ISSAQUAH

All marine engineering details, such as boilers, pressure vessels, main and auxiliary machinery, piping, valves, and fittings, shall be designed, constructed, and installed in accordance with the provisions of this sub-chapter. The #2 end drain pump was reported as intermittently alarming for loss of power. Vessel to diagnose and report root cause. Repairs shall be rendered to MI satisfaction.

Vital systems that are automatically or remotely controlled must be provided with an effective primary control system. Vessel pilot house is displaying an inconsistent meter reading for the controllable pitch propeller system. Vessel to correct issue to the satisfactory of USCG Marine Inspector. 46 CFR 62.25-1

The following emergency lighting and power loads must be arranged: Illuminated signs with the word "EXIT" in red letters throughout a passenger vessel so the direction of escape to the open deck is obvious from any portion of the vessel usually accessible to passengers and crew, except machinery spaces, and except stores and similar spaces where the crew are not normally employed. 10+ photo-luminescent "EXIT" signs throughout the vessel are marked "Replace before May 2025" on the manufacturer's label, and have lost their photo-luminescent properties. Replace all photo-luminescent signs that have passed their service/expiry date to the satisfaction of the Marine Inspector.

Auxiliary machinery vital to the main propulsion system must be provided in duplicate. Loss of #2 MDE caused #1 MDE to take full operational load do to faulty relay. Deficiency rectified.

Approved fire extinguishing systems must be installed, as required by Table 76.05-20. Vessel's spnkler system had 13 nozzles that were clogged and inoperable. 46CFR76.05-20

Vessel's must have a marine radar system for surface navigation. Vessel had inoperable Radars due to installation of new Radars. 33CFR164.35

#2 End Primary steering not responding via rudder angle indicator. The steering gear must be capable of moving the rudder from 35 degrees to 35 degrees at its deepest loadline draft and running at maximum ahead service speed, and from 35 on either side to 30 on the other in not more than 28 seconds under the same condition. 46 CFR 58.25-10(b)(2)

Operator reported an ABT breaker connected to the emergency generator which experienced a malfunction. Each bus meet the requirements of either Section 7.10 of IEEE or IEC 60092-307. Provide technician report to the USCG identifying the root cause of the failure and attesting to repairs.

Each passenger vesssel must carry the following: Launching appliances or marine evacuation systems equally distributed on each side of the vessel. Vessel self-reported that rescue boat winch had experienced a hydraulic leak and as such, vessel will be allowed to continue operations at half-passenger capacity until issue is rectified. -50 C , 46CFR199.201(b)

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

The CP hyd pumps 1-4 and video system breakers do not match the name plate on the switchboard. Steering gear 1,2 not labeled. 46CFR111.30-15

Intermittent grounds on the E-switchboard and ground current panel in the EOS. 46CFR111.01-1

Excessive build up of oil and water under the #2 MDE

Boilers need to have scale, soot and ash removed from fire and waterside and replace deteriorating insulation/refractory. Complete prior to completion of upcoming drydock 46CFR53.01-3

Properly label the following: Bilge system valves. Watertight door local controls. Crew galley vent closure.

#2 Ships boiler failed hydro test and failed safety valve test. Lock out and tag out until test witnessed by CG

“All doors, except those that are normally kept closed, shall be of a type which are capable of release from the control station and from a position at the door.” 46 CFR 72.05-25(b)(9)(ii) -The vessel's fire screen door #2 would not automatically close upon release from the #1 end pilot-house. Provide proof of proper function of FSD to USCG.

All piping, valves and fittings shall meet the applicable requirements of subchapter F. During a routine fire drill, two holes were discovered in the fire main. Company made temporary repairs while a new pipe is fabricated. 46CFR76.10-15(a)

Make repairs to the emergency generator. Replace all deteriorated flexible hoses and repair the oil leak saturating both exhaust manifolds.

Repair all modifications found in way of multiple cables installed in a single cable transit penetrating the class "A" fire boundary between EOS and various adjacent spaces.

Update the fire control plan to reflect the stowage location of the fire out-fits.

Repair loose fan guard for the No.1 reduction gear standby pump.

