MAUNALEI

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended and shall be so installed and protected as to reduce to a minimum any danger to persons on board, due regard being paid to moving parts, hot surfaces and other hazards. Auxiliary boiler easing gear found seized. 74SOLAS(20) II-1/26

Any other machinery space shall be adequately ventilated appropriate for the purpose of that machinery space. Bow thruster/emergency fire pump space ventilation duct found holed at the main deck level. 74SOLAS(20) II-1/35

Where any alterations are made to a ship so as to materially affect the stability information supplied to the master, amended stability information shall be provided. Vessels Cargo Max program found modified by the operator after recent shipyard work without approval of the class or flag. 74SOLAS(20) II-1/5.4

The following fire protection systems shall be kept in good order so as to ensure their required performance if a fire occurs: means of escape systems and appliances. Stairwell door leading to lower laundry room seized in one direction. 74 SOLAS(14)II-2/14.2.3

Where “B” class divisions are penetrated for the passage of electric cables, pipes, trunks, ducts, etc..arrangements shall be made to ensure that the fire resistance is not impaired, subject to the provisions of paragraph 7.3.2. Cable transit above door linen store through lower laundry room missing portion of fire protection for cable transit. 74 SOLAS(14) II-2/9.3.2

Electrical installations shall be such that: the safety of passengers, crew and ship from electrical hazards will be ensured. Poopdeck electrical switchgear room found with dead end wires in overhead run and multiple decks in the main stairwell had wire terminations above the doors that were terminated with electrical tape. 74 SOLAS(04) II-1/40.1.3

Waste receptacles shall be constructed of non-combustible materials with no openings in the sides or bottom. Plastic trash cans found throughout galley and lower deck laundry space. 74 SOLAS(14) II-2/4.4.2

Flag State Dispensation is granted to the M/V MAUNALEI to operate in the Singapore region to conduct sea trials operational testing with five (05) additional persons, provided the following conditions are met: 1. Must remain within 20NM of the Singapore near coastal region. 2. Maximum of (27) total persons onboard. 3. An approved and suitable life jacket and immersion suit will be given to each person onboard. 4. All life saving appliances must be in good working order. 5. Living quarters and bathrooms are to be arranged and available to each person onboard. This is set to expire at the conclusion of sea trials or December 2nd, whichever is first. Vessel must notify our office at the conclusion of sea trials.

Fire-fighting systems and appliances shall be kept in good working order and readily available for immediate use. Vessels current trim renders the emergency fire pump inoperable and not ready for immediate use. 74SOLAS(20)II-2/14.2.1.2

Before the ship leaves port and at all times during the voyage, all life-saving appliances shall be in working order and ready for immediate use. Ships rescue boat found without fuel. 74SOLAS(20)III/20.2

Each liferaft must be arranged to permit it to drop into the water from the deck on which it is stowed, taking into account the height of the stowage location at maximum freeboard. Vessels forward liferafts found in a position requiring significant lifting or carrying for launching. 74SOLAS(20)III/13 & US Supplement 3.1.3.3

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Fractures found in the king posts at frames175P, 193P, 157S, 138S. 74SOLAS(20) I/11(a)

Where air pipes to ballast and other tanks extend above the freeboard or superstructure decks, the exposed parts of the pipes shall be of substantial construction. Vessels MGO tank loop seal found deteriorated at the main deck. ICLL66 A1/Reg.20

All access openings in bulkheads at ends of enclosed superstructures shall be fitted with doors of steel or other equivalent material, permanently and strongly attached to the bulkhead, and framed, stiffened and fitted so that the whole structure is of equivalent strength to the unpierced bulkhead and weathertight when closed. Main deck head door sill found wasted along the knife edge. ICLL66 A1/Reg.12(1)

Before the ship leaves port and at all times during the voyage, all life-saving appliances shall be in working order and ready for immediate use. Forward storage container for lifejackets and immersion suits found mssing equipment. 74SOLAS(20)III/20.2

74 SOLAS (04) II-1/26.3.10 Means shall be provided whereby normal operation of propulsion machinery can be sustained even though one of the auxiliaries becomes inoperative. Special consideration shall be given to the malfunctioning of the hydraulic, pneumatic, or electrical means for control in main propulsion machinery including controllable pitch propellers. Vessel reported an issue with the CPP seal system, which is causing a discharge of CPP oil (Kluberio RM 2-100) into the water at a rate of approximately 2 liters every 24 hours.

EPIRB hydrostatic release unit expiration date must be marked on unit. Provide evidence that unit is within expiration date and mark HRU as such.

The general emergency alarm system shall be supplemented by either a public address system complying with the requirements of paragraph 7.2.2 of the Code or other suitable means of communication. Vessel self reported inoperable public address system. Vessel shall follow risk mitigation plan until rectified.

