CHICHAGOF DREAM

A device must be provided to automatically shut down power ventilation serving the protected space and engines that draw intake air from the protected space prior to release of the extinguishing agent into the space. Starboard MDE did not shutdown when testing the pressure switch installed in the fixed fire fighting system. 46 CFR 118.410(b)(10)

Vessels described by 46 CFR 114.110(f) must submit plans to the cognizant OCMI, in accordance with 46 CFR 115.700, for the installation and use of monitoring device(s) to ensure the wakefulness of the watchmen required in paragraph (a) of this section. (3) Be arranged to ensure proper coverage of the passenger accommodation spaces, common areas, and spaces with potential fire hazards. Several watchman alarm switches were missing and the system could not be fully tested. 46 CFR 122.410(b)(3)

The cognizant OCMI may require that a vessel and its equipment undergo any additional test or inspection deemed reasonable and necessary to determine that the vessel and its equipment are suitable for the service in which they are to be employed. Generator overspeed test did not properly secure the generators when tested. 46 CFR 115.840

Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock; minimize accidental personnel contact with energized parts. The following electrical installation deficiencies were identified: - Crew berthing H2 was missing light cover - crew passageway forward and aft lighting had broken covers -AC flats junction box was found not properly secured or covered and had exposed wiring 46 CFR 120.200

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. The following deficiencies were identified: - Crew berthing passageway had wires exposed and a kill switch installed. -Passenger room 107 did not have functioning PA speaker 46 CFR 116.530

Waste Receptacles. Unless other means are provided to ensure that a potential waste receptacle fire would be limited to the receptacle, waste receptacles must be constructed of noncombustible materials with no openings in the sides or bottom. Waste receptacles in crew heads (mens and womens) were constructed with combustible material (plastic). 46 CFR 116.405(i)

At each inspection for certification and at every other vessel inspection, quarters, toilet and washing spaces, galleys, serving pantries, lockers, and similar spaces may be examined to determine that they are serviceable and in a sanitary condition. Galley range hood and fan had excessive grease build up that was leaking down the bulkhead and pooling up on the floor. 46 CFR 115.818

A grease extraction hood required by § 118.400 of this part must meet UL 710 “Exhaust Hoods for Commercial Cooking Equipment,” or other standard specified by the Commandant. Several holes in the side of the grease extraction hood were identified which does not meet UL 710 or NFPA 96. 46 CFR 118.425

Each vessel must be equipped with at least two operable portable battery lights located at the operating station and machinery spaces. EGen portable light was inoperable. 46 CFR 120.430

Penetrations in A-Class fire control boundaries for electrical cables, pipes, trunks, ducts, etc. must be constructed to prevent the passage of flame and smoke for one hour. In addition, the penetration must be designed or insulated so that it will withstand the same temperature rise limits as the boundary penetrated. Aft bulkhead in laundry space has through hull penetration that would allow the passage of flame and smoke. 46 CFR 116.415(a)(2)(ii)

Remote fuel shutoff stations must be marked in clearly legible letters at least 25 millimeters (1 inch) high indicating purpose of the valve and direction of operations. Egen remote fuel shutoff was not properly labeled. 46 CFR 122.608

A passenger safety bill must be posted by the master in each passenger cabin or stateroom on a vessel of more than 19.8 meters (65 feet) in length with overnight accommodations for more than 49 passengers. passenger safety bills were found missing in passenger rooms 109 and 110. 46 CFR 122.515(a)

A fire control plan must be posted on the vessel in a location that is accessible and visible to all passengers. The plan must show escape routes, areas of refuge, embarkation stations, the location of fire protection/emergency equipment, compartment titles and hazard classification of accommodation and service spaces, and structural fire protection boundaries. The following deficiencies were identified as missing IAW the fire control plan: - Prom deck Chief Engineer berthing was missing a PFD and PFD label - Prom Deck starboard side 3 man berthing was missing PFD - Salt room was missing PFD's. Lounge deck berthing L41 was missing PFD placard. 46 CFR 116.530

For a vessel, the construction of which was begun prior to approval of the plans and information required by paragraphs (a) and (b) of this section, the cognizant OCMI may require any additional plans and information, manufacturers' certifications of construction, testing including reasonable destructive testing, and inspections, which the OCMI determines are necessary to verify that the vessel complies with the requirements of this subchapter. Due to the recent upgrade of the fire detection system, an updated fire control plan shall be completed and approved by MSC prior to operating in 2026. Additionally, it was identified that an A class bulkhead was located on the approved fire control on the main deck in the forward stores but was not present. It appears to be an error on the approved plans as the A class bulkhead was never installed at original construction. 46 CFR 116.202(c)

Complete a survey of hull/side shell and provide a detailed drawing and plans for repairs. Due to multiple welds and scattered pits throughout.

