GREAT LAKES TRADER

At each inspection for certification and periodic inspection, the inspectors shall conduct the following tests and inspections of hull equipment: Every acceptable cargo gear certificate and/or register shall be properly executed by a person authorized to do so and shall:(1) Certify as to the tests and examinations conducted;(2) Show the dates on which the tests and examinations were conducted; and(3) Indicate that the cargo gear described in the certificate or register complies with the standards of the organization or association authorized to issue the certificate or register. Vessel reported discharge of oil into the water from cargo boom at CSX docks. Vessel will need to have ABS survey cargo equipment prior to cargo operations; to the Coast Guard's satisfaction.

A survey, either general or partial, according to the circumstances, shall be made every time an accident occurs or a defect is discovered which affects the safety of the vessel or the efficacy or completeness of its lifesaving appliances, fire-fighting or other equipment, or whenever any important repairs or renewals are made. The survey shall be such as to insure that the necessary repairs or renewals have been effectively made, that the material and the workmanship of such repairs or renewals are in all respects satisfactory, and that the vessel complies in all respects with the regulations in this subchapter. Vessel has report a bulkhead failure between the #4 & #5 cargo holds.

On or before 31MAR25 the ballast stripping system must have plans submitted and then approved by MSC for equivalency of the as built design using unapproved PVC piping materials. Or you may submit new drawings to MSC to replace the piping to ensure the system fully meets all applicable portions of 46 CFR Sub-chapter F and then complete the installation. Any and all modifications must be overseen and inspected by a qualified CG Marine Inspector. Either option must be fully completed NLT 31MAR25 and no extensions will be granted.

In the cargo unloading tunnel there are numerous electrical issues. There are cut cables hanging in cable trays at numerous locations in both the port and stbd tunnel. A survey by crew or third party is to be completed and ALL dead ended cables are to be removed or properly terminated in approved junction boxes.

There are several cable penetrations passing through class A-0 boundaries where the multi cable transit systems approved for structural fire protection are missing. Survey ALL cable penetrations and reinstall approved structural fire protection cable penetrations.

Unloading tunnel ventilation system installation is incomplete. The new partial installation does not have required plans approved by the Marine Safety Center. Also, the system is not yet fully installed. Plans are to be approved by MSC and the system installation complete. Plan approvals must cover, haz area drawing, one line electrical drawing, structural modifications to the fwd and aft sections of the vessel, and ventilation system arrangement details. A CG Marine Inspector must review approved drawings, verify materials used, ensure proper hazard class for equipment installed, and witness satisfactory testing of the system. The system may not be energized or used for any reason until cleared by an attending CG Marine Inspector.

During engine testing on the unloading boom #2 diesel driven hydraulic pump the pump suffered a catastrophic failure. The pump is to be replaced or repaired and demonstrated to function properly. To the satisfaction of a CG Inspector.

The navigation lights on the bow both red and green have broken housings and must be replaced.

Temp Cement Box patch installed in the #2 Stbd ballast tank, at bottom shell in way of Frame 23. Cement Box patch shall be cropped out with permanent steel repairs made at vessels next dry-docking as required by 46 CFR 91.45-5

Both aft engine rooms fixed CO2 system time delays failed to activate within the mfg. specs. Both activated at 45 seconds, vice 26 seconds. Replacement Time Delays unavailable. Both Time Delays may remain but shall be renewed or the fixed CO2 system serving each engine room must be redesigned, approved, installed and re-tested as required by 46 CFR 95.05-10(e)(3)(ii) on or before 31MAR2024.

Suitable hand covers, guards, or rails shall be installed in way of all exposed and dangerous places such as gears, machinery, etc. The cover to the aft winch on the barge is damaged and internal components are exposed. Effect adequate repair to the satisfaction of the attending marine inspector prior to use and prior to the end of 2023 winter layup.

Inspect and verify proper operation of the #2 hydraulic pump and its engine/prime mover prior to placing them online to move cargo.

