KEPOIKAI II

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspections. Jacketing of cables lead to house battery are damaged with exposed strands. Replace cabling with 14 AWG (Gauge) UL Boat or UL Marine cable to satisfaction of attending marine inspector. 46 CFR 183.01-15(a) Old T

A vessel is inspected for compliance with the standards required by this subchapter. Machinery, equipment, materials, and arrangements not covered by standards in this subchapter may be inspected in accordance with standards acceptable to the cognizant OCMI as good marine practice. Bolt on stbd side chain plate for lower shroud pulling through support. Add washer and reset bolt to satisfaction of attending marine inspector.

Abandon ship and man overboard drills and training shall be logged or otherwise documented for review by the Coast Guard upon request. Vessel crew unable to provide records of abandon ship or fire drills. Conducted on-site training and witnessed crew appropriately log completed man overboard and fire drill. 46 CFR 185.520(f)

An adult life jacket must be provided for each person carried on board a vessel. Six adult life jackets found to be unserviceable. Repair or replace life jackets. Vessel is restricted to 34 total persons on board. 46 CFR 180.71(a)

The master of the vessel shall ensure that the EPIRB's battery is replaced after it is used, or before the date required by FCC regulations in 47 CFR part 80, whichever comes sooner. Battery was expired. Replace battery or EPIRB. Vessel operation is restricted to within 3 nm. 46 CFR 185.728(b)

Portable fire extinguishers must be located so that they are clearly visible and readily accessible from the space being protected. Operating station portable fire extinguisher stored in a location not and not mounted at the operating station as required by Table 181.500(b). Mount at operating station. 46 CFR 181.520

A vessel must comply with the applicable requirements for any radio requirements for a station license and installation certificates to be issued by the Federal Communications Commission, as set forth in 47 CFR Part 80. Radio microphone not located at the primary operating station as per Title 47 Subpart S 80.905(d) A VHF-DSC radiotelephone installation or a remote unit must be located at each steering station except those auxiliary steering stations which are used only during brief periods for docking or for close-in maneuvering. A single portable VHF-DSC radiotelephone set meets the requirements of this paragraph if adequate permanent mounting arrangements with suitable power provision and antenna feed are installed at each operator steering station. 46 CFR 184.502

Except as otherwise provided in this section every vessel must be fitted with a suitable magnetic compass designed for marine use, to be mounted at the primary operating station. Vessel missing compass mounted at primary operating station. Provide a compass and prove illumination to the satisfaction of the attending Marine Inspection. 46 CFR 184.402

A vessel must carry either a first-aid kit approved under approval series 160.041 or a kit with equivalent contents and instructions. For equivalent kits, the contents must be stowed in a suitable, watertight container that is marked “First-Aid Kit”. A first-aid kit must be easily visible and readily available to the crew. First aid kit missing aspirin and ammonia inhalants. Provide. 46 CFR 184.710

Each vessel must be equipped with at least two operable portable battery lights. One of these lights must be located at the operating station and the other at the access to the propulsion machinery space. Missing one portable light. Provide. 46 CFR 183.430

As appropriate for the intended voyage, a vessel must carry adequate and up-to-date: Charts of large enough scale to make safe navigation possible; (2) U.S. Coast Pilot or similar publication; (3) Coast Guard Light List; (4) Tide tables; and (5) Current tables. Missing current tables. Provide. 46 CFR 184.420

A durable placard must be posted next to all radiotelephone installations with the emergency broadcast instructions and information, specific to the individual vessel. Missing emergency broadcast instructions placard at radiotelephone installation. Provide. 46 CFR 184.506

A vessel must comply with the applicable design, equipment, personnel, procedures, and record requirements of 33 CFR parts 151. Missing garbage placard IAW 33 CFR 151.59. Provide. 46 CFR 184.702

Remote fuel shutoff stations must be marked in clearly legible letters at least 25 millimeters (1 inch) high indicating purpose of the valve and direction of operation. Missing the above requirement. Provide the above. In lieu of the valve direction, add "Pull fuel supply line quick disconnect fitting to disconnect from portable tank." 46 CFR 185.608

Battery chargers must have an ammeter connected in the charging circuit. Provide ammeter. 46 CFR 183.350(f)

Twist on type connectors may not be used for making joints in cables, facilitating a conductor splice, or extending the length of a circuit. Several wires in port aft compartment with twist on type connectors. Make connection with pressure/crimp type wire connector. 46 CFR 183.340(i)(2)

Electrical equipment on a vessel must be installed and maintained to: Minimize accidental personnel contact with energized parts. Exposed electrical wire strands in port aft compartment. Resolve to the satisfaction of the attending MI. 46 CFR 183.200(c)

An EAP training program must be conducted for the employer's crew members and supervisory personnel. The training program must include at least the following elements: the effects and consequences of drug and alcohol use on personal health, safety, and work environment; the manifestations and behavioral cues that may indicate drug and alcohol use and abuse; and documentation of training given to crew members and the employer's supervisory personnel. Supervisory personnel must receive at least 60 minutes of training. Crew members and supervisory personnel never received the above required training. Provide a roster signed by crew members and supervisory personnel. Also, provide training material used to conduct the training to the attending MI. 46 CFR 16.401(b)

A visual and audible alarm must be provided at the operating station to indicate a high water level in each of the following normally unmanned spaces: (3) A space with a non-watertight closure. The port high water level alarm is inoperable. Prove proper operation of the high water level alarm to the satisfaction of the Marine Inspector.

