MRT 58

A mechanical means of closing each drain and scupper in the container or enclosed deck area required by this section. Marine Inspectors observed all scuppers were seized and unable to function.

Certificates of inspection may be revoked or suspended by the Coast Guard where such process is authorized by law. This may occur if the vessel does not meet the requirements of law or regulations in this chapter or if there is a failure to maintain the safety requirements requisite to the issuance of a certificate of inspection. During vessel's Internal Structural Exam (ISE), marine inspector found multiple area's of concern relating to the structural integrity of the vessel. Along with correcting deficiencies listed below, provide a report to the Coast Guard from a certified marine surveyor attesting to the completion of an ISE, proper repairs, and condition of this vessel. * Rake - Crop to good metal and renew #1, #4, and #5 cargo tank stiffeners (from starboard) - Crop to good metal and renew #6 and #8 bilge frames * #1 Port wing void - Re-weld #2 Inboard vertical frame tripped from tank at top of frame * #1 Port wing void (cont) - Re-weld cracked welds found at cargo tank/ bilge frame interface at frames #2, 3 and 4 - Crop to straight metal and renew bent bilge frames #3, 4, 5, 7, 9, 10 * #2 Port wing void - Re-weld cracked weld found #2 hull stringer between #4 and 5 outboard vertical frames - Crop and renew to original condition buckled frames #3, 4, and 8 under cargo tank. - Crop to straight metal and renew bent bilge frames #3, 6, 9, 12, 15 * All other voids - Crop to straight metal and renew bent bilge frames #3, 6, 9, 12, 15

All cargo tank hatches must be clearly marked in not less than three inch lettering “Danger - Keep Out,”. #1 Forward Cargo Tank Hatch cover missing danger signage by hatch. Label hatch as required.

Bolts and studs must extend completely through the nuts. Bolts to cargo tank top flange blanks do not completely go through the nuts. Install appropriate sized bolts as required.

The transfer procedures required by § 155.720 must be: Available for inspection by the COTP or OCMI whenever the vessel is in operation. Transfer procedures on vessel are for old owner/operator. Update transfer procedures with new owner requirements.

Copies of the submitted and approved response plan must be available as follows: The vessel owner or operator must maintain a current copy of the entire plan, and ensure that each person identified as a qualified individual and alternate qualified individual in the plan has a current copy of the entire plan. Tank Vessel Response Plan on vessel is for old owner/operator. Provide copy of approved Tank Vessel Response Plan with new owner information.

Boilers, main and auxiliary machinery, and piping systems shall conform to the requirements of subchapter F (Marine Engineering) of this chapter. Materials, items of equipment, or installations in vessels which have been accepted and passed as satisfactory and meeting the applicable requirements in this subchapter then in effect and which are maintained in good and serviceable condition to the satisfaction of the Officer in Charge, Marine Inspection, may be continued in use until replacement is deemed necessary by such officer or as specified in the regulations. Hydraulic hose for engine start system wasted. Replace with new.

1 Dog bolt missing from #1 Strbd wing void hatch cover.

Annual inspection is past due

Failure to have onboard a vailid COFR

Provide proof of annual cargo pump relief valve test.

No Decloration of Inspection records were onboard.

Vessel owner must provide copy of vessel response plan approval letter.

Stbd #1 Void. Crop & renew 5 buckled transverse floor frames attached to K-frames. These frames are located between Bays 3&4, 4&5, 5&6, 6&7, 7&8.

Stbd #2 Void. 1st Bay, there is a small insert plate welded in the side of the cargo tank near the bottom. Inspect weld thru Non Destructive Testing (UT or other acceptable means) where the horizontal weld at the top left of the plate meets the vertical weld.

Stbd #2 Void. Crop & renew buckled transverse floor frames attached to K-frame between Bay 3&4. Repair cracked weld where top side shell long attaches to chord.

Stbd #2 Void. Crop & renew 2 twisted side shell chords located between Bays 6&7, 7&8.

