CORAL SEA

Vessel must meet survival craft requirements as per the table in 46 CFR 180.200(c). Vessel is currently missing 01 (30 person) IBA as required on the vessel's COI due to it being found un-serviceable at a servicing facility. Vessel has satisfactorily installed 01 (25 person) loaned IBA on board. Due to vessel operating in cold water months for its operating area as dictated in NVIC 07-91, the vessel is limited to 25 total persons allowed (this number includes crew), while current IBA is on-board. During cold water months, January 1st to February 28th, and from March 1st through May 31st when operating North of a line drawn 255 degrees true from the San Mateo Point Light at latitude 33-23 north, the vessel is limited to 25 total persons while the (25 person) IBA is on board. This CG-835 will remain in effect until such time that the vessel is able to prove satisfactory primary lifesaving for additional persons.

Pre-engineered fixed firefighting system (Fireboy) does not prevent engine restart after shutdown. Demonstrate proper operation of interlock.

Ring lifebuoy water light inoperable. Demonstrate proper operation.

Each bunk shall be immediately adjacent to an aisle leading to a means of escape from the lounge area. Vessel has double occupancy bunks installed which does not allow rapid egress in an emergency. Reduce number of overnight passengers to 21 so that bunks are single occupancy only. **705 C, Prior to carrying more than one person in double bunks.

A vessel not required to have a power driven fire pump must have at least three 2.5 gallon buckets. The required 2.5 gallon fire buckets were not onboard the vessel. Provide 03, 2.5 gallon fire buckets with lanyards to be kept ready for use aboard the vessel.

The existing mattresses used in the passenger sleeping bunks were not flame retardant. Provide flame retardant treatment to the mattresses or provide new mattress's that meet the flame retardant requirements of new subchapter "T".

EPIRB hydrostatic release expired. Vessel restricted to 3 NM from land until corrected.

Properly mark lifejacket storage locations.

Properly mark fwd escape hatch.

Properly mount IBA.

Update coast pilot, light list and chart.

Install blanks in electrical panel in stbd berthing.

Properly mount fire extinguisher on the bridge.

Connect GPS to VHF-DSC radio.

Replace & re-mount bilge high-water alarm.

Forepeak: Make bilge pipe penetration of collision bulkhead watertight.

Port stateroom: Re-route cable to breaker box to protect inner wires.

Properly connect IBA painter to the hydrostatic release.

Replace 2 rejected Type I PFDs

Install outlet cover in bulkhead fwd of galley

Provide CG Approved portable fire extinguisher brackets

Obtain DOT approved alcohol screening device

Replace expired hydrostatic release unit

Install engine room vent intake closure

Secure main engine electronic control cable.

Make engine room vapor tight

Replace all Welding Cable

Provide current U.S. Coat Pilot

Post both pgs of COI in view of passengers

Provide anchor day shape

Post emergency broadcast placard near radio.

Modify rescue platform to allow rescuer to stand at bottom (install platform)

Replace generator raw water supply hose.

Fixed f/f system must shut down propulsion machinery and generator upon activation.

Secure wiring & refrigerator coil IWO the fish hold.

Label e-escape from the fwd accommodation.

Add combing IWO accom access ensuring minimum of 6."

Provide globes for light fixtures in the lazarett.

Provide extension for e-fuel shut-off handle.

Secure wiring in the aft accom port electrical fixture.

Provide metallic security for electrical wiring in the E/R.

Provide blank for the junction box in the E/R.

Conduct hydrostatic test of over due CO2 ext.

Provide vent shut-off prior to operating with passengers.

Provide circuit breakers covers for engine room and crew bunk room panel box as needed.

Re-install guard for rotating machinery for gen set in engine room.

Repair/replace retro reflective material on PFD's as needed.

Replace broken window at operating station/bridge - port side.

Fix/replace horn at operating station.

Document man-overboard drills IAW 46 FR 185.520.

Ensure water tight integrity between engine room and aft bunkroom.

Provide MIS drug report for crew.

Renew one child size and one adult size Type I life preserver. LEGACY COMPONENT DESC: Condition

Double clamp flexible hose pedro connections in bilge piping where needed. Item corrected prior to completion of inspection.

Install proper flex hose in bilge piping system for bilge pick-up line in engine room. Item corrected prior to completion of inspection.

Vessel propellers fouled by trawl net. Prove proper operation of main propulsion prior to carrying passengers.

Renew/Service portable fire extinguisher at entrance to forward bunk room. Extinguisher found with needle on gauge showing low pressure in bottle. Extinguisher had recently been serviced on April 1, 2002.

Post current stability letter. LEGACY COMPONENT DESC: Stability Letter

Post Employee Assistance Program placard.

