ANITA DEE

Each ring life buoy with a floating waterlight msut have a lanyard of 3-6ft in length. Upper deck forward floating waterlight lanyard is not the proper length. Replace the same.

Flexible non-metallic hose in fluid power systems must not penetrate watertigth bulkheads or decks. The flexible hose running from the hydraulic tank to the hydraulic pump in way of the bow thruster penetrates a watertight deck. Properlly install the same.

Each hatch cover must be attached to the fram or coaming by hinges or captive chains. Provide a captive chain for the forepeak deck hatch.

All electrical installations must be to the satisfaction of the OCMI. The switchboard in the steering space does not full close. Repair the same.

All electrical installations must be to the satisfaction of the [name withheld] dead end wiring from 1. Port side forward most bench, main deck. 2. Starboard stern overhead. 3. Beneath operating station. 4. Laundry room, fwd, starboard, overhead.

The inspector shall examine all accessible parts of the hull. There is a small hole in the watertight deck, port side, aft, salon, above the engine compartment.

An adult lifejacket must be provided for each person onboard. Marine Inspectors rejected 30 Type I lifejackets. Repair or replace the same. Vessel is limited to the carriage of 127 persons pending completion.

Each ring life buoy on a vessel must be approved in accordance with 160.050 subchapter Q. The STBD ring buoy line is deteriorated.

Every annual inspection, quarters, toilets and washing spaces may be examined for serviceability. The PVC pipe in the FWD Compartment is melted from contact with heat tape. Replace pipe.

Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons from electrical hazards. Remove the heat tape from pumps in the FWD compartment.

Explosion proof equipment and intrinsically safe systems must meet the requirements in subchapter J. Remove the sump pump from the FWD sewage tank.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

For fixed-gas fire extinguishing systems, the inspections and tests required by Table 176.810(b) of this section, in addition to the tests required by 46 CFR 147.60 and 147.65. The owner or managing operator must provide satisfactory evidence of the required servicing to the marine inspector. If any of the equipment or records have not been properly maintained, a qualified servicing facility may be required to perform the required inspections, maintenance procedures, and hydrostatic pressure tests. Master did not have current fixed firefighting servicing records onboard. Master was able to provide them prior to inspection completion.

Electrical equipment on a vessel must be installed and maintained to: (b) Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Discovered several electrical wiring deficiencies including junction box not mounted behind the bar, daisy chained outlet multipliers behind bar, exposed wiring on poert and starboard generator starting battery cables, and exposed wiring on port main engine starting battery bank.

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI, except during an emergency. Submit electrical plans for the new electric range installation in the galley for approval.

Sea rails, with suitable barriers to prevent accidental movement of cooking pots, must be installed on a cooking range. Install sea rails on electric range in galley.

The number of penetrations in a watertight bulkhead must be minimized. A penetration in a watertight bulkhead must be as high and as far inboard in the bulkhead as practicable, and made watertight. Heat detector penetration on port aft bulkhead is not watertight.

01-Rudder angle indicator t-box on STBD side wire is pulled from stuffing tube.

02-Remove any and all oil from bilge in engine room and under generators.

03-10 Child and 04 adult lifejackets need new retro tape, and Lanyard for upper life ring needs to be repaired.

Starboard window in the pilothouse is fogged and spyder cracked. Replace window.

Prove proper operation of the forward bilge suction. Pump would not take suction, after several attempts and backflushing pump took minimal suction.

Port Main Engine lube oil pressure gauge must operate at the operating station. Gauge did not register pressure while engine was running.

Fire Stations must be provided with a spanner wrench. Spanner wrenchs were missing from all fire stations.

