MIRAGE

The rules concerning shapes shall be complied with by day. Vessel did not have dayshapes on board, Acquire dayshapes and carry onboard.

As appropriate for the intended voyage, a vessel must carry adequate and up-to-date current tables. Vessel did not have current tables on board.

As appropriate for the intended voyage, a vessel must carry adequate and up-to-date tide tables. Vessel did not have tide tables on board.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

A vessel on an oceans, coastwise, limited coastwise, or Great Lakes route must carry six hand red flare distress signals IAW 46CFR160.012; and six hand orange smoke distress signals IAW 46CFR160.037. All of the vessel's hand orange smoke flares were expired.

All vessels must have navigation lights that are in compliance with the applicable sections of the International and Inland Navigation Rules, except that a vessel of more than 19.8 meters (65 feet) in length must also have navigation lights that meet UL 1104, “Standards for Marine Navigation Lights,” or other standard specified by the Commandant. Sternlight means a white light placed as nearly as practicable at the stern showing an unbroken light over an arc of the horizon of 135 degrees and so fixed as to show the light 67.5 degrees from right aft on each side of the vessel. Vessel's stern light inoperable. Vessel provided temporary stern light. Provide correct stern light prior to next departure.

Each vessel must have adequate emergency lighting fitted along the line of escape to the main deck from all passenger and crew accommodation spaces located below the main deck. The port side of the bunk room has been fitted with curtains due to COVID, preventing emergency lighting installed in the starboard bunk room from servicing the port side. Provide emergency lighting showing the escape route to the main deck form the port side bunk room.

The means of escape through the forward hatch from the below deck passenger accommodations did not contain a ladder to allow rapid egress. Provide ladder that allows rapid egress through forward escape hatch.

Smoke detectors in passenger areas did not meet UL 217 approval. Provide smoke detectors that meet UL 217 approval.

There was no emergency lighting installed in the forward part of the below deck passenger accommodation area. Provide emergency lighting installed in the forward part of the below deck passenger accommodation area.

The forward passenger bunk was not secured properly. Properly secure the forward passenger bunk.

The emergency instructions were not specific to the vessel. Provide emergency instructions that is specific to the vessel.

The child sized and adult sized life jackets were stowed mixed together. Separate and stow child and adult sized life jackets and label each stowage area as such.

The painter line for the life floats was not attached to the life float correctly. Attach the painter to the life float in accordance with the life float manufacturer's instructions.

The line that secures the two life floats together was not properly attached. Attach the line in accordance with the life float manufacturer’s instructions.

The trash cans throughout the inside of the vessel were not constructed from non-combustible material. Provide trash cans that are constructed from non-combustible material.

Several wire nuts were used to wire 240 VAC electrical equipment in the pilot house. Remove all wire nuts and replace with permanent type connectors.

Provide VHF radio with GPS.

Install anti-static conductors on all fuel tank fill pipes.

Install foot strainer on forepeak bilge line.

Make emergency escape hatch operable from both sides.

Provide results of pre-employment drug testing for Fellows and updated employeee list.

Return log book to vessel.

Post lifejacket donning placard.

Label all electrical panels.

Provide ladder/steps to top of house to access lifesaving appliances.

Provide cover for battery on bridge.

Provide blank for electrical panel on bridge.

Properly mark vessel name on lifefloats.

Make forward e-escape hatch compliant w/ 46 CFR 171.124(b) ( securing device / attached to prevent loss / accessible from both sides).

Install lanyard on fish hold hatch cover.

Prior to carrying overnight psgrs, repair e-lighting system.

Re-stencil LF with vsl name/capacity

Secure stbd sidelight

Affix reflective tape to ring buoy

Provide painters for L/F oars

Prior to ops with passengers, make vessel available for check-ride.

Vessel may not operate with passengers until a satisfactory hull exam has been completed, or a request for a D/D extension has been approved.

Re-mount generator solenoid.

Install switch on service eng oil change pump.

Provide updated nav pubs (Reed's Almanac).

Provide latch for the E/R breaker panel.

Label breakers switches on the bridge panel.

Replace cotton chafing gear with rubber chafing gear.

replace L/F retro tape (top float).

Seal lazarett blkh and make compartment watertight.

Install cover IWO STBD side engine room access ensuring compartment is air tight.

Double clamp port engine coolant hose.

Tighten/secure gen electrical supply line to breaker box.

Replace generator raw water supply hose.

Double clamp raw water exhaust coolant supply.