Test all electrical cables that were exposed to the heat from the fire for insulation resistance using a megohmeter and provide our office with a report of the readings. Insulation tests should test the insulation of each conductor in a cable, testing insulation resistance between conducter in the cable and insulation resistance between each conductor and the ships hull. Replace or repair any electrical cables which the insulation resistance is found to be less than what is specified in section 34.2.1 of IEEE 45-2002. Any cables replaced should be replaced-in-kind with what was approved/installed prior to the fire. If replacement cables will not be replaced-in-kind, datasheets for the new cables showing that the cables are constructed to meet the requirements of 46 CFR 111.60-1 must be submitted to the cognizant OCMI for review and approval.

Door leading into the ladderwell to the cargo tunnel had missing gasket material preventing it from making a tight seal. Members of the crew had replacement gasket material on hand and issue was corrected before the inspection was completed.

The ballast water system did not have an installed guard over the exposed/rotatating coupling.

USCG Marine Inspector to witness repairs to items identified during dry-dock extension survey conducted on 15Feb2017. See MISLE activity #6093225.

At next drydock inspection USCG Marine Inspector to witness repairs to items identified during dry-dock extension survey conducted on 15Feb2017. See MISLE activity #6093225.

Provide written report from a Caterpillar diesel engine service rep reflecting safeties were tested and verified on all engines per 46 CFR 111.12-11

Observed one remote reach rod on the port sea chest was not connected, reach rod required to be reconnected per 46 CFR 56.50-95

Water light bracket on the port aft side was not attached, bracket is to be properly attached and secured per 46 CFR 199.70

Life Jacket Donning instructions were not posted on vessel.

Life jacket stowage was not labeled IAw 46 CFR 199.70(b)(2)(iii)

Liferaft launching instructions were not visible.

Bow thruster return line flexible hosing was leaking.

Oily rags from thruster leak were being stored in the forepeak. Rags are to be properly disposed.

Ballast stripping line is leaking IWO #3 ballast tank. Vessel is to repair the leak.

Port bilge alarm did not work properly.

Paint draft marks in contrasting color at all locations.

Paint Load Line marks in contrasting color.

Provide nameplate with rating data for ship service generator.

Label pressure switches in Fixed CO2 system to show affected machinery and provide proof of proper testing of same.

Replace missing sections of thermal insulation on engine exhausts in both enginerooms.

Before loading coal, remove jury-rigged outlets and wiring from lighting fixture in port conveyor tunnel near gate 2-5, make same fit for wet and hazardous locations.

Before loading coal, make electrical components for modine heaters in conveyor tunnels suitable for wet and hazardous locations.

Before loading coal, remove electrical outlets in conveyor tunnels or make same fit for wet and hazardous locations.

Before loading coal, make electrical components to cargo vibrators in conveyor tunnel fit for wet and hazardous locations.

Hydrostatic releases expired on barge and tug ILR's. corrected during inspection

Dead end wire not marked in conveyor tunnel, corrected during inspection

Watertight/fume tight plug missing in explosion proof lighting fixture in conveyor tunnel. Replaced during inspection.

Machinery guard missing on raw water cooling pump drive coupling in pumproom, corrected during inspection.

Demonstrate proper operation of pressure relief valve of cargo vibration air system.

Provide ground detection for barge service power system.

Provide non-conductive mats or gratings suitable for the switchboard voltage.

Repair/replace sounding tube for #6 portside ballast water tank.

Repair/replace portside fireman expansion joint on deck.

Verify proper operation of navigational light panel.

Renew gasket on watertight door to forecastle to the satisfaction of the cognizant OCMI.

Renew buoyant lines on ring life buoys located on starboard bow and port quarter on main deck, to the satisfaction of the cognizant OCMI.

Exchange locations of the Inflatable Life Rafts so that the 25-person raft is positioned on the bow of the barge, to the satisfaction of the cognizant OCMI.

Noted several leaks in the port fire main on the main deck, in the vicinity of #7 and #8 cargo holds. Also noticed a section of flexible hose instead on fixed piping near cargo hold # 3. CG-835 issued to "Make permanent repairs port fire main as shown on the approved plan".

