CIM 1002

A survey, either general or partial, according to the circumstances, shall be made every time an accident occurs or a defect is discovered which affects the safety of the vessel or the efficacy or completeness of its lifesaving appliances, fire-fighting or other equipment, or whenever any important repairs or renewals are made. The survey shall be such as to insure that the necessary repairs or renewals have been effectively made, that the material and the workmanship of such repairs or renewals are in all respects satisfactory, and that the vessel complies in all respects with the regulations in this subchapter. Eight 4x4 inch diameter holes on deck. Missing or bent spots on cement tanks need to be replace so deck is not Further damage. As well as Cement on deck needs to be remove and make deck are available for inspection.

In the inspection of hulls, boilers, and machinery of vessels, the standards established by the American Bureau of Shipping, see part 90, subpart 90.35 of this chapter, respecting material and inspection of hulls, boilers, and machinery, and the certificate of classification referring thereto, except where otherwise provided for by the rules and regulations in this subchapter, subchapter E (Load Lines), subchapter F (Marine Engineering), subchapter J (Electrical Engineering), and subchapter W (Lifesaving Appliances and Arrangements) of this chapter, shall be accepted as standard by the inspectors. 2 ladders going above the engine compartment need to be replace. Gaskets for two hatch covers under engine compartment need replacement.

Electric installations on vessels must ensure: Protection of passengers, crew, other persons, and the vessel from electrical hazards. Loose end wires on the engine compartment need to be properly secure or remove. As well as the light cover in the compartment need to be secure or replace.

The inspection for certification shall include an inspection of the structure, boilers, and other pressure vessels, machinery, and equipment. Fan intake above generator has to be Crop and renew during drydock.

Provide an approved shipboard oil pollution emergency plan (SOPEP). Prior to conducting operations. 33 CFR 151.27

Provide valid Ceritificate of Financial Responsibility (COFR) Prior to conducting operations. 33 CFR 138.10

Conduct and provide documentation for completion of cargo hose testing IAW CFR. 33 CFR 156.170(f)(3)

Conduct and provide documentation for completion of cargo pipe testing IAW CFR. Prior to conducting operations. 46 CFR 35.35-70(d)

Conduct and provide documentation for completion of cargo relief valve testing IAW CFR. Prior to conducting operations. 46 CFR 35.35-70(b)

Provide required number of approved immersion suits. Prior to conducting operations. 46 CFR 199.273

Demonstrate proper operation of emergency lighting.Prior to conducting operations.46 CFR 35.40-6

Provide documentation of NOAA registration for EPIRB.Prior to conducting operations.47 CFR 80.1061

Demonstrate proper operation of all life jacket lights. Prior to conducting operations. 46 CFR 199.70(b)(4)(i)

Provide approved and properly outfitted and properly stowed life raft as required by CFR. Prior to conducting operations. 46 cfr 199.261

Provide and demonstrate operation of properly outfitted rescue boat and operation of rescue boat launching davit. Prior to conducting operations. 46 CFR 199.262

Replace expired batteries on life buoy lights. Prior to conducting operations. 46 CFR 199.271

Provide required railing around entire peripheral of deck. Prior to conducting operations. 46 CFR 32.02-10

Provide required number (12)of unexpired Distress Signals.Prior to operations. 46 CFR 199.60 (c)

Crop and renew damaged #1 stiffener at stb side shell IWO frame 5.5.

Crop and renew tripped brackets 3-5 IWO stb side shell frame 37.

Connect the bottom of both sides of the fwd port rake ladder.

Connect installed fire detection system to audible alarm.

Update fire control plan to reflect current configuration.

Make general alarms bells sound at 85dB or greater.

Provide sufficient illumination from e-lighting source to provide safe egress from each space (include berthing and galley).

Repair/replace #3 pump prime mover lube oil filter housing.

Do not operate vessel outside the boundary line until load line certificate is endorsed.

Repair Rescue boat davit, provide SERVS investigation and tech report. Prove proper operation of davit in stored power mode. Keep a standby tug along side the barge until rescue boat davit has been tested and inspected by an attending US Coast Guard Inspector. A standby tug is not necessary if barge is moored to a pier or people are not on board.

Keep a stand by tug along side the barge until new rescue boat davit is weight tested, has approved plans and crew proves proficiency with a drill. A standby tug is not necessary if barge is moored to a pier or people are not on board.

