GRACIE JEAN

Stability information (stability details indicated on stability letter), is required on certain vessels by paragraphs (b), (c), or (d) of this section. Enough stability information, including stability calculations and assumptions made to use them, must be provided to allow the master to be able to determine operating guidelines, loading restrictions, and ensure compliance with the applicable intact and damage stability regulations of this chapter. Vessel had a deployable sonar installation & doubler plate support bracket welded to side of the vessel & vessel is currently sitting with approx. 3.5-5 degree list to STBD. Conduct new Simplified Stability Test or provide documentation from Professional Engineer (PE) Or Naval Architect that vessel is still operating with in the constraints of their Stability Letter dated March 28, 2023.

A vessel not required to have a power driven fire pump by § 181.300 must have at least three 9.5 liter (21/2 gallon) buckets, with an attached lanyard satisfactory to the cognizant OCMI, placed so as to be easily available. Vessel only has 2 buckets.

Each vessel that operates on the high seas, or that operates beyond three miles from the coastline of the Great Lakes, must have on board a FCC Type Accepted Category 1, 406 MHz EPIRB, installed to automatically float free and activate. Battery Expired on EPRIB.

Stowed so that when the vessel sinks the survival craft floats free. Vessel had ratchet strap over life float.

Each life jacket carried on a vessel on oceans, coastwise, or Great Lakes route, must have a life jacket light approved in accordance with § 161.012 in subchapter Q of this chapter, or other standard specified by the Commandant, including, but not limited to, approval series 160.112. Each life jacket light must be securely attached to the front shoulder area of the life jacket. One Life Jacket was incorrectly labeled with wrong vessel name and missing light.

Stability information (stability details indicated on stability letter), is required on certain vessels by paragraphs (b), (c), or (d) of this section. Enough stability information, including stability calculations and assumptions made to use them, must be provided to allow the master to be able to determine operating guidelines, loading restrictions, and ensure compliance with the applicable intact and damage stability regulations of this chapter. Vessel had a deployable sonar installation & doubler plate support bracket welded to side of the vessel. Vessel is to complete new Simplified Stability Test and receive new stability letter in 30 days or return vessel to original state in compliance with Stability Letter issued March 28, 2023.

When the cognizant OCMI or the Commanding Officer, Marine Safety Center determines, in accordance with § 178.210, that a vessel must have stability details indicated on its Certificate of Inspection or a stability letter. Maximum weight of portable equipment permitted on the vessel. Vessel is restricted to no more then 3255 lbs of cargo & the VCG shall not exceed 32 inches until new stability test is conducted or sonar equipment is removed.

Starboard stern remote fuel shutoff valve did not close.

Water leaking from starboard main engine exhaust pipe.

Raw water leaking from inboard port main engine.

Generator did not automatically shutoff when pre engineered fixed fire extiguishing system was tested in the machinery space.

Portside center cabin window cracked.

Life float no longer serviceable.

Stern Stanchions for handrails cracked at connection to deck.

The cognizant OCMI determines that the vessel is designed, arranged, or involved in operations so that the vessel itself cannot serve as an adequate rescue craft. MIs have determined that the vessel does not contain the design or arrangement to effectively rescue a person from the water. 46 CFR 180.210(b)(2)

Operation of transmitters of any ship station must be performed by a person holding a commercial radio operator license or permit; Master did not have permit

A manned oceangoing vessel of 40 feet or more in length engaged in commerce must have a garbage management plan; vessel does not have plan

The marine employer must have a drug testing program in place; vessel unable to provide proof.

A vessel of more than 7.9 meters (26 feet) in length, but not more than 19.8 meters (65 feet), must carry a minimum of one life buoy of not less than 610 millimeters (24 inches) in diameter; vessel's ring buoy is deteriorated.

Fuses must be of the cartridge type only and be listed by Underwriters Laboratories or another independent laboratory recognized by the Commandant; vessel has several terminal boards under pilothouse w/ blade type fuses.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Port side engine lost lower crankshaft bearings. Repair vessel to operate condition.

Crew must conduct drills to the satisfaction of the attending Marine Inspector.

A pre-engineered fixed fire suppression system must automatically shut down engines when activated and have the capability to override and restart engines after activation; vessel’s Fireboy system did not shut down STBD Maine engine and was not capable of manual override.

Buoyant apparatus with plastic foam buoyancy must have a plastic foam body with an external protective covering. The external protective covering must be Elastomeric vinyl accepted by the Commandant. Covering found wasted and cracking and in need of repair as recommended by manufacturer.

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load. Starboard shaft has an unacceptable wobble, indicating engine was possibly not properly aligned during haul-out.