Stbd #2 Void. In Bay 8, crop & renew 2 buckled floor frames located under cargo tank.

Stbd #3 Void. Crop & renew buckled transverse floor frame attached to K-frame between Bay 3&4.

Stbd #4 Void. Crop & renew buckled floor frames located under cargo tank.

Forward Rake, Port side. Replace corner gusset plate.

Forward Rake, fwd bulkhead, Repair cracked weld on #2 frame.

Forward Rake, fwd bulkhead, Repair cracked weld on #11 frame.

Forward Rake, fwd bulkhead, Repair cracked weld on #12 frame.

Forward Rake, fwd bulkhead, Crop & renew buckled vertical #6 frame.

Port #4 void, Repair cracked welds on #3 & #5 side shell frames.

Stern Void, Port corner, replace 2 gussets, 1 side shell frame & repair 3 welds.

Stern Void, Stbd corner, replace 1 gusset & repair 2 welds.

Stern Void ladder, replace last 3 steps.

Port #4 Void, Provide Non Destructive Testing (UT or other acceptable means) of tank bottom plating.

There was a 1inch by 2 inch hole in the deck on the #1 Port void.

Gooseneck vents on Box void and #3 stbd void were wasted and need to be replaced with flame screens.

Replace gasket on the aft inspection port ullage

Cargo operations are not authorized until proof of valid VRP has been provided.

Cargo operations are prohibited until proof of valid COFR has been verified.

Cargo operations are prohibited until valid COD has been verified.

1'0" FRACTURE IN WAY OF #1 CARGO TANK AT DECK MIDWAY POINT OF #2 STARBOARD WING VOID AND RAISED TANK TOP PLATE.

1'0" FRACTURE IN WAY OF #2 CARGO TANK AT DECK MIDWAY POINT OF #3 PORT WING VOID AND RAISED TANK TOP SIDE PLATE.

Replace wasted exhaust piping between manifold and spark arrestor on cargo pump engine.

Provide evidence of cargo piping hydro test and relief valve test to CG Marine Inspector. Last test date was 08DEC92.

Prove proper operation of cargo pump engine in presence of CG Marine Inspector.

PLACE ON BARGE ORIGINAL OR CERTIFIED COPY OF VALID CERTIFICATE OF FINANCIALRESPONSIBILITY.

VESSEL MAY NOT CARRY BENZENE UNTIL RESTRICTED GAUGING IS INSTALLED , INSPECTED, TESTED AND APPROVED TO THE SATISFACTION OF THE ATTENDING MARINE INSPECTOR IN ACCORDANCE WITH 46 CFR 151.05, AS AMENDED BY THE DECEMBER 13 1991 FEDERAL REGISTER.

PROVIDE EVIDENCE OF HYDRO TEST OF CARGO PIPING TO 1.5 MAWP IN ACCORDANCE WITH 33 CFR 156.170.

REPLACE BROKEN FLAME SCREEN ON CARGO PUMP ENGINE FUEL TANK IN ACCORDANCE WITH 46 CFR 31.10-10.

REPLACE BROKEN FLAME SCREEN ON #3 STARBOARD WING VOID GOOSENECK IN ACCORDANCE WITH 46 CFR 31.10-10.

STENCIL " DANGER KEEP OUT " FOR CARGO TANK DOMES IN ACCORDANCE WITH 46 CFR 35.30-1.

PROVIDE CARGO INFORMATION CARD FOR CARGO ONBOARD IN ACCORDANCE WITH 46 USC 3313(A).

MAKE PERMANENT REPAIRS TO HOLE IN BOTTOM PLATE IN WAY OF #4 STBD. VOID PRIOR TO LOADING CARGO BUT NOT LATER THAN 31OCT87.

PLACE A VALID CERTIFICATE OF FINANCIAL RESPONSIBILITY ABOARD THE VESSEL PRIOR TO LOADING CARGO BUT NOT LATER THAN 29MAY87.