Due to the rapid corrosion and excessive deterioration of hull and anodes a corrosion survey needs to be conducted to determine the cause of the corrosion.

24MAY24: A lighting fixture must be installed as follows: Each lighting fixture and lampholder must be fixed. A fixture must not be supported by the screw shell of a lampholder. Overhead lighting in EDG space behind the PA system was found zip tied in the overhead. 46 CFR 120.410(c)(2)

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of its Certificate of Inspection giving consideration to provisions for protection against fire. Laundry room dryer ventilation was found zip tied to the overhead and attached with combustible materiald. The other end of the dryer ventilation was found with a rag inside and ventilating into the space. 46 CFR 116.100

Penetrations in A-Class fire control boundaries for electrical cables, pipes, trunks, ducts, etc. must be constructed to prevent the passage of flame and smoke for one hour. A Class deck penetration in laundry space is missing fire block. 46 CFR 116.415 (a)(2)(ii)

A door in a fire control boundary must meet the following requirements. Class A doors leading from the dining room into the galley do not close properly. 46 CFR 116.435(b)

Holdback hooks are not allowed. If installed, a hold back mechanism for a door must allow the door to be released. Door leading from galley down to the lower engineering space was found with a rope holdback. 46 CFR 116.435(c)(6)

At each initial and subsequent inspection for certification of a vessel, the owner or managing operator shall be prepared to conduct tests and have the vessel ready for inspection of lifesaving equipment and systems including inspection of each inflatable liferaft, inflatable buoyant apparatus, and inflatable lifejacket to determine that it has been serviced as required by § 185.730 of this chapter Liferafts were not onboard at time of inspection. 46 CFR 115.808(a)(4)

Each item of lifesaving equipment determined by the marine inspector to not be in serviceable condition must be repaired or replaced. 06 life rings onboard were found with severe UV damage and cracking. 46 CFR 115.808(b)

At each initial and subsequent inspection for certification, the owner or managing operator must be prepared to conduct tests and have the vessel ready for inspection of its fire protection equipment. The emergency diesel generator space CO2 system had not been serviced. 46 CFR 115.810(a)

Electrical equipment on a vessel must be installed and maintained to: Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Bridge electrical panel on aft bulkhead was missing a blank. 46 CFR 120.200(b)

Doors in A-Class fire control boundaries must meet the following additional requirements: If installed, a hold back mechanism for a door must allow the door to be released locally, upon a signal from a control space; and upon disruption of the power system. Several doors did not close properly and several could not be tested due to obstructions in and around the doors. 46 CFR 116.435(c)(6)(ii)

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. PA system in "MARIA" rooms were inoperable. 46 CFR 121.610(b)

Each floating waterlight must be approved in accordance with § 161.010 in subchapter Q of this chapter, or other standard specified by the Commandant. Waterlight had incorrect batteries installed not IAW approval letter. 46 CFR 117.70(d)(1)

Fire extinguishing equipment installed on a vessel in excess of the requirements of §§ 118.400 and 118.500 must be designed, constructed, installed, and maintained in a manner acceptable to the Commandant. Vessels installed sprinkler system which is excess equipment installed but not required has not been serviced IAW NFPA 13. 46 CFR 118.120

Electrical equipment on a vessel must be installed and maintained to Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Electrical outlet in laundry space to the left of the washer was not mounted to the bulkhead and the cover was cracked. 46 CFR 120.200

Each connection to a conductor or terminal part of a conductor must be made within an enclosure. Exposed wires were found behind the dryer coming from the installed enclosure. 46 CFR 120.340(g)

Each connection to a conductor or terminal part of a conductor must be made within an enclosure. Electrical enclosure in overhead of the aft dry stores space was found with wires exposed and the cover plate missing. 46 CFR 120.340(g)

Electrical equipment on a vessel must be installed and maintained to Protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment, and electrical shock. Hot water tank in engine room was missing the cover for the electrical connection/controller box. 46 CFR 120.200

Electrical equipment and installations must be suitable for the roll, pitch, and vibration of the vessel underway. Several overhead lights in engine room and emergency diesel generator room were mounted with zip ties and bailing wire. 46 CFR 120.220

Distribution panels and switchboards that are accessible from the rear must be constructed to prevent a person from accidentally contacting energized parts. #3 Generator was being serviced and the rear cover was removed. Replace cover while not actively being serviced.

