RUSSELL G

The capacity of the ship's service generating sources must be sufficient for supplying the ship's service loads without the use of a generating source which is dependent upon the speed or direction of the main propelling engines or shafting. Vessel reported a loss of their steam turbine generator. Rectify deficiency prior to departure. Submit a class report attesting to the proper operation of the steam turbine generator to an attending USCG Marine Inspector. 46 CFR 111.10-4 (c).

While a ship is operating within an emission control area, the sulphur content of fuel oil used on board that ship shall not exceed 0.10% m/m. On December 15, 2022, the permit titled “USCG and EPA APPS and MARPOL ANNEX VI Regulation 3 Permit Terms and Conditions to Support the Exemption from MARPOL ANNEX VI Regulations 14.4” for the HORIZON SPIRIT (IMO 7729459) allowing the vessel to operate in the ECA using 0.5% sulfur fuel expired. At the time of expiration, the vessel had a pending extension request into Coast Guard CVC and EPA. While this extension request is being reviewed by Coast Guard CVC and EPA, the vessel may operate under the terms of the aforementioned expired permit. This authorization to operate ceases once Coast Guard CVC and EPA has officially responded, either approving or denying the extension request. 73/78 MARPOL Annex VI, Reg 14.4.4

The person in charge of each vessel underway shall ensure that the vessel's anchors are ready for letting go. Inoperable starboard anchor. Vessel to obtain permanent repairs at next port, LA/LB.

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons onboard. The vessel reported the starboard anchor windlass is inoperable. 74 SOLAS Cons. CH I Reg. 11

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Identified seized reach rod for remote operation of STBD aft chain locker drain valve.

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. Identified 01 louver on STBD side not closing.

Every ship shall be provided with a satellite emergency position-indicating radio beacon which shall be capable of transmitting a distress alert. The EPIRB battery was expired.

All ships shall be fitted with an echo sounding device to measure and display the available depth of water. Depth sounding device was inoperable.

Ships shall be provided with means of making effetive distress signals by day and by night, including at least 12 parachute signals. The onboard flares were expired.

After any survey of the ship under regulations 7,8,9 or 10 has been completed, no change shall be made in the structural arrangements, machinery, equipment and other items covered by the survey, without the sanction of the administration. Armored electrical cable for both crew washing machines had plastic plug spliced into cable.

After any survey of the ship under regulations 7,8,9 or 10 has been completed, no change shall be made in the structural arrangements, machinery, equipment and other items covered by the survey, without the sanction of the administration. Structural fire protection insulation was removed from forward bulkhead of battery room and overhead in emergency generator room.

Maintenance, testing, and inspections of lifesaving applicances shall be carried out in a manner having due regard to ensuring reliability of such appliances. Vessels starboard lifeboat has a 14” fracture on the port side gunnel/sideshell. This fracture was not noted during the annual maintenance inspection (inspection conducted IAW MSC.1/Circ.1206) on 27 February, with the outside hull being marked as “good” condition with no remarks. Additionally the engine cooling water through hull valve was found missing a handle rendering it unable to close in the event of a line break. 74SOLAS Cons. (2014) III/20.3.1

The bulkhead deck or a deck above it shall be weathertight in the sense that in ordinary sea conditions water will not penetrate in a downward direction. All openings in the exposed weather deck shall have coamings of ample height and strength and shall be provided with efficient means for expeditiously closing them weathertight. A hole was found in the forward recess coaming of the 10 port cargo hatch (5 hold) rendering it non weathertight. 60SOLAS II/17b

