MSC MARINA

The purpose of this regulation is to prevent the ignition of combustible materials or flammable liquids. PSCO observed fuel leaking from M/E cylinders #2,3,4,5,and 6. SOLAS(24) II-2/45.1.1 Code 16ac

The machinery....associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended and shall be so installed and protected as to reduce to a minimum any danger to persons on board, due regard being paid to moving parts. PSCO observed all purifiers missing belt access covers. SOLAS(04) II-1/26.1 Code: 10c

Means shall be provided to control leaks of flammable liquids. PSCO observed excessive F/O leaks from the MGO transfer pump and VLSFO transfer pump and oil soaked lagging

The arrangements for the storage, distribution and utilization of oil in pressure lubrication system shall be such as to ensure the safety of the ship and persons onboard. PSCO observed excessive L/O leaks from the No: 3 and 4 air compressor motors.

In considering the design of such equipment and approvals, the administration shall have regard to the specification recommended by the organization. MEPC.107(49)/1.1.5 requires ship. Staff training should include familiarization in the operation and maintenance of the equipment.

The company should establish procedures, plans and instructions, including checklists as appropriate. PSCO's identified multiple areas of oil accumulation around the engine room. Standing oil was observed on main engine and in the purifier room. Several plastic buckets cut to fit under machinery are in use to collect dripping oil, and several metal deflecting plates are in place to deflect spraying oil. These deflection plates are located on the main engine and in the purifier space. Oil-soaked lagging was also discovered in these areas. After reviewing the vessel's "[name withheld]", Line item 6 refers to addressing excessive oil accumulation and line item 11 refers to keeping the engine room in an excellent condition. Additionally, the injectors and fuel pumps have exceeded their maximum running hours per the vessels SMS: fuel injectors to cylinders 1, 4 and 8; fuel pump to cylinder 1. An external SMS audit is required.

Means shall be provided to control leaks of flammable liquids. PSCO’s identified multiple areas of oil accumulation around the engine room. Standing oil was observed on main engine an in the purifier room. Several plastic buckets cut to fit under machinery are in use to collect dripping oil. Additionally, several metal deflection plates were put in place by the crew to deflect spraying oil into buckets. These deflection plates are located on the main engine and in the purifier space. Oil soaked lagging was also discovered in these areas.

The condition of the ship and its equipment shall be maintained to conform with the provisions of the relevant regulations. PSCO’s observed significant leakage of the jacket water main engine cylinder number 5.

Every steam pipe and every fitting connected there to … shall be so designed, constructed and installed as to withstand the maximum working stress … PSCO’s observed active steam leak from piping in vicinity od diesel engines number 3 and 4.

In considering the design of such equipment and approvals the administration shall have regard to the specifications recommended by the organization. MEPC .107(49) / 4.2.10.1 requires the presence of a seal to avoid willful manipulation of the system. There is no seal present.

Doors required to be self-closing shall not be fitted with hold back hooks. Both fire screen doors to purifier space are identified as self-closing on the FCP. Both were found tied open. Purifier space was found to have excessive leaks and accumulation of flammable liquids.

Oil fuel pipes … shall be fitted with a cock or valve directly on the tank capable of being closed from a safe position outside of the space concerned. Valve from HFO tank to boiler found to have its quick closing valve disconnected. Crew states that the tank is no longer in service.

In considering the design of such equipment and approvals the administration shall have regard to the specifications recommended by the organization. MEPC .107(49) / 4.2.10.1 requires the presence of a seal to avoid willful manipulation of the system. There is no seal present.

EACH EMERGENCY GENERATING SET ARRANGED TO BE AUTOMATICALLY STARTED SHALL BE EQUIPPED WITH STARTING DEVICES APPROVED BY THE ADMINISTRATION WITH A STORED ENERGY CAPABILITY OF AT LEAST THREE CONSECUTIVE STARTS. A SECOND SOURCE OF ENERGY SHALL BE PROVIDED FOR AN ADDITIONAL THREE STARTS WITHIN 30 MIN UNLESS MANUAL STARTING CAN BE DEMONSTRATED TO BE EFFECTIVE. PSCO OBSERVED EMERGENCY GENERATOR WAS UNABLE TO START BY PRIMARY AND SECONDARY MEANS.

The main inlets and outlets of all ventilation systems shall be capable of being closed from outside the spaces being ventilated. PSCO observed the natural ventilation closure on bay 22 starboard side is bent and will not close properly.

Ships shall be maintained in compliance with the mechanical requirements of a classification society which is recognized by the Administration in accordance with the provisions of regulation XI-1/1, or with applicable national standards of the Administration which provide an equivalent level of safety. PSCO observed oil leak originating from #3 generator casing.

2110- EACH OPERATION DESCRIBED IN PARAGRAPH 2 OF THIS REGULATION SHALL BE FULLY RECORDED WITHOUT DELAY IN THE OIL RECORD BOOK PART I. THROUGHPUT VALVE WAS EXCEEDED AUG 02, 2018 AND SEP 29, 2018 ON OWS. MARPOL I/17.4, 40abc.

2110 THE 15 PPM BILGE ALARM SHOULD RECORD DATE, TIME, AND ALARM STATUS, AND OPERATIONS STATUS OF THE 15 PPM BILGE SEPARATOR. OIL CONTENT METER IS NOT RECORDING AS STATED. MARPOL I/14.6, MEPC.107(49)/4.2.9. 40ac

1599- THE CONDITION OF THE SHIP AND ITS EQUIPMENT SHALL BE MAINTAINED TO CONFORM WITH THE PROVISIONS OF THE PRESENT REGULATIONS TO ENSURE THAT THE SHIP IN ALL RESPECTS WILL REMAIN FIT TO PROCEED TO SEA WITHOUT DAMAGE TO THE SHIP OR PERSONS ON BOARD. PSCO OBSERVED RUDDER DRIFTING THREE DEGREES PORT DURING EMERGENCY STEERING TEST ON #2 PUMP. 74SOLAS(14)I/11(a). 40ac

2110 - IOPP SHALL BE DRAWN UP IN THE FORM CORRESPONDING TO MODEL IN APPENDIX II. IOPP FORM A LISTS OWS AS MEPC.107. OWS INSTALLED IS MEPC.60 PER PLAQUE AND MANUFACTURER DOCUMENTATION. MARPOL I/9. 40ac

SOLAS 74 (2014 CONS.) II-2/10.6.2: AN AUTOMATIC SPRINKLER SYSTEM SHALL BE SO INSTALLED AS TO PROTECT SERVICE SPACES. THE WATER MIST SYSTEM FOR THE ENGINE ROOM WAS SET IN MANUAL POSITION. 10c

SOLAS 74 (2014 CONS.) II-2/4.1.1: MEANS SHALL BE PROVIDED TO CONTROL LEAKS OF FLAMMABLE LIQUIDS. BENEATH THE MAIN ENGINE AND EMERGENCY GENERATOR THERE WAS EXCESSIVE OIL AS WELL AS OIL SOAKED LAGGING ON THE MAIN ENGINE. 16c

SOLAS 74 (2014 CONS) IX/3.1; ISM CODE 10.3: THE SAFETY MANAGEMENT SYSTEM SHOULD PROVIDE FOR SPECIFIC MEASURES AIMED AT PROMOTING THE RELIABILITY OF EQUIPMENT. FLAME DETECTORS WERE BEING TESTED WITH OPEN FLAME.

Not less than 12 rocket parachute flares shall be stowed on or near the navigational bridge. Vessel only had 11. The Second Mate found an expired flare two months ago, that was over 12 months out of date. SOLAS 14 Ch. III Reg. 6.3 40(c)
