NOA

Where cargo pump shafts pierce gastight bulkheads, stuffing boxes with readily accessible gastight glands shall be provided. Cargo pump shafts #2 and #4 outer gastight glands worn not providing gastight boundry. Renew worn gastight glands for #2 and #4 cargo pump shaft penetrations 46 CFR 32.50-1

Where a cargo pump shafts pierce gastight bulkheads, stuffing boxes with readily accessible gastight glands shall be provided. Gastight glands are worn with light entering the space where the cargo pump shaft pierces the bulkhead. Vessel is restricted from loading or discharging cargo with a flashpoint below 140 degrees fahrenheit in accordance with 46 CFR 111.105-31.

Identified fractures in the port side forward rake compartment 1 at transverse frame 2 and 3, #2 and #3 bottom longitudinal. Port side forward rake compartment 2; transverse frames 1, 2, and 3, #1 bottom longitudinal. Port side forward rake compartment 3; transverse frames 1, and 2, #1 bottom longitudinal. Port side forward rake compartment 4; transverse frames 1, #1 bottom longitudinal. Compartments numbered from keel to port side hull. Bottom longitudinal numbered from keel to port side hull in each compartment. Transverse frames numbered from fwd to aft. Crop and renew to the satisfaction of attending marine inspector.

Identified fractures in the starboard side forward rake compartment 1 at transverse frame 1, 2 and 3, #1 and #2 bottom longitudinal. Port side forward rake compartment 2; transverse frames 1, 2, and 3, #1 and #2 bottom longitudinal. Port side forward rake compartment 3; transverse frames 1, 2, and 3 #1, #2, and #3 bottom longitudinal. Port side forward rake compartment 4; transverse frames 2 and 3, #1 bottom longitudinal. Compartments numbered from keel to port side hull. Bottom longitudinal numbered from keel to port side hull in each compartment. Transverse frames numbered from fwd to aft. Crop and renew to the satisfaction of attending marine inspector.

Identified buckled, tripped frames set in more than 3 inches at internal frames 12 1/2, 13, and 13 1/2 located in #2 void starboard side approx between sideshell frames 4 and 5. Crop and renew to the satisfaction of attending marine inspector.

Vapor collection piping must be electrically bonded to the hull and must be electrically continuous. Vapor collection piping installation on the vessel is not electrically continuous. Install VCS electrical bonding between piping flanges and to hull. Vessel is restricted from conducting VCS operations until resolved.

A fixed pressure-sensing device must be installed as close as practicable to the vessel vapor connection on a tank barge with a vapor collection system. The pressuresensing device must measure the pressure vacuum in the main vapor collection line and have a pressure indicator located where the cargo transfer is controlled. Pressure-indicating devices shall be installed on all independent vapor control lines. Vessel is restricted from conducting VCS operations until resolved.

Cargo pump shafts piercing gastight bulkheads shall be provided with gastight glands. Cargo pump shafts #3 and #4 outer gastight glands worn not providing gastight boundry. Renew worn gastight glands for #3 and #4 cargo pump shaft penetrations.

Prove proper operation of overfill alarm for #2P cargo tank in presence of CG Marine Inspector prior to next cargo onload. 46 CFR 39.2009(a)(2)

Shaft seal on bulkhead between cargo pump engine and cargo pump is not gas-tight; daylight shows clearly through gasket inside machinery space. In accordance with 46 CFR 111.105-31 & IEC 60092-502 4.1.4.1, the seals must pass a fire-hose test to the satisfaction of the attending marine inspector prior to conducting cargo operations.

The #3 diesel engine driven cargo pump emergency shutdown solenoid is inoperable. In accordance with 46 CFR 32.50-35, the #3 cargo pump engine emergency shutdown solenoid must be renewed and tested to the satsifaction of the attending marine inspector prior to using the #3 cargo pump to discharge cargo.

Relief valve on air reciever relieved at 210 psi which is greater than the max allowable working pressure of 200 psi. In accordance with 46 CFR 54.15-10, pressure relief valves shall be set to relieve at a pressure which does not exceed the max allowable working pressure of the pressure vessel.

At dry dock, repair all fractures in the PORT and STBD forward rakes identified by ABS surveyor during the internal structural exam conducted on 14 FEB 2017.

Conduct maintenance on dogs for machinery space watertight doors and gooseneck vent covers to ensure they can operate/close freely.

Provide copy of updated USCG approved test procedures specific to thermal fluid heater installed onboard.

Demonstrate proper operation of thermal fluid heater controls/safeties with USCG approved test procedure specific to the thermal fluid heater make/model on board.

Ensure sections of the VRP identified is 33CFR 155.1030(i)(1) & 33CFR 155.1030(i)(2), and a current copy of the VRP, SOPEP and SMPEP letters are kept on board.

Complete survey for MARPOV Annex VI compliance and issuance of IAPP certificate.

