhile.

All griddles, broilers, and deep fat fryers must be fitted with a grease extraction hood in compliance with 181.425. A grease extraction hood must meet UL 710 or other standard specified by the Commandant. A grease extraction hood must be equipped with a dry or wet chemical fire extinguishing system meeting NFPA 17 or other standard specified by the Commandant, and must be listed by an independent laboratory recognized by the Commandant. Install grease extraction hood equipped with a dry or wet chemical fire extinguishing system to the satisfaction of an attending marine inspector at next credit drydock, not later than Jan 1, 2026.

All escape hatches and other emergency exits used as means of escape must be marked on both sides in clearly legible letters at least 2 inches high.

Steering system must be in suitable condition and fit for service intended. Primary steering failed due to hydraulic leak. Must correct to the satisfaction of the Coast Guard prior to getting underway.

The fire pump outlet must be fitted with a pressure gauge. The numbers on the current pressure gauge of fire pump is unreadable. Must correct to satisfaction of the Coast Guard.

Must complete the following items for credit annual exam: Must get vessel underway and conduct man over board drill and must test the remote shut-offs to the fuel supply to the satisfaction of the Coast Guard.

Emergency escape must not be blocked. Fishing rods holders on the exterior of the window must be removed to prevent poles from being placed there and blocking the escape in the case of an emergency.

VESSELS BILGE PUMP COULD NOT ADEQUATELY DE-WATER FORE PEAK COMPARTMENT. REPAIR IMPELLER/TROUBLESHOOT AND ENSURE VESSEL IS ABLE TO DEWATER EVERY WATERTIGHT COMPARTMENT PRIOR TO DEPARTURE.

VESSEL IS CURRENTLY RE-PIPING BAIT TANK. ENSURE AFT ENGINE ROOM WATERTIGHT BULKHEAD PENETRATIONS ARE PROPERLY SEALED AND WATERTIGHT PRIOR TO DEPARTURE.

VESSEL'S 02 INFLATABLE LIFE RAFTS WERE NOT ONBOARD AT TIME OF INSPECTION. VESSEL TOTAL PERSONS ALLOWED IS REDUCED TO NO MORE THAN 44 PERSONS UNTIL RAFTS ARE ONBOARD AND STOWED PROPERLY. AT WHICH TIME 88 TOTAL PERSONS ALLOWED WILL BE REINSTATED.

PROVIDE THE USCG WITH AN UPDATED AC ELECTRICAL DIAGRAM WITHIN 30 DAYS.

Electrical drawing did not match actual vessel layout. Either update drawing or change electrical equipment.

Provide DSC capability on VHF radio.

Provide safety guards on both main engines.

Install blank in galley panel.

Install Emergency lights at the bunk room main entrances.

Vessel has been identified as having various A/C electrical modifications since initial certification. Sector San Diego does not have vessels electrical plans on file or current installations do not match what we have on file. Provide a one-line electrical drawing for all A/C switchboards and distribution panels. Include all circuit loads, conductor sizes, over current protection, and max panel ratings in amps.

Replace plastic garbage can in galley with metal.

Provide the 02 life rafts required by the COI.

Provide 38 adult lifejackets. Passenger count reduced to 45 adults until corrected.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

A vessel exposed to salt water must undergo a drydock and internal structural examination at least every two years. Subject vessel due date for stated exams on Certificate of Inspection (COI) was 21FEB2019. Vessel shall complete stated exams prior to carrying passengers to maintain valid COI.

MMSI: Vsl is broadcasting MMSI from expired FCC License CLSN: Vsl is broadcasting Call Sign from expired FCC License, ZERO LENGTH OR BEAM: no dimension information (AIS Antenna Position ABCD values equals 0), ZERO DRAFT: no static draft information

Provide hydrostatic release for EPIRB.

Replace damaged fire hose.

Prove proper operation of the fire pump pressure gauge.

Remove or secure fuel filter for starboard generator prime mover

Obtain current FCC station license onboard.

Secure wire in the vicinity of aft bunkroom vent.

Provide current navigational charts for the vessel area.

Replace pedestal bear bolt on the STBD rudder assembly with proper length and size.

Prove proper operation of fire pump pressure gauge.