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. Electrical equipment on a vessel must be installed and maintained to minimize accidental personnel contact with energized parts. Breaker panel in laundry room had an ope slot and was not properly blanked. 46 CFR 120.200(c)

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. Public address speaker in engineering passageway was found zip tied in the overhead and not properly mounted. 46 CFR 184.610(b)

At each inspection for certification and at every other vessel inspection all observed unsafe practices, fire hazards, and other hazardous situations must be corrected and all required guards and protective devices must be in satisfactory condition. Multiple removable deck plates throughout the lower decks including engine room were not secured and missing mounting hardware.

At each initial and subsequent inspection for certification, the owner or managing operator shall be prepared to conduct tests and have the vessel ready for inspection of its fire protection equipment. Vessels fixed fire protection system in the engine room, emergency diesel generator space and galley had not been serviced since Feb 2022. 46 CFR 115.810

On a vessel on which the number of passengers permitted on upper decks is limited by stability criteria, as indicated by the vessel's stability letter, the maximum number of passengers allowed on an upper deck must be indicated by a durable marking of at least 25 millimeters (1 inch) numbers and letters at the entranceway to that deck. Aft stairs leading to the upper deck was not properly marked with maximum passenger capacity. 46 CFR 122.602

Electrical equipment on a vessel must be installed and maintained to minimize accidental personnel contact with energized parts. Room 106 entry light was missing the bulb and light cover. 46 CFR 120.200(c)

Each vessel must be provided with a visual and audible alarm at the operating station. Bilge high water alarm system was not providing an audible alarm at the operating station. 46 CFR 119.530

Complete but simple instructions for the operation of a fixed gas fire extinguishing system must be located in a conspicuous place at or near each pull box and stop valve control and in the space where the extinguishing agent cylinders are stored. If the storage cylinders are separate from the protected space, the instructions must also include a schematic diagram of the system and instructions detailing alternate methods of releasing the extinguishing agent should the local manual release or stop valve controls fail to operate. Simple instructions and schematic diagram of fixed gas fire system in engine room and emergency diesel generator space were missing. 46 CFR 122.612

On a vessel of more than 19.8 meters (65 feet) in length, the public address system must be a fixed installation and be audible during normal operating conditions throughout the accommodation spaces and all other spaces normally manned by crew members. Crew berthing passageway speaker was inoperable. 46 CFR 121.610

At each initial and subsequent inspection for certification, the owner or managing operator shall be prepared to conduct tests and have the vessel ready for inspection of its fire protection equipment. Portable fire extinguisher in ladderwell leading to crew berthing had not been serviced. 46 CFR 115.810

Each vessel that relies on electricty to power vital systems must be arranged so that the loads can be energized from two sources of electricty. Two generators are currently unable to be paralleled to supply adequate load, the third genertor has an excessive oil leak. Provide tech report and demonstrate proper operation prior to movement. 46 CFR 120.310(a)

Electrical equipment on a vessel must be installed and maintained to provide services necessary for safety under normal and emergency conditions. The #3 generator was unable to maintain proper voltage. Demonstrate proper operation of the #3 generator on load to the satisfaction of the attending MI. 46 CFR 120.200(a)

Each survival craft must be secured to the vessel by a painter with a float-free link. Two liferafts on the port side were secured to the cradle with line and the float free link was not installed. The hydrostatic release was properly installed, cleared on the spot. 46 CFR 117.130(a)(1)

Paint and flammable liquid lockers must be constructed of steel or equivalent material, or wholly lined with steel or equivalent material. A fiberglass deck box was located on the main deck aft that was filled with paint and other flammable materials. 46 CFR 116.405(e)

Fire load calculations must be submitted by the owner for review to the Marine Safety Center when: (1) A space is designated as a low risk accommodation space by the owner; or (2) The cognizant OCMI determines, based on the quantity of combustibles, that the fire load present in a high risk accommodations space may exceed 37.5 kg (7.5 pounds) of combustibles per square meter (square foot) of deck area. Space forward of passenger cabins on the lounge deck as well as the starboard forward passenger cabin (aka the Salt Room) had linens, towels and other large quantities of combustibles stored in these spaces. 46 CFR 116.427(a)

A fire control plan must be posted on the vessel in a location that is accessible and visible to all passengers. The plan must show compartment titles and hazard classification of accommodation and service spaces. Starboard main deck passenger cabin has been converted to a "Salt Room". Fire control plan does not reflect on changes made to this space. Deficiency to be corrected prior to beginning of next operating season in 2023. 46 CFR 116.530

