LEDGER T

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI, except during an emergency. When repairs are made during an emergency, the owner, managing operator, or master shall notify the OCMI as soon as practicable after such repairs or alternations are made. Aluminum hull plating was found with a 6-inch longitudinal crack next to the stbd generator exhaust. Submit a repair proposal to the attending marine inspector.

A vessel which, under § 178.310 of this part, complies with requirements in sub chapter S of this chapter, must have stability details on the vessel's Certificate of Inspection, a stability letter issued by the cognizant Officer in Charge, Marine Inspection (OCMI) or the Commanding Officer, Marine Safety Center, or an approved stability booklet. BILGES: The vessel’s bilges and voids shall be kept pumped to minimum content at all times consistent with pollution prevention requirements. Vessel's engine room bilge had approximately 4-6 inches of oily water in centerline bilge. Clean out bilges to the satisfaction of attending marine inspector.

When the exhaust cooling water system is separate from the engine cooling water system, a suitable warning device, visual or audible, must be installed at the operating station to indicate any reduction in normal water flow in the exhaust cooling system. Port exhaust audible and visual warning device at the operating station was inoperable. Repair alarm panel or flow switch and provide satisfactory test of port exhaust audible and visual alarm to the attending marine inspector.

A vessel must comply with the applicable requirements for any radio and Electronic Position Indicating Radio beacon (EPIRB) installations, including the requirements for a station license and installation certificates to be issued by the Federal Communications Commission, as set forth in 47 CFR part 80. Vessel master did not have a valid radio operator permit. Present valid radio operator permit for master on board during inspection or show a vessel log that can prove there is a crew member on board during vessel operation with a valid radio operator permit to the attending marine inspector.

On a vessel of not more than 19.8 meters (65 feet) in length carrying more than 49 passengers, and on a vessel of more than 19.8 meters (65 feet) in length, each hose must be lined commercial fire hose that conforms to UL 19 or hose that is listed and labeled by an independent laboratory recognized by the Commandant as being equivalent in performance. The port side hose was found leaking through a point approximately two feet from the fire plug end of the hose. Replace with approved and properly labeled hose and destroy the damaged hose.

A vessel must be provided with a satisfactory arrangement for draining any watertight compartment, other than small buoyancy compartments, under all practicable conditions. The vessel was unable to get suction from the after bilge pickup in the engine room. The forward bilge suction was functioning. Demonstrate proper operation of engine space bilge suction as designed and approved.

A vessel of at least 7.9 meters (26 feet) in length must be provided with individual bilge lines and bilge suctions for each watertight compartment, except that the space forward of the collision bulkhead need not be fitted with a bilge suction line when the arrangement of the vessel is such that ordinary leakage may be removed from this compartment by the use of a hand portable bilge pump or other equipment, and such equipment is provided. The fore peak bilge suction line was found wasted and unable to provide adequate suction for dewatering. Vessel made temporary repairs using electrical tape and demonstrated suction, and provided additional electric submersible pump to provide space dewatering. Make proper permanent repairs or provide repair plan with appropriate intermediate repairs.

The number of penetrations in a watertight bulkhead must be minimized. A penetration in a watertight bulkhead must be as high and as far inboard in the bulkhead as practicable, and made watertight. Penetrations in the transverse watertight bulkheads located at frames 10 and 20 were found with unsealed cable penetrations. Make penetrations watertight.

All machinery and equipment must be installed and maintained in such a manner as to afford adequate protection from causing fire, explosion, machinery failure, and personnel injury. Macerator pump was found installed with only zip ties. Properly mount macerator pump.

At each inspection for certification and at every other vessel inspection the bilges and other spaces may be examined to see that there is no excessive accumulation of oil, trash, debris, or other matter that might create a fire hazard, clog bilge pumping systems, or block emergency escapes. Galley bilge was found with excessive trash and debris. Remove items and debris.

A vessel must carry either a first-aid kit approved under approval series 160.041 or a kit with equivalent contents and instructions. For equivalent kits, the contents must be stowed in a suitable, watertight container that is marked “First-Aid Kit”. A first-aid kit must be easily visible and readily available to the crew. First aid kit provided did not meet 46 CFR 160.041. Provide complete and current first aid kit.

Spanner wrenches must be provided where a 40 millimeter (1.5 inch) diameter firehose is required by § 181.320. Both fire hydrants were missing wrenches. Provide spanner wrenches.

Materials used in piping systems must meet the requirements of this subpart and be otherwise acceptable to the cognizant [name withheld] piping located in the starboard aft corner of the engine room was found leaking at a coupling. Repair leak.

