ALAKAI

The mark of the Authority by whom the load lines are assigned may be indicated alongside the load line ring. Load Line marks of assignment Authority do not match what is indicated on the International Load Line Certificate. ILLC 7

The craft and equipment shall be maintained to the satisfaction of the Administration. Vessel had work vests on board that were not annually serviced. HSCC 2000 19.2

An owner or operator of a ship to which this subpart applies must review the SOPEP annually and submit a letter to Commandant (CG-MER) certifying that the review has been completed. Vessel has not completed their annual review of the SOPEP. 33 CFR 151.28

Test procedure documents must be in a step-by-step or checkoff list format. Each test instruction must specify equipment status, apparatus necessary to perform the tests, safety precautions, safety control and alarm setpoints, the procedure to be followed, and the expected test result. Generator low l/o set point per procedure is 29 psi. Cat service report stated it was set at 23 psi which is not per approved test procedure. 46CFR61.40

Tests must verify that automated vital systems are designed, constructed, and operate in accordance with all applicable requirements of part 62 of this subchapter. Test techniques must not simulate monitored system conditions by mis-adjustment, artificial signals, improper wiring, tampering, or revision of the system unless the test would damage equipment or endanger personnel. In the latter case, the use of a synthesized signal or condition applied to the sensor is acceptable if test equipment is maintained in good working order and is periodically calibrated to the satisfaction of the Officer in Charge, Marine Inspection. Other test techniques must be approved by the Commanding Officer, Marine Safety Center. Test for requiring power reduction as failsafe for MDE not being conducted per approved periodic safety test procedure. Tests are being simulated on SSDG and not per approved periodic safety test procedure. Complete test per procedure or resubmit for approval how OEM's are conducting tests.

Vessel is restricted to carrying crew only and may not carry passengers until all of the primary lifesaving equipment listed on the "RECORD OF EQUIPMENT FOR HIGH-SPEED CRAFT SAFETY CERTIFICATE" is in working order and ready for immediate use. ALAKAI is permitted to operate with crew only while carrying a single MES (stbd-aft), and a spare 36-person liferaft.

Crack in pre lube pump piping on STBD ME. Replace with new pipe section.

The vessel is currently broadcasting (1) Improper Name. The HSV before the name and Space must be removed so that the vessel name is only”ALAKAI”.

Contact Sector Northern New England prior to departing Yarmouth, N.S. and after completing temporary repairs.

Complete permanent repairs to port hull damage in void #4. Repairs shall be acceptable to USCG and Class Society. Any failure in the existing temporary repairs shall be immediately communicated to the USCG and Class Society. If the vessel is U/W it may complete the voyage. If the vessel is moored it shall remain moored until the failure is assessed by USCG and Class Society.

Grind out & weld lower forward corner on the aft side of frame 14. Small leak to be repaired.

Show proof of current ISM Docs.

Show proper operation of remote operation to bus tie relay.

Provide permanent repairs to bilge piping Identified BY USCG and DNV-GL

Renew liferings on port and starboard bridge wings with properly weighted rings that are suitable for quick release operation.

Reduce the total persons allowed on board to 545 total persons to meet 110% liferaft requirement with six at 100 man rafts.

Provide EIAPP for main diesel and generator prime movers.

Complete the remaining requirements of USCG Marine Safety Center letter 16710/P013651 SER# E1-0903143 Dated November 20, 2009 concerning the machinery space water mist system water supply arrangements.

Provide automation test procedures for the machinery space water mist fire suppression system.

The automation test procedures for the ships service diesel generators do not include specific alarm set points per 46 CFR 61.40-10(a). submit to [name withheld] updated test procedures that include specific alarm set points.

Demonstrate proper operation of the ventilation supply dampers in the starboard main engine space.

Replace the pressure gage for the starboard main engine room air receiver and prove proper operation.