IN LIEU OF THE REQUIREMENTSOF PARAGRAPH 1.1, CARGO SHIPS MAY CARRY: ONE OR MORE INFLATABLE OR RIGID LIFERAFTS COMPLYING WITH THE REQUIREMENTS OF SECTION 4.2 OR 4.3 OF THE CODE, ON EACH SIDE OF THE SHIP, OF SUCH AGGREGATE CAPACITY AS WILL ACCOMMODATE THE TOTAL NUMBER OF PERSONS ON BOARD. THE LIFERAFTS ON AT LEAST ONE SIDE OF THE SHIP SHALL BE SERVED BY LAUNCHING APPLIANCES. THE 2- 16 PERSON LIFERAFTS THAT ARE REQUIRED TO BE SERVICED BY THE DAVIT ON THE PORT SIDE ARE NOT DAVIT LAUNCHED LIFERAFTS. VESSEL IS AUTHORIZED TO SAIL WITH THE LIFERAFTS ONBOARD FOR 30 DAYS. 74SOLAS(20)III/31.1.2.2 50ac

Before the vessel leaves port and at all times during the voyage, each lifesaving appliance must be in working order and ready for immediate use. The vessel's lifeboat was damaged during launching and is not seaworthy. 46 CFR 91.25-15 46 CFR 199.190

All lifesaving appliances and arrangements shall comply with the applicable requirements of the code. The liferaft painter system shall provide a connection between the ship and the liferaft and shall be so arranged as to ensure that the liferaft when released and, in the case of an inflatable liferaft, inflated not dragged under by the sinking ship. The connection point between the liferaft and the ship was missing the pin on the port forward liferaft. SOLAS (20) III/34 LSA Code 4.1.6.1

All lifesaving appliances and arrangements shall comply with the applicable requirements of the code. Self-igniting lights shall be provided with a source of energy or a period of at least 2 hours. The port midships light was found to be inoperable. SOLAS (20)III/34 LSA Code 2.1.2.3

Submit repair proposal for permanent repairs to Control Pitch Propeller lube oil leak.

Record of emission sensitive components (ESC) replacement were not being maintained in the engine technical file. DNV provided guidance to use the vessel’s PMP/NSE. No part number recorded to validate the correct part was installed. Correct record to include required information. Correct procedures to include required information for future entries. MARPOL Annex VI

Aeration pump removed from the CG approved Type II MSD and IMO approved sewage treatment system. No conditions of class noted. DNV issued SOVC requires IMO approved treatment system.

Fire protection insulation was removed in way of a cable penetration between the switchgear room and the space above and in the emergency egress route of the lower engine room. Replace structural fire protection IAW Fire Control Plan. SOLAS II-2/2.3.3

Scaling was noted in the overhead of the e-generator room. The overhead deck was examined and found wasted on the adjacent surface under the output of a deck drain. Boundary appears compromised. Repair as needed. SOLAS II-2/9

Paint locker CO2 system flex loops excessively loose where attached to the manifold. Have system properly serviced.

Each lifeboat shall be provided with an appliance which is capable of launching and recovering the lifeboat. Hydraulic hose on the recovery davit for the free-fall lifeboat was burst, needing replacement to operate as designed.

Seals on forward head tank ruptured, spilling oil at a rate of 4 liters per minute into the bilge. Vessel required to fix seals and ensure safe operation of head tank prior to next departure.

The fire integrity of the divisions shall be maintained at openings and penetrations. MTC in emergency generator room for newly installed shore tie cables missing insulation for appropriate fire boundary. 74SOLAS(04) II-2/9.1.3

Means of control shall be provided for stopping oil transfer pumps and oil seperators (purifiers). Vessel replaced #1 MGO purified in drydock and emergency shutdown outside the space in inoperable. Vessel restricted from using purifier until emergency shutdown is operational. 74SOLAS(04) II-2/5.2.2.3

Electrical Installations shall be such that the safety of the ccrew and ship from electrical hazards will be ensured. Witnessed daisy chain of electrical cords for CCTV system in switchboard room. 74SOLAS(14)II-1/40.1.3

Oil fuel pipes which if damaged would allow oil to escape from a storage, settling or daily service tank having a capacity of 500 L and above situated above the double bottom shall be fitted with a cock or valve directly on the tank capable of being closed from a safe position outside the space. Vessel's pneumatic control station for quick closing valves had a check valve in the air supply to accumulator line that was inoperable. 74SOLAS(14)II-2/4.2.2.3.4

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. The starboard fuel tank (tank 5.05) has multiple sheared studs that allows marine diesel oil to "weep" out.

Before the ship leaves port and at all times during the voyage, all lifesaving appliances shall be in working order and ready for immediate use. Crew could not adequately operate and launch rescue boat, and when attempting to bring rescue boat back in anti-two block switch engaged prematurely forcing crew to manually lift boat into cradle. Prove proper operation and timely deployment of rescue boat. 74SOLAS(14) III/20.2

For a period of three hours emergency lighting at every muster and embarkation station and over the sides must be provided. Emergency lighting at rescue boat embarkation and stbd bow life raft station not functional. Effect proper repairs and prove proper operation. 74SOLAS(04) II-1/43.2.1

