HORNBLOWER HYBRID

Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Dead end wires found in the following areas: above pilothouse (2 sets), under pilothouse console (2 sets), forward voids (port and stbd), lazarettes (port and stbd). 46 CFR 183.200(b)

A penetration in a watertight bulkhead must be as high and as far inboard in the bulkhead as practicable, and made watertight. 02 penetrations in the aft bulkhead of the port forward void are not watertight. 46 CFR 179.320(c)

Nonmetallic hose may be used for wet exhaust systems provided it is...double clamped where practicable. Flexible hose connections to the port main engine exhaust were made with one clamp. 46 CFR 182.430(e)

Each battery must be…secured to protect against shifting with the roll and pitch of the vessel. Battery boxes not secured, both port and stbd. 46 CFR 183.350(b)

Nonconducting mats or grating must be provided on the deck in front of each switchboard. Mat missing in front of switchboard. 46 CFR 183.330(f)

All electrical equipment and circuits must be clearly marked and identified. Breaker panel near switchboard has multiple labels for same breaker. 46 CFR 183.220(d)

Exhaust gas must not leak from the piping or any connections. The starboard main engine exhaust was leaking above the aft end of the engine. 46 CFR 182.430(b)

Each survival craft must be secured to the vessel by a painter with a float-free link permanently attached to the vessel. The IBA painter was found not secured to the vessel. 46 CFR 180.130(a)(1)

A qualified servicing facility must conduct inspections on portable extinguishers and fixed-gas extinguishing systems. Annual fire protection inspection has lapsed. Owner must provide satisfactory evidence of required servicing. 46CFR176.810(b)(1)(2)

All machinery and equipment must be installed and maintained in such a manner as to afford adequate protection from causing fire, explosion, machinery failure and personal injury. Port motor has excessive vibration. 46CFR182.100

An inflatable buoyant apparatus must be serviced at a facility approved by the Commandant no later than the month and year on its servicing sticker. IBA servicing has lapsed. Must provide proof of servicing. 46CFR185.730(a)(1)

Penetrations and openings in watertight bulkheads must have means to make them watertight. Non watertight penetrations found in the following spaces: port and starboard battery room to port and starboard fuel tank void, port and starboard fuel tank void to port and starboard engine room. 46CFR171.114(a)(2)

The discharge ends of fuel tank vent pipes must be fitted with removable flame screens or flame arrestors. Fuel tank vent pipe missing flame screen or flame arrestor. 46CFR182.450(e)

Penetrations and openings in watertight bulkheads must have means to make them watertight. Conduit running from bow to engine room does not have any cap or plug and is fractured in battery room rendering all spaces non-watertight. 46CFR171.114(a)(2)

A vessel must carry either a first-aid kit approved under approval series 160.041 or a kit with equivalent contents and instructions. Found the following three items expired in the first-aid kit: burn dressing, ammonia inhalants, and iodine wipes. 46CFR184.710

Penetrations of required watertight decks and bulkheads by any rigid plastic pipe are prohibited unless the following requirements are met: each penetration must be accomplished using an acceptable metallic through deck or through bulkhead fitting that is welded or otherwise attached to the bulkhead or deck by an accepted method. Vessels submersible electric bilge pumps utilize PVC piping to lead into the common bilge overboard pipe. A metallic shutoff valve must be attached at the overboard pipe in lieu of PVC. 46 CFR 182.720 (d)(1)

The cognizant OCMI may require that a vessel and its equipment undergo any additional test or inspection deemed reasonable and necessary to determine that the vessel and its equipment are suitable for the service in which they are to be employed. Received notification from operator that vessel was taken out of service due to a leaking pipe associated with port main engine sea chest. Provide repair proposal and affect permanent repair to the satisfaction of attending marine inspector. 46 CFR 176.840

The requirements for machinery for electrically propelled vessels are contained in applicable regulations in subchapter J (Electrical Engineering) of this chapter. Each electric propulsion installation must meet section 4-8-5/5.11 of ABS Steel Vessel Rules (incorporated by reference; see 46 CFR 110.10-1). Where two or more control stations are provided outside the engine room, or where the propulsion machinery space is intended for centralized control or unattended operation, the provisions of Part 4, Chapter 9 are to be complied with. Electric power for control, monitoring and safety systems is to be fed from two feeders, one from the main switchboard or other suitable distribution board and the other from the emergency switchboard or an emergency distribution board. The supply status of these feeders is to be displayed and the main power supply failure is to be alarmed. The electric power supply to each of the control, monitoring and safety systems is to be individually monitored. The two feeders are to be connected to a transfer switch in the remote control station. Vessel currently only has one power source for control system. 46 CFR 182.220(b), 46 CFR 111.35-1, ABS Steel Vessel Rules 4-8-5/5.11.2, 4-9-2/11.7.1, 4-9-2/11.7.2

At each inspection for certification all observed unsafe practices, fire hazards, and other hazardous situations must be corrected and all required guards and protective devices must be in satisfactory condition. Vessel bilge/fire piping possessed multiple leaks. Leak witnessed in bilge pipe within the port engine room at bend located above the manifold. Second leak witnessed in crossover pipe connecting the port and starboard engine room bilge systems. Vessel must submit repair proposal to include permanent repair plan to the affected system.