Demonstrate proper operation of the oil level float sensors for the #2 and #4 main engines. Establish and maintain an alternate monitoring schedule for the sensors until operation is proven.

Perform automation tests on #1 main engine.

Machinery space water mist system does not meet the Marine Safety Center (MSC) requirement for a water supply arrangement as per MSC letters E1-0703317 dated, 29 Oct 2007, E1-0900483 dated, 26 Feb 2009 and E0-0900621 dated, 04 Mar 2009. Address and make modifications as required by the aforementioned MSC letters.

Remove unapproved PVC piping in voids 15 and 16 for the black and grey water discharge, sludge oil, and freshwater fill as per MSC Letter E1-0801649 Dated Jun 09, 2008 and install approved piping.

Install non-return valve in fire main system piping in way of generator and tunnel bulkhead as per sister vessel HUAKAI (ON: 1215902) approved drawing 615-652-000 Rev B, Detail 1 for both port and starboard hulls.

The machinery space water mist system aboard the vessel does not meet the MSC requirement for a water supply arrangement as per MSC letters E1-0703317 dated 29Oct07, E1-0900483 dated 26Feb09 and E0-0900621 dated 4Mar09. Submit plans to the MSC addressing requirement to install a 2655 gallon fresh water supply NLT 7Apr09. Upon approval by MSC, install the fresh water supply IAW plans by 07Jun09.

A 5 minute supply of water from the onboard fresh water tank shall be reserved and available exclusively for the mist system.

Make mist system transfer to sea water fully automatic with no delay and prove all above functions to the satisfaction of the OCMI.

Renew buckled gusset in void #4, frame 22, 2nd stringer below catwalk level.

Repair cracked weld in void #4, frame 22, 2nd stringer above catwalk level.

Permanently mark loadline on both sides of vessel.

Gauge areas marked in #11 fuel tank starboard side aft.

Make proper repairs for gusset located aft lower inboard side of cofferdam aft of #5 fuel tank void.

Repair crack in void 3, frame 18 at platform level outboard where frame meets first major side longitudinal (platform level).

Remove t-valve in OWS in void 7 after the 3-way valve.

Provide repair proposal for CG approval for 3 buckled frames in mid-forepeak void between frames 6 and 10. Also, provide class society-verified load analysis for damaged area as part of repair proposal.

Repair cracked weld in forepeak port side at #1 ring frame, void #2, frame #4

Repair cracked weld in void #4 frame 20 at keel inboard aft where the gusset meets the frame.

Repair cracked weld in void #4 frame 24 inboard second level below the catwalk.

Repair cracked gusset in void #19 at bulkhead 47, 11th gusset inboard from starboard side shell.

Repair fractured welds 3rd stringer starboard of centerline at void #19 forward bulkhead and 3rd stringer inboard of port side bulkhead.

Provide repair proposal for fracture in #3 main engine gear box inboard aft mount.

Provide repair proposal for fracture found on #1 engine forward shaft bearing mount inboard.

Repair bad weld at frame 80 starboard side inboard approximately 5 feet up from the deck.

Provide repair proposal for plate fracture in overhead on inboard side forward of frame 15 starboard side (void 3).

Repair cracked toe weld in frame 37 port side inboard at void 8, forward of potable water accumulators port side.

Repair leak in piping at mist system coupling transfer pump in void 8.

Conduct NDT for re-welded repair to fracture on starboard rudder.

Make permanent repairs to void 15 hole in deck drain piping in aft overhead.

Repair/replace faulty breaker or #4 Generator

Repair port fwd (#2) MES automatic deployment system

Perform periodic test procedures for main engines and generators as per approved periodic safety test procedures.

Provide class approved plans prior to commencing repairs.

Make proper repairs to port wing stabilizer and prove proper operation prior to carrying passengers.

NDT test suspected fractures in hull plating located in port sewage space. Provide repair plan to USCG prior to commencing work.

Submit repair plan for 5 inch hole located in #5 void starboard side.