The bulkhead deck or a deck above it shall be weathertight in the sense that in ordinary sea conditions water will not penetrate in a downward direction. All openings in the exposed weather deck shall have coamings of ample height and strength and shall be provided with efficient means for expeditiously closing them weathertight. The following areas of cargo hatches were found lacking weathertight integrity. 1. Hatch cover 1AC inboard forward coaming found fractured and deformed rendering the hatch non weathertight. 2. Hatch cover 2P inboard forward edge found fractured and deformed rending the hatch non weathertight. 3. Hatch cover 3P inboard forward edge coaming found deformed rendering the hatch non weathertight. 4. Hatch covers 4-6 found misaligned leaving gaps between the two covers rendering them non weathertight. 5. Hatch cover 6P after inboard corner found with a fracture rendering it non watertight. 6. The coaming under hatch cover 9S found deteriorated along the after coaming along the main deck. 7. Hatch covers 11 found misaligned and in a non weathertight position. 8. Hatch cover 11P found with fractured landing pad. 60SOLAS II/17b

Where “A” class divisions are pierced for the passage of electric cables, pipes, trunks, ducts... arrangements shall be made to ensure that the fire resistance is not impaired. Navigation panel on the bridge found with multi-cable transit beneath which had been left unsealed after recent wiring renewal. 60SOLAS II/38a

The sidelights of vessels 20 meters or more in length shall be fitted with inboard screens painted matte black and meeting requirements of Section 9 of this annex. Starboard sidelight found with section of white backing at the access panel door. COLREGS Annex I. 5

On and after 01 January 2020 ships powered by propulsion boilers that were not originally designed for continued operation on marine distillate fuel or natural gas that are operating within the North American Emission Control Area (NA ECA) must use fuel oil with a sulfur content not exceed 0.10% m/m. The vessel may use fuel oil with a sulfur content not to exceed 0.50% m/m within the NA ECA until 29 Febuary 2020, when the vessel must meet the NA ECA fuel oil sulfur standard by either obtaining a MARPOL Annex VI Regulation 3 exemption permit, or modifying the vessel to be able to use ECA compliant fuel oil. Note: This CG-835 is being issued because the interim provisions in 40 CFR 1043.97 and MARPOL Annex VI Regulation 14.4.4 expire on 01 January 2020.

Your vessel must undergo an annual inspection within the 3 months before or after each anniversary date. Vessel has not completed required Annual Inspection and must complete required inspection prior to departure from port.

Provide proof of compliance with work/rest hour requirements for the vessel's crew.

Provide a copy of the vessel's watch schedule to demonstrate plan for continued compliance with work/rest hours.

Provide statement attesting to the provision of enough food stores for the voyage to LA/LB to include inspection of stores after 12+ hour refrigerator outage.

Man-overboard light by fire station #18 is not operating. SOLAS[2014] Ch.III/20. 2

Lower, run, release the port lifeboat; provide video or have attending ABS surveyor witness. SOLAS[2014] Ch.III/19.3.3.2

Stern CL ring buoy light inop; replace battery or light as needed to make operable. SOLAS[2014] Ch.III/20. 2

Fractures identified (or suspected) at the entrance trunks to the following cargo holds- #3 stbd (2 areas), #2 stbd, #1 port, #2 port (2 areas), #3 port (2 areas), #7 port, #4 stbd; all areas to be investigated by NDT, bare steel inspection, or other means accepted by ABS to ensure watertight integrity. All fractures/holes shall be repaired prior to departure; temp repairs ok if allowed by ABS. ICLL Reg.16(4)

Ensure the stbd bow vent for the bosun’s stores is made watertight (2 areas noted holed); temp repairs allowed if acceptable to ABS. ICLL Reg.16(4)

Inspect the stern Jacobs ladder for condition and check for appropriate length. SOLAS[2014] Ch.III/20. 2

Ensure all hatch covers which are seated improperly or have lose/missing/bulging gasketing are made watertight before proceeding to sea. Hatches 2s, 3 p/s, 4 p/s, 6 p/s, 7 p/s, 11 p/s and 13s identified as non watertight, but all should be closely inspected prior to departure. Temp repairs to the satisfaction of ABS and will only be acceptable until the hatches are moved/lifted. ICLL Reg. 16(4)

Stern 6 man liferaft deck rail chains hooks seized closed; make operable.SOLAS[2014] Ch.III/20. 2

Complete outstanding maintenance items for the port & stbd lifeboat as noted on the PM list. SOLAS[2014] Ch.III/20.7.2

Forward hatch missing 3 securing dogs; replace and secure. ICLL Reg. 16(4)

Life-boat launching instruction incorrect. Vessel does not use bowsing tackle to hold the lifeboat close to the hull. They use frapping lines. Lines becketed around the hull not long enough. Starboard lifeboat hull slight damage by inboard underside hand rail. SOLAS[2014]Ch.III/9.1.1

Deck framing at the forward stbd corner of the #5 cargo hatch is fractured in 3 places and 1 other area of possible fracture noted.