Adjust the emergency fuel oil shut-off valve to provide full actuation of the valve and achieve positive closure.

NR2 rescue boat davit currently experiencing overload alarm during normal operation. Davit only operable through manual deployment mode. Repair and conduct satisfactory operational test of rescue boat deployment. 46 CFR 71.55-1 (a)

Before the vessel leaves port and at all times during the voyage, each lifesaving appliance must be in working order and ready for immediate use. The accumulator on the #1 rescue davit is at low pressure and the automatic switch that turns on the pump to bring the pressure back up to the normal operating level is not working. Ensure pressure is maintained at the correct level until switch can be permanently repaired. Vessel is required to inform the Coast Guard upon repair of the switch. 46 CFR 199.190 (a)

46 CFR 56.50-50(d) - Prove proper operation of the remote bilge valve located in the No.1 steering gear room.

46 CFR 56.50-50(g) – Replace deteriorated bilge strainer located port/fwd No.1 Engine Room.

46 CFR 171.124(a) – Adjust and repair all water tight hatches on the main deck to ensure each dog makes positive contact with corresponding wedge.

46 CFR 171.070(b) – Repair all seized ventilation closures and prove proper operations.

46 CFR 171.111 – Prove that each bulkhead shaft seal has been maintained to provide water tight integrity in case of compartmental flooding.

46 CFR 72.01-15 – Provide full penetration or double continuous welds in way of all modifications made in the main deck. Port No.1 reduction gear room at Fr. 30-31 and both steering gear rooms in way of pipe sockets.

Pilot house fire screen door release did not release door in pax cabin on #2 end.

EOT power failure alarm did not sound or visually engage.

General alarm did not sound in pax cabin #2 end port side.

condemned 23 child life jackets

General emergency alarm signal must: be located in passenger and crew areas where they can alert persons in spaces where those persons be maintaining, repairing, or operating equipment, stowing or drawing stores or equipment, or transiting such as public spaces, workshops, galleys, ect. The general is not audible in #2 reduction gear space and the #5 fire zone.

Each vessel must carry a lifejacket for each person onboard. 48 lifejackets were deteriorated and were removed the vessel.

Obtain the USCG Marine Safety Center's approval for the installed steering control system and prove proper installation to an attending Caost Guard Marine Inspector, no later than the vessel's next scheduled maintenance period (31MAR2020).

Propulsion control system would not respond in Pilot [name withheld] mode, only manual (Eng Room) controls. No alarm or indicator was given when steering controls were inoperable in PHC mode. Effect repairs to automated vital system, propulsion control system in all modes.

21MAR18, 1917: Received initial JHOC notification. [name withheld], [phone withheld] reported ISSAQUAH experienced two pinhole leaks in the vessels sea chest vent line starboard side in the #2 engine room. Vessel to install soft patch currently underway operating on the Fauntleroy - Vashon run with passengers onboard. [name withheld] requested that the vessel be permitted to operate until it can effect permanent repairs while in their normal yard period in April. 21MAR18, 1925: Brief CDV and OCMI; accepted request to repair in April. 21MAR18, 1929: Notified [name withheld] of same. Vessel currently has two pinhole leaks with temporary soft patch repair installed. Properly effect permanent repairs to the #2 sea chest vent line to the satisfaction of the attending marine inspector.

#23 Fire Screen Door does not latch shut. Repair to the satisfaction of Coast Guard inspector. 46 CFR 72.05-25

Have RADAR, AIS, GPS, and gyro compass ready for inspection. 33 CFR 164.25.

Replace hose for Fire Station # 12. 46 CFR 76.10-10(g)

Replace nozzle for Fire Station # 17.

Replace all ring buoy light batteries. 46 CFR 199.70(a)(3)(ii)

Replace retro-reflective tape on all ring buoys. 46 CFR 160.050.

Crew must complete manual draft readins twice a day, once at the start of operations and again at the end of operations. Additionally, if any unusual listing occurs, crews must complete manual draft reading to ensure they are within the correct range IAW the vessels stability letter. This requirement will remain in effect until the draft indicator system is restored to proper working condition.

#1 END SHELTER DECK PORT SIDE DOOR NOT CLOSING PROPERLY. REPAIR DOOR TO PROPER OPERATION.