Every vessel subject to Part III of Title III of the Communications Act must have a detailed inspection of the radio installation by an FCC-licensed technician in accordance with § 80.59 once every five years. If the ship passes the inspection, the technician will issue a Communications Act Safety Radiotelephony Certificate. Vessel held no valid Safety Radiotelephony Certificate.

Make repairs to bent/cracked hull plate extension IWO aft, port transom.

Demonstrate satisfactory operation of valves within 6" of waterline and below.

Crop and renew the hull plating identified below both shaft where pitting was observed, as discussed.

Re-attach the bonding wire to the top of the fuel tank.

Repair cracked aft hatch frame as discussed.

Repair cracked hatch framing for both engine compartment hatches, as discussed.

Remove rusted fitting observed outboard side of starboard ventilation and repair as discussed.

Remove junction box and associated wiring from port side raw water hose, or identify it's purpose and re-install.

Renew chaffed coolant water exhaust hose forward of starboard exhaust pipe.

The name of the vessel must be marked on some clearly visible exterior part of the port and starboard bow and the stern of the vessel. Provide proof the name of the vessel is correctly marked as Gracie Jean.

Port Engine was disassembled due to overheating condition

Machinery, equipment, materials and arrangements not covered by standards in this sub-chapter may be inspected in accordance with standards acceptable to the cognizant OCMI as good marine practice. There were open boxes of paint cans in the forward compartment. Remove boxes.

The minimum number of portable fire extinguishers required on a vessel must be acceptable by the cognizant Officer in Charge, Marine Inspection, but must not be fewer than the minimum number required. The crew cabin does not have a fire extinguisher rated at 2-A. Place the proper extinguisher with bracket in the crew cabin.

A vessel on an Oceans route must be equipped with an electronic position fixing device, capable of providing accurate fixes for the area in which the vessel operates, to the satisfaction of the cognizant OCMI. The Single Sideband radio did not have the MMSI number installed. Install number into the single sideband.

A vessel not required to have a power driven fire pump must have at least three 2 1/2 gallon buckets, with an attached lanyard satisfactory to the cognizant OCMI, placed so as to be easily available during an emergency. There was only one functional fire bucket onboard. Place two fire buckets on the vessel.

A vessel must comply with the applicable requirements for any radio installations, including the requirements for a station license and installation certificates to be issued by the Federal Communications Commission. The radio safety certificate was expired. Obtain valid certificate.

Each lifejacket kept in stowage must be readily available. The designated lifejacket stowage was filled with other items making the items not readily available.

Vessel must carry a first aid kit approved under 46 CFR 160.041 or equvalent. Vessel's first aid kit was expired.

The master shall conduct sufficient drills to make sure crew members are familiar with duties. USCG needs to witness crew drills.

An exposed hazard, such as rotating machinery, must be properly protected my a cover. The starboard main engine, secondary bilge suction belt/pulley has no guard.

the master and crew will be familiar and have mounted emergency instructions for FIRE/HEAVY WEATHER/MAN OVERBOARD. Emergency instructions not mounted.

A placard must be posted next to all radiotelephones with the emergency broadcast instructions and information, specific to the vessel. Vessel had no placard.

Crew training, drills, and EPIRB testing shall be logged. There is no Ship's Log on board.

Vessel must carry up to date charts, U.S. Coast Pilot, CG Light List, Tide Tables, and Current Tables. Vessel has no charts or pubs on board.

The employer shall provide an Employee Assistance Program (EAP) for all crewmembers. there is no EAP on board.

Employers must maintain records of chemical tests as provided in 49 CFR 40.333 and must make these available to the USCG upon request. There were no records of chemical testing on board.

01 PWG. Complete Satisfactory Annual Inspection. Vessel has not completed an annual inspection since 11APR2015. 46 CFR 176.500

02 PWG. Vessel is overdue for drydock and Internal Examination Interval. 46 CFR 600

Vessel is prohibited from operating outside the Gulf of Mexico until a new to zone inspection is completed by local [name withheld] of passengers or cargo is not authorized. Contact USCG Sector Hampton Roads Inspections Division [phone withheld] to complete exam

Replace/renew fwd peak hatch gasket.

Install swing check valve in fwd passenger space bilge discharge pipe, and properly attached hose with clamps.

Plug holes in E/R bulkhead on stbd side fwd (old wire runs)

Install proper wire thru bulkhead fitting in aft engine room bulkhead on port side ( bilge pump wire to steering space)

Replace hose clamps on aft steering bilge pump hose and double clamp.

Reroute fuel tank vent hose to remove sag.

Label upper deck for max number of passengers

Replace shaft bearing prior to entering water.

Provide proper label for Emergency Fuel Shut-off valve.

