DISNEY WONDER

An international Oil pollution Prevention Certificate shall be issued, after an initial or renewal survey to any ship of 400 gross tonnage and above which are engaged in voyages to ports or offshore terminals under jurisdiction of other Parties to the present Convention. Issued IOPP certificate included an OWS and OCM, which was no longer on the vessel. MARPOL 2017, Annex I/7.1 (10c)

The construction of all doors and door frames in "A" class divisions, with the means of securing them when closed, shall provide resistance to fire as well as to the passage of smoke and flame, as far as practicable, equivalent to that of the bulkheads in which the doors are situated. Sliding fire door 4712 on the main theater stage did not close when activated. 74SOLAS97, II-2/30.2 (10c)

Stairway enclosures in accomodation and service spaces shall have direct access from the corridors and be of a sufficient area to prevent congestion, having in view the number of persons likely to use them in an emergency. PSCO observed multiple trash cans in passengers stairway enclosures. 74 SOLAS 97 II-2/29.2

Spaces are classified according to their fire risk as shown in categories (1) to (14) below. Port and starboard potable water tank compartments in MVZ 6 is category (10) where storage of combustible materials stored is prohibited. PSCO observed various combustible materials stored in port/starboard side potable water tank compartments. 74SOLAS 97 II-2/26.2.2

An International Oil Pollution Prevention Certificate shall be issued, after an initial or renewal survey to any ships of 400 gross tonage and above which are engaged in voyages to ports or offshore terminals under the jurisdiction of other Parties to the present Convention. IOPP supplemental not showing correct oil content meter MEPC approval. MARPOL 2017 Annex I / 7.1

Above the bulkhead deck there shall be at least two means of escape from each main vertical zone or similarly restricted space or group of spaces at least one of which shall give access to a stairway forming a vertical escape. PSCO observed a locked emergency exit with a damaged thumb lock in the crew recreation room on I-95, deck 1. 74 SOLAS 97 II-2/28.1.2

Stairway enclosures in accomodation and service spaces shall have direct access from the corridors and be of a sufficient area to prevent congestion, having in view the number of persons likely to use them in an emergency. PSCO observed a scooter blocking fire door 01.501 74 SOLAS 97 II-2/29.2

Each section of sprinklers shall include means for giving a visual and audible alarm signal automatically at one or more indicating units whenever any sprinkler comes into operation. Such alarm systems shall be such as to indicate if any fault occurs in the system. Section valve 20 failed to give audible and visual alarm at the bridge upon activation. 74 SOLAS 01 II-2/12.1.2

Sprinklers shall be placed in an overhead position and spaced in a suitable pattern. Sprinkler head in way of fire door FSD 01/5/10 is blocked by ventilation duct. SOLAS 97 11-2/12.3 Code: 07109

Every ship of 400 gross tonnage and above and every ship which is certified to carry 15 or more persons shall be provided with a Garbage Record Book. Vessel is logging disposal of multiple mattresses in GRB but has no receipts verifying removal. MARPOL 2017 Annex V / 10.3 Code: 14503

Above the bulkhead deck there shall be at least two means of escape from each main vertical zone or similarly restricted space or group of spaces at least one of which shall give access to a stairway forming a vertical escape. One of the means of egress is blocked in way of Air Condition station AC 01-2-04/5. 74SOLAS97 11-2/28.1.2 CODE: 07120

Crew members shall be trained to be familiar with the arrangements of the ship as well as the location and operation of any fire-fighting systems and appliances that they may be called upon to use. 02 crew members in charge of crew galley on deck 01 were unfamiliar with fixed fire suppression system for deep fat fryers. 74 SOLAS 20 11-2/15.2.2.1 Code: 04109

Fire protection systems and fire-fighting systems and appliances shall be maintained ready for use. Manual call point (A0805) was observed to be inoperable. 74 SOLAS 20 II-2/14.1.1 10c

Doors and door frames in "B" class divisions and means of securing them shall provide a method of closure which shall have resistance to fire equivalent to that of the divisions. B-15 door IVO FSD 04-03-06 did not latch upon closing. 74 SOLAS 97 II-2/31.1 10c

All waste-receptacles shall be constructed of non-combustible materials with no openings in the sides or bottom. Plastic garbage cans were used to store combustible garbage in the main laundry, spa treatment rooms, main theater and throughout the embarkation deck. 74 SOLAS 97 II-2/18.5 16a

The machinery...associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended. While testing the emergency diesel generator, PSCO observed a fuel leak (approximately 1 drop/10 sec) on the fuel priming pump. 74 SOLAS 04 II-1/26.1 10c