Non-metallic flexible hose installed between fuel pump unit and burners on both boilers. Renew piping without non-metallic materials IAW 46CFR56.50-65(a).

Both boilers are provided with only one control for regulation of water level, low water alarm, and low-low water cut out. Provide additional control unit for low-low water cut out IAW ASME CSD-1 CW 140 via 46CFR63.15(b).

Loss of draft air safety limit controls disable on both boilers. Provide loss of draft air safety limit controls IAW 46CFR63.15-1(b).

Restore electrical power to davit and conduct functions test of davit.

Effect permanent repairs to ABT with 480V contactor.

Fire station 24 does not provide marking for extinguisher 34 at the location per approved fire control plan.

#1 end Assembly station is without instruction signage.

Prove proper operation of #1 boiler pressure relief valve after boiler has been in service for at least 2 hours IAW 46 CFR 61.05-20.

Replace overspeed solenoid and prove proper operation IAW 46 CFR 112.50-1.

Replace #2 port floating water light.

Various car deck sprinkler system nozzles in need of replacement.

Fire safety door #1 did not fully close upon release of magnetic holdback.

1 fire hose nozzle found to be leaking, and not fully operable.

Approximately 100 life vests require new stenciling.

Portable CO2 servicing was being conducted at the time of inspection. Vessel rep required to fax documentation for all extinguishers upon completion.

Permanently repair #1 fire pump pin hole leak and hydrostatically test for adequate pressure when vessel goes into maintenance period in November 2010 IAW 46 CFR 76.10-5.

Replace #1 Engine room sea chest, 8 inch general service suction spool piece

Replace #2 Engine room sea chest, 8 inch general service suction spool piece.

#2 Engine room, stbd side, crop/ insert C strake, frame 8 to 14 1/2.

#2 Engine room, stbd side, crop/ insert D strake, frame 8 to 14 1/2.

Replace batteries on all lifebuoy lights per 46 CFR 199.190 (f) (5).

Prove operation of watertight door indicator lights. Ref 170.275 (e).

Prove proper operation of all four car deck lifejacket drop bins. WSF CATHLAMET drop bin operational testing period of no less than 2 weeks will determine safe operation and necessary repairs to be made to correct deficiency. Deficiency to be resolved at next dockside period.

#6 Fire Screen Door did not shut under own power due to air pressure inside passenger area. Required on the spot correction to adjust closing mechanism to account for air pressure difference.

Vessel's bilges' had excess water relative to WSF special ISE inspections & resultant requirements implemented in January 2008.

No. 1 Red Gear Room -- B Stake, stbd side, frames 29 through 36, area immediately out board of 1st girder off C/L, clean/de-scale and gauge.

No. 1 Tank Room -- Replace bilge suction strainer

No. 1 Shaft Alley -- Install striker plate beneath sounding tube.

No. 2 Engine Room -- 1) B and C Strakes, port side, area between frames 6 & 7, 10 & 11, and 13 & 14, clean/de-scale and gauge. 2) B and C Strakes, stbd side, area between frames 13 & 14, clean/de-scale and gauge. 3) B and C Strakes, stbd side, area between frames 6 through 7, clean/de-scale and gauge. (beneath boilers)

No. 2 Red Gear Room -- B Stake, port side, frames 34 through 36, area immediately out board of 1st girder off C/L, clean/de-scale and gauge.

Hydro #2 heating boiler. Prior to operating. See activity 3089844.

Prove proper operation of low water and flame fail alarm and shut down. Prove operation of safety relief valve. Prior to placing in operation.

Fire Doors leading from the passenger deck to the car deck do not have latches on them. Requiring that the vessel install latches.

Make permanent repair to holed #1 oily bilge water tank (slop tank) with temporary repair of 2-1/2" diameter 1/2" thick doubler welded over the 1/2" hole.

Fixed fire system in galley has expired and has not been serviced. System is to serviced prior to operation of galley.

No audible loss of steering power alarm on #2 end of vessel.

Properly install retro-reflective tape on #1 and #2 end starboard side life rings on the weather deck. LEGACY COMPONENT DESC: life rings

EOT System failed to transmit commands from bridge to engine room.