Prove proper operation of override/means or reset at the operating station. 46CFR181.420

Provide repair plan for approval and make permanent watertight repairs for the nickel sized hole in the deck leading into the starboard side lazarette. 46CFR177.100

Repair damage to handrails on port bow. No passengers are allowed on bow until repairs are completed.

Provide a repair proposal for identified through bulkhead cable penetrations for engineering spaces bulkheads in laz spaces, eng rms, and fuel tank voids, as per NVIC 9-97.

Vessel had a loss of propulsion when the variable frequency device tripped offline. O/O must prove proper operation of the propulsion system to the satisfaction of the attending marine inspector.

Provide a repair proposal for the damaged stbd bow as a result of the allision with a pier.

Make proper approved repairs to the stbd bow damaged to the satisfaction of the attending marine inspector.

Replace fire hose on aft deck and prove proper operation.

Crewmembers not properly trained prior to assuming safety sensitive positions regarding company's drug and alcohol policy in accordance with 46 CFR 16.401.

Properly seal holes in P/S lazerette shell plating located above the water.

All required personnel are not in the random drug testing pool as required by 46 CFR 16.230. C/TPA informed of discrepancy and testing pool updated. Individual that was accidentally excluded from pool was immediately subjected to drug test and removed from safety sensitive functions until test results return from lab.

Copy of latest MIS form not available for review as required by 46 CFR part 16.500.

Submit the Deadweight Survey results to the Marine Safety Center and provide a new/updated Stability Letter.

Re-label bilge piping manifold valves.

Provide Oil discharge placard and MARPOL garbage placard.

Provide guards for propulsion motor shafts at coupling/thrust bearing.

Repair engine room vent closures and label.

Provide fuel shut-off valve placard for port side.

Provide flashlights.

Label PFD work vests.

Conduct expired COI exam after receiving final approved plans from MSC for new machinery installation.

Conduct a COI after receiving approved plan review correspondence from the Marine Safety Center for the new machinery installation.

Submit the deadweight survey results to the Marine Safety Center and provide a new/updated Stability Letter.

Make watertight conduit piping penetrating the bulkhead between the engineroom and lazarette in way of centerline.

Provide current copy of US Coast Pilot.

Provide current copy of CG Light List.

Provide current copy of Navigation Rules, Edition D.

Properly secure bilge pump wiring in all spaces IAW 46 CFR 183.340(a)(4).

Provide current FCC Safety Iicense.

Repair cracked weld in starboard side forepeak overhead.

Remove 2 dead end cables on starboard generator control panel.

Repair visual alarm for port lazarette high water alarm in pilot house.

Replace cracked life ring buoy on port side, upper deck, just aft of wheel house.

Replace cracked/dry rotted flex hose on discharge side for aft main deck fire hose, fwd of pressure gauge.

Repair exposed cable insulation on wire to STBD MDE hot start.

Permanently mount electrical submersible bilge pump in port FWD void.

Prove proper operation of STBD FWD void electrical submersible bilge pump.

Properly support all electrical wiring throughout vessels voids IAW 46CFR 183.340. Wiring loose and hanging in bilge.

Properly cap broken PVC pipe from old shower line in way of STBD lazarrate.

Provide lifesaving maintenance log.

Properly dead end electrical wire in way of port side lazarrate.

Repair broken emergency light fixture in way of STBD mid void compartment.

Secure electrical cable runs in both engine rooms and both lazerattes IAW 46 CFR 183.340

Make overhead and FWD bulkheads vapor tight in way of both engine rooms.

Repair cracked welds in STBD focsle (1ea) overhead circled in yellow chalk with arrow, and in PORT focsle (4ea) overhead circled in yellow chalk with arrow.

Make bulkheads in both fuel rooms watertight in way of FWD bulkheads.

Repair MSD PVC line in PORT lazeratte FWD outboard.

Clean and tighten clamps in way of rudder packing in way of STBD lazeratte.

Replace exired items in First Aid kit.

Renew Adult CPR certification for 50% of crew.

Install caps on ball valve through hull fittings in starboard engine room.

Replace damaged waterlight on life ring buoy prior to carrying passengers at night.

Replace batteries with screw top type in two floating water lights prior to carrying passengers at night. Log the battery change.

Properly attach all weak links on life floats.

Provide 2 new floating water lights for life floats prior to carrying passengers at night.

Replace retroreflective tape on 22 person and 12 person life floats.

Remove power ventilation blower from engine room.

Repair visual alarm on starboard mid-compartment bilge high level alarm.

Replace one expired red flare

Submit proposal to remove underwater glass and replace with hull plating.