All vessels must have navigation lights that are in compliance with the applicable sections of the International and Inland Navigation Rules, except that a vessel of more than 19.8 meters (65 feet) in length must also have navigation lights that meet UL 1104, “Marine Navigation Lights,” or other standard specified by the Commandant. All around anchor light was inoperable. 46 CFR 120.420

The construction and arrangement of a vessel must allow the safe operation of the vessel in accordance with the terms of its Certificate of Inspection giving consideration to provisions for a seaworthy hull, protection against fire, means of escape in case of a sudden unexpected casualty, guards and rails in hazardous places, ventilation of enclosed spaces, and necessary facilities for passengers and crew. The starboard galley ventilation did not completely seal when closed. 46 CFR 116.100

Vessels described by 46 CFR 114.110(e) must have an interconnected fire detection system in compliance with 46 CFR 181.450 installed in all enclosed areas where passengers and crew have routine access, including accommodation spaces and machinery spaces. Heat detector in EDG space was damaged. 46 CFR 118.400(d)

Vessels described by 46 CFR 114.110(e) must have an interconnected fire detection system in compliance with 46 CFR 181.450 installed in all enclosed areas where passengers and crew have routine access, including accommodation spaces and machinery spaces. Heat detectors were not properly mounted in the engine room. 46 CFR 118.400(d)

Electrical equipment on a vessel must be installed and maintained to: Minimize accidental personnel contact with energized parts. Electrical panel in engineers stateroom was missing a blank. 46 CFR 120.200(c)

Electrical equipment on a vessel must be installed and maintained to: Provide services necessary for safety under normal and emergency conditions. Multiple rooms were missing overhead lighting bulbs and the connections were left dangling. 46 CFR 120.200(a)

A vessel must be operated in accordance with applicable laws and regulations and in such a manner as to afford adequate precaution against hazards that might endanger the vessel and the persons being transported. Beverage C02 bottles in lounge are unsecured. 46 CFR 122.100

Tubular gauge glasses, if fitted to diesel fuel tanks, must be of heat resistant materials, adequately protected from mechanical damage, and provided at the tank connections with devices that will automatically close in the event of rupture of the gauge or gauge lines. EDG fuel tank has a plastic gauge and does not have a device installed to automatically close in the event of rupture. 46 CFR 119.440(a)(7)

UT tech report found multiple areas of wastage that is above 25% and in some areas as much as 42%. Crop and renew to original scantling. The areas of wastage according to the report were found: -near the keel between frame 13 and running to frame 19 on both port and starboard side -near the keel between frame 22 to frame 26 -On the port side bottom midships between frame 22-frame 24. -Near the keel, port side between frame 29-31 -Between port frame 32 and 33 -Between port frame 33 and 36 -Between port frame 37 and 38 -Between port frame 39 and 42 -Between Starboard frame 30 and 32 -Between starboard frame 33 and 36 -Between starboard frame 38 and 39 -Between starboard frame 39 and 42 -Port side between frame 59-60

In the outboard most area of the bottom of the hull at Port frame 41, UT shots found 30% wastage. Due to the placement of blocks and shipyard restrictions, welding to crop and renew the wastage is not possible during this dry dock. Crop and renew to original scantling during next dry dock.

Vessel has had considerable amount of hull replaced within the past 10 years and the port anchor is no longer on board. There is a concern of a total aggregate vessel weight change of more than 2% since the last stability test. Provide evidence that the vessel's weight has not undergone total aggregate change of more than 2%.

Provide complete instructions for operation of all fixed gas fire extinguishing systems iaw. 46CFR122.612 at or near each pull box and stop valve control. also include a schematic diagram of the system and instructions detailing alternate methods of releasing agent.

Post CO2 warning sign on space storing CO2 for emergency generator iaw 46CFR122.612(h)(i)(1)

Ensure all "break glass in case of emergency" have appropriate hammers attached and signage.

Provide lagging for all hot sections of exhaust piping in engine room.

Replace missing structure fire protection insulation on fwd side of FWD MVZ bulkhead in way of door frame.

Arrange battery cables to ensure there are no chaffing cables in battery arrangement on top deck aft of emergency generator space.

Repair or replace broken hinge on deep fat fryer in galley.

Remove locking door knob on life jacket stowage close in cabin 106.

Replace missing lighting globe/guard on overhead light bulb in lazarette.

Provide updated Lightlist and Coast Pilot.

Replace missing flange plate on flange located on backside of the collision bulkhead near top.