A new stability letter based on the newly established lightship characteristics must be posted on the vessel by August 13, 2003.

Rejected 225 Adult PFD. Reduced total persons allowed to 991adults until additional PFD's are provided. LEGACY COMPONENT DESC: Condition

PRIOR TO CONTINUING SERVICE, REPAIR/REPLACE FSD #2 AUTO CLOSING DEVICE.

Conduct overspeed trip test on #1 MDE within the next 90 days allowing necessary engine hours for break-in. Test to be witnessed by USCG marine inspector.

MAIN STEAM PIPING PENETRATING A0 BOUNDARY BETWEEN #1 ENG ROOM AND CO2 ROOM MISSING SLEAVE/COLLAR.

PROVIDE DESIGNATED STOWAGE AREAS FOR SCBA'S WHICH WILL PREVENT FREEZING.

REMOVE/CORRECT SHARP EDGES ON LATCH FOR EMERGENCY LOCKER ON CAR DECK._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE COVERS FOR FLORESCENT LIGHTING FIXTURES LOCATED IN #2 END PILOT HOUSE, CREW COMPANIONWAYS, AND CREW QUARTERS (VARIOUS LOCATIONS).

CORRECT FAULT WHICH CAUSES "RUDDER POSITION ERROR" IN #1 END WHEN RUDDER ISHARD LEFT._x001C_ _x001C_ X

PERMANENTLY REMOVE FIRE MAIN PIPING PLUMBED INTO VESSEL'S TYPE III MARINE SANITATION DEVICES (SEWAGE HOLDING TANKS).

OBTAIN LOT NUMBERS FOR THE STAINLESS STEEL PIPING THAT HAS FAILED THROUGHOUT THE FIREMAIN. ENSURE THAT OTHER WSF FERRIES THAT HAVE STANLESS STEEL FIREMAIN PIPING DO NOT HAVE PIPING FROM THE BAD LOTS.

INVESTIGATE PROBLEM WITH CURRENT FIREMAIN PIPING FAILURES AND PRESENT SOLUTION. UPON FINDING A SOLUTION MAKE PERMANENT REPAIRS TO PLUG WELDS ANDOTHER EXISTING TEMP REPAIRS.

INSTALL LIGHT COVER IN OVERHEAD LIGHT LOCATED IN GALLEY.

REPLACE RELIEF VALVE FOR #2 START AIR TANK.

REPLACE RECEPTACLE FOR WASHING MACHINE WITH WATERTIGHT, SCREW IN TYPE RECEPTACLE.

PROVE PROPER OPERATION OF ENGINE ROOM #4 SUPPLY FAN, PORT. NOTE ATTACHED ON CONTROLLER INDICATES DOES NOT OPERATE.

WHEN RELEASED, #1 FIRE SCREEN DOOR DRAGS ON DECK TILE AT MID-SWING AND WILLNOT CLOSE WITHOUT ASSISTANCE. DOOR BOTTOM-TO-DECK CLEARANCE MUST BE INCREASED TO PREVENT INTERFERENCE. _x001C_ _x001C_

"DO NOT BLOCK" LABELS ARE WORN AWAY FROM CAR-DECK SIDE OF EMERGENCY ESCAPE SCUTTLES FROM MACHINERY SPACES._x001C_

PROVIDE PROPER LABELING AT EACH SOUND POWERED PHONE INSTALLATION FOR PHONE STATIONS THROUGHOUT VESSEL. PROVIDE PROPER OPERATION OF SOUND POWERED PHONES IN SOLARIUMS ON BOTH ENDS.

PROVIDE PACKING MATERIAL FOR FOLLOWING ELECTRICAL CONDUITS:_x001C_ WHEELHOUSE #1 CIRCUIT BREAKER PNL L1 & EL1_x001C_ WHEELHOUSE #2 CIRCUIT BREAKER PNL L2 & EL2

PROVIDE FOR PROPER LABELING OF NO. 3 FIRE STATION IN NO.1 ENGINE ROOM.