Weld fracture in way of the platform attachment to the deck structure at the radius corner in NO. 3 void.

Pipe tunnel Frame 14 - repair fractured weld in way of the fr. plating attachment to the main deck.

Pipe tunnel - Frame 15: repair fractured weld in way of the fr. plating attachment to the main deck.

Pipe tunnel- port frame 14-15, make proper repairs to defective weld in way of the long bhd attachment to the main deck.

Pipe tunnel- port side at frame 15-16: make repair to defective weld in way of the long bhd attachment to the main deck.

Frame 19 at 13-14th long port off centerline - Make proper repair for fractured weld in way of the fr plating attachment to the main deck.

Pipe tunnel - FM25 - 7th long stbd off centerline- make proper repair to fracture on the main deck plating. 3rd long port off centerline - make proper repair to weld defect in way of the fr. plating attachment to the main deck. 2nd long port off centerline - repair fractured weld in way of the gusset bracket attachment to the main deck.

Pipe tunnel - Fr. 32 - make proper repair to fracture on the main deck plating.

Pipe tunnel - Fr. 33 - make proper repairs to stbd side weld defect in way of the fr. plating attachment to the long bhd and main deck. 14 long stbd off centerline make proper repair to weld fracture in way of the gusset bracket attachment to the main deck.

Pipe tunnel - Fr. 35 stbd - make proper repair to weld defect on the main deck plating in way of the stanchion support.

Pipe tunnel - Fr. 37 - port: Repair weld defect in way of the long bhd attachment to the main deck.

Pipe tunnel- Fr.38 - stbd: Make repair for weld defect in way of the fr. plating attachment to the long bhd. 2nd stiffener from deck.

Pipe tunnel - Fr. 40- port: Make repair to weld defect in way of the long bhd attachment to the main deck in way of reinforcement plating.

Pipe tunnel - Fr. 41 - 14th long stbd off centerline: Make repair to weld defect in way of the gusset bracket attachment to the main deck.

Transom - make repair to main deck rail post socket. 3rd from stbd.

Make proper repairs to inlet jet housing. (4) jets to be removed, port inner, port outer and stbd inner for further inspection. Weld repairs, belzona application, anti - fouling paint application to be approved by class.

Make proper repairs to (6) sea chests. Hydrostastically test and provide test reports of SAT test.

Submit repair plan for damaged hull plating due to improper placement of keel blocks. Plan must be approved by class prior to commencement of work, include NDT method.

Repair buckled frame (15) between side longs, #2-3 on both sides of keel. Bottom plate suspect in way of frame 15. Keel plate buckled in way.

Make proper repairs for Port No. 6 void (Frs. 23-32). Crop and insert bottom plate after relocation blocks for closer inspection and determining boundaries. Crop and insert keel web between FRs.31-32. Crop and renew tripping brackets for bottom long #1 either side of keel at fr. 32 Crop and insert bulkhead fr. 32 along bottom as needed to eliminate buckling.

Port No 8 Delivery fuel tank (frs. 32-34) Crop and renew tripping brackets for bottom long #2 either side of keel at Fr. 42.

Port No. 10 gen set rm. (Frs. 42-50) Crop and renew tripping brackets at outboard bottom longs. #1 & 3 at Fr. 42. Crop and renew tripping bracket for inboard bottom long #3. Crop and insert bulkhead Fr. 50 in way of outboard longs #2-5. Crop and renew tripping brackets in way of bottom long #2 either side of keel at Fr 50.

Port No. 2 fuel tank (Frs. 50-60) Crop and renew inboard bottom long #1 between Frs.59-60. Crop and renew tripping brackets for bottom long #1 on both inboard and outboard sides.

Stbd No. 3 Void (Frs. 13-23) Crop and insert bottom plate at Frs. 22-23. Crop and insert keel web between Frs. 22-23.