Fire stations 11 and 12 sit just below two applicators. These are frozen in place and cannot be removed to attach the applicators. SOLAS74 Ch.II-2/5(f)

Spud release levers on fire stations 2, 17, 19, 20, 21, 23 and 24 do not work. This will cause the spray spud to dislodge when activated (picture). Plus the applicators for fighting containers will not work. SOLAS74 Ch.II-2/5(f)

Bridge wing light and smoke arrangement. The smoke is mounted outboard of the holder for the life-buoy. The light is mounted inboard. The smoke requires a 4 meter line that attaches to the life-buoy. When the life-buoy is deployed the light may hinder the buoy from falling away from the vessel or may cause the buoy and smoke to hang in place and not deploy at all. SOLAS[2014] Ch.III/20.7.2

The port side mooring winch forward of cargo hold #1 leaking oil.

Discharge Pressure gauge line valve has failed and not longer functions properly. Excessive leakage from valve body.

Gauge glasses for both port and stbd boiler not lit. Ensure all gauge glass lit and one set on each works on E-Bus

Emergency fire pump packing leaks excessively when shaft rotating and secured.

Remove oil soak lagging on LP and HP output shafts and identify source of leak.

Replace lagging for STBD boiler superheater pilot safety valve.

Replace lagging on lower soot blower line for Port Boiler

Repair leaking gauage glass drain line elbow on Port boiler

Replace lamp in emergency egress shaft for shaft alley

Repair or replace emergnecy light fixture on fwd end of Main Switchbaord.

Perform fire, abandon ship, and security drills to the satisfaction of a attending Coast Guard Marine Inspector.

Demonstrate main propulsion machinery to the satisfaction of a attending Coast Guard Marine Inspector.

Determine causative factors of loss of electrical power during transfer of load from SSDG to SSTG on 27 May 2017.46 CFR 111.10-4

The HP turbine FWD journal bearing was leaking oil

Make permenent repairs to the holed 14" Ballast piping suction line below the ballast manifold in the engine room

Make permenent repairs to the A/C condensor relief valve piping.

Replace external tailshaft seal and restore tailshaft lubrication system to originally approved configuration.

Remove security grating from starboard side sewage room access and use hatch with locking capability to control access.

Provide repair to port lifeboat in way of stern seating area.

Prove satisfactory operation of fire screen doors located at the port main deck stair tower and vestibule door to passageway. LEGACY COMPONENT DESC: Doorways

Remove all hardwired flexible extension cords, specifically to computer UPS located in Radio Room and to TV in Officer's Lounge. LEGACY COMPONENT DESC: Wiring

Post operating instruction for CO2 discharge in Paint Locker. LEGACY COMPONENT DESC: Operating Controls

Four-inch steam line off starboard boiler's superheater replaced. LEGACY COMPONENT DESC: Superheater

PRIOR TO VESSEL'S DEPARTURE FROM SAN FRANCISCO BAY, 3 CM RADAR MUST BE SATISFACTORILY REPAIRED. TECH REP REPORT MAY BE FAXED TO [phone withheld].

Port lifeboat is approximately 1100 lbs overweight. Suspect buoyancy chambers are waterlogged. Make permanent repairs (to restore vessel at the "A" weight) to the satisfaction of class in accordance with manufacturer instructions.

Vessel's stbd lifeboat and davit assembly severely damaged. SOLAS "A" pack liferafts with a total capacity of 30 persons shall be substituted until the stbd lifeboat and davit assembly are repaired and made operational. Operational test shall be witnessed by the CG or ABS.