INSTALL LOCKING DEVICE ON #2 RESCUE BOAT MOTOR TO PROVIDE SAFE OPERATION WHILE MOTOR IS IN REVERSE.

Repair/Replace heating boiler pressure switches for low feed water alarms/shutdowns and demonstrate proper operation.

SUBMIT OILY WATER SEPARATOR INSTALLATION AND DESIGN PLANS TO THE OCMI FOR APPROVAL

CLEAN CEILING VENT DUCTS IN GALLEY.

REMOVE BOAT HOOKS OFF CAR DECK AND SECURE IN A SAFE AREA.

INSTALL HARD PIPING FOR OVERBOARD DISCHARGE ON ALL RECESSED DECK HATCHES ATNEXT DRYDOCKING.

MAKE REPAIRS/ADJUSTMENT TO FIRE SCREEN DOOR #1 SO AS TO ENSURE PROPER CLOSURE AT ALL ANGLES OF NORMAL TRIM AND HEEL. REPAIRS/ADJUSTMENT TO BE MADE TO THE SATISFACTION OF THE COGNIZANT OCMI AND ATTENDING MARINE INSPECTOR.

PROVIDE LOCKING ARRANGEMENT TO MAIN CROSS HEAD BOLTS ON NO. 2 END RUDDER. BOLTS SHALL BE CHECKED AND LOGGED AT EVERY CREW CHANGE UNTIL REQUIREMENT ISSATISFIED. THIS REQUIREMENT IS TO BE COMPLETED NO LATER THAN 15 FEB 95.

[name withheld] CRACK IN WELD OF STERN TUBE PENETRATION IN NUMBER1 STEERING END, LOG INSPECTION AND REPORT ANY CHANGES TO COAST GUARD. CRACK TO BE REPAIRED DURING AVAILABILITY IN JAN. 1995.

INSTALL MACHINERY GUARDS ON ROTATING END FOR BOTH SSDG'S.

CLEAN OIL OUT OF BILGE IN NUMBER 2 TANK ROOM BILGE.

DEMONSTRATE SAFETY ALARMS AFTER INSTALLATION OF NUMBER 1 SSDG.

INSTALL EMERGENCY LIGHTING IN BOTH ENGINEERING STOREROOMS.

PROVE OPERATION OF ALL EXISTING GENERAL ALARM BELLS TO BE WITNESSED BY A CGINSPECTOR PRIOR TO THE CARRAGE OF PASSENGERS.

PROVIDE IN WRITING A PROPOSAL TO BRING THE GENERAL ALARM BELL'S DB LEVEL INCOMPLIANCE WITH 46CFR113.25-9.

NOT TO OPERATE OWS WITH PASSENGERS ABOARD.

EFFECT REPAIRS TO CREW QUARTERS HEAD, #2 END PORT AND STBD TO ENSURE NO LEAKAGE OF SEWAGE THROUGH FLOOR DRAIN OCCURS, TO ENSURE SANITARY REQUIREMENTS OF 46 CFR 71.25-40 ARE MET.

PROVE PROPER OPERATION OF REMOTE OPERATED FUEL SHUTOFF VALVE FOR EMERGENCY GENERATOR FUEL OIL DAY TANK.

PROVE OPERATION OF LIFE JACKET STOWAGE RELEASE AT NUMBER ONE END, PORT. _x001C_

SERVICE PORTABLE EXTINGUISHER AT STATION NUMBER 16 IN GALLEY.

PROVIDE KEY TO GALLEY IN PILOT HOUSE AND LABEL BOX FOR SAME.

INSTALL FIXED LIGHTING IN #1 AND #2 END STOREROOMS ON MAIN CAR DECK AND PROVIDE APPROVED PLANS FOR SAME.

AS PER 46CFR76.10-5(D), INSTALL A 125 PSI RELIEF VALVE ON THE DISCHARGE SIDE OF BOTH FIRE PUMPS. THIS REQUIREMENT IS BASED ON THE RESULTS OF A PITOT TUBE PRESSURE TEST CONDUCTED ON THE VESSEL KITTITAS.

REPAIR REMOTE WATERTIGHT DOOR #6 INDICATOR LOCATED ON CAR DECK.

