INNER HARBOR SPIRIT

13101 - Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at constant marine load under such requirements without exceeding its designed limitations. While conducting rounds of the engine compartment, after mooring, the vessel's crew observed the starboard shaft had uncoupled from the flange holding it to the gear. While underway the shaft slipped and the vessel began taking on water. A tow plan for the vessel must be submitted in writing to the USCG at [email withheld]. The shaft must be fixed and Coast Guard Marine Inspectors must attend and witness sea trials prior to carrying passengers. 46 CFR 119.200

Piping the temperature of which exceeds 150 degrees Fahrenheit must be insulated where necessary to prevent injuries. The vessel repowered in 2011, which included installation of new grid coolers and associated piping which was not a replacement in kind (see MSC letter E1-1100883). This makes this installation subject to the requirements in "new" K. The return piping on the keel cooler installation is exceeding 150F during normal operating conditions, and thus requires insulation.

At least one ring buoy must be fitted with a floating waterlight approved in accordance with 161.010. Batteries for floating waterlight for ring buoy were expired and not of the proper type.

At every vessel inspection all observed fire hazards must be corrected. A flexible hose for a lube oil line for the port main engine reduction gear is chaffed and leaking.

Vessels which carry >150 passengers shall meet the structural fire protection requirements of 72.05 as determined by the OCMI. In the forward bar there are two multi-cable transits in the deck (A class fire boundary) that are not properly sealed.

At every vessel inspection all hazardous situations must be corrected and all protective devices must be in satisfactory condition. There is an electrical breaker box near the forward head, starboard side, that is missing multiple securing screws on its protective cover plate.

Dry pipe exhausts are permitted if suitably insulated. The lagging on the exhaust for the port main engine has become partially detached and requires securing to adequately insulate/shield the hot surface.

On a vessel on which the number of passengers permitted on upper decks is limited by stability criteria, as indicated by the vessel’s stability letter, the maximum number of passengers allowed on an upper deck must be indicated by a durable marking of at least 1 inch numbers and letters at the entranceway to that deck. The max passenger count labels for upper deck are incorrect (one reads 310 and another 116, neither of which corresponds to the stability letter).

Each inspection shall include inspection and testing of fire confining appliances (such as fire screen doors). The port forward door is not properly sealing when closed (section of gasket appears to be missing).

At each inspection the owner or managing operator shall be prepared to have ready for inspection the operation of the main propulsion machinery both ahead and astern. The starboard dripless shaft seal is leaking upwards of 1 gpm at certain running conditions.

07110 - At each inspection the fire fighting equipment of all vessels shall be inspected and all deficiencies found shall be corrected. The vessel had 09 portable fire extinguishers on board that had not been inspected since April 2022. Annual inspections must be conducted for all portable fire extinguishers. 46 CFR 176.25-25(a) 701c

Repairs or alterations to hull, machinery, or equipment that effects safety of the vessel must not be made without the approval of the cognizant Officer in Charge Marine Inspection (OCMI) except in emergency. At the commencement of vessel hull and internal structure exam the following worklist items were outlined for repair or replacement as original. Provide shaft Bearing report for assessment Prep and prepare rub rail for paint and repair as original any pitting or holes IAW NVIC 7-68 as a guide. Repair as original deck plate supports, support legs for Grey water tank in galley. Clean bilges in way of: fwd. hold, galley, engine room and steering space for completion of inspection in these areas.Lead ballast needs to be removed in order to properly inspect hull aft of steering gear. Re-Coat Potable water tank and clean out suction line. MSD SPACE:Clean up steel under port side tank, outboard for further inspection. Old pump installation wiring/cables need to be removed or properly ended. There is approximately a 2 inch hole, portside, where steel is wasted. clean up wiring and make fire tight in fwd MSD tank space. 46CFR 176.700(c)

Piping used in a vital system must meet § 56.60 in subchapter F of this chapter. Vessel had a rubber hose patch installed in galley bilge piping system. 46 CFR 119.710

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected. Larg engine battery foound stowed on vessels main deck under PFE. 46 CFR 115.830

Each vessel must have adequate emergency lighting fitted along the line of escape to the main deck from all passenger and crew accommodation spaces located below the main deck. Emergency Lights in male and female heads on main deck were inoperable. 46 CFR 120.432