Renew leaking valve in way of port aft engine room bulkhead. repairs should include bulkhead spool piece. LEGACY COMPONENT DESC: Marine Sanitation Device, Type III

Submit repair proposal to repair as new shell plating between port and starboard hulls in way of pitting. LEGACY COMPONENT DESC: Bottom Plating

Submit proposal to renew vital system piping in way of PVC pipe as required by 46 CFR 182.720. LEGACY COMPONENT DESC: Piping

Renew aluminum fuel oil pipe on starboard fuel oil filters as required by 46 CFR 182.720. LEGACY COMPONENT DESC: Piping

Correctly label the port hull bilge suction manifold.

Provide emergency broadcast placard.

PROVIDE PROOF OF CURRENT EPIRB NOAA REGISTRATION IAW 46 CFR 180.64. FAX PROOF TO THIS OFFICE AT [phone withheld]. THIS ITEM MUST BE COMPLETED PRIOR TOTRANSIT WITH PASSENGERS MORE THAN 3NM FROM SHORE.

REPLACE WEAK LINK ON PAINTER FOR THE 12 AND 10 PERSON LIFEFLOATS WITH A LINK RATED FOR "21 OR MORE." FAX OF A PICTURE SHOWING PROPER INSTALLATION WILL BE ACCEPTED.

PROVIDE ADEQUATE LIFESAVING EQUIPMENT IAW 46 CFR 180.205.

RAILS SHALL BE INSTALLED ALONG THE STERN IAW 46 CFR 177.900.

MARKINGS SHALL BE PROVIDED FOR THE TOP DECK IAW STABILITY LETTER DATED 19 MAY 98.

SUBMIT VIEWING WELLS INSTALLATION PLANS FOR APPROVAL

CONDUCT UNDERWAY CHECK RIDE.

PROVIDE PHOTOGRAPHS OF UNDERWATER VIEWING WELLS.

Repair both main engine driven fire pumps. The fire pumps must be repaired prior to operating with passengers.

PROVIDE DOCUMENTATION THAT THE CREW IS ENROLLED IN A RANDOM DRUG TESTING PROGRAM AS PER 46 CFR 16.230._x001C_ NO PASSENGERS MAY BE CARRIED UNTIL THIS ITEM IS CORRECTED.

PROPERLY SEAL THE COMPRESSED AIR DIVE SYSTEM HOSE CONDUIT AFTER FINAL INSTALLATION.

PROVE PROPER OPERATION OF THE MAIN ENGINE VENTILATION CLOSURES AS REDESIGNED. 46 CFR 182.465(h). _x001C_ _x001C_ NO PASSENGERS SHALL BE CARRIED UNTIL THIS ITEM IS CORRECTED.

A RE-EVALUATION MUST BE COMPLETED BY THE ATTENDING COAST GUARD MARINE INSPECTOR OF THE MINOR LEAK LOCATED ON THE STARBOARD CENTER VIEWING PORT INAS PRESCRIBED BY THE CHIEF OF THE INSPECTIONS DEPARTMENT, MSO MOBILE._x001C_ NO PASSENGERS SHALL BE CARRIED UNTIL THIS ITEM IS CORRECTED.

PROPERLY MARK THE ENGINE ROOM ESCAPE HATCHES AS PER 46 CFR 185.606. "EMERGENCY EXIT, KEEP CLEAQR!".

PROVE PROPER OPERATION OF THE INSTALLED AMPERAGE METERS UNDER LOAD AS PER 46 CFR 183.320(c).

PROVIDE ON BOARD UP TO DATE CHARTS AND PUBLICATIONS REQUIRED BY THE COGNIZANT OCMI AS PER 46 CFR 184.420.

CONDUCT SATISFACTORY FIRE, ABANDON VESSEL AND MANOVERBOARD DRILLS IN THE PRESENCE OF THE ATTENDING MARINE INSPECTOR AS PER 46 CFR 176.808(g) AND COAST GUARD NVIC 1-91._x001C_ NO PASSENGERS SHALL BE CARRIED UNTIL THIS ITEM IS CORRECTED.

PROVE PROPER OPERATION OF THE COMPASS LIGHT AS PER 46 CFR 184.402(c)._x001C_ VESSEL IS RESTRICTED TO DAYLIGHT OPERATIONS ONLY UNTIL THIS ITEM IS CORRECTED.

PROVE PROPER OPERATION OF THE MAIN ENGINE AND GENERATOR SHUT DOWNS BY THE FIXED FIREFIGHTING SYSTEM. 46 CFR 181.420(a)(3). _x001C_ _x001C_ NO PASSENGERS SHALL BE CARRIED UNTIL THIS ITEM IS CORECTED.

PRESENT VESSEL FOR INSPECTION TO THE COGNIZANT OCMI_x001C_ _x001C_ NO PASSENGERS SHALL BE CARRIED UNTILL THIS ITEM IS CORRECTED.

PROVE PROPER INSTALLATION AND OPERATION OF THE DIVE AIR SYSTEM AS PER 46 CFR 197.310. AND 197.338.