SWING COMPASS AND PROVIDE CURRENT DEVIATION TABLES.

PROVIDE REMOTE FIRE DAMPER PULL IN ENGINEERS PAINT LOCKER ON CAR DECK.

PROVIDE VENTILATION AND MEANS OF CLOSURE BY REMOTE FIRE DAMPER PULL IN DECK CREW PAINT LOCKER ON CAR DECK.

PROVIDE REMOTE FIRE DAMPER PULL IN GALLEY.

REPLACE MULTI-OUTLET ELECTRICAL TERMINAL IN THE PUBLIC ADDRESS SYSTEM AND HARD WIRE WITH APPROVED CABLE.

REPAIR STBD FIRE SCREEN DOOR #1 ON THE PASSENGER DECK AND DEMONSTRATE PROPER OPERATION.

REMOVE CARDBOARD AND INSTAL INSULATION AND COVERING AS PER APPROVED DRAWING AND REGULATIONS, IN CREW'S DAY ROOM ON AUTO DECK.

INSTAL WIRE INSERTED GLASS IN #1 AND #2 PILOT HOUSE DOORS PORT AND STARBOARD SIDES. (ENTRY DOORS FROM OUTSIDE)

REPLACE EXTENTION CORD IN PUBLIC ADDRESS SYSTEM. HARD WIRE WITH APPROVED CABLE AS PER REGULATIONS. TO BE COMPLETED PRIOR TO CARRYING PASSENGERS.

REPAIR NEWLY INSTALLED PA SYSTEM TO WORK IN ALL ZONES IN PILOT HOUSE #2. TO BE COMPLETED PRIOR TO CARRYING PASSENGERS.

INSTAL RESCUE BOAT LIGHTS AND SHOW PROPER OPERATION. TO BE COMPLETED PRIORTO CARRYING PASSENGERS.

CONDUCT FIRE AND BOAT DRILL WITH NORMAL VESSEL CREW.

3. REMARK EMERGENCY ESCAPE HATCHES FROM #2 END STEERING FLAT "KEEP CLEAR".

4. REPAIR SCREW CAP TO WATERTIGHT 110 VOLT ELECTRICAL OUTLET IN WAY OF #2 END SHELTER DECK CENTERLINE OUTBOARD BULKHEAD.

5. REMARK THROTTLE CONTROL UNIT NUMERALS ON THE #1 END, AND CALIBRATE THE PITCH POSITION INDICATOR #2 END TO SHOW ZERO (0) PITCH.

1. PROVIDE DONNING INSTRUCTIONS FOR CHILDRENS LIFEJACKETS (HORSE COLLOR TYPE) ON THE SHELTER DECK ON BOTH ENDS OF THE VESSEL NEAR CHILDRENS LIFE- JACKET STOWAGE LOCKER.

2. PROVIDE A MEANS OF SECURING VENDING MACHINES ON THE PASSENGER DECK (IE. NEWSPAPER RACKS, ECT.).

FIRE SCREEN DOOR NO 7(?) FROM BACK OF GALLEY, NOTED TO HAVE NO SELF CLOSINGDEVICE AND THE LATCH HAS BEEN REMOVED FROM THE DOOR KNOB. INSTALL BOTH.

CONDUCT A BOAT DRILL

CONDUCT A FIRE DRILL

REPAIR PA SYSTEM AND OPERATE SAME TO THE SATIFICATION OF THE ATENDING CG MARINE INSPECTOR

REPLACE OR REMOVE OUT DATED EXTRA LIFERAFTS

REPAIR WATERTIGHT DOOR CONTROL PANEL INDICATOR LIGHTS.

PROVIDE KEY FOR LOCKBOX TO #2 END DECK GEAR LOCKER TO FIRE DAMPER IS ACCESSABLE. KEEP UNLOCKED UNTIL KEY IS PROVIDED.

REPAIR GENERAL ALARM RINGER IN #1 WHEEL HOUSE.

COUNT AND RESTOW LIFE PRESERVERS IN SOLARIUMS AND MAIN PASSANGER LOUNGE LOCKERS TO ENSURE CORRECT PLACEMENT OF ADULT AND CHILD SIZES BY 27JUNE1985.