Cable and wire for power and lighting circuits must: (1) Meet Section 310-13 of NFPA 70 (incorporated by reference; see 46 CFR 175.600) except that asbestos insulated cable and dry location cables may not be used; (2) Be listed by Underwriters Laboratories (UL), as UL Boat or UL Marine cable; or (3) Meet § 111.60-1 in subchapter J of this chapter for cable, and § 111.60-11 in subchapter J of this chapter for wire. Engine start batteries were found with battery jumper cables using spring clips connecting the two banks. Vessel representative replaced jumper cables with 0000 cable and proper terminal connectors, but cable did not meet 46CFR183.340 amd was not what was listed in plan bill of materials. Replace with UL-marine or other approved cable.

When the cognizant OCMI or the Commanding Officer, Marine Safety Center determines, in accordance with §178.210, that a vessel must have stability details indicated on its Certificate of Inspection or a stability letter, the owner or operator must submit the information listed in paragraph (b) of this section: Provide an approved stability letter noting stability details for a minimum of 50 passengers, 4 crew and cargo.

Pursuant to 46 CFR 170.010, substitutions for calculations, information, or tests required in sub-chapter T may be approved by the Officer in Charge, Marine Inspection, if the substitution provides an equivalent level of safety. While the vessel is carrying more than 50 total persons the maximum cargo load must be reduced to no more than 15,000 lbs.

Replace lagging on port and starboard engine exhuast. Found 5X& holes in both outboard side exhaust lagging.

Found electrical panel to be missing drip shield in generator room. Provide drip shield for panel B in generator room.

Provide spanner wrenches for fire hydrants.

Electrical breaker panel on the bridge had a breaker that did not fit inside the face of the plate and was exposing the inside of the panel.

electrical panel in the number two forward void under the galley was missing two screws and the front cover was swinging open, exposing the wires inside.

An electrical cord with semi exposed wires made with a temporary type splice, held together with only electrical tape, was utilized on the bridge to extend the length of an extension cord for an installed fan.

One lifejacket found to be missing required light

three lifejackets were found to be missing retroreflective material

Stuffing tubes on watertight bulkhead in engine room not sealed.

Prove proper operation of all bilge suctions and both pumps

Transverse watertight bulkhead cable penetrations not watertight.

Discovered insulation lagging on turbochargers to be loose.

Discovered missing backing plates on engine's battery start connections on switchboard.

Vessel overdue for drydock; complete hull exam prior to carrying passengers or cargo.

Battery Charger failed to maintain a charge on vital navigational equip battery bank.

Loose live wires were discovered behind navigation console on the bridge.

Prove compliance with the stability requirements of 46 CFR Subchapter S - Subdivision and Stability following final completion of all work associated with the generator installation, by means of a new stability letter or stability document issued by the Marine Safety Center.

Provide proof of satisfactory stability to the satisfaction of the [name withheld]/LB.

Drug and alcohol history checks not being completed as required by 49 CFR 40.25.

Alcohol testing devices not onboard as required by 46 CFR 4. Devices located onboard were expired.

Make proper repairs to cracked hinge on door leading to main deck from accommodations

Provide access to line locker for inspection

Replace/Provide adequate guaging report for Port Strut Bearing

Tighten loose battery connections on Port side battery bank in steering space.

Make all penetrations in Aft bulkhead of galley space void watertight.

Repair / Replace hatch leading to galley void space.

Service all lifejackets including retroflective tape.

Apply adequate retroflective tape to all lifefloats

Replace temperature gauge port main engine

Properly label emergency fuel shut-off valves with proper closure method

Make vessel available for out-of-water damage survey by CG inspector.

46CFR184.620(b): Install means to shut down all engines at pilothouse control station

Install additional emergency lighting for lazarette, and ensure adequate amperage brightness.

Port engine gauges: tach & lube oil pressure - determine cause & correct. (Tach: no reading; L/O pressure: rapid increase corresponding to RPM).

Make vsl available for check-ride incl. test of machiner, bilge pump & emergency power/lighting.

Install UL-approved anchor light for vessels >65 ft.

Repair stbd MDE cooling water hi-temp alarm

Stencil name/hailing port on stern

Replace stern light lens.

Remove vinyl sight glass (fuel tank).

Replace PVC elbows in port wet exhaust line w/ metallic.

Secure secondary bilge pump in E/R

Gen Rm: secure wiring entering main distribution panel and breaker panel.

Clean lube oil IVO port generator engine and determine source.