Replace expired items in First Aid Kit

Update Charts and pubs for the operation area

Provide voyage plan prior to carriage of passengers.

Install guard on Stbd engine pulley for Fire and bilge pump.

Renew/replace leaking Gen fuel filter

Properly route clutch cable in engine room.

Repair/replace leaking hydraulic hose in steering space.

Provide a means of securing sewage overboard discharge valve.

Properly support or remove electrical conduit in engine room.

Seal aft deck hatches.

Clean all bilges.

Remove all dead ended wires throughout boat.

Replace missing life jackets.

Call for sea trials when ready.

Provide proof of portable fire extinguisher servicing.

Provide flare for intended route and service.

Provide proper fire hoze and nozzle.

Prove operation of fire pump.

Prove operation of emergency fuel shut-off valve.

Label emergency fuel shut-off valve.

Provide new hydrostatic release for EPIRB LEGACY COMPONENT DESC: EPIRB

Prove to CG Marine Inspector that all wiring is 14 AWG or larger. Not all wiring in vessel is original. Some wiring has been added since vessel allowed COI to expire. LEGACY COMPONENT DESC: Wiring

Provide new battery for EPIRB

Provide current NOAA registration for EPIRB LEGACY COMPONENT DESC: EPIRB

Provide emergency lighting system where needed.

Provide circuit breaker for shore power connection.

Provide current Certificate of documentation

Provide shore power connection box or receptacle IAW with 46 CFR 183.390 LEGACY COMPONENT DESC: Overcurrent Device

Provide current operators license to operate a 28 ton vessel with an oceans route.

Prove dual voltage generator meets 46 CFR 183.324

Provide retroreflective tape for all lifejackets.

Provide new FCC documentation.

Provide separation for child and adult life jackets and mark accordingly.

Provide waste managment placard

Provide one child-size lifejacket.

Provide voyage plan IAW 46 CFR 185.503. Owner has stated that this vessels route will be Oceans.

Provide new fuse for VHF radio. Radio would not operate. Prove operation of VHF radio. LEGACY COMPONENT DESC: VFH Radiotelephone

Replace water light batteries in all PFD's LEGACY COMPONENT DESC: Lights

Provide new SOLAS retro tape on all lifebuoys

Prove operation of navigation lights and anchor light. LEGACY COMPONENT DESC: Navigation Lights

Properly wire circulating fans inside house.

Provide paddles for Lifefloat

Prove operation of bilge high water alarms.

Replace batteries for life float light

Prove operation of electrical bilge pumps.

Properly cap off existing through hull located amidship center of vessel not currently in use. Through hull was used for an A.C. unit that has since been removed.

Provide new life ring.

Provide first aid kit

Provide proper railing with appropriate courses. Some areas of vessel only have top railing. All railings must be IAW 46 CFR 177.900 LEGACY COMPONENT DESC: Deck Rail

Install fixed fire fighting system IAW 46 CFR 181.400

INSTALL BILGE ALARMS.

REPAIR REACH ROD FOR EMERGENCY FUEL CUTOFF VALVE.

PROVIDE UPDATED COPIES OF NAVIGATION CHARTS FOR OPERATING AREA.

PROVIDE FCC RADIO STATION LICENCE IAW 47CFR80.

SECURELY STOW 2 OXYGEN BOTTLES.

PROPERLY SUPPORT LOOSE ELECTRICAL CABLES IN VOID SPACE BELOW SEATING AREA IAW 46CFR183.340.

REPLACE ALL SYNTHETIC LINES ON LIFEFLOATS IAW 46CFR181.610.

PROVIDE GUARD ON FOR'D SIDE OF VENT FAN PORT SIDE BETWEEN SEATING AREA AND OPERATING STATION._x001C_

PROVIDE WASTE MANAGEMENT PLAN IAW 33CFR151.57.

PROVIDE MEANS TO LOCK-OUT MSD IAW 33CFR159.7._x001C_

REPAIR APPRX 6 INCH CRACKED WELD IWO DECK AND TRANSOM INTERFACE ON CENTERLINE IN LAZERETTE SPACE.

PROVIDE RETROREFLECTIVE TAPE ON BOTH LIFEFLOATS IAW 46CFR180.130

PROVIDE AND MOUNT LIFEJACKET PLACARD IAW 46CFR185.516.

STENCIL FIRE BUCKETS IAW 46CFR181.610.

REPLACE HOLDED FUEL TANK OVERFILL HOSE IN LAZARETTE WITH APPROVED FUEL HOSE(SAE J1942).

REPLACE CORRODED BONDING WIRE IN LAZARETTE FROM FUEL DECK FILL TO FUEL TANK.

INSTALL NEW EXHAUST LAGGING ON THE INBOARD EXHAUST PIPING FOR BOTH MAIN ENGINES.