Document monthly testing of 406 MHz EPIRB. LEGACY COMPONENT DESC: Logbook/Record (unofficial)

Replace "SO" cable for blower in forward tank space with approved marine grade cable. Master disconnected and removed cable prior to completion of inspection. LEGACY COMPONENT DESC: Cable

Make fuel return line penetration through forward engine room bulkhead watertight. Packing material previously installed around penetration had parted from circumference of opening and was showing minor gap. LEGACY COMPONENT DESC: Hull Construction

Provide 2 orange smoke flares. Found 2 orange smoke flares past expiration date during inspection.

Fill in required vessel information on emergency broadcast placard in pilot house.

SUBMIT APPLICATION TO CORRECT ADDRESS ON VESSEL CERTIFICATE OF DOCUMENTATION.

PROVIDE ON BOARD CURRENT NAVIGATIONAL CHARTS AND PUBLICATIONS UPDATED THROUGH CURRENT LOCAL NOTICE TO MARINERS.

PROVIDE SINGLE LINE WIRING ELECTRICAL DIAGRAM FOR DC ELECTRICAL SYSTEM INCLUDING EQUIPMENT LISTS.

INSTALL SHORE POWER CIRCUIT BREAKER AS REQUIRED BY 46 CFR 183.390(C)&(D).

LABEL BREAKERS IN ELECTRICAL POWER PANEL.

MAKE HOLES IN ENGINE ROOM BULKHEADS WATERTIGHT.

GROUND ELECTRICAL SYSTEM POWER PANELS PER 46 CFR 183.372.

RE-SUBMIT AC ELECTRICAL DIAGRAM WITH CORRECTIONS AS NOTED.

INSTALL V-BELT GUARD ON PORT MAIN ENGINE.

INSTALL F/O VENT FLAME SCREENS.

INSTALL CAPTIVE CHAINS ON SCUTTLES.

VESSEL IS RESTRICTED FROM OPERATING WITH PASSENGERS UNTIL AFTER ELECTRICAL PLANS HAVE BEEN SUBMITTED AND APPROVED BY MSO LALB.

VESSEL HAD ALL ELECTRICAL PULLED. ALL NEW WIRING, BATTERIES AND GENERATORSTO BE INSTALLED. OWNER TO PROVIDE WIRING PLAN FOR USCG APPROVAL PRIOR TO INSTALL.

VESSEL TO RECEIVE NEW ENGINES AND STEERING COMPONENTS. OWNER DIRECTED TO NOTIFY USCG FOR DRYDOCK FOLLOWUP INSPECTION AND STABILITY EVALUATION PRIOR TO SAILING.

Vessel to conduct underway tests with USCG and undergo COI Re-Exam prior tooperating with passengers.

Prior to refloating vessel, clean and make temporary repairs to hull to prevent oil discharge from vessel.

Submit Repair Plans which covers damage to Hull, Port Shaft, Strut, Rudder,Engines to the satisfaction of [name withheld].

Clean bilges and make free from oil

Post COI and Stability letter

Replace PVC piping in main engine cooling system with approved metallic material

Install ventilation closures to engineroom

Renew hose (suction) to head flush pump using approved hose

Due to primary lifesaving change vessel is restricted from operating with more than 30 persons on an Oceans route. This requirement will be cleared upon re-issuance of COI with changes made to VFLS

Update first aid kit

Renew line To lifefring buoy light and install corrosion ressistant clip_x001C_ per 46 CFR 180.70 and MSO LALB CID policy

Renew painter attaching lifefloats together as required by 46 CFR 180.137(e)

Repair or renew 1 adult and 1 child PFD, vessel is restricted from operating with more than 4 child and 44 adult passengers until completed.

Install stuffing tube to wiring servicing head flush pump & hard wire pump

Renew R/W suction and discharge hose to genset R/W cooling system

Install stuffing tube to wiring servicing hot water heater

Install machinery guard to condensor fan in galley

Replace windshield port side fwd due to cracked pane. As required by 46 CFR177.1010,1020,& 1030

Repair F/O leak on fwd bulkhead to E/R

Replace pedro connection to main engineroom bilge suction hose with approved hose

Post instructions for fixed fire fighting system per 46 CFR 185.612

Install emergency lighting for fwd accomodation space

Repair as new battery support box in way of engineroom stbd side aft

Install smoke detectors of the independent modular type meeting the requirements of 46 CFR 181.450 in overnight accommodation spaces

Update charts with local Notice to Mariners

Have on board copy (current) of coast pilot

Repair as new F/O leak on bilge maniforld & port main engine

Make the vessel available for a follow-up ride after drydocking with a Coast Guard Marine inspector on board.

Repair or replace the SSB radio.

Install shaft grards.

Replace the stbd gallery window.

CONDUCT A SIMPLIFIED STABILITY TEST IN THE PRESENCE OF A COAST GUARD MARINEINSPECTOR.