Tubular gauge glasses, if fitted to diesel fuel tanks, must be of heat resistant materials, adequately protected from mechanical damage, and provided at the tank connections with devices that will automatically close in the event of rupture of the gauge or gauge lines. Sight glass was made of plastic. 46 CFR 119.440(a)(7) Due by end of credit drydock in February 2023

Each ring life buoy on a vessel must be approved IAQ 160.050 in subchapter Q or this chapter. Port bridge ring buoy grab line was wasted and needs replacement. 46 CFR 117.70(b)(1)

Each life jacket must be approved IAW either 160.002, 160.005 or 160.055 in subchapter Q of this chapter. Over half of vessel PFDs onboard had non SOLAS retroflective tape. Prove that retroflective materal meets type I under 46 CFR 164.018-9 or replace with approved material. 46 CFR 117.71(c)

At least one ring life buoy must be fitted with a lifeline. If more than one ring life buoy is carried, at least one must not have a lifeline attached. Deficiency: 1 out of the 3 required ring life buoys on board has dry-rotten grab lines.

Each lighting fixture and lampholder must be fixed. A fixture must not be supported by the screw shell of a lampholder. Deficiency: The light fixture located at the steering compartment broke off the mount and the light switch box was missing its cover.

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of its COI giving consideration to provisions for the seaworthy of the hull, protection against fire, and ventilation of enclosed spaces. Provide written specifications describing the details of any repairs (repair proposal) to address all the damages and corrective actions for the following deficiencies: 1. starboard rudder post 2. port and starboard vents (steering compartment) 3. Temporary clamps (grease trap) 4. Temporary patch on a pipe (galley) *** Repairs or alterations that affect the safety of the vessel must not be made without the approval of the cognizant OCMI. ***

Each vessel must be provided with a bilge pump in accordance with 46 CFR 56.50. All vessels shall be provided with a satisfactory bilge pumpingplant capapble of pumping from and draining any watertight compartment. Multiple bilge stations unable to provide suction from the space. 46 CFR 119.520(a) / 46 CFR 56.50(a)

At each inspection for certification the bilges and other spaces may be examined to see that there is no excessive accumulation of oil debris or other matter that might clog bilge pumping systems. The bilge in the galley had excess water/grease/debris theat could block bilge system and did not allow for proper inspection. 46 CFR 115.830(b)

Vsl is broadcasting: Invalid IMO #.

Stowage location for child size lifejackets on Deck 2 not labeled.

Distribution Panel located in the galley not labeled with associated electrical switch and openings need covered on panel, starboard side near female head.

Exhaust ventilation in galley not connected to emergency shut down.

Electrical wiring to E/R hi water alarm connection not properly connected. Ensure wiring is properly connected to hi water alarm using proper pressure type connectors.

Circuit breaker panel in pilot house not properly secured and missing a switch. Properly secure panel and blank or install missing switch.

Vessel missing fire axe. Provide proper fire axe and properly mark with vessel's name.

Vessel has removed fixed concrete ballast and re-installed fixed lead ballast. As per MSC requirements a deadweight survey is required. Perform survey in presence of CGMI.

Port side shaft slipped from coupling. Submit a damage survey, repair proposal and conduct sea trials.

Update FCP to reflect hose stations and layout of vessels internal compartments

Repair or replace port and starboard fire doors on fwd 2nd deck. Door frames are rusted and do not close on their own power. Doors are adjacent to area of safe refuge for passengers.

Install gasket material on fire door, 2nd deck.

Install end caps on stairs leading from 1st to 2nd deck interior compartment.

Provide permanent electrical connections for air compressor, galley dishwasher and steam drain pumps(02)

Install strainer for Bilge pickup in steering compartment.

Secure galley equipment, stoves, warming equipment.

Secure CO2 bottles in beverage station.

Replace extinguished lights in steering compartment.

Post in view of public, vessels COI and Stability letter.

Vessel steering system leaking hydraulic oil from one of its fittings, repair to the satisfaction of the attending marine inspector.

FCC Certificate expired. Provide current FCC certificate to the satisfaction of the CG Marine Inspector.

Retroflective tape wasted on 40 child lifejackets. Replace as new to the satisfaction of the CG marine inspector.

