KNOX

The company and the ship shall comply with the requirements of the International Safety Management Code. For the purpose of this regulation, the requirements of the Code shall be treated as mandatory. The company should establish procedures to ensure that new personnel and personnel transferred to new assignments related to safety and protection of the environment are given proper familiarization with their duties. Instructions which are essential to be provided prior to sailing should be identified, documented and given. The crew was not familiar with the shipboard emergency procedures regarding the fire drill. The crew failed the fire drill 02 times because of their inability to properly don firefighting equipment and follow shipboard firefighting procedures. A safety management audit report satisfactory to the Captain of the Port must be submitted prior to the clearence of this deficiency.

A ship when in a port of another Contracting Government is subject to control by officers duly authorized by such Government concerning operational requirements in respect of the safety of ships, when there are clear grounds for believing that the master or crew are not familiar with essential shipboard procedures relating to the safety of ships. The fire team did not properly don firefighting equipment. The crew was not familiar with SCBA operations, which resulted in dispensing 02 SCBA bottles. Additionally, crew was not familiar with shipboard firefighting procedures, such as not securing ventilation. This resulted in a failure of their fire drill 02 times.

The purpose of this regulation is to contain a fire in the space of origin. For this purpose, the following functional requirements shall be met. (1) the ship shall be subdivided by thermal and structural boundaries (2) thermal insulation boundaries shall have due regard to the fire risk of the space and adjacent spaces: and (3) the fire integrity of the divisions shall be maintained at openings and penetrations. The galley, accommodation spaces, and the navigation bridge are not separated by thermal or structural boundaries. The fire control plan fails to indicate any "A" or "B" class divisions throughout the ship. This deficiency constitutes a significant and unmitigated hazard of both fire and safe navigation if the bridge fills with smoke while underway.

Ducts provided for ventilation to accommodation spaces, service spaces or control stations shall not pass through... galleys... unless they comply with the conditions specifies in paragraphs 7.2.2.1.1 to 7.2.2.1.3 or 7.2.2.2.1 and 7.2.2.2.2. A single ventilation system connects the galley, the accommodation spaces, and the navigation bridge without complying with the precautions in the specified paragraphs. Of note, the ducts were neither insulated to "A-60" standard nor fitted with fire dampers. When asked how they would secure the galley ventilation in the event of a fire, the crew could not answer the question. This deficiency constitutes a significant and unmitigated hazard of both fire and safe navigation if the bridge fills with smoke while underway.

The activation of any detector or manually operated call point shall initiate a visual and audible fire detection alarm signal at the control panel and indicating units. if the signals have not been acknowledged within 2 min, an audible fire alarm shall be automatically sounded throughout the crew accommodation and service spaces, control stations and machinery spaces of category A. This alarm sounder system need not be an integral part of the detection system. The smoke detectors in the galley and accommodation spaces were modular isolated household smoke detectors that were connected to a fixed system and did not initiate a visual and audible signal at the control panel.

For ships constructed before 1 July 1998, the Administration shall ensure that when life-saving appliances... are replaced or... undergo repairs, alterations or modifications of a major character which involve replacement... they comply with the requirements of this chapter. Each launching appliance shall be so arranged that the fully equipped survival craft or rescue boat it serves can be safety launched against unfavorable conditions of trim of up 10 degrees and list of up to 20 degrees either way when boarded. The rescue boat was replaced in 2012. The davit must be physically swiveled by manpower alone, and the crew struggled to rotate the davit with no persons in the rescue boat while moored to the pier in calm weather conditions.

An onboard means of recharging breathing apparatus cylinders used during drills shall be provided or a suitable number of spare cylinders shall be carried on board to replace those used. The vessel only had a total of 04 SCBA bottles on board for 02 fire fighting outfits. Following the drill, 02 SCBA bottles were required to be refilled at a shoreside facility leaving only 02 bottle remaining on board

Not less than 12 rocket parachute flares, complying with requiremnts of section 3.1 of the Code, shall be carried and be stowed on or near the navigation bridge. The vessel only has 06 parachute flares.

Every line-throwing appliance shall include not less than four lines, each having a breaking strength of not less than 2 kN. The vessel only had 02 line-throwing appliances.

All electrical apparatus shall be so constructed and so installed as not to cause injury when handled or touched in the normal manner. Electrical wires were exposed in the freezer above the door and in the engine room on the main engine controls.

A ship, except a ship of less than 26 feet in length, must have a placard of at least 5 by 8 inches, made of durable material fixed in a conspicuous place in each machinery space, or at the bilge and ballast pump control station. The vessel was missing discharge placards

Every oil tanker of 150 gross tonnage and above and every ship of 400 gross tonnage and above other than an oil tanker shall be provided with an Oil Record Book Part I (Machinery space operations). The Oil Record Book, whether as a part of the ship’s official logbook or otherwise, shall be in the form specified in appendix III to this Annex. The soundings of the dirty oil tank were not being logged weekly. Additionally, the sounding logs (i.e. tank capacity, tank level, etc.) were not in accordance with the ORB’s instructions.