Replace ring bouys x 2. 46CFR180.30-1

Replace cover 2nd deck port side for throttle pressure gauge. 46CFR176.25-50

Cable connections need junction or proper splice by bar area receptacle, same for LED driver mounted behind bar. 46CFR183.01-15

Main deck panel, electrical panel, repair or replace handle/latch. 46CFR176.20-30

Communication cable in engine room bilge under center engine shaft has heat damage to its outer insulation jacket. Repair/replace damage cable section to satisfaction of attending Marine Inspector. Cable is for bilge alarm system, system is operating and was tested. 46CFR183.01-15

AIS antenna cable splice in pilot house corner has bare conductors visible with broken insulation. Repair/replace to satisfaction of attending Marine Inspector. "OLD T" 46CFR183-01-15

Light fixture on vessel stern has missing lens/cover. Repair/replace to satisfaction of attending Marine Inspector. "OLD T" 46CFR183.10-20(L)

Repair/replace emergency light fixture in steering room to satisfaction of attending Marine Inspector. "OLD T" 46CFR184.30-5

Steering cable in aft steering needs metal supports at least every 24" to the satisfaction of attending Marine Inspector. "OLD T" 46CFR183.01-15

Main distribution panel is missing "STBD VOLTAGE SWITCH" knob. Repair/replace to satisfaction of attending Marine Inspector. "OLD T" 46CFR183.01-15

Firemain aft isolation valve leaks. Repair leak to satisfaction of attending Marine Inspector. "OLD T" 46CFR181.15-5(c)

Port generator battery charger has pulled out cable stuffing tube. Repair/replace to satisfaction of attending Marine Inspector. "OLD T" 46CFR183.01-15

Water tight door between generator room and engine room, gasket has gaps. Repair/replace to satisfaction of attending Marine Inspector. "OLD T" 46CFR176.25-1

Engine room breaker panel has uneven/warped dead front cover allowing gaps into the enclosure of the panel. Repair/replace gap areas to satisfaction of attending Marine Inspector. "OLD T" 46CFR183.01-15

Cover hole on top of wooden console in pilot house to Marine Inspector satisfaction. "OLD T" 46CFR176.25-1

Quick acting water tight door between engine room and state room passageway needs labeling on both sides of door to satisfaction of attending Marine Inspector. "OLD T" 46CFR185.30-25

Replace Compass Light - Day time operations only

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Make No. 4 WTBH watertight.

Remove debris from forepeak bilge pick up line and prove proper operation.

Search light needs new bulb to make operational.

Bar stores and laundry room need light coverings.

Light above aft steering Gear needs the protective cover.

Emergency shut off valve reach rod was worn due to rod damage. 46CFR182.20-45(b)(3)

Radar was recieving an "error" and was not working properly. Repair radar so that it operates properly.

There was an unused pipe that was cut off in the #3 void. Cap off both ends to ensure watertight integrity. 46CFR 182.25-1

Electrical wiring against bulkhead in main generator space has missing wall brackets. Replace to secure wiring. 46CFR183.1020

Hydraulic line to steering pump has a metal covering that has been dented and and has crimped the hydraulic line. Replace wasted lines and fabricate new metal covering. 46CFR128.30-1

Wiring cable in the forepeak was not supported with metal clips every 24 inches.

Port and starboard pilothouse windshields were fractured, reducing visibility and impeding navigation at night. Restricted vessel to daylight operations.

Replace floatlight line and life line due to deterioration.

Remove debris and oily mixtures from bilges

Bilge eductor would not remove water from the forepeak.

Provide proof of CO2 system charging, main engine room.

Conduct fire and MOB drills and provide proof of same.

Install hazared guards to front ends of center and port MDE's.

Replace light covers in engine room.

Replace waterlight at upper deck operating station.

Replace water light securing clips on lifefloat waterlights (battery cover hold-downs).

Reconnect lifefloat weak links and restow connecting lines aft.

Vessel needs to install self-priming fire pump prior to carry passengers.

Locate source & repair ground discovered (40 amp) during inspection. Alternatively, repair gage and show proper operation.

Remove/replace non-metallic items in bilge eductor piping system iaw 46 CFR 182.710.

Demonstrate proper operation of WTS/emergency escape hatch from steering compartment and provide means of opening/securing from both in and outside of space iaw 46 CFR 179.360

Install Deadlight covers in accordance with 46 CFR 171.119

Provide proof of annual drug and alcohol program in accordance with 46 CFR part 16 prior to carrying passengers.

Replace or renew EPIRB battery in accordance with 46 CFR 180.64, vessel's route is limited to three miles until 01 October 05 in which it is limited to the harbor.