Vessel is restricted to carrying a maximum of 30 persons until the stbd lifeboat and davit assembly are operational and tested by the CG or ABS.

COMPLETE PERMANENT REPAIRS TO THE INTERMEDIATE SHAFT COUPLING AND FAIRWATERIN ACCORDIANCE WITH ABS CLASS REQUIREMENTS ISSUED 30JUL95.

REPAIR CRACKS IN PORT AND STBD STAIRWAY WELLS IN FWD HOUSE.

RENEW OR END/END STBD LIFE BOAT FALLS AND CONDUCT WEIGHT TEST IN THE PRESENCE OF A MARINE INSPECTOR

CONDUCT PERMANENT REPAIR TO THE CRACK ON THE BOTTOM SHELL PLATE 20B AT FRAME 206 STARBOARD SIDE IN WAY OF NO. 7 BALLAST TANK. REPAIR PROPOSAL MUSTBE SUBMITTED TO THE COGNIZANT OCMI PRIOR TO THE START OF THE REPAIR. TO BE COMPLETED ON NEXT SCHEDULED DRYDOCKING.

RENEW AS ORIGINAL THE BILGE SUCTION PIPING TO THE #5 CARGO HOLD. LINE IS HOLED APPROXIMATELY 8FT FROM THE MANIFOLD.

PROVE PROPER OPERATION OF HEAT ACTUATOR FOR FIXED FIRE FIGHTING SYSTEM STARBOARD SIDE DECK PAINT LOCKER. SPACE IS TO BE VISUALLY INSPECTED AT LEAST ONCE PER WATCH UNTIL REPAIRED.

MAKE PERMANENT REPAIRS TO THE LEAKS IN THE #6 PORT F/O TANK IN WAY OF: 1) #6 CARGO HOLD PNUMERCATOR TUBE, AND AT TANK WELD SEAM APPROX. 4 FEET ABOVE THE DECK; 2) E/R VOID ALONG FR 95 AS MARKED; 3) #7 PORT WATER BALLAST TANK AT BULKHEAD PENETRATION OF TOP BALLAST PIPE INTO THE TANK.

PROVIDE THE SERVICING REPORT, OR PROPERLY SERVICE THE 2-75 LB. CO2 BOTTLES LOCATED IN THE ENGINE ROOM.

MAKE PERMANENT REPAIRS TO THE LEAKS IN THE #6 STBD FUEL OIL TANK IN THE WAYOF: 1) TOP WELD SEAM IN THE BILGE WELL IN THE #6 CARGO HOLD; 2) ENGINE ROOM VOID ALONG FR 95; 3) WELD SEAM IN THE ENG ROOM COMMON TO THE E/R VOID AND F/O TANK AT FR 95 ; 4) SHAFT ALLEY VOID BETWEEN FR 95-98 AS MARKED.

SUBMIT PLANS FOR THE #3 FUEL OIL TANK MODIFICATIONS FOR COAST GUARD APPROVAL TO COMMANDANT (G-MSC).

SUBMIT UPDATED FIRE CONTROL PLAN FOR COAST GUARD APPROVAL.

PROVIDE 3 ADDITIONAL 100 POUND CO2 BOTTLES FOR ENGINEROOM FIXED CO2 SYSTEM.

PROVIDE THREE (3) FULLY CHARGED 100 POUND CARBON DIOXIDE CYLINDERS FOR THE ENGINE ROOM FIXED FIRE EXTINGUISHING SYSTEM. _x001C_ _x001C_ _x001C_

PROVIDE PINS WITH CHAINS FOR THE VENT COVERS ON MAIN DECK. PINS AND CHAINSARE MISSING.

REPLACE OR CLEAN THE VENT SCREENS FOR THE #3 WG F/O TK AND THE #6 WG F/O TK.

PROVIDE VENT COVERS FOR THE VENTS THAT ARE MISSING THEM.

PROVE PROPER OPERATION OF REVERSE POWER RELAYS FOR DIESEL AND STEAM TURBINEGENERATORS.