Bulbs in emergency lighting out. Replace as new prior to carrying passengers.

Bulbs in galley out. Replace as new to the satisfaction of CG Marine Inspector.

Cover missing from fuse box in engine room. Replace as new to the satisfaction of CG Marine Inspector.

Oven in galley excessively dirty. Clean to the satisfaction of CG Marine Inspector.

Exhaust fan in galley heavily greased. Remove & clean to the satisfaction of the CG Marine Inspector.

Cooking range in galley heavily greased. Clean to the satisfaction of CG Marine Inspector.

Exhaust fans in engine room dirty. Remove & clean to the satisfaction of CG marine inspector.

Jabsco pump that served as the 2nd bilge pump for vessel inoperable. Repair/replace and run to the satisfaction of CG marine inspector.

Fire doors in galley not operating correctly. Conduct maintenance and prove proper operation prior to carrying passengers.

Transformer on main deck is partially covered, open to the weather and doesn't appear to have been properly installed. Submit plan to cover/move transformer to a location safe from the weather and install in a condition that's safe for proper operation.

Audible high water alarms not operating correctly. Prove proper operation of high water alrams prior to carrying passengers.

Electric grade matting missing from in front of switchboard. Provide electric grade matting to the satisfactioj of the CG Marine Inspector.

Vessel missed 90 Day window for annual reinspection. Vessel was operated without a valid COI for several months.

Provide detailed plan proposal to OCMI in reference to repairs to hull in the area of the sewage tank.

Excessive wastage found to the hull in the vicinity of the stbd shaft. Provide repair proposal to OCMI detailing procedures for replacement hull plating.

Complete repairs to hull plating on the starboard stern of vessel and conduct NDT in the presence of OCMI.

Provide proposal for replacement of longitudinal frames as discussed with CG Marine Inspector.

Inspect hole in deck in the vicinity of the "Wait Station" and provide a repair proposal.

Provide results of additional UT shots ordered by CG Marine Inspector.

Remove, inspect, and renew, a section of hull plating located at frame 29 to original scantling.

Provide operational high water alarm and show proper installation of equipment.

Provide lagging / insulation material for starboard generator exhaust.

Secure cover panel for transformer in aft steering compartment.

Tighten port and starboard shaft pickings.

Provide mounting brackets for portable fire extinguisher on bridge.

Renew/replace bilge pump. Pump must be capable of pumping 25 gal per minute at a minimum.

Prior To working in a safety-sensitive position background check as per 49 CFR 40.25.

Does not have Hotline Numbers available for employees.

Did not have proof of training for Supervisors. Self admittance that this requirement has not been met.

Remove scaling on sponson and properly coat.

Clean and coat bilges forward of the head in void space.

Permanently afix draft marks in place.

Provide way to keep water out of transformer in aft steering space.

Provide bracket for fire extinguisher on bridge.

Prior to carrying passengers on the upper deck, replace or tighten the bolts on the benches on the upper deck.

Prior to allowing passengers to use the female head below the main deck, repair/replace broken seal between it and the deck.

Prove proper operations of Fire Door into galley. LEGACY COMPONENT DESC: Fire Doors

Renew all inoperable speakers for public announcements on all decks, LEGACY COMPONENT DESC: Safety Orientation & Emergency Announcements

Provide plan for a scheduled replacement of all aging Buoyant Apparatus' with Life Floats over the next year. LEGACY COMPONENT DESC: Replacement Plan

Ensure/prove proper operation of Emergency Lighting. LEGACY COMPONENT DESC: Operation

Renew water light for Buoyant Apparatus. LEGACY COMPONENT DESC: Water Light

Pump & Dry aft steering compartment, check for leakage and perform surface preparation. LEGACY COMPONENT DESC: Bottom Plating

Secure loose CO2 bottles on top deck. LEGACY COMPONENT DESC: Loose Hazards

Replace wood that was removed due to tor on canopy stiffners. LEGACY COMPONENT DESC: Superstructure

Plug holes between ladies head and galley. LEGACY COMPONENT DESC: Privacy

Clean grease from around stove and trap. LEGACY COMPONENT DESC: Trap

Provide current tide tables. LEGACY COMPONENT DESC: Carriage of Charts and Publications