Bulkhead between forepeak and #1 Port ballast tank had a fractured weld aprox. 15" wide at the bottom hull plating due to hull bottom deformation. Shipboard welder ground and welded fractured weld from the forepeak side, unable to weld the #1 side due to deformation. Owner to submit permanent repair proposal and make permanent repairs under the discretion of the cognizant OCMI.

Provide copy of ABS Class Report for temporary repair to damage in bottom of #6 starboard ballast tank by May 15, 2010, to Coast Guard MSU Cleveland.

Make permanent repairs to damage in bottom of #6 starboard ballast tank no later than May 25, 2012. Cut, Crop, & Renew damaged hull plating, frames, and cement box within the #6 Stbd Ballast Tank. Repairs shall be completed during vessels next scheduled dry-docking or before Load Line Certificate Expires. 14June Extended due date to 25May2012. [name withheld]

Post operating instructions and label valves on the Engine Compartments fixed CO2 System IAW 46 CFR 95.15-10 (h)

Install reflective tape and fix ring buoy light (aft stbd side) IAW 46 CFR 199.70

Make repairs to stbd aft raw water cooling remote reach rod IAW 46 CFR 56.50-94

Cable in tunnel raceway port and stbd not supported. Support cables every 24 inches with metal ties. Remove dead end wires and extension cords.

Cable splice in supply to #8 port stripping pump outside proper enclosure, using screw-on wire ties. properly repair supply cable.

Reach rod to sea chest valve in place but disconnected. Re-connect reach rod to valve handle.

Make permanent repairs to damaged hull plating and associated frames in #1 stbd ballast tank ivo frames 14 3/4 - 15 at the bilge turn during next drydock.

Make permanent repairs to damaged hull plating and associated frames in #2 stbd ballast tank ivo frames 16 at the bilge turn during next drydock.

EPIRB's hydrostatic release expired.

Lifering on poor condition and needs to be replaced.

Install missing guard on port ballast pump engine.

Install missing crankcase vent hose on the port ballast pump.

Install remote operated fuel oil cutout valve on port day tank.

Make permanent repairs to #1 Port Ballast tank in way of cement box patch prior to next credit Dry Dock Exam. Cement box patch covers crack located on bottom shell between frames 11 and 12, outboard from longitudinal bulkhead between frame 6 and 7. Temporary repair to be re-examined at next ISE. LEGACY COMPONENT DESC: #1 Port Ballast Tank

Provide an echo depth sounding device readable at the main operating station for the ITB JOYCE L. VANENKEVORT/GREAT LAKES TRADER prior to the compliance date.

Complete permanant repairs to the bow thruster to eliminate hydralic oil leak (to the sea) and demonstrate proper operation prior to the compliance date.

Provide a suitable secure mounting for compressed gas cylinders prior to the compliance date.

Make paint locker electrical system explosion proof as per 46 CFR 111.105- 43 prior to the compliance date, meanwhile the existing lighting system shall not be energized.

Repair and demonstrate proper function of the electrical shutdowns related to the CO2 fixed system pressure switches prior to the compliance date.

Repair broken safety glass window in the bow lookout station prior to the compliance date.

Provide 2 BII fire extinguishers in both engine rooms prior to the compliance date, meanwhile provide at least 4 BI fire extinguishers in eachengine room.

Provide valid cargo gear certificate prior to unloading cargo and before the compliance date.

provide oil transfer procedures in compliance with 33 CFR 155.750 prior to fueling and prior to the compliance date.

Mount battery rack for batteries located in port hydraulic room prior to getting underway and prior to the compliance date.

Install supports for electrical cable to forward sump pump prior to the compliance date.

Install labeling for all electrical panel boxes prior to the complaince date.

Provide written designation letter assigning personnel for cargo supervisonoperations prior to the compliance date.

Mark all watertight doors as per 46 CFR 97.37-60 prior to the compliance date.