Stbd. No. 5 Void (Frs. 23-32) Crop and insert bottom plate at Frs. 27-28. Crop and insert keel web between Frs. 27-28 Crop and renw bottom long #1 either side of of keel Frs. 27-28. Crop and insert bottom plate at Frs. 31-32. Crop and insert keel bet. Frs. 31-32. Crop and and insert bhd Fr. 32 bet. keel and inboard long#5. and crop and renew bottom long #1 tripping brackets either side keel

Stbd NO. 7 Delivery fuel tank (Frs. 32-42) Crop and insert bottom plate at Frs. 41-42. Crop and insert keel between frs. 41-42. Crop and renew keel tripping bracket and bottom long #1 tripping bracket, either side of keel at Fr. 42.

Stbd NO. 9 Gen Set Rm. (Frs. 42-50) Crop and renew vertical stiffener in way of inboard bottom long#3 at bottom of Fr. 42. Crop and insert keel bet. Frs. 42-42. Crop and renew outboard bottom long #1 and adjacent vertical blkhd stiffener and gusset.

Forward smart pack lube oil cooler has leak. Prove proper operation.

Reinstall insulation that was removed in order to complete welding repairs.

Provide Officer's certificates, licenses, type rating certificates, and crew documents as required by HSC Code 18.3, STCW 95 I & VI, and ILO 147 Art II.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

CG Marine Inspector to verify that safe manning for vessel is IAW HSC Code Chapter 18, and 46 CFR Subchapter B.

Provide Certificate of Financial Responsibility per 33 CFR Subchapter M.

Provide on board vessel stability information as required by HSC Code Chapter 2.14.

Provide on board the vessel stability logging information required by HSC Code 2.8

Demonstrate that radio records are maintained, ship to shore distress alerts by two separate and independent means, ability to receive shore to ship distress, ability to transmit and receive ship to ship distress, SAR Communications, On-scene communications, Signals for locating Maritime Safety Information as required by HSC Code 14 and 33 CFR 26.

Provide muster lists and emergency instructions as required by HSC Code 18.2.3, HSC Code 8.4

Provide fuel oil transfer procedures that meet the requirements of 33 CFR 155.750.

Demonstrate proper operation of propulsion systems including required independent means of propulsion required for Category B Craft by HSC Code 9.7. The most likely casualty conditions must be simulated to the satisfaction of the attending USCG Marine Inspector for delivery crew training and to check equipment response; e.g., opening of main generator circuit breaker, loss of ship service generat

Post USCG Approved fire control plan.

Post USCG Approved lifesaving equipment plan.

Provide USCG Certificate of Documentation

Demonstrate proper operation of sound reception system to enable officer in charge of navigational watch to hear sound signals and determine their direction per HSC Code 13.14.

Provide approved Shipboard Oil Pollution Emergency Plan in accordance with 33 CFR 151.26.

Post approved damage control plans at the operating station in accordance with HSC Code 2.7.6.

Provide adequate towing arrangements to enable the craft to be towed in the worst intended conditions. If towage is to be from more than one point, provide a suitable bridle to meet the requirements of HSC Code 6.3. USCG Marine Inspector to verify adequate towing bridle arrangements.

Provide waste management plan to include all of the information required by 33 CFR 151.57

Provide means to protect personnel from excessive heating of forward bulkheads in jet room. Address potential for structural problems with this bulkhead due to excessive heat. Temperature of bulkhead during sea trials measured up to 190 degrees Celsius during full power endurance trial.

Provide designation of persons in charge of oil transfers per 33 CFR 155.700-715

Provide signed/completed Loadline Certificate and GL equivalent of Form LL-11-D.

Provide current NOAA registration.

Demonstrate that a qualified person will be assigned only to radiocommunication duties during distress incidents per HSC Code 14.16.1.2.