Ensure public address system is operational throughout the vessel's accommodation spaces.

Replace expired battery in ring buoy water-light on upper deck.

Replace missing bolts in breaker panel cover for electrical breaker panel in lazarette on the port side.

Properly secure electrical junction box in way of HVAC machinery.

Post instructions for emergency fuel shut off vlave operation.

While the vessel is engaged in towing the vessel must be controlled by a licensed Master or Mate of towing. Vessel has until April 1st 2022 to man vessel with licensed Master and Mate of towing.

Vessel must provide updated stability calculations to include towing to Coast Guard Marine Safety Center to update vessels stability letter by April 1st 2022

Vessel shall provide correct light and day shape configuration for the tow being conducted prior to towing.

Vessel shall start and maintain records for towline and terminal gear used for towing astern or alongside prior to towing

Vessel has two fractured stiffeners on the forward bulkhead of the potable water tank, starboard side. Repair cracked welds no later then May 1, 2020.

Posted Emergency Instructions and Station Bill fail to address procedures for rough seas and addressing the fitting of daedlight covers on main deck windows as required by COI's routes and conditions. Update Emergency Instructions and Station Bill as appropriate.

Operating instructions for engine room fixed halon system are outdated/inaccurate and need to be updated.

Distribution panels must prevent persons from accidentally contacting energized parts; the 110vac panel in the port lazzarette had multiple openings inside the panel.

Each connection to a conductor must be made within an enclosure; there are two dead ended cables in the overhead of the lazzarete and a pump on the port outboard side missing a cover for the junction box.

Nonconducting matting must be provided on the deck in the rear of a switchboard; the engine room and emergency generator switchboards were not provided with matting.

Each ungrounded system must be provided with a ground detection system; the egen ground detection system was not properly working.

Egen fuel shutoff valve must be operable from outside the space; the remote fuel stop was inoperable.

The vessel must have an audible and visible alarm in the pilothous upon failure of power to the steering gear; the loss of power alarm did not function properly.

Exposed hazards must be protected with a cover; an AC compressor flywheel and belt were missing a cover.

Each lighting fixture must have a globe, lens, or diffuser; the light cover for the fixture over the engine room air receiver was missing.

The temporary lighting system in the voids forward of the engine room needs to be removed or of the permanent type.

Deck hatches must close watertight; the forepeak scuttle would not properly close.

Demonstrate drills prior to seasonal operations.

Open hatch pilot house warning lights were not available for inspection.

Vessel did not have a device on station to open the forepeak remote bilge suction valve.

Vessel must be equipped with a sound powered telephone system to communicate between the pilot house and steering gear compartment.

Engine room ventilation fire dampers failed to properly deploy upon activation. Service dampers to allow for full closure.

Identified that the aluminum life jacket stowage boxes on the upper aft weather deck were not secured to the deck. Secure boxes to prevent shifting in the event of heavy weather.

Distribution panels located on the port aft bulkhead of the engine contained unlabled circuits. Properly label all circuit breakers.

Submit boilers PSTP's to MSC for approval.

Complete Coast Guard credit dry-dock and internal examination when vessel is removed from layed-up status.

Replace rescue boat with Coast Guard approved 46CFR160.156 rescue boat IAW 46CFR199.202(b).

Provide liferafts for 200% of vessel passenger capacity, 100% capacitiy on each side of vessel IAW 46CFR199.201(d)(1)(i).

Complete interim verification with class prior to departure from port.

Vessel to make permanent repairs to damaged cause due to grounding prior to carrying revenue passengers. Vessel to proceed to ASD Ketchikan for drydock to survey the extend of grounding damaged by local [name withheld] is to follow submitted transit plan approved by SECTOR Juneau OCMI.

Vessel does not have a Geographic Specific Appendix for Alaska (neither SE or W AK) as required by the United States Federal Water Pollution Control Act as amended by Section 701 and the Coast Guard Maritime Transportation Act of 2004.

Vessel restricted to GOLDBELT Dock Juneau, Alaska until repairs to the Main Propulsion Engine are completed to the satisfaction of an attending CG marine inspector.

Install proper engine gauges at operation stations IAW 46CFR119.410(b).

Make repairs to boiler and conduct hydrostatic test and operational test IAW 46CFR61.01-1.

Properly secure all wires with metal supports throughout vessel IAW 46CFR120.340(b)(4).

Replace broken light cover on overhead light on aft lounge deck IAW 46CFR120.200.

Replace rescue boat with CG approved 160.135 rescue boat IAW 46CFR199.202(b).