Seal FWD collision blkh access cover IWO fwd accom.

Owner/operator failed to report positive random chemical test results for a CG-licensed mariner to USCG.

Prove proper means of securing ventilation to engine room. Item completed prior to completion of the inspection.

Double clamp all pedro connections in bilge piping throughout vessel as necessary. Repair completed prior to completion of inspection.

Repair and prove proper operation of stern light. Vessel is restricted from conducting passenger operation from 1/2 hour before sunset to 1/2 hour after sunrise. Repair completed prior to completion of inspection.

Provide a ladder or other means to safely return a person back on board the vessel from the water. Ladder was provided prior to completion of the inspection.

Repair holding stanchions for life floats on starboard side.

Provide 2 adult size type I PFD's. Vessel passenger capacity is reduced by 2 persons until corrected.

Replace port and starboard forward shaft cutlass bearings.

Plug/repair hole in bulkhead between engine room and fuel space (port side).

Replace wire nuts with crimp connectors on splice for bilge alarm float switch in lazarette.

Post MARPOL V trash placard in main salon.

Noted 1 adult Type 1 PFD with a torn chest strap and 1 child Type 1 PFD with deteriorated retro-reflective material. Both discrepancies corrected prior to the completion of the inspection.

Noted during inspection that the battery for the 406 MHz EPIRB had expired 8/03. Vsl O/O obtained a rental EPIRB from local marine electronics vendor and loner EPIRB was registered in vessels name until a new battery can be procured and installed in the vessel's original EPIRB. LEGACY COMPONENT DESC: EPIRB

Stencil vessel name on ring buoy.

Properly support electrical wires on starboard side of bunk room above aft most berth.

Ensure all pedro connections in bilge suction piping lines have double hose clamps.

Post for display vessel waste management plan, MARPOL V garbage discharge placard, emergency instructions and Employee Assistance Program placard.

Renew fuel tank vent screens. LEGACY COMPONENT DESC: Vent Pipe

Renew flex hose sections on intake and discharge to bilge pump and double clamp. LEGACY COMPONENT DESC: Hose

Tighten hose clamps on bilge manifold. LEGACY COMPONENT DESC: Hose

Renew expired items in first aid kit. LEGACY COMPONENT DESC: Medicine Chest

Install grease extraction hood over griddle in accordance with 46 CFR 181.400(d).

Prove proper operation of remote fuel shut-off valves. LEGACY COMPONENT DESC: Valve

Prove proper operation of scuttle for lazarette.

Provide metal supports for electrical wire in engine room as per 46 CFR 183.340(b)(4). Wiring supplying power to engine block heaters not supported with metal supports every 24". LEGACY COMPONENT DESC: Wiring

Mark forward passenger compartment emergency escape hatch as per 46 CFR 185.606. Hatch cover not marked on top side as required.

PROVE FUEL HOSE, GATES 12C2AT, SUCTION LINE IS APPROVED FOR FUEL OIL SERVICE IN ACCORDANCE WITH SAE J-1942-1.

PROVIDE ADEQUATE MEANS OF SECURING VENTILATION TO ENGINE ROOM.

STENCIL VESSEL NAME ON LIFE RING BUOY.

MAKE BULKHEAD PENETRATIONS IN REQUIRED WATERTIGHT BULKHEADS IN ACCORDANCE WITH 46 CFR 182.720.

CONDUCT ANNUAL SERVICING OF PORTABLE AND FIXED FIRE EXTINGUISHERS.

DOUBLE HOSE CLAMP PEDRO CONNECTIONS AS NEEDED IN VITAL SYSTEMS IN ENGINE ROOM.

PROVE FUEL HOSE, GATES 12C2AT, SUCTION LINE IS APPROVED FOR FUEL OIL SERVICE IN ACCORDANCE WITH SAE J-1942-1.

MAKE BULKHEAD PENETRATIONS IN REQUIRED WATERTIGHT BULKHEADS IN ACCORDANCE WITH 46 CFR 182.720.

Show proof that the AC circuit breakers in the main electrical distributionsystem are approved under UL standard UL489.

Install volt, frequency and amperage meter as required by 46 CFR 183.320(c).

20-PERSON LIFEFLOAT NEEDS SERVICED AND/OR REPLACED._x001C_

15-PERSON LIFEFLOAT NEEDS NEW LINE THROUGHOUT.