Provide one adult lifejacket, until provided onboard vessel is limited to 148 passengers.

Provide proof of first aid/CPR training in accordance with NVIC 1-91.

Provide servicing of fixed fire extinguishing system in attendance of USCG marine inspector in accordance with 46 CFR 176.810(b)(2).

Provide supports every 24 inches on wiring in the engine room in accordance with 46 CFR 183.340.

Properly mount outlet under floor board in centerline bilge in accordance with 46 CFR 183.340.

Properly fix toilet in second port state room in accordance with 46 CFR 176.818.

Remove all plastic trash cans in accordance with 46 CFR 177.405(f).

Check bend radius on #1 steering pump hyd hose LEGACY COMPONENT DESC: Hydraulic Hose

Replace missing lagging on port eng exaust pipes. LEGACY COMPONENT DESC: Piping (exhaust)

Two through hull fittings in forward peak need to be capped or filled.

3 open ended wires in forward peak. Need to properly secure or remove. LEGACY COMPONENT DESC: Wiring

Renew lifefloats or test existing ones for proper flotation characteristics in presence of Marine Inspector. Must have capacity for 50% of total persons allowed on board (1/2 of 119=60 persons capacity).

VESSEL RESTRICTED TO 1 MILE FROM SHORE UNTIL PROPER OPERATION OF POWER DRIVEN BILGE PUMP WITNESSED BY MARINE INSPECTOR.

REPLACE RETRO-REFLECTIVE TAPE ON ALL LIFE FLOATS

INSTALL FLAME SCREEN IN STARBOARD FUEL VENT.

PROPERLY MARK EMERGENCY ESCAPE HATCH FROM GENERATOR ROOM.

Establish effective procedure for shore-side monitoring of passenger count.

Properly mark upper deck passenger capacity

Mount lifejacket donning placards near donning stations as discussed.

Update contents of first aid kit.

Update Great Lakes agreement.

Replace 3 inch fresh water service gate valve, located in port side of engine room, prior to refloating vessel from drydock and prior to the compliance date.

Renew grab lines on port aft life ring.

Prove proper operation of compass light

Provide orange liferings per 46 CFR 180.70(b)(5) or request elimination of Coastwise portion of route

Clean posts on all batteries and remove excess water from battery boxes.

IAW 46CFR180.64 vessel is resrticted to operating and carrying passengers within #NM of shore until FCC Cat. 1, 406mhz EPIRB is obtained and installed.

VESSEL IS RESTRICTED FROM CARRIAGE OF PASSENGERS UNTIL REPAIRS ARE COMPLETED ON THE PORT MAIN ENGINE REDUCTION GEAR TO THE SATISFACTION OF THEATTENDING MARINE INSPECTOR.

Provide plan for permanent repair of center reduction gear or removal of center engine/red gear/shaft assembly for implementation during November, 1999 drydocking. Address compensation for weight removed and permanent sealing of associated portions of the hull.

Vessel is restricted to operation within 1000 feet from shore pending provision of evidence of FCC Great Lakes Agreement

Vessel is restricted to ops inside Chicago breakwall pending repair/proof of proper ops of center reduction gear to satisfaction of MI. Vessel is precluded from operation with passengers after compliance date if gear not operational to satisfaction of [name withheld]2 D. E. Majors

Properly istall and hardwire crew cabin heaters or remove entirely. If heaters are kept, properly install guards in area of fan blades.

Vessel is restricted to the protected waters of the Chicago Harbor, inside of the outer breakwall, until such time as the successful completion of a scheduled safety inspection of 21 AUG 98.

Remove loose wires, deadended wires, drain tubes from below decks in bilgesof passenger cabins as discussed.

Properly remove and dispose of oily waste in bilges below deck spaces. Pro-vide receipt or documentation of proper disposal.

Replace broken handle to center main diesel engine raw water suction valve.

Prove proper operation of pressure vessel (compressed air receiver) pres- sure relief valve.

Provide missing indicator lights and lenses on main switchboard and prove proper operation of ground detection circuit.

Correct multiple dead-ended wiring and open electrical junction boxes in crew's quarters and engine room.