Prove proper operation of anchor light.

Provide current epirb registration.

Remove or use loose wires in aft engine room.

Provide blanks or breakers in distribution panel.

Provide 52 adult and 06 children lifejackets for limited coastwise route, vessel restricted to 51 total adults and 05 children until replaced.

Provide updated crew list for DAPI program.

Electric extension cord in forward bunk room needs replaced or removed due to damage.

Replace fire hose nozzle on STBD side.

Retro tape required on both sides 4 evenly spaced locations on ring lifebuoys.

Cap keel cooler in piping in Eng Room (Port and Stbd). Temp repairs accepted during COI exam, make perrmanent repairs prior to next credit drydock in 2010.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Provide 2008 MIS Report.

Register owner info for EPIRB.

Update FCC operator licence

Provide a lifejacket instruction

Provide safety guard for main diesel engines belts.

Porvide ship horn.

Provide chart for ocean route.

Have servicing station inspect liferaft dues to expired inspection date.

Replace expired hydrostatic release for EPIRB.

Post COI, stability letter, station billet, and emergency procedure on wheel house.

Pay user fee.

Replace inoperable smoke detectors (2) in pax berthing spaces.

Replace safety covers (2) for engine room lights.

Vsl is short (2) of the req'd (12) parachute flares for vsls with Zone II routes (Ref: Sector SD CID Policy Ltr #10). Purchase (2) additional parachute flares.

Replace faded buoy & lifelines on all (3) lifebuoys.

Replace (1) rejected child PFD.

Replace or provide updates for the following: Light List, Coast Pilot [name withheld], nav chart.

Update 1st Aid Kit/replace all expired items.

Prove proper installation of new sea chest.

Prove proper installation of steering and rudder system.

Reinstall captive chains on hatches prior to Topside Inspection.

Properly mark emergency exits from berthing spaces prior to carrying passengers overnight and prior to Topside Inspection.

Remove broken, dirty, oily portable fan installed in engine room.

Current navigational charts are out of date.

Coast Pilot (1997) is out of date.

CG Light List (1997) is out of date.

Vessel is missing the Tidal Current Table pub.

PFD storage containers were improperly labeled. The number labels on the containers did not correctly match the number of adult & child PFDs stored in each container.

Properly install foam IAW stability calculations approved by the Marine Safety Center. This requirement will serve to extend the temporary COI until 5 June 2004 at which point the vessel will no longer be allowed to operate unless these measures have been met.

2nd extension granted by [name withheld] foam IAW calcs approved by CG-MSC. Requirement serves to extend temp COI until 19 June 2004 at which point vessel's no longer allowed to operate unless these measures have been met. Passengers reduced to 49 and use of center fish hold is unauthorized.

Work closely with the vessel P.E. (Marty Ward) to properly add additional foam flotation as required by CG Marine safety center. Complete to the satisfaction of the attending marine inspector prior to the issue of the new COI.

Repair inoperable bilge alarm system IAW 46 CFR 182.530

Replace rupture fire hose IAW 46 CFR 181.320 LEGACY COMPONENT DESC: Condition

Renew expired EPIRB battery IAW 46 CFR 185.728(b) LEGACY COMPONENT DESC: EPIRB

Provide valid FCC operators license IAW 47 CFr 80.155 LEGACY COMPONENT DESC: FCC SSL

Provide Station Bill IAW 46 CFR 185.514

Replace inoperable compass light IAW 46 CFR 184.402c LEGACY COMPONENT DESC: Magnetic Compass

Properly label ring buoys with vessels name IAW 46 CFR 185.604(b)(i) LEGACY COMPONENT DESC: Markings (ship name/port)

Replace expired items in the first aid kit IAW 46 CFR 184.710 LEGACY COMPONENT DESC: Medicine Chest

Properly wire engine room light IAW 46 CFR 183.340 LEGACY COMPONENT DESC: Lighting Fixture

Attach lanyards or capture chains to all unhinged hatch covers IAW 46 CFR 179.360(a)(z) LEGACY COMPONENT DESC: Capture Chains

Provide metallic wire supports every 24" for overhead wire runs through out the vessel IAW 46 CFR 183.340(b)(4)

Properly mount and hardwire all overhead lighting in both the FWD and AFT bunk rooms IAW 46 CFR 183.340 and 183.410 LEGACY COMPONENT DESC: Lighting Fixture

Properly label emergency escape hatches with "Emergency Exit Keep Clear" IAW 46 CFR 185.606 LEGACY COMPONENT DESC: Emergency Escape Hatches

Provide covers or screens for both the supply and exhaust ventilation ducts in Fwd. and Aft bunk rooms.