Increase liferaft capacity to meet requirements IAW 46CFR199.201(d).

Remove sealant from tonnage opening on forward weather deck on promenade deck IAW 46CFR69.65(g)(2).

With full compliment of ships crew, perform abandon ship, fire, and security drills IAW 46CFR122.520, 46CFR122.525, and 33CFR104.230(b).

Repair as original 24 inch crack in hull plating 3 foot aft of rudder post.

Determine cause of SCBA alarms and ensure all SCBA's working properly

Conduct training on SCBA alarms.

ENSURE ALL LIFE RAFT CERTS ARE CURRENT.

UPDATE ALL SERVICING ON PORTABLE FIRE FIGHTING EQUIPMENT.

Relabel child size lifejacket storage compartment.

high water alarm midships , ensure that it is operational

Improper seal on forward deck hatch and fwd vent closures, renew or repair to obtain proper seal for watertight integrety

Deck in state room H-7 is wasted, crop and renew deck material and related support frames.

Deck plating broken loose from support fames, reweld deck plate to support frames.

Flammable stores, liquor stores, galley stores, paints and solvents improperly stowed due to ship yard work. Properly stow all flammable materials and clean all bilges, machinery, galley and misc work spaces to the satisfaction of CG inspector.

Boiler exhaust fan missing, install new boiler exhaust fan in stack space and conduct operational test.

Crop and renew bulkhead stiffiner, on aft side, port side third from centerline, of bulkhead 43, also crop and renew wasted frame section 18in x 18in of frame 45 port side.

Crop and renew 8ft by 28in lower section on port side of tranverse bulkhead 43 during next drydock.

Provide copy of fixed and portable fire fighting equipment technician inspection results.

Crop and renew vent duct starboard side forward compartment, that supplies ventilation to laundry room.

Replace 1ea 50ft fire hose to provide a total of 15 onboard.

Crop and renew fwd peak ballast tank bilge suction valve and related piping.

Starboard side shaft tube support frame and strut needs croped and renewed.

Port side life boat davit missing motor/pump assembly. Repair davit to safisfaction of CG inspector.

Child size life jackets are stowed imporperly, must provide stowage separate from adult life jackets and clearly marked stowage locker.

Crop and renew all wasted frames and stiffeners under both forward port and starboard side fresh water tanks to the satisfaction of CG inspector.

Crop and renew all wasted frames and stiffeners under both port and starboard side crew berthing areas to the satisfaction of CG inspector

Mounting bolts for #1 rescue boat sponson are excessive length, creates safety hazard. Cut off to a reasonable length to prevent injury while recovering person in water.

PROVIDE CERTIFIED TRUE COPIES OF ITC AND WORKSHEETS TO THE NVDC TO HAVE ITC INCLUDED IN VESSELS OFFICAL FILE. REFER TO NVIC 11-93.

PROVE FIXED FIREFIGHTING IN ENGINE ROOM SECURES ALL ENGINES IAW 46CFR118.420(3).

MAKE PERMANENT REPAIRS TO LAGGING FOR STARBOARD MAIN ENGINE.

REVISE FIRE CONTROL PLAN TO REFLECT POSITION OF ALL ITEMS ON VESSEL, INCLUDING SMOKE DETECTORS, PULL STATIONS, EEBA'S, AND LOCATION OF HALON BOTTLES. LEGACY COMPONENT DESC: Fire Control Plans

Fire control plan does not represent vsl as built, various items not marked. LEGACY COMPONENT DESC: Safety Orientation

Label manual fire dampers and automatic fire dampers in overhead.

Insatll AFD as required in way of frame 39 on main deck passageway as per plan

Clean engine room bilge to the satisfaction of the [name withheld] oil and debris again

EXCESSIVE ACCUMULATION OF OIL, TRASH, DEBRIS IN ALL BILGES. HISTORY OF NOTED IN PAST TWO YEARS.

Provide and submit fire control plan for gally modifications completed this shipyard period, to MSC for Approval

Access to fire hose station #2 in engine room blocked by parts storage rack

Portable water extinguisher in engine room discharged. Item should be serviced or removed from crew access.

Oxygen and acetylene cylinders improperly secured with manila rope rather than proper chain or rack.

SUBMIT CORRECTED FIRE AND SAFETY PLAN TO MSO JACKSONVILLE FOR REVIEW AND APPROVAL AS DISCUSSED IN CID LETTER DTD 28DEC98.