Provide non-conductive electrical matting in front of main switchboard.

Correct and provide missing globes, cages and lamps in engineering spaces.

Correct exhaust leak from port generator.

Provide evidence of current and updated charts and publications.

Properly mark vessel's hailing port on stern on vessel.

Acquire ship's bell.

Provide evidence of proper logs and log entries of crew training, drills and vessel maintenance.

Mark emergency escape hatches from crew's quarters, engine room & lazaretteand indicate route of egress in passageways.

Provide proper draft markings.

Provide retro-reflective tape on port aft ring buoy and floating line for port fwd ring buoy.

Provide evidence of current FCC Great Lakes Agreement.

Vessel is restricted to daylight oprations only when operating without required masthead and anchor lights.

Make repairs to vessel's radar and running lights prior to 13 July 98 to the satisfaction of the attending marine inspector.

Vessel is restricted to the protected waters of the Chicago Harbor, inside of the outer breakwall, when operating with proper running lights but with out required radar.

Prior to carrying passengers, repair fuel shut off connection.

Prior to carrying passengers, service/replace portable fire extinguishers.

Patch life floats with appropriate material.

General Housekeeping - clean all staterooms, particularly those with alcohol and used as crew quarters. Clean under bar areas.

Prior to carrying passengers, service fixed fire system in engineroom.

Prior to operating at night, or restricted visibility, replace/fix all waterlights.

Reduce passenger capacity to 146 until 157 life jackets are aboard.

Affix retro-reflective tape in 4 spots on all liferings.

Mark life jacket containers with quantity and type of jackets stowed.

Provide 6 current red hand flares.

Provide current FCC Great Lakes Agreement.

Install electrical stuffing tube for thru deck penetration located under seat forward of deckhouse.

Vessel is restricted to not more than one (1) mile from shore until the float lights attached to each life float are repaired or replaced.

Install cover on junction box located at forward end of centerline engine.

Install light fixture globe, junction box cover and properly strap all wiring in place with metal wire ties.

Mark both sides of life floats with vessels name and life float capacity.

Mark fore and aft draft marks and midship freeboard marks on hull in contrasting colors.

Install marine approved portable extinguisher bracket at upper deck bar.

Properly install emergency light in engine room.

Permanently wire with approved marine type wire both beer cooler refridgeration pumps and outlet plug for galley refidgerator under PORT bridge stairwell.

PROVE PROPER OPERATION OF CENTERLINE MAIN DIESEL ENGINE.

REPAIR L/O PRESSURE GAUGE FOR THE STBD MAIN DIESEL ENGINE, LOCATED ON THE BRIDGE CONSOLE.

REPAIR OR REPLACE THE MAGNETIC COMPASS ON THE BRIDGE CONSOLE.

PROVIDE 2 EACH USCG APPROVED FIRE HOSE NOZZLES, 1 EACH PER FIRE STATION.

PROVIDE 1 EACH ADULT PFD TO REPLACE MISSING PFD. VESSEL IS RESTRICTED TO CARRYING 156 PERSONS.

PROVE PROPER OPERATION OF- DECCA RADAR.

PROVE PROPER OPERATION OF CENTERLINE MAIN DIESEL ENGINE.

RENEW FIRE HOSE ON FIRE STATION #2.

PROVIDE 2EA WATERLIGHTS FOR LIFE FLOATS WITHOUT WATER LIGHTS.

REPLACE 2EA MISSING ADULT PFD'S.

PROVE PROPER OPERATION OF SMOKE DETECTORS INSTALLED IN STATEROOMS.

POST STABILITY LETTER.

LABLE FIRE DAMPER CLOSURES IN AFT SALON (2EA ON PORTSIDE, 1EA ON STDBSIDE).

POST EMERGENCY CHECK OFF LIST.

INSTALL A SCREW DOWN VALVE IN BILGE SUCTION PIPE TO FOREPEAK IN WAY OF THE COLLISION BULKHEAD.

PROVIDE VENT PIPES FWD ENGINEROOM BULKHEAD UPPER OUTBOARD CORNERS P/S OF A STRENGHT EQUAL TO THE BULKHEAD.

