CAROLINIAN

Overcurrent protection must be provided for each ungrounded conductor for the purpose of opening the electric circuit if the current reaches a value that causes an excessive or dangerous temperature in the conductor or conductor insulation. The primary overcurrent protection for the DC circuit was found with blown 30 amp fuses that were modified with copper "jumpers" to bypass the fuse. The conductor is not protected by overcurrent protection.

Emergency instructions must include at a minimum the information found in 46 CFR 185.25-5 which require closing machinery space openings in the event of a fire. The machinery space opening for the natural air duct on the stbd side was frozen open and cannot be closed in the event of a fire.

At each initial and subsequent inspection for certification of a vessel, the owner or managing operator shall be prepared to conduct tests and have the vessel ready for inspections of machinery, fuel, and piping systems, including the following: Operational test of all overboard discharge and intake valves and watertight bulkhead pipe penetration valves. The sea water intake valve for machinery cooling on the port main engine was found leaking at the valve thread coupling.

Piping used in a vital system must: (1) Be composed of ferrous materials except when: (i) Nonmetallic piping materials are permitted by § 182.720; or (ii) Nonferrous metallic piping materials are permitted by § 182.730; Flexible rubber hose that does not comply with § 182.720 was found installed in the vital piping for the fwd void bilge pickup. The rubber hose is installed in between original metallic piping and does not comply with 182.40-5 or 182.710.

Piping used in a vital system must: (1) Be composed of ferrous materials except when: (i) Nonmetallic piping materials are permitted by § 182.720; or (ii) Nonferrous metallic piping materials are permitted by § 182.730; The bilge suction piping for the fwd void space was found corroded in the AC room space.

When necessary for safe operation, the cognizant OCMI may place specific stability restrictions in a stability letter or on the Certificate of Inspection of a vessel not more than 65 feet (19.8 meters) in length, which, under § 178.310 of this part, complies with the requirements of § 178.320 of this part. The stability letter for the vessel requires that the bilge remain clean and dry at all times. The marine inspector identified approximately 1 foot of water in the AC room bilge and approximately 1-2 gallons of oil in the machinery space bilge.

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI, except during an emergency. The owner reported that the vessel lost hydraulic steering with eight passengers on board while underway. The vessel is equipped with dual propulsion and the master navigated safely back to the dock without further incident. The crew identified a fractured flexible hose which led to the hydraulic leak. The vessel is restricted from passenger operations until the steering and repairs are verified by a marine inspector. 46 CFR 176.700

New installations of electrical equipment and material, and the repair or replacement of wire and cable, on an existing vessel, which are completed to the satisfaction of the cognizant Officer in Charge, Marine Inspection (OCMI) on or after March 11, 1996, must comply with New Subchapter T regulations. Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment. Overcurrent protection must be provided for each ungrounded conductor. Conductors must be protected in accordance with their current carrying capacities. Cable and wire for power and lighting circuits must: Meet Section 310-13 of NFPA 70; Be listed by Underwriters Laboratories (UL), as UL Boat or UL Marine cable; or Meet § 111.60-1 in subchapter J of this chapter for cable, and § 111.60-11 in subchapter J of this chapter for wire. The company installed new engine control modules along with new power conductors sometime after 1996. Crew members installed a 30-amp double pole AC breaker to protect the 10 AWG conductor in the DC circuit from the battery switch to the main engine control module panel. The double pole AC breaker is not rated or approved as overcurrent protection for a DC circuit. This exact installation was found on one of the company's sister vessels which resulted in the conductor overheating at the battery switch and causing a fire in the engine room. The installation is not approved and is not to the satisfaction of the OCMI. 46 CFR 183.115