PROVE PROPER OPERATION OF 1 LIFEFLOAT LIGHT (20 PERS)._x001C_ _x001C_ _x001C_ _x001C_

UPDATE LOGS TO INCLUDE CREW TRAINING (PER 46 CFR 185.420), ABANDON SHIP/MANOVERBOARD (PER 46 CFR 185.520), AND EPRIB TRAINING (PER 46 CFR 185.728).

UPDATE RADIO STATION LICENSE TO INCLUDE NEW 406 MHZ EPIRB.

PROVIDE ORIGINAL SAFETY RADIO TELEPHONE CERTIFICATE ON BOARD._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE SERVICING REPORT FOR PORTABLE AND FIXED FIRE EXTINGUISHING SYSTEMS.

PROVIDE PROPER EAP PROGRAM PER 46 CFR 16.401._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE PROPER STENCILING OF ALL LIFEFLOATS AND EQUIPMENT (46 CFR 185.604).

PROVIDE ON BOARD A NEW LIGHT LIST, COAST PILOT, 46 CFR 166-199, 46 CFR 1- 40, 33 CFR 125-199.

PROVIDE ON BOARD OIL POLLUTION PLACARD AND MARPOL V PLACARD (33 CFR 155.450AND 151.59).

CLEAN BILGES AND MAKE FREE FROM OIL

SHOW PROOF THAT INSTALLED F/O TANK VENTS & SUPPLY LINES ARE COAST GUARD APPROVED, OR RENEW WITH APPROVED HOSE.

INSTALL EMERGENCY F/O SHUT DOWN DEVICE FOR F/O TANKS PER 46 CFR 182.455(b)(4).

INSTALL BONDING LINES FROM F/O FILL CONNECTION ON DECK TO F/O TANK.

CORRECTLY INSTALL F/O VENT PIPES PER 46 CFR 182.450(d).

MAKE LAZARETTE DECK WATERTIGHT IN WAY OF LAZARETTE SCUTTLE.

Install exhaust lagging over non water cooled parts of exhaust piping on both propulsion and auxilary generator engines.

Install smoke detector in overnight passenger accomadation space in accordance with 46 CFR 181.450.

Replace worn life lines and hand lines on buoyant apparatus in accordance with 46 CFR 160.010-4.

Replace broken electrical outlet on the forward engine room bulkhead.

Replace all PVC or plastic bilge and main engine cooling pipe and fittings in the engine room using approved metallic pipe. Non-ferrous pipe where used must have a melting temperature of less than 1700 degrees F or meet the specific requirements listed in 182.730

Post fire extinguishing system instructions at helm station

Renew bilge piping with approved pipe

repair as new temp guage and oil pressure guage to port engine

Conduct and log required drills

Update charts with NTM's

Post emergency broadcast placard

Repair as new stbd engine cooling system

Install retroreflective tape on lifering buoy & lifefloats

Submit plan to upgrade boats electrical wiring to correct the following problems: Conduit ends in junction boxes missing, SO Cable hard wired throughout boat and No cable or wire clamps at intervals required.

Install corrosion resistant clip on lifering buoy light

update FCC Station safety license to include 406 EPIRB

Renew weak link on lifefloat

Repair as new audible alarm & bunkroom bilge alarms and label

Remove household electrical wiring in engineroom and replace with approved marine grade cable

Renew pedro connections from main engine cooling system discharge to pipingwith approved hose.

Submit plan for ventilation closures in engineroom

Renew F/O line from #2 engine to return

Pay user fees

Replace galley window port side, aft.

Provide 1 Coast Guard approved type I child lifejacket prior to carring more than 5 persons weighing less than 90lbs.

Conduct crew training as per 46 CFR 185.420 and log this training.

Provide a first aid kit as per 46 CFR 184.710.

Put type II retroreflective material on all lifefloats & lifering.

Provide a Category 1, 406 MHz EPIRB install to automatically float free andactivate.

Mark fuel shutoff valves as per 46 CFR 185.608.

Conduct a follow-up ride after repairs to the stbd shaft.

PROVIDE CURRENT AND UPDATED CHARTS, TIDE AND CURRENT TABLES, LIGHT LIST ANDCOAST PILOT.

PROVIDE A WASTE MANAGEMENT PLAN AND LOG BOOK.

BLANK OFF OPEN SPACES IN THE 110V BOX IN THE E/R.

REPAIR OR REPLACE THE WASTED BATTERY BOX COVER.