Each section of sprinklers shall include means for giving a visual and audible alarm signal automatically at one or more indicating units whenever any sprinkler comes into operation. Such alarm systems shall be such as to indicate if any fualt occurs in the system. Upon testing, sprinkler section valves 39 & 50 did not give a visual or audible alarm when in operation. 74 SOLAS 01 II-2/12.1.2 10c

EVERY COMPANY SHOULD DEVELOP, IMPLEMENT, AND MAINTAIN A SAFETY MANAGEMENT SYSTEM WHICH INCLUDES THE FOLLOWING FUNCTIONAL REQUIREMENTS: INSTRUCTIONS AND PROCEDURES TO ENSURE SAFE OPERATION OF SHIPS. VESSEL FAILED TO IMPLEMENT ITS SMS WITH RESPECT TO CYBER RISK MANAGEMENT. PASSWORD AND USERNAME OPENLY DISPLAYED ON LAPTOP THAT WAS CONNECTED TO THE SERVER IN SERVER ROOM ON DECK 2. RECOMMEND INTERNAL AUDIT TO ENSURE SMS CYBER HYGIENE IMPLEMENTATION. 74 SOLAS(14)/IX/3.1 & ISM Code 1.4 Action Taken: 10C

...the minimum fire integrity of all bulkheads and decks shall be as prescribed in tables 26.1 to 26.4. Approximately 10" of A-60 insulation in the engine room overhead was missing on both the port and starboard sides, aft of diesel generators 4 & 5. SOLAS 97 II-2/26.1

All survival craft required to provide for abandonment by the total number of persons on board shall be capable of being launched with their full complement of persons and equipment within a period of 30 min from the time the abandon ship signal is given. Vessel did not have an appropriate spare liferaft to deploy to prove crew competency during the abandon ship drill. SOLAS 97 III/20.1.4

Electrical installations shall be such that the safety of passengers, crew and ship from electrical hazards will be ensured. On deck 1, in the passageway outside the carpenters workshop, an extension cord was zip-tied in place for permanent use of the ships computer. SOLAS 04 II-1/40.1.3

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons onboard. PSCO observed a fuel leak on the fuel priming pump on the emergency diesel generator. SOLAS (20) I/11(a)

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. It was discovered that there were exposed, dead end wiring from unknown sources in the port, upper HVAC room and in common ways on various decks of the vessel presenting a potential electrical hazard to personnel. All dead end wiring on-board must be capped and/or removed. Must correct to the satisfaction of attending RO that this has satisfactorily been completed in accordance with the vessel maintenance plan prior to sailing with passengers.

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Port/starboard electrical isolator handles on Evaporator electrical panel need to be replaced to the satisfaction of the attending RO.

The purpose of this chapter is to require the fullest practicable degree of fire protection, fire detection, and fire extinction in ships. While testing fuel oil valves on main engines, PSCOs discovered 01 leaking valves from valve stem and bonnet. SOLAS 1997 CH II-2 REG 2.1

Sprinklers shall be placed in an overhead position and spaced in a suitable pattern to maintain an average applicaiton rate. Sprinklers at the following locations found recessed into drop ceiling: 01 at FSD 01/6/12 and 02 in "zoo" space near Buena Vista Theater. Carpenter shop storage found above sprinkler heads. Correct storage height markings. SOLAS 1997 CH II-2 REG 12.3

Suitable instructions and component spares for testing and maintenance shall be provided. Suitable instructions for testing and maintenance detector C1168 could not be tested. No equipment or procedures onboard for testing. SOLAS 1997 CH II-2 REG 13.1.12

Fire doors in main vertical bulkheads and stairway enclosures shall satisfy the following requirements: The doors shall be self-closing and shall have an approximately uniform rate of closure of no more than 40s and no less than 10s with the ship in the upright position. During exam, PSCOs tested numerous fire doors that failed to close in the required amount of time.

found fire screen doors reopening greater thank 1 meter when panic bar was depressed. SOLAS (97) II-2/30.4.2 50 a,c

found loud speaker on deck 11 port side in A/C space not properly installed. SOLAS(97) II-1/40.1.3 10C

a hole in overhang on deck 11 was allowing water to drip into a light fixture. SOLAS(97) II-1/40.1.3 50a,c

001- Only public spaces, corridors, lifts, public toilets, special category spaces, other escape stairways, and external areas are permitted to have direct access to these stairway enclosures. While the HR office is a category (7) accommodation space, it does not qualify as a public space, and the direct access must be removed. 74SOLAS (2004 Consd) II-2/Reg 13.3.2.3- 50ac

0950 - Condition after Class Survey, While docked alongside at the POM, the vessel sustained a black out event lasting 26 minutes. The vessel has not been able to identify the cause involved with the black out event and cannot guarantee the black out from reoccuring. 74SOLAS (14) CH. I/11