An electrical installation that has any current carrying conductor intentionally connected directly or indirectly to the metal hull shall be subject to certain additional requirements as determined by the [name withheld] additional requirements are contained in applicable regulations in Subchapter J. The neutral of a dual-voltage AC system shall be solidly grounded at the generator switchboard with an ammeter in the ground connection as per 46 CFR 111.55-10(b). The marine inspector identified that the dual voltage AC generator neutral is not grounded at the switchboard or anywhere onboard. If a neutral wire is not connected to ground, the primary electrical hazard is the potential for a significant shock hazard due to the possibility of the neutral wire becoming energized, causing exposed metal parts of appliances or equipment to reach a dangerous voltage if a fault occurs, potentially leading to severe electric shock if touched by a person. The installation is not to the satisfaction of the OCMI. 46 CFR 183.10-30

An electrical installation that has any current carrying conductor intentionally connected directly or indirectly to the metal hull shall be subject to certain additional requirements as determined by the [name withheld] additional requirements are contained in applicable regulations in Subchapter J. The neutral of a dual-voltage AC system shall be solidly grounded at the generator switchboard with an ammeter in the ground connection as per 46 CFR 111.55-10(b). There is no ground fault detection installed at the switchboard. The installation is not to the satisfaction of the OCMI. 46 CFR 183.10-30

A vessel of not more than 19.8 meters (65 feet) in length is not required to carry a rescue boat unless: The vessel carries passengers on an open or partially enclosed deck; and the OCMI determines that the vessel is designed, arranged, or involved in operations so that the vessel itself cannot serve as an adequate rescue craft. The CAROLINIAN was deemed to be adequate as its own rescue craft by the OCMI so long as a sufficient rescue platform is used in conjunction with the vessel due to the free board of the vessel. The rescue ladder on board does not have a sufficient platform at the bottom that can be used by the crew member to retrieve a person. The crew member must hold the ladder with one hand and retrieve the person in the water with the other. The rescue platform was also found to be unstable unless lashed to the CAROLINIAN and no lashings were used during the observed drill. Provide an updated rescue platform with a sufficient platform to retrieve personnel at the bottom and lash the ladder to the side of the vessel when performing drills. 46 CFR 180.210(b) and 46 CFR 176.30-1

The number and identification of the items stowed inside, and their sizes, must be marked in clearly legible letters and numbers on each container for life jackets. Identification of the items may be in words, or the appropriate symbols in IMO Resolution A.760(18). Letters and numbers must be at least 50 millimeters (2 inches) high. Provide new 2" high letters for CHILD life jacket storage in each compartment used for storage. CHILD life jackets cannot be stored on the bridge due to the door that can be closed while underway separating the bridge from the passenger space. 46 CFR 185.604(f)

New installations of electrical equipment and material, and the repair or replacement of wire and cable, on an existing vessel, which are completed to the satisfaction of the cognizant Officer in Charge, Marine Inspection (OCMI) on or after March 11, 1996, must comply with New Subchapter T regulations. Electrical equipment on a vessel must be installed and maintained to protect passengers, crew, other persons, and the vessel from electrical hazards, including fire, caused by or originating in electrical equipment. Overcurrent protection must be provided for each ungrounded conductor. Conductors must be protected in accordance with their current carrying capacities. Cable and wire for power and lighting circuits must: Meet Section 310-13 of NFPA 70; Be listed by Underwriters Laboratories (UL), as UL Boat or UL Marine cable; or Meet § 111.60-1 in subchapter J of this chapter for cable, and § 111.60-11 in subchapter J of this chapter for wire. The company installed new engine control modules along with new power conductors sometime after 1996. The emergency battery installation that supplies DC voltage to the vital systems onboard is missing a battery switch and overcurrent protection for the main supply conductor. The installation is not approved and is not to the satisfaction of the OCMI. 46 CFR 183.115

All escape hatches and other emergency exits shall be marked on both sides using at least 1-inch letters "Emergency Exit, Keep Clear." The fwd emergency exit in the centerline void space where the AC system is located is not marked IAW regulations. 46 CFR 185.30-15

Repairs or alterations to the hull, machinery, or equipment that affect the safety of the vessel must not be made without the approval of the cognizant OCMI, except during an emergency. When repairs are made during an emergency, the owner, managing operator, or master shall notify the OCMI as soon as practicable after such repairs or alternations are made. MI identified a fracture on the #1 transverse beam in the fwd void space and on the backing strip for the vertical weld on the port hull in the fwd void space. 46 CFR § 176.700

