MSC PEGASUS VII

The machinery, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended. PSCO observed leaking pipe on cascade tank and leaking pump for #1 feed water pump to the boiler. 74 SOLAS (04) II-1/26.1

The provision of safe means of access to and throughout the ship, and the satisfactory physical condition of [...] handrails. PSCO observed broken handrails on landing platform of main engine. ILO-147/PWSA 46 USC 70002 ILO-147 pg. 45, 3-b

The machinery, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended. PSCO observed leaks on quick closing valve to #2 service generator.

The purpose of this regulation is to prevent the ignition of combustible materials or flammable liquids. For this purpose, the following functional requirements shall be met: Means shall be provided to control leaks of flammable liquids. PSCO observed evidence of old fuel oil leaks on FO pump for cylinders 9 and 13 on ME, inlet valve for No. 2 fuel oil purifier, and flange on FO supply to incinerator. 74SOLAS(14) II-2/ 4.1 16ac

The machinery, boilers, and other pressure vessels, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended and shall be so installed and protected as to reduce to a minimum any danger to persons on board, due regard being paid to moving parts, hot surfaces and other hazards. PSCO observed hydraulic oil leaks on the No.1 steering gear. 74SOLAS(04) II-1/26.1 16AC

To assist in casualty investigations ships when engaged on international voyages, subject to the provisions of Reg. 1.4, shall be fitted with a voyaged data recorder(VDR)as follows; ships, other than passenger ships, of 3,00 gross tonnage and upwards constructed on or after 1 July 2002. PSCO was informed by vessel even that the PCB unit is not operational, preventing voyage data transfer to the float free unit. 74SOLAS(20) V/20.1.4 16ac

The ring, lines and letters shall be painted in white or yellow on a dark ground or in black on a light ground. PSCO observed 2 load lines on Port side due to worn paint. 66ICLL (Prot88) Reg 8 40ac

Oil residue (sludge) may be disposed of directly from the oil reside (sludge) tank(s) to reception facilities through the standard discharge connection referred to in regulation 13, or to any other approved means of disposal of oil residue (sludge), such as... other acceptable means which shall be annotated in 3.2 of the Supplement to IOPP Certificate Form A or B. PSCO observed evaporation being used as other acceptable means, this method was not approved item 3.2 of IOPP Supplement. MARPOL I/ 12.2 40ac

Muster and embarkation stations shall be adequately illuminated by lighting supplied from the emergency source of electrical power required by Regulation II-1/ 42 & 43, as appropriate. PSCO observed two non- operational emergency lights in the vicinity of the STBD survival craft muster station. 74SOLAS(20) III/ 11.4 10c

The machinery, boilers and other pressure vessels, associated piping systems and fittings shall be of a design and construction adequate for the service for which they are intended and shall be so installed and protected as to reduce to a minimum any danger to persons on board, due regard being paid to moving parts, hot surfaces and other hazards. The design shall have regard to materials used in construction, the purpose for which the equipment is intended, the working conditions to which it will be subjected and the environmental conditions on board. PSCO observed portable air duct connecting from engine room ventilation duct to air intake on No 4 diesel generator.

Every ship of 100 gross tonnage and above, and every ship which is certified to carry 15 or more persons, and fixed or floating platforms shall carry a garbage management plan which the crew shall follow. PSCO observed multiple oil buckets filled with engine oil next to the main engine.

"THE MACHINERY, BOILERS, AND OTHER PRESSURE VESSELS ASSOCIATED PIPING SYSYEMS AND FITTINGS SHALL BE OF A DESIGN AND CONSTRUCTION ADEQUATE FOR THE SERVICE FOR WHICH THEY ARE INTENDED SALL BE SO INSPTALLED AND PROTECTED AS TO REDUCE A MINIMUM ANY DANGER TO PERSONS ON BOARD...." PSCO OBSERVED PORTABLE AIR DUCT CONNECTING FROM ENGINE ROOM VENTILATION DUCT TO AIR INTAKE ON NO. 4 DIESEL GENERATOR. VESSEL MUST REPLACE THE COVER RING ON THE TURBOCHARGER EXAHUST GAS INLET. 74 SOLAS (04) II-1/26.1

The second means of starting, hydraulic accumulator, failed to start emergency generator after multiple attempts. 74SOLAS(2004 cons)II-I/44.2 (CODE 17AC)

74 SOLAS (04 CONS) II-1/17-1 & 17.2: The arrangement and efficiency of the means for closing any opening in the shell plating shall be consistent with its intended purpose and the position in which it is fitted and to the satisfaction of the administration. Lube oil was discharged from the stern tube due to unknown causes. 60ac

AIS MALFUNCTIONING