The Oil Record Book, whether as part of the ships official logbook or otherwise, shall be in the form specified in appendix III to this annex. PSCO observed weekly soundings of tanks listed in item 3.1 of from A of the IOPP certificate was not being logged per ORB part I section (C)11. MARPOL Annex I/17.1 Code 10c

The condition of the ship and its equipment shall be maintained to conform with the provisions of the present regulations to ensure that the ship in all respects will remain fit to proceed to sea without danger to the ship or persons on board. PSCO observed port and starboard liferafts have not been serviced in the last twelve months.

A ship when in a port or an offshore terminal of another Party is subject to inspection by officers duly authorization by such a Party concerning operational requirements under this Annex there are clear grounds for believing that the master or crew are not familiar with essential shipboard procedures relating to the prevention of pollution by oil. During Port State Control Exam, Port State Control Officer discovered manufacturer's operational instructions for the oily water separator were no on board vessel and master and crew were not familiar with how to properly operate the oily water separator.

Oily water separator discharge valve did not fully close during function test. Repair prior to use.

CO2 portable extinguisher located in engine room, near OWS, hose is wasted. Replace hose prior to departure from port.

Oily water seperator was inoperable. Vessel to have fully operational OWS prior to use.

Make permanent repair to #3 STBD mud tank (used as ballast tank only) deck plating. Deck plate peeled back with 4" hole.

Make permanent repair to STBD bulwark from frame 49 to 52F.

Make permanent repair to forward #3 STBD mud tank vent bell.

Fire Drills and Abandon Ship drills not being conducted on alternate weeks in the proper timelines as required by 46CFR131.535 and 46CFR131.525

Multiple improper splices were found on vessel not in junction boxes.

Charts not updated with current local to mariners.

Crop and renew stbd bow bulwark and adjacent main deck plating. Repair bent fwd masthead and masthead light. Crop and renew deckplate fracture where masthead light joins main deck.

Provide guards for moving parts on port/stbd diesel generators.

Flexible fuel lines cannot exceed 30". Install fixed fuel piping systems on P/S MDE's.

Replace guage on stbd air receiver.

Seal wiring & A/C duct iwo engine room passageway, as noted.

Provide stability book to coincide w/ updated stability letter.

Prove proper operation of shaft tachometers.

Replace/ provide approved rescue harness.

Provide proof of FCC Station license. LEGACY COMPONENT DESC: FCC SSL

Provide proof of Bridge-to-Bridge certificate. LEGACY COMPONENT DESC: Bridge to Bridge Certificate

Label liferaft stations on superstructure. LEGACY COMPONENT DESC: Markings

Provide updated Fire Safety Plan to the Coast Guard for approval. LEGACY COMPONENT DESC: Fire Control Plans

Provide emergency broadcast placard. LEGACY COMPONENT DESC: Making Voice Radio Distress Call

Provide metal guard for operating station emergency light. LEGACY COMPONENT DESC: Lighting Fixture

Renew 02-deck lifebuoy floating light. LEGACY COMPONENT DESC: Self-igniting Lights

Renew stbd liferaft hydrostatic release. LEGACY COMPONENT DESC: Hydrostatic Release Unit

Renew gaskets on stbd operating station weather tight door and 01 deck watertight door. LEGACY COMPONENT DESC: Door

Provide ventilation louver for operating station back-up battery. LEGACY COMPONENT DESC: Battery Installation Ventilation

Provide protective guard for stove light. LEGACY COMPONENT DESC: Guards for Exposed Hazards

01. DEMONSTRATE COMPLIANCE WITH CG DISTRICT 8 RESCUE BOAT POLICY DATED 12NOV99.

REPAIR STAINLESS STEEL FIRE MAIN - 1 PLACE ON 6" LINE - 4 PLACES ON 10" LINE. QUALIFIED WELDER AND MATERIALS TO BE USED. HYDRO SAME IN PRESENCE_x001C_ OF COAST GUARD INSPECTOR.

ADMIN EXTENDED TWO DAYS

ADMIN EXTENDED TWO DAYS

ADMIN. EXTENDED TWO DAYS

ADMIN EXTENDED TWO DAYS

EFFECT PERMANENT REPAIRS TO WASTED FIRE MONITOR PIPING.

REPAIR PORT S/S GENERATOR OVERSPEED TRIP WITHIN SEVEN (7) DAYS OF THE ABOVEDATE BUT NOT LATER THAN 20DEC84.

REPAIR STBD MAIN ENGINE OVERSPEED TRIP WITHIN SEVEN (7) DAYS BUT NOT LATER THAN 20DEC84.

REPAIR PORT AND STBD MAIN ENGINE REMOTE STOPS TO COMPLETELY SECURE ENGINES WITHIN SEVEN (7) DAYS.
