THE WORLD

The ring, lines, and letters shall be painted in white or yellow on a dark background, or in black on a light ground. The deck line was not marked in black on the light background.

The construction of all fire doors and door frames in "A" class division, with the means of securing them when closed, shall provide resisitance to fire as well as to the passage of smoke and flame, as far as practicable, equivalent to that of the bulkheads in which the doors are situated. Such doors and door frames shall be constructed of steel or other equivalent material. Fire door A0 1.001 leading from passageway to hypermist pump room was found with holes from previous plate installation as well as a break in the door sill, preventing it from protecting from the passage of smoke and flame. Rectify deficiencies prior to departure to the satisfaction of RO/RSO and Coast Guard. 74 SOLAS 01 II-2/30.2.

The Administration may require that all reasonable and practicable measures shall be taken to limit the entry and spread of water above the bulkhead deck. The PSCO found that 4 of 10 semi-watertight doors had the door securing handle in the closed position when the doors were open and on the magnetic hold back. If the doors are automatically released and there is water pressure holding the doors closed the door's securing devices would not to be engaged to make the doors semi-watertight. There were no markings on the doors to indicate the correct position of the handle when the doors are open. SOLAS 81 amend II-1/2, 50ac

Fire protection systems and fire-fighting systems and appliances shall be maintained ready for use. Smoke detector #202059 located at the chemical locker, Deck 3, was found inoperable. SOLAS 20 II-2/14.1.1, 10c

Fire doors in main vertical zone bulkhead and stairway enclosures shall satisfy the following requirements: A door designed to re-open upon contacting an object in its path shall re-open sufficiently to allow a clear passage of at least 0.75m but not more that 1m. Doors 8.003, 8.004 and 7.045 were not operating as intended. These doors were opening approximately 0.2032m (8 inches) upon contact. SOLAS 97 II-2/30.4.2, 10c

The construction of all doors and door frames in "A" class divisions, with the means of securing them closed, shall provide resistance to fire as well as to the passage of smoke and flame, as far as practicable, equivalent to that of the bulkheads in which the doors are situated. Fire door A15 4.071 was missing the lock barrel allowing an opening for the passage of smoke and flame. SOLAS 97 II-1/30.2, 10c

A Class divisions are those divisions formed by bulkheads and decks that shall be constructed of steel or other equivalent material. Crew gym located on deck three has multiple pentrations on the deck.

Above the bulkhead deck, there shall be at lest two means of escape from each main vertical zone. The primary escape route in the head chef's office located on deck 5 MVZ 1 is not clearly marked on the fire control plan.

0299 Seafarers employed or engaged in any capacity onboard a ship shall before being assigned to any shipboard duties receive appropriate approved basic training in fire prevention and fire fighting as set out in Table A-VI/I-2. 02 members of galley staff were unfamiliar with their fire fighting/prevention duties.

THE VESSEL'S SAR PLAN IS NOT APPROVED BY THE USCG. THE SAR PLAN WILL BE SUBMITTED TO USCG HEADQUARTERS AS SOON AS APPROVAL FROM BAHAMA GOVT. VESSEL NEEDS TO SUBMIT PLAN TO CG HEADQUARTES FOR APPROVAL. LEGACY COMPONENT DESC: SEARCH AND RESCUE PLAN

Provide evacuation procedures for persons starnded on balconies and place them in way of key boxes. LEGACY COMPONENT DESC: Escape Route Signs

Provide classification society attestation of satisfactory installation of B-class bulkhead extensions of ceiling panels between Category 7 Changing Room and Category 8 Colliseum (theater stage area). LEGACY COMPONENT DESC: Bulkheads - Aux Spaces (moderate fire risk)

Prove satisfactory completion of outstanding worklist items issued to vessel on February 28, 2002 by USCG MIO Europe at the vessel's United States port of call. A total of 126 items remain outstanding.