Demonstrate that the crew is able to perform necessary safety and pollution prevention duties to include personal survival techniques, firefighting emergencies, and elementary first aid as required by STCW 95 VI/1

Provide weathertight enclosure outside the deck house for posting the fire control plan as required by HSC Code 7.9.1.2

Demonstrate compliance with MARPOL Annex V and all of the requirements for shipboard control of garbage as required by 33 CFR 151.63

Complete proper fire drill in accordance with HSC Code 18.5, MSM Vol. II/22.C.7 and NVIC 6-91 - to the satisfaction of the attending USCG Marine Inspector.

Complete proper damage control drill in accordance with HSC Code 18.5.10 - to the satisfaction of the attending USCG Marine Inspector.

Provide evidence of Administration approval for sound reception system per HSC Code 13.17.1.

The manual operating positions for automatic fire dampers in ventilation ducts passing through main vertical zone bulkheads shall be identified by red day light-reflecting letters at least 1/2 inch high ‘‘VENTILATION FIRE DAMPER.’’ In addition, the open and closed positions shall be similarly marked.

Each lifeboat and rescue boat must be plainly marked as follows: (1) Each side of each lifeboat and rescue boat bow must be marked in block capital letters and numbers with— (i) The name of the vessel; and (ii) The name of the port required to be marked on the stern of the vessel to. (2) The number of persons for which the boat is equipped must be clearly marked, preferably on the bow, in perm

Submit periodic safety test procedures for review & approval to USCG [name withheld] prior to 24 August 2007. Demonstrate proper operation of all engine safety devices to protect against overspeed, loss of lube oil pressure, loss of cooling medium, high temperature, malfunction of moving parts, and overload per HSC Code 9.2.2 and to the discretion of [name withheld].

Provide evidence of Administration approval for daylight signaling lamp per HSC Code 13.17.1, but no later than 24 July 2007.

Provide evidence of Administration approval for night vision equipment per HSC Code 13.17.1, but no later that 24 July 2007.

Demonstrate adequate cruise performance & testing in all sea conditions required by HSC Code and Annex 9 Section 3.

In addition to the emergency lighting required by 12.7.3.1, 12.7.4.1, and 12.7.5.1, on every craft with RORO spaces, all passenger public spaces and alleyways shall be provided with supplementary electric lighting that can operate for at least 3 hours when all other sources of electrical power have failed and under any condition of heel. Prove proper operation of lighting required by HSC Code 12.

Provide Coast Guard approved dead-ship start procedures to insure a safe & orderly manual restoration of the ship's service electrical power in the event of a failure of a blackout start system as per MSC Letter Serial No. E2-0603840 dated December 29, 2006. Satisfy any outstanding comments from the plan review process.

Provide USCG Approved Vessel/Coast Guard SAR Plan in accordance with SOLAS 74/78 V/15.

Provide documentation & procedures that demonstrate compliance for the information on passengers as per HSC Code 18.2.5.

Provide approved craft maintenance & servicing manual/system as required by HSC Code Chapter 18 addressing items contained in 18.2.4

Demonstrate proper local and remote operation of all fire doors in fire resisting divisions per HSC Code 7.9.3. Doors at tops of engine room stairtowers do not self close, and are very difficult to manually close when all engineroom ventilation systems are running.

Provide approved training manual to include all of the information required by HSC Code 18.2.3 for locations required under HSC Code 8.4.5.

Provide means to reduce ambient noise level on aft passenger weather deck to below 75d(B)A per HSC Code 4.10.1, or provide information proving that existing dBA levels do not exceed allowable time weighted averages when calculated & based on length of actual voyage legs.

Complete proper evacuation drill in accordance with HSC Code 4.8 to the satisfaction of the attending USCG Marine Inspector.

All exterior seating on the aft weather deck shall meet the prescriptive requirements and design standards of HSC Code 4.5 and HSC Code Annex 10.

Provide MSC approved procedures for conducting HSC Code Annex 9 testing if intentions are to conduct this testing during delivery voyage.