Repair port genset exhaust hanger.

Gen room frame repairs (port & stbd sides).

Secure port rudder post packing bolts.

Steering hydraulic lines: secure from vibration.

Repair port side wet exhaust leak at sideshell.

Install UL-approved RV-type smoke detectors.

Stencil E/R vent closures (main deck)

Re-stencil deck markings as necessary.

Remove or re-configure grating over laz deck hatch.

COI lapsed after 05 DEC 2007

Repair and ensure the e-lighting is adequatly bright.

Provide Certificate of Documentation with correct vessel's name.

Provide original certificate of Inspection with correct vessel's name

Label vessel's name on lifefloats

Label vessel's name on lifejackets

Label rife rings with vessel's name

Replace lines on two liferings

Provide and post stability letter

Label emergency shut- off valves

Label emergency escape hatch to Lazerette

Repair outboard exhaust on starboard engine

Complete annual inspection prior to taking passengers or cargo.

Repair/replace retro reflective tape on PFD's as necessary.

Install pressure gauge on discharge side of fire pump.

Attach L/R lights with a 3' to 6' lanyard using a detachable clip.

Install dryer vent & clean area behind accommodation wall starboard side.

Re-route & properly support electrical cables at forward end of starboard generator.

Prove proper operation for SSB radio.

Provide adequate seal/closure for vents (port & starboard) for main generator space.

Internal Communication system to passenger/crew spaces did not work. Vsl crewmembers effected repairs and retested, sat.

Repair C/L engine and prove proper operation. C/L engine exuding excessing smoke/steam from engine head during U/W trials.

Replace missing lagging on port generator exhaust. LEGACY COMPONENT DESC: Piping (exhaust)

Repair two fractured welds in the steering compartment overhead deck longitudinal.

Weld the exterior sewage overboard hull penetration for a full penetration weld.

Install indicator light at the operating station for the water tight door below the bulkhead deck.

The compass binnacle light did not work. The light was fixed prior to the completion of the inspection LEGACY COMPONENT DESC: Lighting Fixture

The ships bell was onboard but not mounted. The ships bell was mounted prior to the completion of the inspection

Outdated supplies in the first aid kit. Issued a worklist item to replace outdated medication in the first aid kit. LEGACY COMPONENT DESC: Medicine Chest

Port main engine exhaust pedro was missing a hose clamp. Issued a worklist item to provide double hose clamps on main exhaust pedro connections. LEGACY COMPONENT DESC: Piping (exhaust)

The bilge pump impeller was burned up and did not work. A new impeller was installed and the bilge pump was tested SAT prior to the completion of the inspection LEGACY COMPONENT DESC: Pump

The bilge pump suction pedro had loose hose clamps. The hose clamps were corrected prior to the completion of the inspection. LEGACY COMPONENT DESC: Hose

VESSEL WAS MISSING 6 RED HANDHELD FLARES.

VESSEL WAS MISSING SEVERAL COTTER PINS ON THE STEERING GEAR.

PROVIDE VALID SAFETY RADIOTELEPHONY CERTIFICATE.

WRONG SIZE EXTINGUISHER INSTALLED.

IMPROPER LIGHT BULBS INSTALLED INSIDE RUNNING LIGHTS.

REPAIR FIRE PUMP SO ADJACENT PRESS CAN BE OBTAINED.

IMPROPER MSD ONBOARD, REPLACE WITH PROPER MSD.

NO VENT CLOSURE ON PAINT LOCKER.

REPLACE/REMOVE SHORE TIE CABLE.

NO GROUND METER IN PANEL BOARD.

REPAIR WORN STEERING PINS.

NO GUARD ON LIGHT GLOBE.

MAIN ENGINE EXHAUST LAGGING IN NEED OF REPAIR.

POOR LIGHTING IN GENERATOR ROOM.

FRACTURED WELDS IN LASS PORT & STBD SIDES & F/P FRAMES 2 & 3.

IMPROPER WIRE SPLICES ON BRIDGE & ENGINE ROOM.

STUFFING BOX BOLTS LOOSE.

REPAIR OR REPLACE RELIEF VALVE FOR PORT AIR RECEIVER AND TEST FOR PROPER OPERATION.

PROVIDE LIGHT COVERS FOR FIXTURES THROUGHOUT MACHINERY SPACES.

MAKE TEMPORARY REPAIRS TO FRACTURES ON ALL THREE THROTTLE LINKAGE MOUNTING BRACKETS ON FORWARD END OF EACH ENGINE.