Each distribution panel and switchboard must be in as dry a location as practicable, adequately ventilated, and protected from falling debris and dripping or splashing water. Each switchboard must be fitted with a dripshield. The ventilation distribuition panel located in the engine room on the starboard side is missing a drip shield and installed directly under the fire main piping. 46 CFR § 183.330

All vessels except non self-propelled vessels shall be provided with suitable steering apparatus. The operator reported a loss of steering while underway. 46 CFR 182.30-1

All electrical installations shall be to the satisfaction of the OCMI. The air conditioner pump conductors were found burned due to resistance and the air conditioner is out of service. Replace the conductors in accordance with 46 CFR 183 New "T". 46 CFR 183.01-15(a)

Repair damaged light fixture in steering compartment.

Cut the excess electrical wire for bile alarm in steering compartment and install support brackets to secure the wire.

Propulsion machinery shall be capable of operating at constant marine load without exceeding its design limitations (46CFR182.05-1). Port propulsion engine sustained alarm conditions for high engine air inlet temperature, high temperature reduction gear and high pressure fuel.

Replace all identified worn out & damaged gaskets for doors & hatches.

Repair fuel leak on fuel hose fitting on port propulsion engine racor fuel filter.

Install missing front cover on electrical panel in aft engine room.

Replace damaged engine room ventilation ducts.

Replace wasted electrical junction box for AFT deck flood light.

Replace damaged engine RPM gauges at AFT control station.

Troubleshoot and repair low fuel pressure alarm for port propulsion engine.

Repairs or alterations to fuel tank must not be made without the approval of the cognizant [name withheld] of the fuel tank around fill pipe was found to be severely wasted and holed. Submit repair plan/drawing to CG for Approval.

Vessel reported a loss of propulsion while transiting back to port. Vessel returned on her port ME. Vessel is to conduct permanent repairs prior to carrying passengers.

Repair surface damage on life float IAW manufacture procedures.

Repair lose locking mechanism on bridge weather tight doors and demonstrate that the door are water tight.

Repair wasted remote reach rod for suction valve on bilge pipe in space forward of collision bulkhead.

VSL's SSB radio is not programed to operate in frequency. Program proper frequency into SSB and show proper operation.

Provide plan for replacement of the old adult lifejackets.

Provide proof of annual service to (01) portable CO2 fire extinguisher.

Repair inoperable locking device on STBD bridge weathertight door.

Replace cracked window on aft door to main cabin.

Replace damaged gasket on aft main cabin door.

Replace chafed salt water hose on STBD propulsion engine cooling system.

Make proper wire connection on sewage salt water pump motor.

Reroute natural ventilation duct in engine room to lowest part of the bilge.

Replace damaged wood planks on aft cargo area.

Show proper oepration of the vessel's Single Side Band.

Replace light bulb on anchor light with manufacture recommended light bulb.

Repair and install inoperable motor for engine room exhaust ventilation motor.

Repair wasted/holed pipe on salt water cooling system for STBD Propulsion engine.

Show proper operation of the Single Side Band radio.

Replace all identified wasted/broken hose clamps in engine room and tank space with new hose clamps.

Install missing front cover for engine room breaker panel.

Make proper wire connectors to fuse panel in bridge.

Make proper cable connector for generator battery terminal.

Remove standing battery acid and clean battery box for propulsion engines.

Replace expired asprin in first aid kit.

Install missing hand rail (rope) aft deck.

Replace wasted electrical junction box on main mast.

Replace deteriorate line on port life float light.

Re-stencil faded vessel name on one of the life float paddle.

Remove paints on hold down studs for engine room ventilation covers.

Vessel name must be marked on life float paddle as required by 46 CFR 185.30-5, Re-stencil faded vessel name.

Escape hatch must be mark with 1 inch letter "EMERGENCY EXIT, KEEP CLEAR" as required by 46 CFR 185.30-15. Re-stencil faded mark on emergency hatch in wheel house.