PROVIDE PROOF THAT THE EXPIRED EPIRB BATTERY HAS BEEN SATISFACTORILY REPLACED.

Provide five adult size type I Coast Guard approved life preservers prior to carrying more than 48 adults, for a total of 53 adult size type I Coast Guard approved life preservers.

Fix one waterlight for the life floats for a total of four waterlights.

Conduct emergency drill in the presence of a Coast Guard marine inspector.

Replace the line for all waterlights on the life floats and the life ring.

Tie the paddles to the life floats.

Replace the batteries for the PFD water lights.

Provide one child size, Coast Guard approved type I life preserver prior tocarrying more than 5 childern. Vessel needs a total of 6 children size_x001C_ life preservers.

Provide proof of Certification of Documentation.

INSTALL A WATER SHUT OFF VALVE TO BOTH HEADS AND A WAY TO LOCK THE OVERBOARD DISCHARGE FOR EACH MSD.

Remove glass coating from after starboard fuel tank.

Provide drip shield for battery charger.

Properly wire fresh water pump switch and remove circuit multiplier from galley.

Renew missing dog for lazarette watertight hatch.

Renew forward port and starboard fuel tanks. Tanks are to be removed from service and emptied.

Repair and prove proper operation of fuel tank emergency fuel tank shut- offs. Make activation handles readily accessible. Vessel is not to carry passengers for hire until corrected.

Make after engineroom transverse bulkhead watertight.

Provide one additional USCG approved type I adult size life preserver priorto operating the vessel with more than 48 passengers. (only 52 were inspected on 01Apr93)

Provide bridge electrical panels with "as original" covers.

Repair interior netting on two (02) eleven (11) person life floats. Vesselis limited to forty-nine (49) passengers (Coastwise) and thirty-five (35) total persons on oceans route.

Provide navigation side lights with 36 inch flat black screens.

Repair seam on forward 15 person lifefloat.

THE VESSEL IS RESTRICTED TO AN OCEAN ROUTE NOT MORE THAN 60 MILES FROM A BASELINE EXTENDING FROM POINT CONCEPTION TO CAPE SAN LUCAS, MEXICO UNTIL A SINGLE SIDE BAND RADIO IS PROVIDED.

At next drydocking make permanent repairs to the transom (4"x12" area inside the starboard lazarette)._x001C_

RENEW ALL GRAB LINES ON ALL THREE LIFE FLOATS.

REPLACE/REPAIR PORT SIDE AFTER WINDOW IN PASSENGER SALON.

REPAIR LEAK IN MAIN DECK PORT SIDE FORWARD ENGINE ROOM.

PROVIDE BATTERY BOX FOR BRIDGE ELECTRONICS BATTERY.

PROVIDE ANCHOR LIGHT FOR VESSEL; VESSEL IS NOT TO OPERATE UNTIL CORRECTED.

CLEAN UP VESSEL WIRING, PROPERLY SUPPORT WIRING, AND PROPERLY DEAD END UNUSED WIRING.

PROVIDE ROTATING MACHINERY GUARD FOR PORT MAIN ENGINE.

CLEAN AND TREAT DRY ROT IN ENGINE COMPARTMENT.

PROVIDE LIGHTS ON LIFE PRESERVERS.

REPLACE BATTERY ON EPIRB.

REPAIR WATER LEAKING IN LAZZERETTE IN-WAY-OF PORT EXHAUST.

REPAIR STBD TACHOMETER ON BRIDGE.

DRILL AND COTTER PIN RUDDER TIE BAR THROUGH-BOLTS PORT AND STBD SIDE.

REPAIR SSB.

PROVIDE RADIOTELEPHONY SAFETY CERTIFICATE.

PROVIDE A MAGNETIC COMPASS DEVIATION CARD.

REPAIR INOPERABLE WATER LIGHTS ON TWO(2) LIFE FLOATS.

INSTALL/MOVE EXISTING STERN LIGHT TO THE STERN TRANSOME.

PROVIDE AND INSTALL GLOBE LIGHT FIXTURES IN EVERY LIGHT IN PASSENGER ACCOMMODATIONS AND TOILETS.

INSTALL PROTECTIVE GUARDS ON BELT AND DRIVE PULLEYS ON PORT AND STARBOARD MAIN DIESEL ENGINES.

PROVIDE PUBLICATIONS ON BOARD SUCH AS RULES OF THE ROAD AND TIDE TABLES FOR SAN DIEGO, CALIFORNIA.