Renew primary general alarm. LEGACY COMPONENT DESC: General Alarm

Provide CPR/1st Aid Qualifications for 50% of the crew. LEGACY COMPONENT DESC: First Aid Certified Personnel

Prove proper operation of all Fire Doors. LEGACY COMPONENT DESC: Fire Doors

Prove proper operation of all high water alarms (Visual & Audible). LEGACY COMPONENT DESC: Alarms

Provide means for Person-In-Charge of emergency operations to have communications with master at all times. LEGACY COMPONENT DESC: Portable Radios

Repack/tighten starboard rudder stuffing box. LEGACY COMPONENT DESC: Rudder Bearing

Provide rudder controls as Bridgewing operating stations. LEGACY COMPONENT DESC: Rudder controls

RENEW/REPAIR PUBLIC ANNOUNCE SYSTEM. LEGACY COMPONENT DESC: PUBLIC ANNOUNCE SYSTEM

RENEW CEILING TILES. LEGACY COMPONENT DESC: Superstructure

RE-FABRICATE FIRE DOORS FROM THE MAIN TO THE SECOND DECK SIMILARLY TO THE FIRE DOORS ON THE BAY LADY. THIS WILL DECREASE TIME IT TAKE TO CLOSE THE DOORS IN AN EMERGENCY. LEGACY COMPONENT DESC: FIRE DOORS

PROVIDE 'POP-LOCK' OR PANIC BAR IN INSIDE OF EXIT DOOR ON 2ND DECK OR PROVIDE MEANS TO ENSURE THAT DOOR IS ALWAYS UNLOCKED WHEN PASSENGERS ARE ON BOARD. LEGACY COMPONENT DESC: Door

REMOVE SLIDE BOLT FROM ENGINE ROOM DOOR. LEGACY COMPONENT DESC: Door

ENSURE SHORE TIE IS OUT OF WATER AT ALL TIMES. SHORTEN CABLE PAST THE TORN SPOT IN CABLE. ENSURE PROPERLY SPLICED. LEGACY COMPONENT DESC: Shore Connection Box

Clean out bilges in the galley. LEGACY COMPONENT DESC: Bliges

Provide M/V Lady Baltimore and crew for required inspection to renew Certificate of Inspection prior to carriage of passengers. Scheduling of inspection must be preceeded by the OCMI receiving the required Application for Inspection. LEGACY COMPONENT DESC: Certificate of Inspection

PROVE PROPER OPERATION OF ALL HIGH WATER ALARMS.

PROVIDE CURRENT DRUG TESTING INFORMATION FOR ALL EMPLOYEES.

SERVICE 2 PORTABLE FIRE EXTINGUISHERS.

PROVIDE PROPERLY RATED WEAK LINKS FOR EACH BUOYANT APPRATUS. LEGACY COMPONENT DESC: WEAK LINK

PROVIDE SIGNS FOR LOCATIONS AND NUMBERS OF LIFE JACKETS.

PROVIDE LIFE JACKET DONNING PLACARDS FOR EACH DECK. LEGACY COMPONENT DESC: DONNING PLACARD

PROVIDE ELECTRICAL MAT FOR ELECTRICAL CONTROL PANEL.

REPAIR AND PROVE PROPER OPERATION OF PORT GENERATOR. LEGACY COMPONENT DESC: Generator

REPLACE GAGES WHICH MELTED ON THE ELECTRICAL CONTROL PANEL.

PROVIDE WARNING SIGNS TO EMERGENCY ESCAPE FROM ENGINE ROOM & GALLEY ON NEXT DECK. LEGACY COMPONENT DESC: Escape Route Signs

PROVIDE SIGNS FOR NOTICE OF MAX PASSENGERS ON UPPER DECKS.

REPLACE ACCESS COVER TP A/C UNIT ON MAIN DECK. LEGACY COMPONENT DESC: ACCESS COVER

REPLACE OUTLET COVER NEXT TO HEATING UNIT ON MAIN DECK.

SPOT PATCH MINOR PAINT DELAMINATION AREAS ON THE BUOYANT APPRATUS. LEGACY COMPONENT DESC: PATCH

REPLACE MISSING BOLTS ON PASSENGER BENCHES ON UPPER DECK.