This part is intended to provide a minimum standard of regulations for electrical installations and equipment that will result in a vessel that is reasonably safe from electrical shock of personnel. Electrical terminal in aft port battery compartment is exposed creating an electrical or fire hazard. Properly cover terminals to the satisfaction of the attending marine inspector.

A vessel must comply with the structural design requirements of one of the standards listed. Stbd rudder backing plate showing signs of deterioration, renew plate and bolts to the satisfaction of attending marine inspector.

Except as otherwise allowed by this subpart, a vessel must comply with the structural design requirements of one of the standards listed below for the hull material of the vessel. Vessel has area of fiberglass damage on the inboard stbd side of vessel under the deck. Clean and submit repair proposal to the satisfaction of attending inspector.

Except as otherwise allowed by this subpart, a vessel must comply with the structural design requirements of one of the standards listed below for the hull material of the vessel. Vessel has areas of fiberglass damage and exposed wood forward of the outboard engines submit repair proposal to the satisfaction of attending inspector.

An adult life jacket must be provided for each person carried on board a vessel. Vessel is restricted to 24 total adults due to lack of properly outfitted lifejackets. Replace/repair damaged lifejackets.

Vessels operated solely within 20 nautical miles of land must be equipped with a VHF-DSC radiotelephone installation meeting the requirements of § 80.1101(c) (2). VHF radio missing MMSI and LAT/LONG (position) for digital select calling (DSC) operation. Provide radio with GPS input and DCS capability.

Deck rails must be designed and constructed to withstand a point load of 200 pounds applied at any point in any direction, and a uniform load of 50 pounds per foot applied to the top rail in any direction. Forward railing stanchions on port and starboard side of the vessel were found to be loose. Investigate wasted foundation. Provide repair plan to repair railing stanchion back to original strength.

A vessel must comply with the applicable requirements for any radio and EPIRB installations, including the requirements for a station license and installation certificates to be issued by the Federal Communications Commission, as set forth in 47 CFR Part 80; Vessel did not have FCC Station license. Prove validity of station license.

A vessel is inspected for compliance with the standards required by this subchapter. Machinery, equipment, materials, and arrangements not covered by standards in this subchapter may be inspected in accordance with standards acceptable to the cognizant OCMI as good marine practice; Vessel's preventative maintenance plan (PMP) did not have inventory of rigging components to include: the age of component, size, type of material, and a replacement schedule for all rig components based on inspection results, service history, and manufacturer or designer recommendations. Add inventory of rigging components to PMP iaw NVIC 02-16.

At least one ring life buoy must be fitted with a lifeline. If more than one ring life buoy is carried, at least one must not have a lifeline attached. Each lifeline on a ring life buoy must: Be of at least 18.3 meters (60 feet) in length; Lifeline on vessel's ring life buoy was 50 feet. Attach lifeline that is at least 60 feet in length.

On a vessel of at least 26 feet in length, a visible and audible alarm must be provided at the operating station to indicate a high water level in each of the following normally unmanned spaces; vessel only had one visible and audible alarm and is unable to indicate which space has the high water level. Add separate visible and audible indicator to determine the space that has the high water level.

Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment and electrical shock; Weight of vessel shore tie is too heavy and is removing the plug from it's connection to vessel batteries. Add support to support weight of shore tie cable.

At each initial and subsequent inspection for certification, the owner or managing operator shall be prepared to test the steering systems of the vessel and make them available for inspection to the extent necessary to determine that they are in suitable condition and fit for the service intended; the port rudder bolt assembly is not sized appropriately. Replace assembly with appropriately sized components.

Replace 2 unserviceable lifejackets. Passenger count is reduced from 37 to 35 until corrected.

Replace reflective tape on all lifejackets.

Add in sufficient amount of pain reliever and ammonia inhalants to first aid kit.

Post signage indicating location of fuel shutoff valve

Remove or cap dead end wiring near battery installation.

Vessel did not have updated chart onboard.

Port and starboard non-watertight compartments were not fitted with a high level bilge alarm.

Noted corroded throttle cable on stbd outboard engine.

VSl must post Stability Letter.

Vsl must provide rigging log per CID Note 13.

Provide new battery and hydrostatic release unit for EPIRB.

Repair starboard stanchion third aft from bow.

Make repairs to steering gear bushings.

Determine extent of damage to port and starboard hull attachment to wing deck.

Determine extent of damage to port anchor attachment point on bow.

Sand down and determine extent of wood rot in port aft compartment.

Replace aft hatches both port and starboard.