REMOVE WATER TIGHT DOOR AT FRAME 24 AND WELD UP OPENING.

REMOVE EXISTING DOORS AT FRAMES 9 AND 18 AND INSTALL CLASS I QUICK ACTING WATER TIGHT DOORS AS PER 46CFR 170.270 (A) (B)

PROVIDE (1) ADULT P.F.D. FOR A TOTAL OF 157 AS PER CERTIFICATE OF INSPECTION. THE NUMBER OF PERSONS IS LIMITED TO 156 UNTIL THIS ITEM IS COMPLETED.

REPAIR RUDDER ANGLE INDICATOR.

REPAIR EMERGENCY SHUT DOWN ON STARBOARD MAIN ENGINE.

INSTALL NEW PROPER SIZE GROMMETS ON THE ELECTRICAL PENETRATIONS FOR THE TRANSDUCER SEA CHEST COVERS TO THE SATISFACTION OF THE COGNIZANT OCMI.

PROVIDE MEANS TO SECURE AFT COMPARTMENT VENTILATION DUCTS TO MAKE WATER- TIGHT ON AFT DECK TO THE SATISFACTION OF THE COGNIZANT OCMI.

PAINT NAME AND HAILING PORT ON STERN OF VESSEL TO THE SATISFACTION OF THE COGNIZANT OCMI.

COMPLETE INSTALLATION OF FORWARD WATERTIGHT HATCHES IN MAIN DECK BY PROVIDING GASKET AND BOLTING INTO PLACE TO THE SATISFACTION OF THE COGNIZANT OCMI.

REPAIR GASKETS ON MASTER AND AFT ENGINEROOM WATERTIGHT DOORS AND PROVE WATERTIGHT USING CHALK TEST TO THE SATISFACTION OF THE COGNIZANT OCMI.

INSTALL CENTER SHAFT PROPELLER WITH LOCK NUTS AND COTTOR KEYS. CENTER ENGINE CONTROLS MUST BE DISCONNECTED TO PREVENT ITS USE UNTIL NEW PROPELLERIS INSTALLED. ITEMS TO BE COMPLETED TO THE SATISFACTION OF THE COGNIZANT OCMI.

PROVIDE AND SUBMIT REVISED MIDSHIP SECTION, OUTBD AND INBD PROFILE, FUEL SYSTEMS, ARRANGEMENT OF DECKS, MACHINERY INSTALLATIONS, ELECTRICAL INSTALL-ATIONS, PIPING SYSTEMS, HULL PENETRATIONS, SHELL CONNECTIONS, FIXED CO2 SYSTEM, PRIOR TO THE COMPLIANCE DATE.

REMOVE GALLEY STOVE OR PROVIDE VENTILATION HOOD, PRIOR TO THE COMPLIANCE DATE.

INSTALL PERMANENT 20 X 20 MESH FLAME SCREEN IN MSD TANK VENTS, PRIOR TO THECOMPLIANCE DATE.

SECURE DECK PLATES IN ENGINEROOM AND GENERATOR ROOM PRIOR TO THE COMPLINCE DATE.

SECURE, CONNECT OR REMOVE LOOSE WIRES IN ENGINEROOM, GENERATOR ROOM AND BRIDGE, PRIOR TO THE COMPLIANCE DATE.

CLEAR EXCESS AND LOOSE GEAR FROM BRIDGE/PILOT HOUSE, PRIOR TO THE COMPLIANCE DATE.

MAKE PERMANENT REPAIRS TO THE BRIDGE ENGINE CONTROLS AND GAUGES, PRIOR TO THE COMPLIANCE DATE.

PERFORM HYDROSTATIC TEST AT 1.5 MAWP ON ALL NEWLY INSTALLED PIPING SYSTEMS,PRIOR TO THE COMPLIANCE DATE.

PROVIDE HAND FIRE PUMP, PRIOR TO THE COMPLIANCE DATE.

PROVIDE A CLOSURE DEVICE FOR THE VENTILATION DUCTS FOR THE GENERATOR ROOM AND ENGINEROOM, PRIOR TO THE COMPLIANCE DATE.