Provide junction box for wiring of Fwd. vent. fan in aft bunk room IAW 46 CFR 183.340 LEGACY COMPONENT DESC: Lighting Branch Circuit

Renew retro-reflective tape on ten(10) identified PFD's IAW 46 CFR 185.604(h) LEGACY COMPONENT DESC: Retroreflective Material

Properly mark one(01) PFD with vessels name IAW 46 CFR 185.604(b) LEGACY COMPONENT DESC: Marking

Replace cracked lens cover on 4' florescent light fixture in Aft bunk room IAW 46 CFR 183.410(a) LEGACY COMPONENT DESC: Lens cover

Insure proper aisle width in berthing area FWD IAW 46CFR 177.810(c). LEGACY COMPONENT DESC: Berth

Undergo a satisfactory inclining test as witnessed by a U. S. Coast Guard Inspector

Submit deadweight survey results from a Marine Architect to reflect stability data and proposals for operation.

Provide drawings of all new installations on the vessel.

Rotate fore peak bilge valve in forward bunkroom 180 degrees.

Provide belly bands for portable fire extinguishers as needed.

Install proper size relief valve for air receiver in lazerette.

Replace fire hose on port side fire station.

INSTALL COVER ON FWD ACCOMMODATION SPACE "E" LIGHTING.

RENEW NON-APPROVED F/O LINES ON BOTH ENGINES WITH FUEL HOSE MEETING 46 CFR 182.720/SAE J 1942 STD.

RENEW AIR RECEIVER WITH CG APPROVED RECEIVER MEETING 46 CFR 182.330. THIS REQUIREMENT SHALL BE COMPLETED PRIOR TO 31 DEC 2000.

UPDATE FCC STATION LICENSE.

UPDATE CHARTS WITH LOCAL NOTICE TO MARINERS.

Replace "SO" electrical wiring in AC electrical system with "approved" wire. This item must be completed by the end of the next hull exam.

Repair as new engineroom deckplates.

Install receptical on shore tie electrical cord.

Renew leaking 90 degree fitting on discharge side of firepump.

Add lights to 24 adult & 1 child PFD and renew 1 adult PFD.

Have on board NAVTEX receiver.

Mark lifejacket stowage IAW 46 CFR 185.604(f).

Rewire grease extraction hood wiring with "approved" wire IAW 46 CFR 183.

Update contents of first aid kit.

OPEN FOR INSPECTION PRESSURE VESSEL OR HYDO TEST TO 1.25 MAWP.

RENEW THE FOLLOWING FLEX HOSES; SUCTION/DISCHARGE LINE TO PORT MDE ATTACHEDBILGE PUMP, PEDRO TO MSD OVBD, SUCTION TO GENSET R/W PUMP, SUCTION/DISCHARGE TO HEAD R/W SUPPLY PUMP

Install retroflective tape on four life floats.

Install bulbous bow markings on hull.

Make air receiver available for inspection and provide all information to prove suitability for service.

Install either draft marks or loading marks on the hull.

Make permanent repairs or replace all four life floats.

Properly label aft emergency exit with "Emergency Exit Keep Clear"

Label emergency exits with mode of operation for opening scuttles.

Replace painter line connecting life floats to weak link.

Install approved fuel fittings on both generators fuel supply and return lines.

Renew line attaching waterlight to ring buoy with a halyard clip.

Provide positive locking device for MSD overboard valve.

Provide vessels station bill.

Replace the lifelines for 3 lifefloats prior to carring more than 50 total people Limited Coastwise or 25 total people Oceans.

Replace the waterlights for the 5 lifejackets prior to carring more than 120 adults passengers.