REPAIR/REPLACE MACHINERY SPACE PORT SIDE WTD.

RENEW GASKET MATERIAL AND MAKE PORT SIDE MACHINERY SPACE DOOR WATERTIGHT.

REPAIR/REPLACE MACHINERY SPACE STARBOARD SIDE WTD.

RENEW GASKET MATERIAL AND MAKE STBD SIDE MACHINERY SPACE DOOR WATERTIGHT.

PROVE WATERTIGHT INTEGRITY OF CENTERLINE WTD IN MACHINERY SPACE.

ELEVATE ELECTRICAL WIRING OFF OF DECK. PORT SIDE GEN ROOM OUTBOARD.

REPAIR/REPLACE INBOARD PORT GEN. RADIATOR -- AS ORIGINAL. PROVE PROPER OPERATION.

MAKE PERM. REPAIRS TO F/O PIPE T-UNION AND UNION AT CHECK VALVE FROM #3 PUMP ENGINE.

REMOVE ALL PLASTIC "ZIP TIE" RETAINERS ON LIGHT FIXTURES IN ENGINE ROOM AND RENEW METAL RETAINERS AS ORIGINAL.

INSTALL ROTATING RED LIGHT TO BE VISIBLE IN PUMP ROOM FROM ALL LOCATIONS TO INDICATE GENERAL ALARM ACTIVATION. INSTALL PROPER PLACARDING NEAR THE INSTALLATION.

MAKE PERM. REPAIRS TO F/O LEAK AT STBD GEN. UNION AFTER FILTER AND CHECK VALVE.

REPLACE/RENEW EMER. LIGHTING ON LIGHT TOWER FORWARD OF DECK HOUSE.

ROTATE EMERGENCY LIGHTING TO ENSURE FRC EMBARKATION AND LAUNCH STATION IS ILLUMINATED.

INSTALL GENERAL ALARM BELL IN PUMP ROOM TO ENSURE ACTIVATION OF GEN. ALARM IS AUDIBLE.

REPLACE RING BUOY LIFE LINES WITH UV RESISTANT LINE AND TIE AROUND THE BODY OF THE BUOY.

REMOVE PAINT ON INFO PLACARD ON LOWER AIR RECEIVER.

Thoroughly clean all tanks by end of next dry dock.

Remove all oily/water waste from #5 tanks port and starboard and make ready for internal structural exam.

Provide plan for removal of all crude oil sludge from all tanks and make ready for inspection.

It was discovered that the barge's fast rescue boat was damaged. Repairs were affected without CG oversight.

Demonstrate required shutdowns on #3 Aux Generator.

Remove dead end wires in way of aft stb cargo pump room.

Replace wire rope on falls and weight test.

Make general alarm light flash/rotate in generator room.

When away from the dock another vessel shall be along side until the rescue boat is operational.

Troubleshoot & demonstrate proper operation of FRB HPU controls as per SERVS work request 2-197-003A

R & R #2 genset f/o supply & return hose to hoses of proper type and length.

Demonstrate proper operation of overspeed trip on cat generator.

Send out all overdue air breathing composite cylinders for hydrostatic test.

Re-pack seal glands on all (4) shaft seals cargo pumps penetrating bulkhead of the cargo pump room .

Renew faded retro-reflective tape on the rescue boat and install reflective tape on the bottom hull.

Provide proper documentation for the rescue boat release mechanism last static load test within a 5 year period.

Restore insulation removed in several places in the STBD side forward machinery room.

Stenciled barge name (BARGE 450-8) or call sign (WBP2181) on the rescue boat.

Reduce the air bubble of the rescue boat magnetic compass to 1" diameter.