Watertight door must be marked on both sides 1-inches "Watertight Door - Close in Emergency" as required by 46 CFR 185.30-25. Stencil watertight door forward of engine room.

Vessel on ocean route required to have operational Sing Side Band radio as required by 47 CFR 80. Repair or replace inoperable SSB. Restricted vessel route to no more than 100 NM from shore until SSB radio is properly install and attest by attending MI.

Make repair IAW with approved design and operational test to be completed to the satisfaction of the attending MI.

Found hydraulic oil leaking from steering gear piping. Bilge must be free of oil and fire hazards as required by 46 CFR 176.830. Repair hydraulic oil leaks and remove oil in the engine room bilge.

Found engine oil leaking through engine valve cover. Engine room bilge must be freed of oil engine oil create fire hazard as required by 46 CFR 176.830. Replace valve cover gasket.

Found lagging on generator exhaust pipe saturated with oil. Exhaust lagging must be free of oil to reduce fire hazard as required by 46 CFR 176.830. Replace oil saturated exhaust lagging.

Found automobile light bulb installed on anchor light. Anchor light must be approved under UL 1104. Replace light bulb with UL 1104 approved light bulb.

Flexible hose designed for use with hose clamps may have two clamps at both ends of the hose. Missing one hose clamp on fuel supply line to fuel filters. Install hose clamp.

Air condition shall be fit for service intended. Water leaking from salt water pump. Repair as original.

Flexible hose must be protected from mechanical damage. Found fuel supply hose to STBD engine chafing against engine foundation. Install hose protection.

Exhaust pipe not expose to cooling water must be insulated. Found exhaust pipe for SSDG & both propulsion engines missing lagging insulations. Install missing lagging.

Piping must comply with Subpart G, part 182. Found fire main pipe leaking. Repair damaged pipe.

Vessel sustained hull damage to port side shell due to typhoon. Submit repair plan to CG, conduct repair IAW approved plan to be attest by attending MI.

Horn not functioning. Repair/replace horn.

Provide donning placards for the combination type lifejackets.

Provide a pressure guage at the fire pump discharge.

Fire pump must produce 10 GPM with 25 foot stream of water.

Repair fuel leak on fuel piping inboard side of starboard engine.

Bilge high level alarm visual indicators not operating for the store room and the steering room.

Port pilot house door fractured at the closures. Weld fractures or replace door.

Properly renew/ repair frayed wiring in engineroom and stern void(Port side).

Replace missing electrical junction box for freshwater pump motor.

Replace missing wire hangers through vessel.

Provide proof that installed flexible hoses for diesel fuel meet requirements.

Weld all fractured welds as marked.

Crop and renew port and starboard stern corners as original.

CLAD weld pitting in engine room bottom hull plating, starboard side forward as marked.

Crop and renew wasted hull plating in stern void port side iwo rudder post and strut.

Crop and renew wasted lowest port frame in bow void, as original.

Properly insert stern plating where existing exhaust penetrates the hull.

Properly insert transverse watertight bulkhead where existing exhaust pipe penetrates.

Crop and renew wasted frame in stern void portside aft.

Repair/replace SSB, no volume.

Provide public address system onboard, vessel has more than one passenger deck.

Replace worn retro and re-stencile vessel name on lifering.

Starboard engine overheated and is currently inoperable.

Found STBD remote propulsion engine RPM gauge and engine temperature gauge inoperable .

Found Main batteries cable with expose conductors.

Found wiring to port engine stop solenoid with lose wire connection.

Found oily water in steering space bilge.

Found oily water in engine room bilge.

Found saltwater leak on port and starboard engine exhaust pipes.

Found in-operable RPM gauge for port engine.

Found cover for circiut breaker box unable to close - expose internal to salt water leak.

Starboard propulsion engine suffered casualty. Engine will be replace with an in kind engine.

Found deteriorated grab line holder on both life float. Repair grab line holder IAW manufacture guidelines.

Found First Aid Kit with expired eye wash sollution. Replace solution.