PROVE PROPER OPERATION OF EMERGENCY LIGHTING IN MID-SECTION OF STBD TUNNEL.

REPAIR LEAKING GASKET IN REDUCING STATION STOP VALVE FROM STBD BOILER.

REMOVE ABANDONED WIRING FOR OLD OILY WATER SEPARATOR.

INSTALL A COVER FOR FUSES IN FDR P-101, PANEL #4-87-5.

INSTALL SPRAY SHIELDS FOR FUEL OIL PIPING FLANGES IN FRONT OF BOTH BOILERS.

CLEAN FLAME SCREEN ON PV VALVE FOR LUBE OIL GRAVITY FEED TANK.

MAKE REPAIRS TO BULKHEAD AT FRAME 79 BETWEEN NO.3 PORT WING FUELOIL TANK AND NO. 4 BALLAST TANK. NO FUEL IS TO CARRIED IN NO. 3 F/O TANK AND NO BALLAST TO BE CARRIED IN NO. 4 BALLAST TANK. IAW 46 CFR 91.45.

ALL NONMETALLIC EXPANSION JOINTS WHICH MEET THE REQUIREMENTS OF 46 CFR 61.15-12. ARE TO BE REPLACED.

REMOVE EXISTING OILY WATER SEPARATOR AND REPLACE IT WITH A U.S. COAST GUARDAPPROVED SEPARATOR. IAW 33 CFR 155.380.

SUBMIT INSTALLATION PLANS FOR OILY WATER SEPARATOR. PLANS TO INCLUDE PIPING AND ELECTRICAL DETAILS. IAW 46 CFR 50.20.

DEMONSTRATE PROPER OPERATION OF REMOTELY OPERATED FUEL OIL VALVES, IAW 46 CFR 56.50-60.

MAIN STEAM PIPING IS TO BE HYDROSTATICALLY TESTED IAW 46 CFR 61.15-5

CARGO HOLD HATCH COVERS ARE TO BE REPAIRED OR REPLACED AS NECESSARY MEET WATER TIGHT INTEGRITY REQUIREMENTS OF 46 CFR 97.15-20.

IN ACCORDANCE WITH CGHQ ABD [name withheld], LA. INSTRUCTIONS, VESSEL IS PERMITTED TO MAKE A ONE WAY VOYAGE FROM NEW ORLEANS, LA. TO KOBE JAPAN TO DRY DOCK VESSEL. VESSEL IS NOT PERMITTED TO CARRY CARGO. VOYAGE IS TO BE MADE IN THE MOST EXPEDIENT ROUTE POSSIBLE.

PROVIDE PROTECTIVE COVERS FOR LIFEBOATS AS REQUIRED BE 46 CFR 96.20-10 (MM)

REPAIR OR REMOVE THE FORWARD EMBARKATION LIGHT ON THE PORT SIDE.

MAKE REPAIRS TO THE FORWARD FUEL OIL HEADER PRESSURE GUAGE.

PROVIDE U.S. GUARD APPROVAL FOR NAVIGATION LIGHTS MODIFICATION OR OBTAIN A CERTIFICATE OF ALTERNATIVE COMPLIANCE. IAW 46 CFR 110.26 (1) AND 33 CFR PART 81.

INSTALL A CLASS "A" BOUNDARY AND A SELF CLOSING DOOR IN WAY OF STAIRS CONNECTING EMERGENCY GENERATOR ROOM AND THE SPACE BELOW IT, IAW 46 CFR 92.07-10.

FREE-UP AND REPAIR AS NECESSARY VENTILATION DUCT DAMPERS ON P/S ENGINEROOM VENTS (STACKS) AND FWD PORT DECK HOUSE PRIOR TO DEPARTURE FROM N.Y.

REPAIR THE STBD POWER BOILER BURNER MANAGEMENT LOW LOW WATER ALARM & CUTOUTAND TEST IN THE PRESENCE OF A COAST GUARD INSPECTOR.

REPAIR BOW THRUSTER AT NEXT SCHEDULED DRYDOCK.