REPAIR AREAS OF WOOD ROT ON CANOPY STIFFNERS. LEGACY COMPONENT DESC: Superstructure

REPLACE OR REPAIR VENT SCREEN IN GALLEY. LEGACY COMPONENT DESC: SAFETY SCREEN

CLEAN GREASE FROM GALLEY HOOD AND FROM SURROUNDING AREA. LEGACY COMPONENT DESC: GREASE TRAP

PROVIDE CURRENT COPY OF NAVIGATION RULES.

REPAIR RAILING INTO GALLEY.

REPLACE COVER TO ELECTRICAL BOX NEXT TO COFFEE MACHINES.

REPLACE CEILING TILES OVER COFFEE MACHINES. LEGACY COMPONENT DESC: Superstructure

TIGHTEN AND CHECK PACKING AROUND BOTH SHAFTS IN ENGINE ROOM.

RENEW GASKET TO HATCH INTO AFT-MOST COMPARTMENT. LEGACY COMPONENT DESC: Gasket

POST EMERGENCY INSTRUCTIONS ON EACH DECK. LEGACY COMPONENT DESC: EMERGENCY INSTRUCTIONS

ENSURE CLEAR PATH TO EMERGENCY ESCAPE IN ENGINE ROOM & GALLEY. LEGACY COMPONENT DESC: ESCAPE ROUTE

Open 1.5" gate valve at sea chest for inpsction.

Provide report for gauging of side shell, port and starboard side engine room, below natural vents.

Clean galley bilge to allow for inspection.

Post placard with maximum number of persons allowed per deck.

Remove/Repair broken light fixture above stove in galley.

Replace controller covers and removed wire nuts for freshwater and raw water pumps in MSD compartment.

Provide SAE J-1942 Flex hose or hard piping for all fuel return lines.

Remove dead end wire (starboard side, aft main deck exterior)

Provide globe for light on aft main deck.

Replace main engine exhaust insulation for both main engines.

Provide approved piping for firemain system.

Provide and post station bill

Provide fan guard and ceiling panel in 2nd deck male head.

Replace grabline on Buoyant Apparatus

Repair mooring bit (port side, aft main deck)

Provide machinery guard for starboard main engine.

Provide and install bilge high level alarm for engine room bilge.

Mount B-II fire extinguisher bracket (2nd deck stbd aft).

Replace retro-reflective tape on PFD's and Buoyant Apparatus as discussed.

Service and repair B-II CO2 fire extinguisher in engine room.

Remove electrical space heaters from spaces._x001C_ _x001C_ _x001C_ _x001C_

Replace securing strap on no#8 AC unit.

Fire pump will not produce 60 psi as requiored by 46 cfr.

bilge pipe in starboard void is holed and has been soft patched. crop and renew.

Lifering worn and requires replacement.

Seals for both rudder posts are worn and leaking severly. Vessel will require drydocking and replacement of rudder post seals.

Remove deep fat fryer due to lack of fixed fire fighting capability.

Remove portable lighting and fan from galley.

Properly rig lines for buoyant apparatus.

Ensure watertight door over lazarette is watertight. Appears to be leaking.

RENEW AS ORIGINAL SIDE HULL PLATE IN AREA OF FWD PORT DRY EXHAUST OUTLET._x001C_ REPLACE INTERNAL HORIZONTAL STIFFNER JUST ABOVE SAID EXHAUST OUTLET.

INSTALL HAND WHEEL ON PORT SIDE FWD KEEL COOLER VALVE.

Install locking device for rudder angle indicator._x001C_

RESTENCIL/REPLACE RETROFLECTIVE TAPE ON ALL B/A'S

PLACE VESSELS NAME OR COMPANY NAME ON EXTRA CHILD SIZE PFD'S

PLACE PIPING FROM WATER HEATER RELIEF VALVE IN ACCORDANCE WITH MANUFACTUR- ER'S INSTRUCTIONS

SECURE SPARE PROPS/SHAFT PROPERLY ON AFT MAIN DECK

Unknown Component - Unknown Cause/Condition

REMOVE HYDRAULIC OIL FROM STEERING GEAR SPACE

REPLACE OR MAKE PERMANENT REPAIRS TO 8 OF VESSEL'S BUOYANT APPARATUS

PROVIDE ADDITIONAL VENTILATION IN STERN VOID/STEERING GEAR SPACE TO CREATE AN ATMOSPHERE FREE OF MOISTURE AROUND MAIN ELECTRICAL TRANSFORMER, IAW IEEE STD 45, SECTION 44.2.