REPAIR FRACTURED WELD ON THE PORT FORWARD INBOARD ENGINE MOUNT.

REPLACE GASKETS ON BOTH ENGINE ROOM HATCH COVERS.

REPLACE PIPE INLET ON BOTH P/S EXPANSION TANKS IN THE ENGINE ROOM.

REPAIR BROKEN HINGE ON PORT ENGINEROOM HATCH COVER.

REPLACE GASKET ON LAZARETTE HATCH COVER.

REPAIR HOLE IN STBD WET EXHAUST PIPING IN WAY OF OLD GENERATOR INLET.

VESSEL RESTRICTED TO DAYTIME OPERATIONS UNTIL PROPER MASTHEAD AND STERN LIGHTS ARE INSTALLED ON BOARD VESSEL IAW INLAND NAVIGATION RULES.

REPLACE ONE (1) RINGBUOY WITH COAST GUARD APPROVED RINGBUOY.

PROVIDE ONE HAND HELD BILGE PUMP.

PROVIDE ON BOARD VESSEL ONE (1) FIRE HOSE OR THREE (3) 2.5 GALLON BUCKETS. VESSEL RESTRICTED FROM OPERATION UNTIL PROVIDED.

PROVIDE REQUIRED FCC RADIO TELEPHONY CERTIFICATE, VESSEL RESTRICTED TO OPERATIONS NOT MORE THAN 1000FT. FROM SHORE UNTIL CERTIFICATE IS PROVIDED.

VESSEL IS LIMITED TO CARRIAGE OF 19 ADULT PASSENGERS AND NO CHILDREN UNTIL PFD LIGHTS AND WHISTLES ARE PROVIDED FOR ALL PFD'S ON BOARD AND THREE (1) CHILD-SIZED PFD IS PROVIDED ON BOARD THE VESSEL.

MAKE PERMANENT REPAIRS TO PUBLIC ADDRESS SYSTEM.

PROVIDE ON BOARD VESSEL, UP-TO-DATE INLAND NAVIGATION RULES.

VESSEL RESTRICTED TO OPERATIONS NOT MORE THAN ONE (1) MILE FROM SHORE UNTILPADDLES FOR LIFEFLOATS ARE REPLACED._x001C_ _x001C_ _x001C_

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

INSTALL TWO (1 1/2") GOOSENECK VENTS TO LAZARETTE.

PROVIDE DOCUMENTARY EVIDENCE THAT THE VSL CREW IS CURRENTLY PARTICIPATING_x001C_ IN A DRUG TESTING PROGRAM.

REPLACE WATERTIGHT HATCH LEADING TO FOWARD COMPARTMENT.

PROVIDE 6 ORANGE SMOKE HAND DISTRESS SIGNALS.

PROVIDE AND INSTALL 30X30 MESH SCREEN ON FUEL VENT PIPE._x001C_ _x001C_

PROVIDE 4 CHILD-SIZE LIFE JACKETS; VESSEL MAY NOT CARRY CHILDREN UNTIL CHILD-SIZE JACKETS ONBOARD FOR EACH CHILD CARRIED.

PROVIDE WEAK LINK WITH CORRECT CAPACITY FOR LIFE FLOAT ONBOARD. VESSEL MAY NOT CARRY MORE THAN 15 TOTAL PERSON UNTIL THIS IS CORRECTED.

PROVE PROPER OPERATION SSB RADIO. VESSEL LIMITED TO 20 MILES FROM A HARBOROF SAFE REFUGE AND BELOW UNTIL THIS IS CORRECTED.

REPAIR CRACKED RAILS AROUND THE AFTER DECK.

REPAIR THE TWO BITTS ON THE STERN.

INSTALL COTTER KEYS IN STEERING PINS.

FREE UP EMERGENCY FUEL SHUTOFF AND LABEL SAME.

SECURE WIRING TO ANCHOR LIGHT.

PROVIDE HEAT SHIELDS ON ALL THREE FUEL FILTERS.

REPAIR ELECTRICAL FUSE BOX ON FWD BKD IN ENGINE ROOM.

REMOVE TEMPORARY WIRING ON BATTERIES.

REPAIR WIRING AND DEMONSTRATE OPERATION OF GENERATOR.

PROVIDE 2 ADDITIONAL ORANGE FLARES.

PROVIDE 100' PAINTER FOR LIFEFLOAT.

PAINT NAME ON STERN

PROVIDE BRACKET FOR WATERLIGHT ON LIFERING.

SERVICE ALL 4 FIRE EXTINGUISHERS

REPAIR EXHAUST LEAKS ON MANIFOLD.

REPAIR FOREPEAK HATCH COVER.