Found inoperable anchor light. Repair anchor light.

Found temporary wire connection on starboard engine shut off solenoid. Repair with permanent wire connection.

Found deck hatch forward of captain station and aft engine room without captive chains. Install captive chains.

Found deteriorated non-metallic hose on firemain forward starboard engine room. Replace non-metallic hose.

Found port engine battery missing one cap and electrolytes spill within battery storage. Clean excess electrolyte and install cap.

Found (01) B-II with low pressure. Service portable CO2.

Provide proof that 50 % of the deckhands have First-Aid/ CPR training by the American Red Cross, American Heart Association or a course approved by the local OCMI in accordance with NVIC 1-91.

Label emergency exits and escape hatches "EMERGENCY EXIT KEEP CLEAR"

Label all watertight doors and hatches "WATERTIGHT DOOR KEEP CLOSED" or "WATERTIGHT HATCH KEEP CLOSED" as appropriate.

Repair/ replace flame screen for port fuel oil tank vent and sewage tank vent.

Replace painters on both life floats.

Replace lifeline on ring lifebuoy.

Properly secure ladder to air condition compartment at top and bottom.

Replace hydraulic steering hoses in engine room with piping. Hose can not be longer than 60 inches.

Install chaffing gear on all hydraulic hoses.

Install and label a reach rod for the forward peak bilge suction valve.

Install pipe brackets on forward peak bilge piping.

Install pipe brackets on oil piping in the engine room.

Install a cotter pin in the bolt for the steering linkage.

Repair hydraulic oil leak aft of the port engine.

Prove horn audibility is in accordance with 33 CFR Part 86.

Re-install missing rope/chain used to secure deck rail openings.

Ensure passenger safety orientation is conducted in accordance with 46CFR185.506

Found emergency spot light not operational. Repair emergency spot light.

Found anchor light not operational. Repair or replace anchor light.

Found the crew unable to safely recover an injured person from the water. Prove the crew can recover an injured person from the water. Recommend utilizing floating stokes liter type recovery system.

Found engine room bilge visual alarm not operational. Repair or replace engine room visual alarm.

Found lifefloats weak link painted and in poor condition. Replace both weak links on lifefloats.

Found bilge pump not hard wired. Hard wire bilge pump.

Found 24 volt power converter and other electrical equipment on the bridge not hard wired. Hard wire all permanent electrical equipment.

Found natural ventilation to engine room without fire covers. Install fire covers to engine room ventilation.

Found electrical wire stuffing pipe in sewage compartment not water tight. Install proper marine grade electrical packing (mucky crap) to sewage compartment stuffing pipes.

Found EPIRB teather line not attached to the vessel. Connect EPIRB teather line to vessel.

Found all batteries attached to knife style quick disconnects. Replace knife style with approved quick disconnect throughout vessel.

Charts and publications not corrected to date in non-adherence with 46 CFR 184.420.

Fore-peak deck board fractured. Replacement required not later than 28 Oct 2002

Two pin holes observed at hull - aft deck centerline interface. Temporary repair required to restore watertightness required nlt 28 Oct 02, with permanent repair required at next drydock.

Generator, leaking oil, requires regasketing.

Watertight door hinge pins require replacement and upper dog (closure) requires adjustment.

Port propulsion MDE RPM gauge inoperable.

Electrical wiring to MSD pump exhibiting signs of deterioration. In-kind replacement of wiring required not later than 21 Nov 02.

Port and Stbd MDE shaft connection bolts loose. Bolts to be fully examined, replaced as necessary, and tightened not later than 28 Oct 02.

Emergency lighting system inoperable.

Vsl missing light cover in lower crew space.

Vsl has not paid congressionally mandated user fee.

Vsl missing BII fire extinguisher.

Properly cap or seal unused lines running thru the port side, fwd bulkhead in the store room compartment.

Label all breakers on the engine room electrical panel and install a drip shield.

Prove the operation of the fire pump.

Remove all hydraulic and lube oil in all bilges.

Renew the gasket for the engine room watertight door.