PROVE PROPER OPERATION OF INDICATOR LIGHTS & 24V DC SWITCHBOARD & MAIN SWITCHBOARD. PROVIDE PROPER HANDLE FOR SWITCH ON 24V PANELBOARD

PROVIDE SEVEN ADULT LIFE JACKETS. VESSEL LIMITED TO 593 TOTAL PERSONS

DEMONSTRATE OPERATION OF LOW OIL PRESSURE TRIP AND HEIGHT WATER TEMP TRIP ON TWO DIESEL GENERATORS

OPEN AIR RECEIVED IN ENGINE ROOM FOR INTERNAL EXAM

REMOVE EXCESS OIL FROM ENGINE ROOM BILGE

DEMONSTRATE THAT NEW CARPETING ON MAIN DECK MEETS ASTM STANDARD

DEMONSTRATE THAT NEW FIRE HOSE MEETS UL STANDARD 19 OR FEDERAL SPEC ZZ-H-451E OR PROVIDE HOSE THAT MEETS THIS STANDARD FOR LIME COMMERCIAL FIRE HOSE (46CFR 181.15)

PROVIDE GLOBES/GUARDS TO TWO LIGHT FIXTURES IN ENGINE ROOM AND SEWAGE ROOM.PROVIDE COVER TO LIGHT FIXTURE ON 0-1 LEVEL AT STERN

PROVIDE PROPER FIXTURE FOR SHORE TIE ON VESSEL. PERMANENT MOUNTING OF SHORE TIE CABLE IS NOT PERMITTED. ACTUAL COMPLIANCE DATE: 13MAY88

PROPERLY MARK TWO EMERGENCY ESCAPES ON MAIN DECK

REMOVE WIRE NUTS FROM REEFER COMPRESSER IN GALLEY

PROPERLY MARK FIRE STATION ON 0-1 DECK AT STERN

PROVIDE CHARTS FOR AREA OF OPERATION THAT ARE LESS THAN THREE YRS OLD. PROVIDE SMALL PASSENGER VSL REGS

PROVIDE ONE ADULT PFD. VESSEL IS RESTRICTED TO 574 PASSENGERS.

PROVIDE GRAB LINES FOR THREE BUOYANT APPARATUS. LINES SHALL BE 1/4" DIA 12' LONG.

PROVIDE THREE OPERATING WATERLIGHTS FOR THREE BUOYANT APPARATUS. VESSEL ISRESTRICTED TO DAYTIME OPERATIONS.

PROPERLY MARK EMERGENCY ESCAPE HATCHES (BOTH SIDES) FROM GALLEY AND MACHINERY SPACE. KEEP ESCAPES CLEAR.

PROPERLY MARK FUEL SHUT-OFF ON MAIN DECK.

REMOVE OR PERMANENTLY INSTALL 220 VOLT SHORE TIE LEADING FROM GALLEY. PERMANENT SHORE TIE SHALL BE CONNECTED TO MAIN DISTRIBUTION PANEL.

PROPERLY MOUNT ONE RING BUOY.

PROVIDE GLOVES AND GUARDS WHERE MISSING FROM STEERING COMPARTMENT AND FORWARD PORT AND STBD VOIDS (TOTAL=4)

PROPERLY WIRE ELECTRICAL RECEPTACLE FOR ICE CREAM MACHINE. REMOVE THHN CABLE AND USE PROPER STANDED CABLE.

PROVIDE PROPER SEA STRAINER FOR BILGE PUMP.

COMPENSATE MAGNETIC COMPASS AND POST DEVIATION CARD IN WHEELHOUSE PRIOR TO CARRYING PASSENGERS FOR HIRE OR ANY PERSONS OTHER THAN CREW.

PLACE VESSEL DOCUMENT ON BOARD; FORWARD COPY OF SAME TO [name withheld].

POST VESSEL STABILITY LETTER, FROM USCG, MMT03, ON BOARD.