Cargo Pressure gauges not calibrated

Ensure dogs on emergency escape hatches operate freely. LEGACY COMPONENT DESC: Watertight Doors

Repair floating water light attached to Ring Buoy 2-701-7 LEGACY COMPONENT DESC: Self-igniting Lights

Obtain and post donning instructions for life jackets in living quarters. LEGACY COMPONENT DESC: Instructions

Remove NOAA Registration sticker and reaffix to EPIRB itself. LEGACY COMPONENT DESC: EPIRB

Obtain and place onboard, one more approved fire hose for a total of four. LEGACY COMPONENT DESC: Number

Terminate and/or repair lighting sockets on outboard bulkhead in generator space. LEGACY COMPONENT DESC: Lighting Fixture

Remove old alarm switch located outside cargo pump engine room. LEGACY COMPONENT DESC: General Alarm

Repair hydraulic oil leak(s) on the Kepner Boom Control Unit . LEGACY COMPONENT DESC: Hydraulic control unit

Remove all residue from all tanks or provide proposal for the removal all residues from all tanks. LEGACY COMPONENT DESC: Tank Bottoms

PROVIDE TWO IN-SERVICE LIFERAFTS AND HYDROSTATIC RELEASES.

PROVIDE PERSON-IN-CHARGE AND TRAINING INFORMATION FOR OIL TRANSFER PROCEDURES.

MAKE PERMANANT REPAIRS TO DAMAGE TO BOTTOM PLATING AND INTERNALS BETWEEN FRAMES 4-5 #1P CARGO TANK.

REPLACE ELECTRICAL WIRING LEADING TO HEAT TAPE.

PROVIDE RETROREFLECTIVE TAPE ON ALL FOUR QUADRANTS OF RING LIFE BUOY LOCATED AT STARBOARD QUARTER STATION.

PROPERLY LABEL ALL BREAKERS IN ELECTRICAL PANELS LOCATED PORT AND STARBOARDMACHINERY SPACE.

PROPERLY LABEL BREAKERS IN ELECTRICAL PANEL LOCATED IN GENERATOR ROOM ON ACCOMODATION LEVEL.

PROVIDE FLAME IMPINGEMENT BOWL FOR GENSET FUEL FILTER.

PROVE PROPER OPERATION OF CONTROLS, SHUTDOWNS AND ALARMS OT THE THERMAL FLUID HEATER.

PROVE PROPER OPERATION OF THE THERMAL FLUID HEATER.

PROVIDE ONBOARD A COMBUSTABLE GAS INDICTOR.

PROVIDE TO [name withheld] PLANS AND COPIES OF APPROPRIATE TESTING COMPLETED FOR DECK CRANE INSTALLATION.

Repair f/o emergency stop valve.

Repair fire doors on thermo fluid heater.

Make permanant repair to stbd skeg.

Reinstall flame deflector on f/o filter stbd cargo pump.

Repair flame screens on 3s, 1p P/V valves.

Provide current hydro certificate on cargo hoses.

THEMAL FLUID HEATER CASING IS WASTED, RENEW TO ORIGINAL SPECS.

PROVE PROPER OPERATION OF DIESEL GENERATOR LOW L/O ALARM/SHUTDOWN._x001C_ _x001C_ _x001C_ _x001C_

REPAIR OR REPLACE THE THERMAL FLUID HEATER. AFTER REPAIRS OR REPLACEMENT IS COMPLETED, PROVIDE THE FOLLOWING TESTS/INSPECTIONS TO THE SATISFACTION OF AN ATTENDING CG MARINE INSPECTOR: (1) HYDROTEST TO 1.5 TIMES MAWP; (2) AUTOMATION TEST IAW 46 CFR 61.30-10/20.

RESET AND PROVE OPERATION OF SAFETY RELIEF VALVE ON AIR RECIEVER 80-14.

PLACE BLANKS IN POWER PANEL PORT SIDE ENGINEROOM TO FILL IN OPEN GAPS BETWEEN BREAKERS.

REPAIR HANDRAIL ON LADDER TO TUG THAT HAS SEPERATED AT THE TOP AND THE BOTTOM.

CONDUCT CARGO PUMP ENGINES EMERGENCY SHUTDOWN.

CONDUCT SAFETY CHECKS ON THERMAL FLUID HEATER.

HYDRO CARGO PIPING. THIS DEFICIENCY WAS TO HAVE BEEN CORRECTED BY 18 FEBRUARY 1986.

TEST CARGO PIPING RELIEF VALVES. THIS DEFICIENCY WAS TO HAVE BEEN CORRECTED BY 18 FEBRUARY 1986.

REPAIR AND DEMONSTRATE PROPER OPERATION OF GENERATOR OVERSPEED.

DEMONSTRATE THE PROPER OPERATION OF THE MARINE SANITATION DEVICE.