REPAIR HOLE IN GOOSE NECK VENT PIPE AND REPLACE FLAME SCREEN ON STARBOARD FUEL TANK VENT.

Clean galley ventilation fan hood and fan filter.

Provide vessel with thirty-eight (38) adult P.F.D.s. Vessel is restricted to a total of ninty-one (91) total persons on board on the "Limited Coastwise" route.

Repair exterior coating on life floats.

Provide vessel with thirty-one (31) additional adult P.F.D.s. Vessel may only carry ninty-eight (98) total persons on board when operating on a limited coastwise route.

Rework both emergency escape hatchs, prove proper operation.

Remove all wire nuts and make proper electrical connections.

Clean grill vent fan and provide filter for vent fan intake.

Renew both head windows and frames.

Provide proper covers for unused openings in engineroom junction box.

Repair raw water leak at sea chest. Line supplies water to Isuzu generator.

Provide and install clamps for fuel gauge on fuel tanks.

Provide lifeline on intermediate run on sundeck liferail.

Prove proper pressure on vessel's fire pump in accordance with 46 CFR 181.10-1(c).

Provide vessel with forty-nine (49) additional adult P.F.D.'s. Vessel may only carry eighty (80) total persons on board.

REPLACE FLEXIBLE HOSE AT BILGE PUMP (AFT) AND PORT GENERATOR COOLING WATER.

REPLACE WIRE NUTS AT FIRE PUMP ELECTRICAL CONNECTIONS WITH CRIMP ON WIRE CONNECTORS. ALL OTHER WIRE NUTS TO BE REPLACED.

PROVIDE BLANK FOR STBD ENGINE ROOM BREAKER BOX OPENING.

PROVIDE PROPER DAY SHAPES FOR VESSEL AT ANCHOR, VESSEL AGROUND AND VESSEL NOT UNDER COMMAND PER NAV RULES.

PROVIDE 15 ADDITIONAL ADULT LIFE JACKETS PRIOR TO CARRIAGE OF OVER 114 TOTAL PEOPLE.

HYDRO TEST ONE B-II PORTABLE FIRE EXTINGUISHER FROM LOWER AFT BUNKROOM.

PROVIDE VALID FCC STATION LICENSE OR EVIDENCE OF CURRENT APPLICATION.

PROVIDE 6 ADDITIONAL ADULT LIFEJACKETS.

REPLACE 6 RED AND 6 ORANGE SMOKE FLARES.

RECHARGE ONE B-II DRY CHEMICAL IN EXCESS OF REQUIRED ABOARD.

REPAIR PRESSURE GAGE ON FIRE PUMP, PROVIDE GUARD AT COUPLING AND PROVE OPERATION OF FIRE PUMP.

REPAIR TWO WATERLIGHTS FOR LIFE FLOATS.

REPLACE BROKEN VALVE HANDLE TO BILGE LINE JUST AFT OF COLLISION BULKHEAD.

REPAIR AND PROVE STBD GENERATOR OPERATION.

AT NEXT DRYDOCK CONTINUOUSLY WELD INSIDE OF PORT AND STARBOARD GREY WATER DISCHARGE SPOOL PIECE TO HULL.

HYDRO ONE B-II PORTABLE FIRE EXTINGUISHER.

PROVIDE VAPORTIGHT LIGHT FIXTURE IN ENGINEROOM.

REPAIR PORT AND STARBOARD RUNNING LIGHTS, CABLES AND BRACKET(STARBOARD).

PROVIDE THREE PROPER RING BUOYS

REPAIR WATERLIGHT FOR LIFEFLOAT

PIN OR DOUBLE NUT, BOLTS ATTACHING STEERING RAMS TO STANCHIONS

PROVIDE MEANS TO SECURE MAIN ACCOMODATION DOORS.

INSTALL COVER ON ENGINE ROOM LIGHT, STARBOARD.

UNTIL 6 ADDITIONAL ADULT LIFE JACKETS ARE PROVIDED, TOTAL PASSENGERS IS LIMITED TO 115(COASTWISE)

PROVIDE EMERGENCY CHECK OFF LIST AND POST

INSTALL PERMANENT EMERGENCY ESCAPE SIGN FOR FORWARD BUNK ROOM.