RESUBMIT VESSEL'S FIRE & SAFETY PLAN TO THE USCG MARINE SAFETY CENTER FOR APPROVAL. THE PLAN SHALL IDENTIFY THE MAIN VERTICAL ZONE BOUNDARIES AS OUTLINED IN ELLIOT BAY DESIGN GROUP PROPOSAL DATED 09APR98.

INSTALL FIRE DAMPERS IN ACCORDANCE WITH APPROVED PLANS.

PROVIDE ELECTRICAL SUPERVISION OF THE TWO MIST PUMP STOP-CHECK VALVES AS REQUIRED BY U.S. COAST GUARD POLICY FILE MEMORANDUM ON GUIDANCDE FOR USE OFNFPA 750 (1996) WITH WATER MIST SYSTEMS ON U.S. VESSELS.

EXTEND COVERAGE OF THE MIST SPRINKLER SYSTEM TO INCLUDE THE MAIN GALLEY WALK-IN FREEZER.

INSTALL FIRE DAMPER AND FIRE EXTINGUISHING SYSTEM INSIDE THE GALLEY RANGE DUCT AS REQUIRED BY SOLAS 74 REG. 41-2.4.3.

PROVIDE PROPOSAL TO CORRECT COVERAGE OF INBOARD EDGE ON TONNAGE OPENING LOCATED ON THE MAIN DECK STARBOARD SIDE AT CABIN M6.

PROVIDE PLAN FOR THE INSTALLATION OF FIRE DAMPERS (AUTOMATIC WITH MANUAL CONTROL) IN ALL VENTILATION DUCTS THAT PENETRATE THE MAIN VERTICAL ZONE BOUNDARIES. PLAN SHOULD INCLUDE CLEAR IDENTIFICATION OF THE MAIN VERTICAL ZONE BOUNDARIES AND LOCATION OF ALL DUCTS.

PROVIDE POSITIVE LOCKING DEVICES FOR BOTH VALVES ON THE SPRINKLER SYSTEM PRESSURE SWITCHES SENSING LINE SO THEY MAY BE LOCKED IN THEIR APPROPRIATE OPERATIONAL POSITION.

PROVIDE CURRENT DEVIATION TABLE FOR VESSEL'S MAGNETIC COMPASS.

PROVIDE PHOTO LUMINESCENT MARKINGS FOR ALL FIRE EQUIPMENTT LOCATIONS.

PROVIDE POSITIVE LOCKING DEVICES FOR SPRINKLER PUMP DISCHARGE VALVES SO THEY MAY BE SECURED IN THE OPEN POSITION.

PROVE PROPER OPERATION OF MAGNETIC DOOR RELEASES ON 5 NEWLY INSTALLED FIRE DOOR SETS. VESSEL TO CORRECT DEFICIENCY PRIOR TO CARRIAGE OF PASSENGERS ANDSHALL MAINTAIN DOORS IN THE CLOSED POSITION UNTIL CORRECTED.

PROVIDE CLOSURES FOR VENT OPENINGS IN BOTH ACCESS DOORS TO THE EMERGENCY GENERATOR ROOM.

PROVIDE APPROVED BRAZING PROCEDURE SPECIFICATIONS FOR THE BRAZING PROCESS BEING APPLIED TO THE SPRINKLER SYSTEM. 46CFR 57.03-1.

OBTAIN COMMANDANT, U.S. COAST GUARD, APPROVAL OF THE AWS A5.8 BRAZE MATERIAL IN THE NEWLY INSTALLED SPRINKLER/WASTER MIST SYSTEM.

PROVE PROPER RELIEVING PRESSURE OF AUXILIARY BOILER RELIEF VALVE. THIS REQUIREMENT IS TO BE COMPLETED TO THE SATISFACTION OF AN ATTENDING MARINE INSPECTOR.

PROVE PROPER RELIEVING PRESSURE OF AUX BOILER SAFETY RELIEF VALVE.

MAKE REPAIRS TO PERMANENTLY AFFIX PORT AFTERMOST LIFERAFT CRADDLE FOUNDATION TO VESSEL ON FOURTH DECK. REPAIRS MUST BE COMPLETED PRIOR TO DEPARTURE FROM NEW YORK HARBOR AND TO THE SATISFACTION OF THE ATTENDING MARINE INSPECTOR.

Remove all gasket material from tonnage opening, port side, Promenade deck,crew cabin forward of fire station #11. Metal to metal contact, no seals allowed.

Demonstrate proper operation of following General Alarm bells: Observation Lounge port & stbd; Lounge Deck aft transverse passageway stbd side; diningroom stbd forward.

REPAIR AND PROVE PROPER OPERATION OF FIVE REMOTE FUEL OIL REACHRODS.