Conduct and log annual lifesaving equipment inspections.

Install blanks on the unused electrical breakers on the switchboard.

Properly wire the power supply for the Engine room blower with Marine Gradecable.

Renew the flex hose on the discharge side of the sewage pump.

Prove the operation of the forward compartment bilge suction.

Prove the operation of the vessel's whistle.

Provide a small scale chart encompassing the Mariana Islands.

Insulate the turbo charger and exhaust piping up to the first water injection point on the port and starboard engines.

Double clamp all salt water cooling hoses.

Label the direction of closure for the emergency fuel shut off valves.

Provide proof of payment for annual USCG Vessel Inspection fees by 17OCT99.Vessel will not be issued new COI until completion.

Properly mark the emergency exits.

Properly enclose the starting battery emergency disconnect switch to prevent accidental contact or replace with a UL approved type.

Provide sufficient length of discharge hose for the portable bilge pump to de-water any compartment directly overboard.

Make watertight the aft bulkhead of the engine room.

Restore to original the fracture on the flange of the 2nd transverse frame from the fwd bulkhead, starboard side in the A/C compartment.

Renew the female coupling on the discharge side of the sewage holding tank.

PLACE ON BOARD APPROPRIATE NUMBER OF DISTRESS SIGNALS

REPLACE RING BUOY AND 60 FT LIFE LINE. ATTACH WATERLIGHT WITH 3 FT LANYARDAND CORROSION RESISTANT CLIP.

PROVIDE SPLINT AND TOURNIQUET FOR FIRST AID KIT

REMOVE DEAD END WIRING UNDER PILOT HOUSE CONSOLE

Fuel shutoff station not clearly marked.

Clean gear out of lifefloats, attach paddles to each and ensure float free arrangement.

Remove paint and flammable from storage area and thriughout vessel.

Repair and relable emergency fuel shutoffs (port and starboard).

Remount EPIRB w/approved bracket.

Repair dog on weather tight door.

Replace MDE cooling raw water feeder hoses w/approved hose assemblies.

Repair damaged AC ducting.

Install proper globe on engineroom light.

Show proof og fire extinguisher servicing.

Secure steering gear ram bolts and double nut or drill and pin.

REPLACE OR REPAIR LEAKING STEERING GEAR RAM AND PROVE PROPER OPERATION IN PRESENCE OF ATTENDING USCG INSPECTOR.

Install proper protective blanks to missing breakers in power panel in engineroom.

Corrections to coi to reflect stability information of 40 passengers when cargo carried. Master to assure this condition met.

Obtain 12 person lifefloat for examination by attending inspector prior to operating on oceans route.

Secure by, means of locking device, marine sanitation overboard valve.

INSTALL PROPER ENGINE COMPARTMENT EXHAUST VENTILATION.

REPLACE EPIRB.

Install flame shields on Racor fuel filters.

REMOVE ALL OLD BATTERYS FROM THE VESSEL, INCLUDING THE ONE UNDER THE_x001C_ CONSOLE IN THE WHEEL HOUSE.

PLACE NAME AND HOME PORT OR HAILING PORT ON THE STERN OF THE VESSEL.

REPLACE BROKEN WINDOW ON STARBOARD SIDE WHEEL HOUSE.

REPAIR RADAR.

SERVICE PORTABLE FIRE EXTINGUISHERS.

POST OIL POLUTION PLACARD.

PROVIDE A VALID DOCUMENT FOR THE VESSEL.

PRIOR TO PLACING THE VESSEL IN SERVICE, REPAIR THE FRACTURES IN THE STERN RUB RAIL AND THE FRACTURED WELDS IN THE STBD AFT CORNER OF THE LAZARETTE.

IN ACCORDANCE WITH 46 CFR 182.25-5(A) PROVIDE INDIVIDUAL BILGE LINES AND BILGE SUCTIONS FOR THE FOREPEAK TANK & THE NEXT AFT WATERTIGHT COMPARTMENT.

THE FOLLOWING DEFICIENCIES ARE FOR THE GULF MIST, DN525827.