Structural fire protection and protection of openings and penetrations in these divisions shall be kept in good order to ensure required performance if fire occurred. Multiple Cable Transit's in electrical switch gear rooms 613 and 113 as well as CO2 room are non-compliant due to unauthorized drilling and additional cable installations in existing compression blocks. Effect adequate repairs IAW MCT type approval. 74SOLAS(04) II-2/14.2.1.1.1

Ship must have fixed containment under or around each fuel oil or lube oil tank vent overflow / fill pipe. Secondary containment around stbd side aft fuel tank vents missing mechanical closures. Provide satisfactory closure for containment. 33CFR 155.320(a)

The company should clearly define and document the masters responsibility with regard to implementing safety and environmental protection policy of the company. Vessel personnel failed to utilize required confined space entry checklist as per SMS. 74SOLAS(14) IX ISM Code 5.1.1

The number of openings in watertight subdivisions is to be kept to a minimum compatible with the design and proper working of the ship. Where penetrations of watertight bulkheads and internal decks are necessary for access, piping, ventilation, electrical cables, etc., arrangements are to be made to maintain the watertight integrity. The Administration may permit relaxation in the watertightness of openings above the freeboard deck, provided that it is demonstrated that any progressive flooding can be easily controlled and that the safety of the ship is not impaired. All multiple cable transits (MCT) inspected were not installed IAW manufacture type approval, in both port and starboard side enclosed tunnels. All MCTs in watertight bulkheads throughout both port and starboard side enclosed tunnels are to be repaired and installation verified IAW manufacture type approval. Installation must include consideration of location of MCT as to the type approval water pressure rating. CG-835 to be completed in 60 days (29APR2019)

Prove proper repairs to cracks identified in #4 P/S (tanks 1.12 + 1.13).

Prove proper repairs to cracks identified in #3 P/S (tanks 1.08 + 1.09).

Conduct internal structural exam of #5 double bottom (tanks 1.14 + 1.15).

Conduct internal structural exam of F/W tanks (2.02 + 2.01).

Make fuel tanks available for internal structural exam (5.04 + 5.05).

Provide as built structural analysis.

Provide failure analysis report addressing structural failures in vicinity of amidships with causative factors to OCMI.

Conduct visual inspection of all known areas of structural failures for additional damage at each port of cargo operations. Provide reports after each inspection to OCMI.

Provide OCMI with report of completed Internal Structural Exam conducted by class (DNV). To be completed in concurrence with hull survey (UWILD) 28APR19.

Before the ship leaves port and at all times during the voyage all lifsaving appliances shall be in working order and ready for immediate use. Rescue boat fuel level was found to be at 1/3. Fuel level shall be maintained at the 1/2 -3/4 as per Chief Mate.

Before the ship leaves port and at all times during the voyage all lifsaving appliances shall be in working order and ready for immediate use. As per rescue boat operation manual a lanyard for the kill switch shall be used for the outboard. Vessel does not have a lanyard onboard and has never had one in operation.

Vessel did not have documentation of current enrollment in drug and alcohol program.

Light for smoke life ring of STBD brige was INOP.

Amend and submit periodic safety test procedures to the Marine Safety Center and provide approved periodic safety test procedures for verification to the satisfaction of the attending Marine Inspector.

Complete COI insp prior to next departure from Sector LA/LB to include automation testing, verification of OWS and deadman alarm, to the satisfaction of the attending USCG Marine Inspector

Provide permanent repairs in way of the temporary repairs made to the port arm on the free fall launching appliance.

Provide repair plan for free-fall launching appliance to the satisfaction of the attending CG Marine Inspector.

Make repairs to free-fall launching appliance to the satisfaction of the attending CG Marine Inspector.

Found all floatlight had the wrong batteries in them which caused the lights to submerge in the water.

Submit plans for new CHLOROPAC sea water treatment system to Germanishcer Lloyd for approval. System must remain disconnected from power source until approved.

Repair/replace main control panel processor for local fire fighting system.

Provide proof that the vessel's automation test procedures are being done per schedule. Vessel currently has no way to show what has been completed or what is due. 46 CFR 61.40.

Provide means of embarkation for foward liferafts IAW 46 CFR 199.110 (f).

Submit updates to fire control plan to include correct number of lifejackets.

Submit written repair proposal, through GL for concurrence, to Coast Guard for approval for repair needed on stbd #22 and #26 (if necessary) webframes. Proposal must include NDT of welds on both #22 & #26 webframes, means to repair existing (known) cracks, cracks found during NDT, and long term repair to buckled portion of #22 webframe.

Repair missing weld in the aft peak ballast tank # 1.18 adjacent to the fuel oil over flow tank # 4.12, test repair upon completion.

Prove proper operation of remote shutoff for ventilation dampers in machinery space. 46CFR111.103

Provide engine automation test procedures to the Coast Guard for approval. 46CFR61.40

Provide proof of air receivers and fire pump relief vlv testing. 46CFR61.10

Prove proper operation of time delay system

Remove hold back in fire doors in stairwells

Repair door closures, fire doors in stairwells to not close and latch

Prior to departure complete a satisfactory fire & boat drill.

Prior to departure provide the Safety Management Certificate

Prove proper operation of the vessel installed OWS system.