REPAIR ELECTRICAL WIRING SPLICES IN ENGINEROOM WITH METAL CRIMP CONNECTORS.

1 MOUNT FUEL SHUT OFFS OUTSIDE FUEL TANK COMPARTMENTS.

5 INSTALL DRIP SHIELD OVER VOLTAGE REGULATOR ON AFT BULKHEAD OF ENG. ROOM.

3 REMOVE OR SECURE BILGE PUMP BELOW LADDER IN ENG. ROOM STBD SIDE.

4 REPAIR/REPLACE VALVE ON BILGE MANIFOLD FOR HAND PUMP.

2 REPLACE SEA VALVE FOR BAIT TANK.

STENCIL CAPACITY ON 22 MAN LIFE-FLOAT.

REPAIR (1) ONE WATER LITE FOR LIFE FLOAT.

REPLACE PENDANTS ON LIFE-FLOATS.

PROVIDE ONE (1) EMERGENCY FLASH LITE.

REINSTALL SINK PLUMBING FOR LADIES HEAD.

REPAIR PIPE LEAKING INTO FUEL SPACE FROM BAIT TANK.

REPAIR HOLES IN GLASS IN PORT & STBD FUEL SPACE.

INSTALL LOCKS OR POLLUTION SIGNS FOR BOTH MSD'S.

PROVIDE ONE (1) BII FIRE EXTINGUISHER.

REPAIR COOLING WATER LEAK IN EXHAUST PIPING AND LEAK IN BAIT TANK LINE IN AFT STEERING.

PROVIDE FUEL VENT LINE FOR AFT STBD FUEL TANK.

PROVIDE FLAME SCREEN FOR FWD PORT FUEL TANK.

PROVIDE ONE (1) CHILD AND THREE (3) ADULT LIFE PRESERVERS.

REPLACE RING BOUY HAND LINE.

PROVIDE ONE (1) BATTERY BOX.

PROVIDE A SINGLE SIDE BAND RADIO.

REPAIR STERN LITE.

REPLACE WEAK LINK FOR FOR LIFE FLOATS.

PROVIDE BRONZE NOZZLE.

PROVIDE AND LABEL EMERGENCY FUEL SHUT-OFFS FOR ALL SIX FUEL TANKS.

LABEL OUTSIDE FWD EMERGENCY ESCAPE HATCH.

PROVIDE SAFETY CHAIN ON FWD HATCH, FUEL SPACE HATCH, AND AFT STEERING HATCH

REMOVE OIL, OIL FILTERS, GUNNEY SACKS,CANS, AND UNNECESSARY GEAR FROM ENGINEROOM.

RENEW VESSEL'S DOCUMENT PRIOR TO 17DEC86.

REPAIR CRACKS, RENEW GRABLINE AND PLACE RETRO-REFLECTIVE TAPE ON PORT 6-MANLIFEFLOAT.

STENCIL ESCAPE HATCH ON INSIDE OF PASSENGER COMPARTMENT PRIOR TO 17DEC86.

SUBMIT TO MSO LA/LB INSPECTION DEPT. SIMPLE LINE DRAWINGS OF EMERGENCY LIGHTING SYSTEM.

PROVIDE TWO ADULT AND ONE CHILD LIFEJACKETS ON BOARD. UNTIL THIS DEFICIENCYIS CORRECTED THE VESSEL'S TOTAL NUMBER OF PASSENGERS IS REDUCED BY TWO. A CHILD LIFE JACKET IS TO BE PROVIDED FOR EACH PERSON ABOARD WEIGHING LESS THAN 90 POUNDS.

REMOVE ALL DEAD ENDED WIRES, SUPPORT ALL HANGING WIRES AND NEATEN UP ALL WIRING IN THE ENGINE ROOM.

REPAIR CRACKS IN SIX MAN LIFE FLOAT.

INSTALL THREE LIGHTS IN ENGINE ROOM USING GOOD MARINE PRACTICE.

REPAIR OR RENEW DEFECTIVE WATER LIGHT ON 11 MAN LIFE FLOAT. RENEW BATTER- IES ON WATER LIGHTS AND AND PROVIDE A MEANS OF HANGING THE SAME.

CONDUCT A GENERAL HOUSE CLEANING OF THE ENGINE ROOM.

PROVIDE A BELT GUARD FOR STARBOARD MAIN ENGINE ALTERNATOR BELT.

SCRAPE AND TREAT DRY ROT IN OVERHEAD OF ENGINE ROOM.