PROVIDE INDICATOR LIGHTS AND CIRCUITS FOR ALL WATERTIGHT DOORS WITH PANEL INSTALLED ON BRIDGE, PRIOR TO THE COMPLIANCE DATE.

PROVIDE CALCULATIONS FOR REVIEW FOR INCLINE STABILTY TEST, AND CONDUCT THE INCLINE STABILITY TEST PRIOR TO THE COMPLIANCE DATE.

MOUNT PORTABLE FIRE EXTINGUISHERS, ONE B-I FOR EACH STATEROOM BELOW THE MAIN DECK. TO BE COMPLETED PRIOR TO THE COMPLIANCE DATE.

LABEL ALL HEADS APPROPRIATELY, PRIOR TO THE COMPLIANCE DATE.

REPAIR 5" CRACK ON FWD HATCH COVER DECK ATTACHMENT, REINSTALL RETAINING PINON FWD HATCH TO ALLOW CLOSING AND SECURING WATERTIGHTNESS, TO BE COMPLETED PRIOR TO THE COMPLIANCE DATE.

REPLACE SIGHT GLASS FOR FUEL TANKS WITH REAL GLASS AND AUTOMATIC BALL CHECKVALVES ON EACH END OF SIGHT GLASS, TO BE COMPLETED PRIOR TO THE COMPLIANCE DATE.

INSTALL LADDER FOR EMERGENCY ESCAPE FROM ENGINE ROOM/GENERATOR ROOM AND STENCIL HATCH ON DECK TO READ "KEEP CLEAR EMERGENCY ESCAPE", TO BE COMPLETED PRIOR TO THE COMPLIANCE DATE.

ADJUST WATERTIGHT DOOR TO OWNERS STATEROOM TO ENSURE DOOR IS WATERTIGHT, TOBE COMPLETED PRIOR TO THE COMPLIANCE DATE.

PROVIDE ADMEASUREMENT CERTIFICATION, PRIOR TO THE COMPLIANCE DATE.

INSTALL PERMANENT 30 X 30 MESH FLAME SCREEN IN FUEL TANK VENTS, PRIOR TO THE COMPLIANCE DATE.

REPLACE FIRE HOSE NOZZLE WITH ONE THAT FITS FIRE HOSES.

REPLACE MISSING FLOATING RINGBOUY.

PROVIDE EVIDENCE OF MEETING FCC REQUIREMENTS (VALID FCC CERT.)

PROCURE AND CARRY EMERGENCY PROTECHNICS SIGNALS AS PER 46CFR180-35-5(A)

SERVICE PORTABLE FIRE EXT. IN PRESENCE OF A MARINE INSPECTOR

SERVICE AND TEST INSTALLED CO2 FIRE EXTINGUISHING SYSTEMS IN THE PRESENCE OF A MARINE INSPECTOR

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

CONDUCT RADIO CHECK TO PROVE OPERATION OF RADIOS.

REPLACE BATTERIES IN RING BOUY FLOATING LIGHTS

REPLACE BATTERIES IN TWO LIFEFLOAT FLOATING LIGHTS.

REPLACE LIFEFLOAT FLOATING LIGHT THAT IS MISSING.

ADD ONE (1) CLAMP TO PORT ENGINE COOLER LINE.

REPLACE SLEEVE FOR STBD EXHAUST ON CENTER LINE ENGINE.

ADD THREE (3) CLAMPS TO SLEEVE FOR STBD ENGINE, STBD EXHAUST SLEEVE.

CENTER LINE ENGINE STBD EXHAUST ADD ONE (1) CLAMP AND REPLACE MOVABLE SLEEVE.

MOVE 32 POINT LIGHT TO MAST HEAD FROM STERN OR PROVIDE PROPER SHEILDING AS REQUIRED BY INLAND RULES.

PROVE OPERATION OF DECCA 060 RADAR

REPAIR W/T DOOR INFWD CABIN BULKHEAD TO MAKE SAME W/T.

PROCURE CLASS C EPRIB AND MOUNT SAME.

POST EMERGENCY CHECK OFF LIST.