Provide hose clamp for sewage overboard discharge.

Repair gasket on forward starboard hatch.

Provide FCC Safety Radio-telephone certificate.

Provide local Coast Pilot [name withheld], Local Notice to Mariners and Tides publications.

Repair hook for shore power in port aft compartment.

Make repairs to wiring splice for stereo.

Provide one additional fire bucket.

Remove all dead end wiring from vessel.

Satisfy all required personnel to be enrolled into testing pool.

Prove implementation of EAP training and policy.

Submit 2008 MIS report.

Repair cracked fiberglass stbd hull internal 3rd frame fwd.

Repair/replace remount fwd an daft mounting brackets for trampoline center supports.

Repair/replace mast shroud spreaders where cracked. (wood)

Repair mast & sail rigging as per approved repair proposal.

Provide survey report from qualified sail rigging surveyor attesting to the satisfactory installation of modified mast and sail rigging as per approved repair proposal.

Replace worn steering linkage bushings.

Replace all fuel hoses for outboards.

Refasten external wood cross member between hulls.

In Head Compartment, remove old bilge piping.

In port aft compartment, remove old bilge piping.

Replace all expired medical items in first aid kit.

Replace plastic fuel tanks with metal tank.

Install battery covers for boxes in port aft compartment.

Provide adequate DAPI program.

Replace rotted deck bem in aftmost space of port hull LEGACY COMPONENT DESC: Deck Plating

Replace bolt on bracket of aft port hull which secures the rudder guides with an appropriate size. LEGACY COMPONENT DESC: Side Shell

Replace rotted wood backing plates on chain plates for the port and starboard hulls. LEGACY COMPONENT DESC: Bracket

Re-glass starboard hull forepeak at the forwardmost frame. LEGACY COMPONENT DESC: Hull Plating

Passenger count is not being maintained IAW 46CFR185.504. LEGACY COMPONENT DESC: Passenger Count

Repair damage to hull caused by collision with vessel Nahoku II.

Line on Water Light for Ring Life Buoy was longer than required. LEGACY COMPONENT DESC: Self-igniting Lights

Eye wash and inhalants were expired. LEGACY COMPONENT DESC: First Aid Kit

Provide a U.S. Coast Pilot and a Coast Guard Light List in accordance with 46 CFR 184.420.

Provide documentation of employee and supervisor drug and alcohol training in accordance with 46 CFR 16.

Complete removal of sea valves and closure of through-hull fittings to the satisfaction of the attending marine inspector.

Reglass approximately 6" outboard of stbd sea valve.

Reglass port side frames 3 and 4 along keel.

Reglass stbd side frame 6 along keel.

Provide proof of emergency training.

Replace handle on Y-valve for MSD discharge.

Provide proof of man overboard/abandon ship training.

Provide proof of firefighting training

Provide proper container for distress signals.

Provide evidence of drug awareness training for vessel's crew members. Mininum of sixty minutes required for supervisors.

CONDUCT STABILITY TEST TO THE SATISFACTION OF THE ATTENDING MARINE INSPECTOR.

POST EMERGENCY CHECKOFF LIST.

ATTACH LINE AND WEAK LINKS BETWEEN VESSEL HULL AND LIFE FLOATS.

PROVIDE ADDITIONAL B II FIRE EXTINGUISHER TO MEET MINIMUM REQUIREMENTS.

REMOVE AND REPLACE THE BEAM SUPPORTING THE LOWER SHROUD CHINEPLATE IN THE PORT HULL.

REMOVE AND REPLACE ALL ROTTEN WOODEN DECK IN WAY OF THE DAGGERBOARD TRUNK IN THE STARBOARD HULL.

REMOVE AND REPLACE ALL ROTTEN WOODEN DECK IN WAY OF THE DAGGERBOARD TRUNK IN THE PORT HULL.

ADVISE MSO HONOLULU AT 546-5564, AT LEAST WEEKLY, THE PROGRESS IN REPLACINGTHE VESSEL'S MAST AND RIGGING. A COAST GUARD INSPECTOR MUST VISIT VESSEL PRIOR TO OPERATION.

INSTALL AND SECURE BATTERIES IN PROPER CONTAINER.

PROVIDE WATERTIGHT ELECTRICAL JUNCTION BOX FOR WIRING WHICH SERVICES THE MAST LIGHT.

PORT AN EMERGENCY CHECK-OFF LIST IN A CONSPICUOUS LOCATION.

PROVIDE WATERTIGHT CONTAINER FOR DISTRESS SIGNALS.

REMOVE OBSOLETE AND UNUSED WIRING FROM PORT HULL.

REPLACE BROKEN TRANSVERSE DECK BEAM IN PORT HULL FOREPEAK ARM.

MOUNT PORTABLE FIRE EXTINGUISHERS IN ENGINE AREA AND COCKPIT AS REQUIRED BYCOI.

REMOUNT ELECTRICAL CABLE IN WING SECTION OF VESSEL, TO THE BULKHEAD.