INSTALL AND PROVE PROPER OPERATION OF LOW LUBE OIL PRESSURE SHUTDOWNS FOR ALL THREE SHIP SERVICE GENERATORS AS PER 46 CFR 111.12-1.

REMOVE ALL DEAD-END CABLES FROM THE MAIN DIESEL ENGINES AND GENERATORS.

REPLACE THE CRACKED HEAT SENSOR ABOVE THE SWITCHBOARD IN THE ENGINEROOM.

PROVE PROPER OPERATION OF THE STARBOARD MAIN DIESEL ENGINE TACHOMETER.

REPAIR THE INOPERATIVE DOGGING BAR ON THE STEERING COMPARTMENT ESCAPE SCUTTLE.

PROVE PROPER OPERATION OF THE STARBOARD GENERATOR TACHOMETER.

PROVE PROPER OPERATION OF THE CENTER SSDG REVERSE POWER RELAY SAFETY DEVICE

PROVIDE AN ADDITIONAL RUBBER MAT IN FRONT OF THE S/S ELECTRICAL SWITCHBOARD

PROVIDE PIPE PLUGS FOR ALL MDE AND SSDG PRIME MOVER RAYCO FUEL OIL FILTERS.

MAKE READY FOR INSPECTION ALL MACHINERY SPACE PRESSURE VESSEL DATA PLATES.

PROVE PROPER OPERATION OF THE VESSEL'S MSD TYPE III, HOLDING TANK AFTER TANK TOP RENEWAL.

SUBMIT FOR APPROVAL TO G-MSC-1, THE MARINE SAFETY CENTER, THE ALTERATION DRAWINGS AND STABILITY CALCULATIONS FOR THE NEWLY INSTALLED GREY WATER TANKFITTED AFT OF THE ENGINEROOM.

CONDUCT AN INSTALLATION LOAD TEST TO 25% IN EXCESS OF THE RATED LOAD FOR THE NEW DECK CRANES PRIOR TO USE.

PROVIDE FOR ACCEPTANCE, CERTIFICATES FOR THE CARPET INSTALLED IN -10- PASSENGER STATEROOMS.

CONDUCT GENERAL CLEAN UP OF ALL STORAGE AREAS OF CONBUSTIBLE MATERIALS.

CONDUCT FIRE AND MUSTER DRILL FOR CG REVIEW (PENDS CG AVAILABILITY)

PROVIDE HANDLE FOR STEERING COMPLARTMENT ACCESS HATCH IN CREWS GALLEY.

ADJUST AND DEMONSTRATE ALL WT DOOR AND ASSOCIATED INDICATORS (BRIDGE INDICATOR LIGHTS)

REPAIR LEAKS IN CREW GALLEY SINK AND IN MAIN GALLEY GARBAGE DISPOSAL.

PROVIDE PAPER TOWELS FOR GALLEY HAND WASH STATION.

REMOVE EXCESS OIL AND FUEL FROM ENGINEROOM BILGES.

MAKE ELECTRICAL SWITCHES LOCATED IN LOCKED WIRE STORAGE ARES ACCESSIBLE IN AN EMERGENCY.

FREE FLAP ON STEERING COMPARTMENT GOOSENECK VENT.

PERFORM SANITARY CLEANUP OF CREWS GALLEY.

REPAIR AND PROVE PROPER OPERATION OF STARBOARD MAIN DIESEL PROPULSION PRIORTO LEAVING PORT.

CONDUCT UNDERBODY HULL SURVEY DUE TO GROUNDING AT THE FIRST AVAILABLE PORT.PERFORM EFFECTIVE REPAIR TO ANY DAMAGE AS NECCESSARY TO THE SATISFACTION OFCOGNIZANT OCMI, NOT LATER THAN 07 DEC 1986.

SUBMIT APPROVED PLAN TO [name withheld] PERFORMED AT THE SUN DECK FORWARD CABINS BETWEEN FRAMES 32 AND 38.

PROVE PROPER OPERATION OF THE P.A. SYTEM THROUGHOUT THE VESSEL PRIOR TO CARRYING PASSENGERS FOR HIRE.

MAKE PERM REPAIRS TO SIDE SHELL PL. AT FRAME 38, DAMAGED AREA 1" DEEP X 6" WIDE X 24" LONG AND AT FRAME 35, AREA 1&1/4" DEEP X 6" WIDE X 20" LONG. BOTH TO BE CROPPED AND RENEWED. LOCATED STRBD SIDE BETWEEN W/L AND RUB RAIL.