Acquire EIAPP certificates and completed technical files for each diesel engine installed onboard rated above 130kW/174hp that was installed after January 1st, 2000.

Replace burnt out lamps for 480 volt ground-detection.

Vessel reported damage to side shell plating approx 4"X3/4" located stbd side amidships. Provide ABS approved repair proposal for the damaged area. Vessel is restricted from cargo operations.

Provide repair plan for damaged area located portside fwd rake, include NDT procedures for shell plating between frame 2 and 3 above 9th longitudinal. Provide CG-2692 for damages exceeding $25,000.00

Relief Valves on the fuel tank for thermal fluid heater and air receiver not serviced within 5 years.

SRV's on thermal fluid heater not services within 5 yrs.

Prove proper operation of navigational lights IAW 72 COLREGS.

Properly hydrotest all cargo piping and hoses IAW 46 CFR 56.04 and 33 CFR 156.170.

Hydro test cargo piping and hoses IAW 46 CFR 56.04 & 33 CFR 156.170.

Properly install and provide required SOPEP locker contents IAW 33 CFR 155.210 and 33 CFR 155.215.

Properly install lagging on boiler piping IAW 46 CFR 38.05-20.

Prove proper operation of all high level and overfill tank alarms IAW 46 cfr 39.20-9 and 46 CFR 39.30-1(3)(e).

Demonstrate proper operation.

Rinstall anchor windlass (on stern) prior to carring cargo; upon return to Honolulu, HI IAW 46 CFR 32.15-15.

Failed to conducted ISE and Cargo Tank External Exam. Complete same prior to issuance of COI.

Properly mark vapor control line at manifold IAW 46 CFR 39.20-1 (d).

Properly label tank overfill and high level alarms IAW 46 CFR 39.20-7(c)(2) and (d)(3).

Properly demonstrate emergency shutdown (overspeed) of generator IAW 46 CFR 111.12-1(b) and (c).

Prove proper operation of #2 and #4 port tank high level alarms prior to carrying cargo in those tanks.

Renew all missing tow wire clips and properly rig emergency towing line at next drydock.

Renew broken railings and repair inoperable anchor windlass (on stern) at next drydock.

Repair brackets for alarm system on # 2 and # 4 tanks over ullage openings (manholes).

Renew transfer hose for 8" black oil hose - first hose off the pipe due to deteriorated hose. This is to be completed prior to using the cargo hose for transferring black oil.

Prove proper operation of # 4 port tank overfill alarm. This is to be completed prior to using # 4 port tank for cargo. # 4 port tank is not to be loaded past 95%.

Ensure navigation lights background panels are painted matte black. LEGACY COMPONENT DESC: Navigation Lights

Ensure piping diagram is put into the oil transfer procedures prior to cargo transfer.

Ensure draft marks are painted in a color contrasting to the hull. LEGACY COMPONENT DESC: Draft Marks/Indicating System

Repair or renew wire for the deck crane prior to use.

Prove proper operation of the thermal fluid heater and relief valve prior to using the thermal fluid heater.

Prove proper operation of the high level and overfill alarms for the #1 port cargo tank. LEGACY COMPONENT DESC: Overfill Devices

Prove proper operation of the stbd generator emergency remote fuel-oil shutdown valve.

Prove proper operation of overfill (and high) level alarms.

Prove proper operation of the #1 port cargo tank high level and overfill alarms. LEGACY COMPONENT DESC: Liquid Overfill Protection

Prove proper operation of the forward most cargo pump engine emergency shutdown. LEGACY COMPONENT DESC: Emergency Shut-down

Remark the vapor control piping iaw 46 CFR 39.20-1(d) LEGACY COMPONENT DESC: Piping/Hoses

Ensure cargo pump emergency shutdowns are conspicuously marked on both sides LEGACY COMPONENT DESC: Emergency Shut-down

Provide a mechanical plug for the cargo manifold containment where missing portside. LEGACY COMPONENT DESC: Drains/Scuppers (means of closure)

Provide spill discharge removal equipment

Prove proper operation of starboard generator set overspeed trip. LEGACY COMPONENT DESC: Overcurrent Device

Prove proper operation of both generator set circuit breakers upon shutdown of generators. (Breakers should open on shutdown.) LEGACY COMPONENT DESC: Circuit Breaker

Provide a valid International Loadline Certificate. LEGACY COMPONENT DESC: International Load Line Certificate

Provide an approved Stability Letter. LEGACY COMPONENT DESC: Stability Letter

Ensure cargo heating system lines, currently filled with oil, remain blanked until the thermal fluid heater is installed and tested to the satisfaction of an attending Coast Guard marine inspector.

Provide proof of cargo hose hydrostatic pressure testing prior to conducting cargo operations with these hoses. LEGACY COMPONENT DESC: Transfer Hose