Conduct a fire and rescue drill in the presence of the U. S. Coast Guard.

Repair and prove proper operation of starboard independant generator.

PROPERLY STENCIL THE REMOTE FUEL SHUTOFF VALVE FOR THE DAY FUEL TANK._x001C_ _x001C_ _x001C_ _x001C_

INSTALL A BLANK FOR THE MISSING SWITCH IN THE LIGHT PANEL ON THE STARBOARD SIDE OF THE CREW'S BUNKROOM._x001C_ _x001C_ _x001C_

PROPERLY LABEL ALL CIRCUITS IN THE LIGHT PANEL ON THE STARBOARD SIDE OF THECREW'S BUNKROOM._x001C_ _x001C_ _x001C_

INSTALL A NEW REGULATOR ON THE PORT GENERATOR AND PROVE PROPER OPERATION._x001C_ _x001C_ _x001C_ _x001C_

MAKE THE REMOTE FUEL SHUTOFF VALVE FOR THE DAY FUEL TANK ACCESSIBLE OUTSIDEOF THE FUEL TANK SPACE._x001C_ _x001C_ _x001C_

HAVE FCC RADIOTELEPHONY CERTIFICATE CORRECTED TO INDICATE PROPER EXPIRATIONDATE._x001C_ _x001C_ _x001C_

HAVE THE VESSEL'S CERTIFICATE OF DOCUMENTATION CORRECTED TO REFLECT THE COASTWISE ENDORSEMENT._x001C_ _x001C_ _x001C_

STENCIL ON THE FORWARD BULKHEAD IN THE FORWARD BUNKROOM, THE PROPER DIRECTION TO OPEN THE EMERGENCY ESCAPE SCUTTLE._x001C_ _x001C_ _x001C_

INSTALL MISSING LIGHTS FOR ALL PASSENGER BUNK SPACES, CREW BUNK SPACES, ANDENGINEROOM._x001C_ _x001C_ _x001C_

PROVIDE ONE SINGLE SIDE BAND RADIO. VESSEL LIMITED TO ZONE 1A (PACIFIC OCEAN AREA BETWEEN POINT CONCEPTION AND LATITUDE 31 DEGREES, 45 MINUTES NORTH NOT MORE THAN 60 MILES OFF THE BASELINE) UNTIL INSTALLED._x001C_ _x001C_

PROPERLY REPAIR THE BROKEN WINDOW GLASS ON THE STARBOARD GALLEY AND FORWARDBUNK ROOM CENTER WINDOW.

REPAIR FORWARD PASSENGER BERTHING LOWER STEP.

REPAIR AND PROVE PROPER OPERATION OF MAIN ENGINE TACHOMETER, FOR STARBOARD MAIN ENGINE.

PROVIDE AND POST A COPY OF THE EMERGENCY CHECK OFF LIST.

OBTAIN AND POST COPY OF VESSEL'S STABILITY LETTER.

PROVIDE CAPTURE CHAINS FOR WATERTIGHT HATCHES.

PROVIDE COVER FOR STARBOARD AFTER BATTERY BOX.

INSULATE GENERATOR EXHAUSTS FORWARD OF COOLING WATER INLET.

CLEAN AND TREAT DRYROT IN ENGINEROOM VENTILATION OPENINGS.

RENEW ROTTEN 2" X 4" CENTER CAPS, AFT OF MAIN ENGINE.

FIND SOURCE OF ELECTROLYSIS.

REPAIR ROTTEN SECTIONS OF MAIN DECK STBD SIDE MIDBODY.

REPAIR ROTTEN LOWER SECTION OF AFT FISH TANK BEFORE USE.

MOUNT BELL OUTSIDE WHEEL HOUSE.

PROVIDE LIGHT LISTS.

PROVIDE UPDATED MAGNETIC COMPASS DEVIATION CARD.

REPAIR BLOWER ON PORT ENGINE.

REPLACE THE BROKEN GLASS IN THE FORWARD ACCOMODATION AREA AND ALONG THE PORT AND STARBOARD SIDE OF THE GALLEY.

PROVIDE THE FOLLOWING PUBLICATIONS: TIDAL CURRENT TABLES,LIGHT LIST,COAST PILOT AND NAVIGATION RULES.

PROVIDE A VALID FCC RADIO STATION LICENSE.

PROVIDE BATTERIES FOR (22) ADULT LIFE PRESERVERS.

PROVIDE AN EMERGENCY CHECK-OFF LIST.

PROVIDE EXHAUST DUCT OF AT LEAST 17 SQUARE INCH CROSS SECTION INTO THE ENGINE ROOM. DUCT SHALL BE RUN FROM OUTSIDE ATMOSPHERE AND TERMINATE IMMEDIATELY ABOVE THE BILGE AT THE CENTERLINE.
